NISSAN JUKE 2021 Owners Manual

SAA3444
USB main operation:
The USB connection port is located on the
lower part of the instrument panel. Connect a
USB memory device into the connector. When
the audio system operates, the system will
switch to the USB memory device mode
automatically.
If the system has been turned off while the USB
memory device was playing, pushing the Power
button will start the USB memory device.

CAUTION
.Do not force the USB device into the
USB port. Inserting the USB device
tilted or up-side-down into the port
may damage the port. Make sure
that the USB device is connected
correctly into the USB port.
. Do not grab the USB port cover (if
so equipped) when pulling the USB
device out of the port. This could
damage the port and the cover.
. Do not leave the USB cable in a
place where it can be pulled unin-
tentionally. Pulling the cable may
damage the port.
Refer to your device manufacturer’s owner
information regarding the proper use and care
of the device.
Connecting iPod
Š:
The USB connection port is located on the
lower part of the instrument panel. Connect the
iPod
Šcable to the USB connector. See “USB
(Universal Serial Bus) connection port” (P.4-48) .
When the audio system operates, the system
will switch to the iPod
Šmode automatically. The
battery of the iPodŠis charged while the cable is connected to the vehicle.
Depending on the version of the iPod
Š, the
display on the iPodŠshows a NISSAN or
Accessory Attached screen when the connec-
tion is completed. When the iPod
Šis connected
to the vehicle, the iPodŠmusic library can only
be operated by the vehicle audio controls.
*iPod
Šand iPhoneŠare a trademark of Apple
Inc., registered in the U.S. and other countries.
Compatibility:
The following models are compatible:
. iPod nano
Š1G (Firmware version 1.3.1 -)
. iPod nanoŠ2G (Firmware version 1.1.3 -)
. iPod nanoŠ3G (Firmware version 1.0.0 -)
. iPod nanoŠ4G (Firmware version 1.0.2 -)
. iPod nanoŠ5G (Firmware version 1.0.1 -)
. iPod nanoŠ6G (Firmware version 1.0 -)
. iPod nanoŠ7G (Firmware version 1.0.0 -)
. iPodŠ5G (Firmware version 1.2.1 -)
. iPod classicŠ(Firmware version 1.0.0 -)
. iPod TouchŠ(iOS 1.1 -)
. iPod TouchŠ2G (iOS 2.1.1 -)
. iPod TouchŠ3G (iOS 3.1 -)
. iPod TouchŠ4G (iOS 4.1 -)
. iPod TouchŠ5G (iOS 6.0.0 -) .
iPhone
Š(iOS 1.0.0 - 2.2.1)
. iPhoneŠ3G (iOS 2.1 -)
. iPhoneŠ3GS (iOS 3.0 -)
. iPhoneŠ4/4S (iOS 4.0 -)
. iPhoneŠ5 (iOS 6.0.0 -)
Operations attributable to firmware update by
Apple are not guaranteed.
iPod
Šmain operation:
The system operates when the ignition switch is
in the ON or ACC position. Push the
