Silencing the horn beep feature
If desired, the horn beep feature can be
deactivated using the multi-remote controller.
To deactivate:Press and hold the LOCK
and UNLOCK buttonsfor at least two
seconds.
The hazard lights will quickly flash three
times to confirm that the horn beep feature
has been deactivated.
To activate:Press and hold the LOCK and
UNLOCK buttonsfor at least two seconds
once more.The hazard lights will quickly flash once and
the horn will sound once to confirm that the
horn beep feature has been reactivated.
Deactivating the horn beep feature does not
silence the horn if the alarm is triggered.
If the system does not operate as de-
scribed above, have it checked by an
authorized NISSAN dealer.
LIC0116
LIC0117
WINDSHIELD WIPER AND
WASHER SWITCH
2-18Instruments and controls
ZX

3 Pre-driving checks and adjustments
Key .........................................................................3-2
Doors ......................................................................3-2
Locking with key ................................................3-2
Locking with inside lock knob............................3-3
Locking with power door lock switch.................3-3
Child safety rear door lock
(Crew Cab models only)....................................3-4
Remote keyless entry system (if so equipped)......3-4
How to use remote keyless entry
system ...............................................................3-4
Battery replacement ..........................................3-7
Hood .......................................................................3-8
Roof rack (if so equipped)......................................3-9
Step rail (if so equipped) ......................................3-11
Fuel filler lid ..........................................................3-11Fuel filler cap ...................................................3-11
Steering wheel .....................................................3-12
Tilt operation (if so equipped) .........................3-12
Sun visors.............................................................3-13
Vanity mirror (if so equipped) ..........................3-13
Mirrors ..................................................................3-13
Inside mirror.....................................................3-13
Outside mirrors ................................................3-13
Outside mirror remote control
(if so equipped)................................................3-14
Truck box..............................................................3-15
Tailgate ............................................................3-15
Tie down hooks ...............................................3-17
ZX

Unlocking doors
1. Push the UNLOCK button on the keyfob.
Only the driver's side door unlocks.
2. Push the UNLOCK button on the keyfob
again within five seconds. All doors un-
lock.3. The interior light illuminates for 30 sec-
onds when the light switch is in the O or
DOOR position.
The interior light can be turned off without
waiting 30 seconds by inserting the key into
the ignition and turning to the ON or START
position, locking the doors with the keyfobor pushing the interior light switch to the
OFF position.
Auto Relock
All doors will lock automatically within 5
minutes unless one of the following opera-
tions is performed:
cany door is opened
ca key is inserted into the ignition switch
and the key is turned from OFF to ON.
Using the panic alarm
If you are near your vehicle and feel threat-
ened, you may activate the panic alarm to
call attention as follows:
1. Push the PANIC button on the remote
controller forlonger than 0.5 seconds.
2. The theft warning alarm and headlights
will stay on for 30 seconds.
3. The panic alarm stops when:
cit has run for 30 seconds, or
cthe LOCK or UNLOCK button is pressed,
on the keyfob.
WPD0080
Pre-driving checks and adjustments3-5
ZX

Folding outside mirror
Push the mirror backward to fold it.
OUTSIDE MIRROR REMOTE
CONTROL (if so equipped)
The outside mirror control operates only
when the ignition switch is in the ACC or ON
position.
Select the right or left mirror, then adjust
using the control lever.
APD1096WPD0056LPD0065
3-14Pre-driving checks and adjustments
ZX

