sensor NISSAN GT-R 2022 User Guide

The Vehicle Dynamic Control (VDC) sys-
tem uses various sensors to monitor
driver inputs and vehicle motion. Under
certain driving conditions, the VDC sys-
tem helps to perform the following func-
tions.
.Controls brake pressure to reduce
wheel slip on one slipping drive wheel
so power is transferred to a non
slipping drive wheel on the same axle.
. Controls brake pressure and engine
output to reduce drive wheel slip
based on vehicle speed (traction con-
trol function).
. Controls brake pressure at individual
wheels and engine output to help the
driver maintain control of the vehicle
in the following conditions:
— understeer (vehicle tends to not
follow the steered path despite
increased steering input)
— oversteer (vehicle tends to spin due to certain road or driving condi-
tions).
The VDC system can help the driver to
maintain control of the vehicle, but it
cannot prevent loss of vehicle control in
all driving situations.
When the VDC system operates, the VDC
warning light
in the meter flashes so note the following:
.
The road may be slippery or the
system may determine some action
is required to help keep the vehicle on
the steered path.
. You may feel a pulsation in the brake
pedal and hear a noise or vibration
from under the hood. This is normal
and indicates that the VDC system is
working properly.
. Adjust your speed and driving to the
road conditions.
. The VDC mode can be changed using
the VDC setup switch. (
“VDC,
transmission and suspension setup
switches” page 5-25)
(
“Vehicle Dynamic Control (VDC)
warning light” page 2-34,
“Vehicle
Dynamic Control (VDC) off indicator light”
page 2-33)
If a malfunction occurs in the system, the
VDC warning light
illuminates in the
meter. The VDC system automatically
turns off.
The VDC setup switch is used to turn off
the VDC system. The VDC off indicator
illuminates to indicate the VDC sys-
tem is off.
When the VDC setup switch is used to
turn off the system, the VDC system still
VEHICLE DYNAMIC CONTROL (VDC) SYSTEM

could affect the proper operation
of the TPMS.
. Do not inject any tire liquid or
aerosol tire sealant into the tires,
as this may cause a malfunction
of the tire pressure sensors.
NOTE:
. You can check the pressure of all
four tires on the touch screen dis-
play. See the separate Multi Func-
tion Display Owner’s Manual.
. The tires of this vehicle are filled
with nitrogen gas. When the tire
pressure is low, fill the tires with
nitrogen. It is recommended you
contact a GT-R certified NISSAN
dealer for information on filling the
tires with nitrogen.
. If nitrogen is not available, com-
pressed air may be safely used
under normal driving conditions.
However, NISSAN recommends re-
filling with nitrogen for maximum
tire performance.
RUN-FLAT TIRESRun-flat tires are those tires that can be
used temporarily if they are punctured.
(
“Run-flat tires” page 8-36)
Also, see the tire safety information in the
Warranty Information Booklet.
position.
4. Turn off the engine.
5. Raise the hood to warn other traffic,

NOTICE
Make sure the tire valve stem cap is
installed and that the valve stem is
tight. When installing the cap, make
sure to tighten the cap by hand. If a
tool is used to tighten the cap, the
cap may be damaged.TIRE PRESSURE
Tire Pressure Monitoring System
(TPMS)This vehicle is equipped with the Tire
Pressure Monitoring System (TPMS). It
monitors tire pressure of all tires. When
the low tire pressure warning light is lit,
one or more of your tires is significantly
under-inflated. The system also displays
pressure of all tires on the touch screen
display by sending a signal from a sensor
that is installed in each wheel.
The TPMS will activate only when the
vehicle is driven at speeds above 16 MPH
(25 km/h). Also, this system may not
detect a sudden drop in tire pressure.
(
“Low tire pressure warning light”
page 2-30) (
“Tire Pressure Monitoring
System (TPMS)” page 5-4) (
“Flat tire”
page 6-3)
Tire inflation pressure
Check the tire pressure often and
always prior to long distance trips.
The recommended tire pressure
specifications are shown on the F.
M.V.S.S./C.M.V.S.S. label or the Tire
and Loading Information label (if so
equipped) under the “Cold Tire
Pressure” heading. The Tire and
Loading Information label is affixed
to the driver side door end. Tire
pressures should be checked reg-
ularly because:.
Most tires naturally lose air over
time.
.
Tires can lose air suddenly when
driven over potholes or other
objects or if the vehicle strikes
a curb while parking.
NOTE:
. You can check the pressure of all
four tires on the touch screen dis-
play. See the separate Multi Func-
tion Display Owner’s Manual.
. The tires of this vehicle are filled
with nitrogen gas. When the tire
pressure is low, fill the tires with nitrogen. It is recommended you
contact a GT-R certified NISSAN
dealer for information on filling the
tires with nitrogen.
. If nitrogen is not available, com-
pressed air may be safely used
under normal driving conditions.
However, NISSAN recommends re-
filling with nitrogen for maximum
tire performance.
The tire pressures should be
checked when the tires are cold.
The tires are considered COLD after
the vehicle has been parked for 3 or
more hours, or driven less than 1
mile (1.6 km) at moderate speeds.
Incorrect tire pressure, including
under inflation, may adversely
affect tire life and vehicle hand-
ling.
WARNING
.
Improperly inflated tires can
fail suddenly and cause an
accident.
.
The Gross Vehicle Weight
rating (GVWR) is located on

