NISSAN GT-R 2018 Owners Manual

NOTICE

NOTICE

Coolant level and mixture ratioThe information and specifications in
this section apply only when engaging
in performance driving.
Check the coolant level in the pressurized
coolant reservoir. Adjust the level so that
the fluid is between the MAX and MIN
markings. For the coolant, use genuine
NISSAN Long Life coolant. (On delivery of
new vehicle, the reservoir is filled to the
MIN level. Be sure to replenish approxi-
mately 3/8 US quart (0.3 to 0.4 liter) of
coolant.)
NOTICE
Do not overfill the coolant. This may
increase the pressure in the cooling
system and cause coolant leaks.
To maximize vehicle performance, the
coolant mixture ratio should be a combi-
nation of 30% coolant antifreeze and 70%
demineralized or distilled water for max-
imum cooling system performance re-
gardless of ambient temperatures.
If ambient temperatures are anticipated
below 5°F (−15°C), make sure a proper
mixture ratio of 50% antifreeze and 50%
demineralized or distilled water mix is used.
Engine and powertrainThe information and specifications in
this section apply only when engaging
in performance driving.
.
Check the engine, transmission, differ-
ential and under the vehicle for oil and
coolant leaks.
. Inspect the areas surrounding of the
catalytic converter for heat deteriora-
tion.
. Always perform the transmission
setting. After that, adjust the clutch
clearance so that the clearance is less
than the clearance used for daily
driving. Your GT-R certified NISSAN
dealer has the necessary information
and equipment to set the clutch
clearance to the correct specification.
The clearance used for daily driving
increases clutch heat generated dur-
ing Performance Driving. This leads to
an increase in temperature of the
transmission oil. In addition, a more
direct shifting feel can be obtained by
reducing the clutch clearance for
Performance Driving. The clutch clear-
ance should be reset to the daily
driving specification after Perfor-
mance Driving. It is recommended you see a GT-R certified NISSAN dealer
for information.
NOTICE
Failure to have the clutch properly
adjusted before performance driving
may cause the transmission oil tem-
perature to increase which may
cause transmission damage.
. Inspect and confirm the clearance
between the exhaust finisher and rear
bumper is more than 0.24 in (6 mm)
(up/down) and more than 0.20 in (5
mm) (left/right).
. Inspect the dust boot of the drive
shaft universal joint for cracks or
damage.Suspension and wheel alignmentThe information and specifications in
this section apply only when engaging
in performance driving.
.Check the steering and suspension
system and other links for loose and/
or damaged parts.
. Measure and adjust the wheel align-
ment. (

in this section for 48 hours after tires
are installed on the wheels. The tire
may slip on the wheel if the vehicle is
driven in these conditions before 48
hours have passed. If the tire slips on
the wheel, the wheel/tire assembly
will be out of balance and will require
rebalancing.
BrakesThe information and specifications in
this section apply only when engaging
in performance driving.
.Check for the heat deterioration of the
brakes and parts around the brakes.
. It is recommended that you remove
air from the brake system after any of
the following:
— When engaging in high perfor-
mance driving for the first time
after purchasing a new vehicle.
— After replacing the brake fluid.
— When engaging in high perfor- mance driving for a sustained per-
iod of time. It is recommended that
bleeding the brake be performed
when the brake calipers are hot
(about 212°F (100°C)). Brake pad break-in procedure:
NISSAN recommends that a special brake
pad break-in procedure be performed
before engaging in performance driving.
It is recommended you contact a GT-R
certified NISSAN dealer for details.
INSPECTION AND ADJUSTMENTS
AFTER DRIVINGThe information and specifications in
this section apply only when engaging
in performance driving.
NOTICE
At the completion of performance
driving, all fluid and other adjust-
ments should be returned to the
normal fluid specifications as shown
in the “Maintenance and do-it-your-
self” section of this manual.FluidsThe information and specifications in
this section apply only when engaging
in performance driving.
.
Check the engine, transmission, differ-
ential and under the vehicle for oil and
coolant leaks. .
Check the fluid levels and adjust as
necessary using the specified fluid as
described under the conditions listed
in this section. (
