key NISSAN GT-R 2022 User Guide

Intelligent Key warning light
After the ignition switch is pushed to the
ON position, this light comes on for about
2 seconds and then turns off.
This light warns of a malfunction with the
electrical steering lock system or the
Intelligent Key system.
If the light comes on while the engine is
stopped, it may be impossible to free the
steering lock or to start the engine. If the
light comes on while the engine is run-
ning, you can drive the vehicle. However
in these cases, it is recommended you
contact a GT-R certified NISSAN dealer for
repair as soon as possible.
“Tire
Pressure Monitoring System (TPMS)”
page 5-4) (
“Tire Pressure Monitor-
ing System (TPMS)” page 6-3)
Run-flat tire warning:
“Run-flat tires” page 8-36)
TPMS malfunction:
If the TPMS is not functioning properly,
the low tire pressure warning light will
flash for approximately 1 minute when the
ignition switch is pushed to the ON
position. The light will remain on after
the 1 minute. It is recommended you have
the system checked by a GT-R certified
NISSAN dealer. (
“Tire Pressure Mon-
itoring System (TPMS)” page 5-4)
(
“Tire pressure” page 8-30)

Vehicle security system activationThe vehicle security system will give the
following alarm:
.The headlights blink and the horn
sounds intermittently.
. The alarm automatically turns off
after approximately 1 minute. How-
ever, the alarm reactivates if the vehicle is tampered with again.
The alarm is activated by:
. Opening the door or the trunk lid
without using the button on the
Intelligent Key, the door handle re-
quest switch or the mechanical key.
(Even if the door is opened by releas-
ing the door inside lock knob, the
alarm will activate.)
. Opening the hood.
How to stop an activated alarmThe alarm will stop by:
.Unlocking a door by pushing the
UNLOCK button on the Intelligent Key.
. Unlocking a door by pushing the door
handle request switch.
. Pushing the ignition switch to the ACC
or ON position.
If the system does not operate as
described above, it is recommended
you have it checked by a GT-R certified
NISSAN dealer.
Instruments and controls
2-49

Security indicator lightThe security indicator light is located on
the instrument panel. It indicates the
status of the NISSAN Vehicle Immobilizer
System.
The light blinks whenever the ignition
switch is in the ACC, OFF or LOCK posi-
tion. This function indicates the security
systems equipped on the vehicle are
operational.
If the NISSAN Vehicle Immobilizer System
is malfunctioning, this light will remain on
while the ignition switch is in the ON
position.
If the light still remains on and/or theengine will not start, it is recommended
you see a GT-R certified NISSAN dealer
for NISSAN Vehicle Immobilizer System
service as soon as possible. Please
bring all Intelligent Keys that you have
when visiting a GT-R certified NISSAN
dealer for service.

GLOVE BOX
WARNING
Keep glove box lid closed while driv-
ing to help prevent injury in an
accident or a sudden stop.
Pull the knob toward you to open the
glove box.
To close the glove box, press the lid
forward until it locks in place.
Use the mechanical key to lock
and
unlock
the glove box. (
“Mechanical
key” page 3-3)
The mechanical key stops when it is
inserted approximately halfway in.
Instruments and controls
2-65

, DOOR
and OFF
.
ON positionWhen the switch is in the ON position
,
the map lights will illuminate.
NOTICE
Do not use the light for extended
periods of time with the engine
stopped. This could result in a dis-
charged battery. NOTE:
The lights will also turn off after a
period of time when the lights remain
illuminated after the ignition switch has
been pushed to the OFF or LOCK posi-
tion to prevent the battery from becom-
ing discharged.
DOOR positionWhen the switch is in the DOOR position, the map lights will turn on when the
door is opened and turn off when the
door is closed. The map lights will turn off
approximately 15 seconds after the door
is closed with the ignition switch in the
OFF or LOCK position.
NOTE:
When the interior light control switch is
in the DOOR position and the door is
open, the light will remain on even
when the map light switch is pressed
to turn off.
Key-linked interior light control system:
OFF positionWhen the switch is in the OFF position
,
the map lights will not illuminate, regard-
less of any condition.