10 Index
A
Air bag
Passenger supplemental air bag
ON/OFF switch and light ...................... 1-13
Air bag (See supplemental restraint
system) ...................................................... 1-10
Air bag warning light .................................. 1-16
Air cleaner housing filter ............................ 8-23
Air conditioner
Air conditioner specification label ......... 9-14
Air conditioner system refrigerant and
lubrication recommendations.................. 9-8
Alarm system (See vehicle security
system) ...................................................... 2-15
Anchor point locations ............................... 1-36
Antenna...................................................... 4-31
Anti-lock brake system (ABS).................... 5-26
Anti-lock brake system, rear (R-ABS) ....... 5-26
Anti-lock brake warning light ..................... 2-11
Ashtray (See cigarette lighter and
ashtray) ...................................................... 2-24
Audio system
FM-AM radio with cassette player and
compact disc (CD) player ..................... 4-13
FM-AM radio with compact disc (CD)
changer ................................................. 4-18
Steering wheel audio control switch ..... 4-31
Auto-lock free-running hubs ...................... 5-21Automatic
Automatic power window switch .......... 2-29
Automatic transmission fluid (ATF) ...... 8-15
Driving with automatic transmission ....... 5-9
Transmission selector lever lock
release .................................................. 5-12
B
Battery........................................................ 8-18
Battery replacement (See remote keyless
entry system) ............................................... 3-7
Before starting the engine ........................... 5-8
Belts (See drive belts) ............................... 8-20
Brake
Anti-lock brake system (ABS) .............. 5-26
Anti-lock brake system, rear (R-ABS) .. 5-26
Brake booster ....................................... 8-27
Brake fluid ..................................... 8-17, 9-3
Brake light (See stop light) ................... 8-35
Brake pedal .......................................... 8-26
Brake system ........................................ 5-25
Brake warning light ............................... 2-11
Brake wear indicators ................. 2-15, 8-27
Parking brake check ............................. 8-26
Parking brake operation ....................... 5-16
Break-in schedule ...................................... 5-19
Bulb check/instrument panel ..................... 2-10Bulb replacement ....................................... 8-35
C
Capacities and recommended fuel/
lubricants...................................................... 9-2
Car phone or CB radio .............................. 4-32
Cargo (See vehicle loading information) ... 9-15
Check engine indicator light
(See malfunction indicator light) ................ 2-14
Child restraint with top tether strap ........... 1-36
Child restraints ........................................... 1-27
Cigarette lighter and ashtray
(accessory) ................................................ 2-24
Cleaning exterior and interior ...................... 7-2
Clutch
Clutch fluid ............................................ 8-17
Clutch pedal.......................................... 8-28
Cold weather driving .................................. 5-27
Controls
Audio controls (steering wheel) ............ 4-31
Coolant
Capacities and recommended fuel/
lubricants ................................................ 9-2
Changing engine coolant...................... 8-11
Checking engine coolant level ............. 8-10
Engine coolant temperature gauge ........ 2-5
Corrosion protection .................................... 7-5
ZX

Hubs
Auto-lock free-running hubs ................. 5-21
I
Indicator lights and audible reminders
(See warning/indicator lights and audible
reminders) .................................................. 2-10
Inside mirror ............................................... 3-13
Instrument brightness control .................... 2-20
J
Jump seat .................................................... 1-5
Jump starting ............................................... 6-8
K
Key ............................................................... 3-2
Keyless entry system (See remote keyless
entry system) ............................................... 3-4
L
Labels
Air conditioner specification label ......... 9-14
Emission control information label........ 9-14
Engine serial number ........................... 9-13
F.M.V.S.S. certification label ................ 9-13Vehicle identification number (VIN)
plate ...................................................... 9-12
Warning labels (for SRS) ..................... 1-16
Light
Air bag warning light............................. 1-16
Brake light (See stop light) ................... 8-35
Bulb check/instrument panel ................ 2-10
Bulb replacement.................................. 8-35
Headlight aiming adjustment ................ 8-32
Headlight and turn signal switch .......... 2-20
Headlights ............................................. 8-31
Light bulbs ............................................ 8-31
Passenger supplemental air bag
ON/OFF switch and light ...................... 1-13
Spotlights (See map light) .................... 2-33
Warning/indicator lights and audible
reminders .............................................. 2-10
Lock
Door locks............................................... 3-2
Power door locks .................................... 3-3
Luggage rack (see roof rack) ...................... 3-9
Luggage (See vehicle loading
information) ................................................ 9-15
M
Maintenance
General maintenance ............................. 8-3
Inside the vehicle.................................... 8-3
Maintenance precautions ....................... 8-5
Outside the vehicle ................................. 8-3Seat belt maintenance.......................... 1-26
Under the hood and vehicle ................... 8-4
Malfunction indicator lamp (MIL) ............... 2-14
Manual windows ........................................ 2-29
Map lights .................................................. 2-33
Meters and gauges ...................................... 2-2
Mirror
Inside mirror.......................................... 3-13
Outside mirror control ........................... 3-14
Outside mirrors ..................................... 3-13
Vanity mirror ......................................... 3-13
Multi-remote control system (See remote
keyless entry system) .................................. 3-4
O
Octane rating (See fuel octane rating) ........ 9-5
Odometer ..................................................... 2-3
Oil
Capacities and recommended fuel/
lubricants ................................................ 9-2
Changing engine oil.............................. 8-13
Changing engine oil filter...................... 8-14
Checking engine oil level ..................... 8-11
Engine oil .............................................. 8-11
Engine oil and oil filter
recommendation ..................................... 9-6
Engine oil viscosity ................................. 9-7
Outside mirror control ................................ 3-14
Outside mirrors .......................................... 3-13
Overdrive switch ............................... 5-13, 5-14
10-3
ZX

