NISSAN GT-R 2021 User Guide

4 Display screen, heater, air conditionerand audio systems

CAUTION
Do not scratch the camera lens when
cleaning dirt or snow from the front
of the camera.
The RearView Monitor system automati-
cally shows a rear view of the vehicle
when the shift lever is placed in theposition.
The radio can still be heard while the
RearView Monitor is active.
MULTI FUNCTION DISPLAY
OWNER’S MANUAL REARVIEW MONITOR

located
just above the vehicle

Backing up on a steep uphillWhen backing up the vehicle up a hill, the
distance guide lines and the vehicle width
guide lines are shown closer than the
actual distance. Note that any object on
the hill is further than it appears on the
monitor.
do not
touch the object in the display. However,
the vehicle may hit the object if it projects
over the actual backing up course.

is shown further than the
position
in the display. However, the
positionis actually at the same dis-
tance as the position
. The vehicle may
hit the object when backing up to the position
if the object projects over the
actual backing up course.
HOW TO PARK WITH PREDICTIVE
COURSE LINES
WARNING
. If the tires are replaced with
different sized tires, the predic-
tive course line may not be dis-
played correctly.
. On a snow-covered or slippery
road, there may be a difference
between the predictive course
line and the actual course line.
when the shift
lever is moved to theposition.
Display screen, heater, air conditioner and audio systems
4-5

enter the park-
ing space
.
4. Maneuver the steering wheel to make the vehicle width guide lines
parallel
to the parking space
while referring to the predictive course lines.
5. When the vehicle is parked in the space completely, move the shift lever
in an appropriate gear and apply the
parking brake.

HOW TO TURN ON AND OFF PRE-
DICTIVE COURSE LINESIf the RearView Monitor is in operation
and the rear view is displayed, turn on
and off the predictive course line setting
according to the following procedure.
1. Touch the touch screen display.
2. Touch the “Predictive Course Lines”key to turn the feature on or off.
If the RearView Monitor is not in opera-
tion, change the setting according to the
following procedure.
1. Touch the “Settings” key on theLaunch Bar
on the touch screen
display.
2. Touch the “Camera” key.
3. Touch the “Predictive Course Lines” key. The indicator illuminates when
the item is turned on.
SONAR INDICATORThe sonar indicator will appear in the
RearView Monitor display. (
“Sonar
system” page 5-48)
REARVIEW MONITOR SYSTEM LIM-
ITATIONS
WARNING
Listed below are the system limita-
tions for RearView Monitor. Failure to
operate the vehicle in accordance
with these system limitations could
result in serious injury or death.
. The system cannot completely
eliminate blind spots and may
not show every object.
. Underneath the bumper and the
corner areas of the bumper can-
not be viewed on the RearView
Monitor because of its monitoring
range limitation. The system will
not show small objects below the
bumper, and may not show ob-
jects close to the bumper or on
the ground.
. Objects viewed in the RearView
Monitor differ from actual dis-
tance because a wide-angle lens
Display screen, heater, air conditioner and audio systems
4-7

is used.
. Objects in the RearView Monitor
will appear visually opposite
compared to when viewed in the
rearview and outside mirrors.
. Use the displayed lines as a re-
ference. The lines are highly af-
fected by the number of
occupants, fuel level, vehicle po-
sition, road conditions and road
grade.
. Make sure that the trunk lid is
securely closed when backing up.
. Do not put anything on the rear-
view camera. The rearview cam-
era is installed above the license
plate.
. When washing the vehicle with
high-pressure water, be sure not
to spray it around the camera.
Otherwise, water may enter the
camera unit causing water con-
densation on the lens, a malfunc-
tion, fire or an electric shock.
. Do not strike the camera. It is a
precision instrument. Otherwise,
it may malfunction or cause da-
mage resulting in a fire or an
electric shock. The following are operating limitations
and do not represent a system malfunc-
tion:
.
When the temperature is extremely
high or low, the screen may not clearly
display objects.
. When strong light is directly coming
on the camera, objects may not be
displayed clearly.
. Vertical lines may be seen in objects
on the screen. This is due to strong
reflected light from the bumper.
. The screen may flicker under fluores-
cent light.
. The colors of objects on the RearView
Monitor may differ somewhat from
the actual color of objects.
. Objects on the monitor may not be
clear in a dark environment.
. There may be a delay when switching
to the RearView Monitor screen.
. If dirt, rain or snow accumulates on
the camera, the RearView Monitor
may not display objects clearly. Clean
the camera.
. Do not use wax on the camera win-
dow. Wipe off any wax with a clean
cloth dampened with mild detergent
diluted with water.
SYSTEM MAINTENANCE
CAUTION
.Do not use alcohol, benzine or
thinner to clean the camera. This
will cause discoloration. To clean
the camera, wipe with a cloth
dampened with diluted mild
cleaning agent and then wipe
with a dry cloth.
. Do not damage the camera as the
monitor screen may be adversely
affected.

, the RearView Monitor may not
display objects clearly. Clean the camera
by wiping it with a cloth dampened with a
diluted mild cleaning agent and then
wiping it with a dry cloth.

HEATER AND AIR CONDITIONER