1. Intelligent Key (2 sets)
2. Mechanical key (inside Intelligent Keys) (2sets)
3. Key number plate (1 set)INTELLIGENT KEYYour vehicle can only be driven with the
Intelligent Keys which are registered to
your vehicle’s Intelligent Key system com-
ponents and NISSAN Vehicle Immobilizer
System components. As many as 4 In-
telligent Keys can be registered and used
with one vehicle. The new keys must be
registered by a GT-R certified NISSAN
dealer prior to use with the Intelligent
Key system and NISSAN Vehicle Immobi- lizer System of your vehicle. Since the
registration process requires erasing all
memory in the Intelligent Key compo-
nents when registering new keys, be sure
to take all Intelligent Keys that you have
to a GT-R certified NISSAN dealer.
NOTICE
.
Be sure to carry the Intelligent
Key with you when driving. The
Intelligent Key is a precision de-
vice with a built-in transmitter. To
avoid damaging it, please note
the following.
— The Intelligent Key is water
resistant; however, wetting
may damage the Intelligent
Key. If the Intelligent Key gets
wet, immediately wipe until it
is completely dry.
— Do not bend, drop or strike it against another object.
— Do not place the Intelligent Key for an extended period in
a place where temperatures
exceed 140°F (60°C).
— If the outside temperature is below 14°F (−10°C), the battery
of the Intelligent Key may not
KEYS

function properly.
— Do not change or modify the Intelligent Key.
— Do not use a magnet key holder.
— Do not place the Intelligent Key near an electric appliance
such as a television set, per-
sonal computer or cellular
phone.
— Do not allow the Intelligent Key to come into contact with
water or salt water, and do
not wash it in a washing
machine. This could affect
the system function.
. If an Intelligent Key is lost or
stolen, NISSAN recommends
erasing the ID code of that Intel-
ligent Key. This will prevent the
Intelligent Key from unauthorized
use to unlock the vehicle. For
information regarding the eras-
ing procedure, please contact a
GT-R certified NISSAN dealer.
“Locking with mechanical key” page
3-6) (
“Glove box” page 2-65)
“Trunk
release power cancel switch” page 3-
21)
2. Remove the mechanical key from the Intelligent Key.
3. Lock the glove box with the mechan- ical key. (
“Glove box” page 2-65)
4. Hand the Intelligent Key to the valet, keeping the mechanical key in your
pocket or bag for insertion into the
Intelligent Key when you retrieve your
vehicle.
Pre-driving checks and adjustments
3-3

then close the door.
To unlock, lift up the inside lock knob to
the unlock position
.
NOTE:
When locking the door without an
Intelligent Key, be sure not to leave the
Intelligent Key inside the vehicle.
LOCKING WITH POWER DOOR LOCK
SWITCHOperating the power door lock switch will
lock or unlock all the doors. The switches
are located on the driver’s and front
passenger’s door armrests.
To lock the doors, push the power door
lock switch to the lock position
with the
driver’s or front passenger’s door open,
then close the door. NOTE:
When locking the door this way, be sure
not to leave the Intelligent Key inside
the vehicle.
To unlock the doors, push the power door
lock switch to the unlock position
.
Lockout protectionWhen the power door lock switch (driver
or front passenger) is moved to the lock
position with the Intelligent Key left in the
key port and any door open, all doors will
lock and unlock automatically.
When the power door lock switch (driver
or front passenger) is moved to the lock
position with the Intelligent Key left in the
vehicle (not in the Intelligent Key port)
and any door open, all doors will unlock
automatically and a chime will sound
after the door is closed.
These functions help to prevent the
Intelligent Key from being accidentally
locked inside the vehicle.AUTOMATIC DOOR LOCK SYSTEM.
All doors lock automatically when the
vehicle speed reaches 15 MPH (24
km/h).
. All doors unlock automatically when
the ignition switch is placed in the OFF
position.Pre-driving checks and adjustments
3-5

WARNING
CAUTION
.Be sure to carry the Intelligent
Key with you when operating the
vehicle.
. Never leave the Intelligent Key in
the vehicle when you leave the
vehicle.
. The Intelligent Key is always commu-
nicating with the vehicle as it receives
radio waves. The Intelligent Key sys-
tem transmits weak radio waves. En-
vironmental conditions may interfere
with the operation of the Intelligent
Key system under the following oper-
ating conditions. In such cases, cor-
rect the operating conditions before
using the Intelligent Key function or
use the mechanical key.
— When operating near a location
where strong radio waves are
transmitted, such as a TV tower,
power station and broadcasting
station.
— When in possession of wireless equipment, such as a cellular tele-
phone, transceiver, and CB radio.
INTELLIGENT KEY SYSTEM

Intelligent Key operating rangeThe Intelligent Key functions can only be
used when the Intelligent Key is within
the specified operating range from the
request switch. The operating range is
within 31.50 in (80 cm) from each request
switch.
NOTE:
.When the Intelligent Key battery is
discharged or strong radio waves
are present near the operating loca-
tion, the Intelligent Key system’s
operating range becomes narrower,
and the Intelligent Key may not
function properly. .
If the Intelligent Key is too close to
the door glass, handle or rear bum-
per, the request switches may not
function.
. When the Intelligent Key is within
the operating range, it is possible for
anyone who does not carry the
Intelligent Key to push the request
switch to lock/unlock the doors.
Intelligent Key operationYou can lock or unlock the doors without
taking the key out from your pocket or
bag.