being uninstalled from the
wheels, use equipment such as a
leverless automatic tire changer.
It is only possible to reuse the
tires when they have no cracks
and/or deformations on the bead
portion. However, if you use a
lever-type tire changer, cracks
and deformation may occur on
the bead portion of the tires
meaning that the tires cannot be
reused.
. Make sure the tire valve stem cap
is installed and that the valve
stem is tight. When installing the
cap, make sure to tighten the cap
by hand. If a tool is used to
tighten the cap, the cap may be
damaged.
WARNING
.The use of tires other than those
specified or the mixed use of tires
of different brands, construction
(bias, bias-belted, radial or run-
flat), or tread patterns can ad-
versely affect the ride, braking,
VDC system, handling, ground
clearance, body-to-tire clearance, tire chain clearance, speed-
ometer calibration, headlight
aim and bumper height. Some of
these effects may lead to acci-
dents and could result in serious
personal injury.
. If the wheels are changed for any
reason, always replace with
wheels which have the same off-
set dimension. Wheels of a differ-
ent off-set could cause prema-
ture tire wear, degrade vehicle
handling characteristics, affect
the VDC system and/or cause
interference with the brake discs.
Such interference can lead to
decreased braking efficiency
and/or early brake pad wear.
(
“Wheels and tires” page 10-
10)
. When a wheel is replaced, tire
pressure will not be indicated,
the TPMS will not function and
the low tire pressure warning
light will flash for approximately
1 minute and remain on after the
1 minute. It is recommended you
contact a GT-R certified NISSAN
dealer as soon as possible for tire
replacement and/or system re-
setting. .
Replacing tires with those not
originally specified by NISSAN
could affect the proper operation
of the TPMS.
. The TPMS sensor may be da-
maged if it is not handled cor-
rectly. Be careful when handling
the TPMS sensor.
. When replacing the TPMS sensor,
the ID registration may be re-
quired. Contact a GT-R certified
NISSAN dealer for ID registration.
. Do not use a valve stem cap that
is not specified by NISSAN. The
valve stem cap may become
stuck.
. Be sure that the valve stem caps
are correctly fitted. Otherwise the
valve may be clogged up with dirt
and cause a malfunction or loss
of pressure.
. Do not install a damaged or
deformed wheel or tire even if it
has been repaired. Such wheels
or tires could have structural
damage and could fail without
warning.
. Never use retread tires.
. For additional information re-

being uninstalled from the
wheels, use equipment such as a
leverless automatic tire changer.
It is only possible to reuse the
tires when they have no cracks
and/or deformations on the bead
portion. However, if you use a
lever-type tire changer, cracks
and deformation may occur on
the bead portion of the tires
meaning that the tires cannot be
reused.
. Make sure the tire valve stem cap
is installed and that the valve
stem is tight. When installing the
cap, make sure to tighten the cap
by hand. If a tool is used to
tighten the cap, the cap may be
damaged.
WARNING
.The use of tires other than those
specified or the mixed use of tires
of different brands, construction
(bias, bias-belted, radial or run-
flat), or tread patterns can ad-
versely affect the ride, braking,
VDC system, handling, ground
clearance, body-to-tire clearance, tire chain clearance, speed-
ometer calibration, headlight
aim and bumper height. Some of
these effects may lead to acci-
dents and could result in serious
personal injury.
. If the wheels are changed for any
reason, always replace with
wheels which have the same off-
set dimension. Wheels of a differ-
ent off-set could cause prema-
ture tire wear, degrade vehicle
handling characteristics, affect
the VDC system and/or cause
interference with the brake discs.
Such interference can lead to
decreased braking efficiency
and/or early brake pad wear.
(
“Wheels and tires” page 10-
10)
. When a wheel is replaced, tire
pressure will not be indicated,
the TPMS will not function and
the low tire pressure warning
light will flash for approximately
1 minute and remain on after the
1 minute. It is recommended you
contact a GT-R certified NISSAN
dealer as soon as possible for tire
replacement and/or system re-
setting. .
Replacing tires with those not
originally specified by NISSAN
could affect the proper operation
of the TPMS.
. The TPMS sensor may be da-
maged if it is not handled cor-
rectly. Be careful when handling
the TPMS sensor.
. When replacing the TPMS sensor,
the ID registration may be re-
quired. Contact a GT-R certified
NISSAN dealer for ID registration.
. Do not use a valve stem cap that
is not specified by NISSAN. The
valve stem cap may become
stuck.
. Be sure that the valve stem caps
are correctly fitted. Otherwise the
valve may be clogged up with dirt
and cause a malfunction or loss
of pressure.
. Do not install a damaged or
deformed wheel or tire even if it
has been repaired. Such wheels
or tires could have structural
damage and could fail without
warning.
. Never use retread tires.
. For additional information re-