Overheat
If your vehicle overheats ...................... 6-10
Owner's manual order form ....................... 9-30
P
Parking
Parking brake check ............................. 8-26
Parking brake operation ....................... 5-16
Parking/parking on hills ........................ 5-24
Passenger supplemental air bag ON/OFF
switch and light
Passenger supplemental air bag
ON/OFF switch and light ...................... 1-13
Power
Power door locks .................................... 3-3
Power steering fluid .............................. 8-17
Power steering system ......................... 5-25
Power windows..................................... 2-27
Precautions
Maintenance precautions ....................... 8-5
On-pavement and off-road driving
precautions ............................................. 5-3
Precautions on seat belt usage............ 1-18
Precautions when starting and driving ... 5-2
Push starting ................................................ 6-9
R
Radio
Car phone or CB radio ......................... 4-32FM-AM radio with cassette player and
compact disc (CD) player ..................... 4-13
FM-AM radio with compact disc (CD)
changer ................................................. 4-18
Steering wheel audio control switch ..... 4-31
Readiness for inspection maintenance
(I/M) test..................................................... 9-28
Rear sliding window................................... 2-29
Rear window defogger switch ................... 2-19
Registering your vehicle in another
country ....................................................... 9-12
Remote keyless entry system .................... 3-4
Reporting safety defects (USA) ................. 9-28
Roof rack (see luggage rack) ...................... 3-9
S
Safety
Reporting safety defects (USA) ............ 9-28
Seat
Jump seat ............................................... 1-5
Seat belt
Precautions on seat belt usage............ 1-18
Seat belt extenders .............................. 1-26
Seat belt maintenance.......................... 1-26
Seat belts.............................................. 1-18
Three-point type with retractor ............. 1-21
Two-point type without retractor ........... 1-24
Seat belt warning light ............................... 2-13
Seats
Adjustment .............................................. 1-2
Separate seats ....................................... 1-2Service manual order form ........................ 9-30
Shifting
Automatic transmission ........................ 5-10
Manual transmission............................. 5-15
Spark plug replacement............................. 8-21
Speedometer ............................................... 2-3
Spotlights (See map light) ......................... 2-33
SRS warning label ..................................... 1-16
Starting
Before starting the engine ...................... 5-8
Jump starting .......................................... 6-8
Precautions when starting and driving ... 5-2
Push starting........................................... 6-9
Starting the engine ................................. 5-8
Steering
Power steering fluid .............................. 8-17
Power steering system ......................... 5-25
Tilting steering wheel............................ 3-12
Steering wheel audio control switch .......... 4-31
Step rail...................................................... 3-11
Stop light .................................................... 8-35
Sun shade.................................................. 2-31
Sunroof ...................................................... 2-30
Supplemental restraint system
(Supplemental air bag system).................... 1-6
Switch
Automatic power window switch .......... 2-29
Hazard warning flasher switch ............. 2-22
Headlight and turn signal switch .......... 2-20
Overdrive switch.......................... 5-13, 5-14
Passenger supplemental air bag
ON/OFF switch and light ...................... 1-13
10-4
ZX