back and as far-away as practical
from the steering wheel or instru-
ment panel. Always use the seat
belts.
. The driver and front passenger
seat belt buckles are equipped
with sensors that detect if the
seat belts are fastened. The Ad-
vanced Air Bag System monitors
the severity of a collision and seat
belt usage then inflates the air
bags as needed. Failure to prop-
erly wear seat belts can increase
the risk or severity of injury in an
accident.
. The front passenger seat is
equipped with an occupant clas-
sification sensor (pattern sensor)
that turns the front passenger air
bag OFF under some conditions.
This sensor is only used in this
seat. Failure to be properly
seated and wearing the seat belt
can increase the risk or severity
of injury in an accident.
(
“Front passenger air bag
and status light” page 1-42)
. Keep hands on the outside of the
steering wheel. Placing them in-
side the steering wheel rim could
increase the risk of hand injury if the supplemental front air bag
inflates.

back and as far-away as practical
from the steering wheel or instru-
ment panel. Always use the seat
belts.
. The driver and front passenger
seat belt buckles are equipped
with sensors that detect if the
seat belts are fastened. The Ad-
vanced Air Bag System monitors
the severity of a collision and seat
belt usage then inflates the air
bags as needed. Failure to prop-
erly wear seat belts can increase
the risk or severity of injury in an
accident.
. The front passenger seat is
equipped with an occupant clas-
sification sensor (pattern sensor)
that turns the front passenger air
bag OFF under some conditions.
This sensor is only used in this
seat. Failure to be properly
seated and wearing the seat belt
can increase the risk or severity
of injury in an accident.
(
“Front passenger air bag
and status light” page 1-42)
. Keep hands on the outside of the
steering wheel. Placing them in-
side the steering wheel rim could
increase the risk of hand injury if the supplemental front air bag
inflates.

and
located on the
instrument panel help maintain a con-
stant temperature. Do not put anything
on or around the sensors.
IN-CABIN MICROFILTERThe air conditioning system is equipped
with an in-cabin microfilter which collects
dirt, dust, etc. To make sure the air
conditioner heats, defogs, and ventilates
efficiently, replace the filter in accordance
with the maintenance schedule in the “9.
Maintenance and schedules” section of
this manual. It is recommended to see a
NISSAN dealer or GT-R certified NISSAN
dealer to replace the filter.
The filter should be replaced if air flow
is extremely decreased or when win-
dows fog up easily when operating
heater or air conditioning system.
Display screen, heater, air conditioner and audio systems
4-13

back and as far-away as practical
from the steering wheel or instru-
ment panel. Always use the seat
belts.
. The driver and front passenger
seat belt buckles are equipped
with sensors that detect if the
seat belts are fastened. The Ad-
vanced Air Bag System monitors
the severity of a collision and seat
belt usage then inflates the air
bags as needed. Failure to prop-
erly wear seat belts can increase
the risk or severity of injury in an
accident.
. The front passenger seat is
equipped with an occupant clas-
sification sensor (pattern sensor)
that turns the front passenger air
bag OFF under some conditions.
This sensor is only used in this
seat. Failure to be properly
seated and wearing the seat belt
can increase the risk or severity
of injury in an accident.
(
“Front passenger air bag
and status light” page 1-42)
. Keep hands on the outside of the
steering wheel. Placing them in-
side the steering wheel rim could
increase the risk of hand injury if the supplemental front air bag
inflates.

switch
or apply glass cleaner on
them. Doing so will reduce the sensi-
tivity of the sensor, resulting in im-
proper operation.
OUTSIDE MIRRORS
WARNING
Objects viewed in the outside mirror
on the passenger side are closer
than they appear. Be careful when
moving to the right. Using only this
mirror could cause an accident. Use
the inside mirror or glance over your
shoulder to properly judge distances
to other objects.
The outside mirror will operate only when
the ignition switch is in the ACC or ON position.
Adjusting the outside mirrors1. Turn the switch right or left to select
the right or left side mirror
.
2. Operate the control switchto adjust
the mirror angle.
