CONSULT-II CHECKING SYSTEM
Revision: June 20062007 Versa
CONSULT-II Data Link Connector (DLC) CircuitEAS001ZX
WAWA0009E

CONSULT-II CHECKING SYSTEM
GI-41
C
D
E
F
G
H
I
J
K
L
MB
GI
Revision: June 20062007 Versa
INSPECTION PROCEDURE
If the CONSULT-II cannot diagnose the system properly, check the following items.
NOTE:
The DDL1 and DDL2 circuits from DLC pins 6, 7 and 14 may be connected to more than one system. A short
in a DDL circuit connected to a control unit in one system may affect CONSULT-II access to other systems.
Symptom Check item
CONSULT-II cannot access
any system.

CONSULT-II DLC power supply circuit (Terminal 8) and ground circuit (Terminal 4). For detailed cir-
cuit, refer to EC-592, "
MIL AND DATA LINK CONNECTOR" .

CONSULT-II DLC cable and CONSULT-II CONVERTER.
CONSULT-II cannot access
individual system. (Other sys-
tems can be accessed.)

CONSULT-II program card. Check the appropriate CONSULT-II program card for the system.
Refer to GI-38, "
Checking Equipment" .

Power supply and ground circuit for the control unit of the system (For detailed circuit, refer to wir-
ing diagram for each system).

Open or short circuit between the system and CONSULT-II DLC (For detailed circuit, refer to wiring
diagram for each system).

Open or short circuit CAN communication line. Refer to LAN-42, "Precautions When Using CON-
SULT-II" .

GI-42
LIFTING POINT
Revision: June 20062007 Versa
LIFTING POINTPFP:00000
Special Service Tools EAS001ZY
CAUTION:

Every time the vehicle is lifted up, maintain the complete vehicle curb condition.

Since the vehicle's center of gravity changes when removing main parts on the front side (engine,
transmission, suspension etc.), support a jack up point on the rear side garage jack with a mission
jack or equivalent.

Since the vehicle's center of gravity changes when removing main parts on the rear side (rear axle,
suspension, etc.), support a jack up point on the front side garage jack with a mission jack or
equivalent.

Be careful not to smash or do not do anything that would affect piping parts.
Garage Jack and Safety Stand and 2-Pole LiftEAS001ZZ
WAR NIN G:

Park the vehicle on a level surface when using the jack. Make sure to avoid damaging pipes,
tubes, etc. under the vehicle.

Never get under the vehicle while it is supported only by the jack. Always use safety stands when
you have to get under the vehicle.

Place wheel chocks at both front and back of the wheels on the ground.

When lifting the vehicle, open the lift arms as wide as possible and ensure that the front and rear
of the vehicle are well balanced.

When setting the lift arm, do not allow the arm to contact the brake tubes, brake cable, fuel lines
and sill spoiler.
Tool number
Tool nameDescription
LM4086-0200
Board on attachment
LM4519-0000
Safety stand attachment
S-NT001
S-NT002

LIFTING POINT
GI-43
C
D
E
F
G
H
I
J
K
L
MB
GI
Revision: June 20062007 Versa
CAUTION:
There is canister just behind Garage jack point rear. Jack up be carefully.
Board-On Lift EAS00200
CAUTION:
Make sure vehicle is empty when lifting.

The board-on lift attachment (LM4086-0200) set at front end
of vehicle should be set on the front of the sill under the
front door opening.

Position attachments at front and rear ends of board-on lift.
1. Safety stand point and lift up point (front) 2. Safety stand point and lift up point
(rear)3. Garage jack point (front)
4. Garage jack point (rear)
PIIB2498E
AGI016

GI-44
TOW TRUCK TOWING
Revision: June 20062007 Versa
TOW TRUCK TOWINGPFP:00000
To w Tr u c k To w i n gEAS00201
CAUTION:

All applicable local laws regarding the towing operation must be obeyed.

It is necessary to use proper towing equipment to avoid possible damage to the vehicle during
towing operation. Towing is in accordance with Towing Procedure Manual at dealer.

Always attach safety chains before towing.

When towing, make sure that the transmission, steering system and power train are in good order.
If any unit is damaged, dollies must be used.
NISSAN recommends that the vehicle be towed with the driving (front) wheels off the ground as illustrated.
TOWING AN AUTOMATIC TRANSAXLE MODEL WITH FOUR WHEELS ON GROUND
CAUTION:
Never tow an automatic transaxle model with four wheels on the ground as this may cause serious
and expensive damage to the transaxle.
Vehicle Recovery (Freeing a Stuck Vehicle)EAS00202

Tow chains or cables must be attached only to the main structural members of the vehicle.

Pulling devices should be routed so they do not touch any part of the suspension, steering, brake or cool-
ing systems.

Always pull the cable straight out from the front or rear of the vehicle. Never pull on the vehicle at an
angle.

Pulling devices such as ropes or canvas straps are not recommended for use in vehicle towing or recov-
ery.
WAR NIN G:

Do not spin the tires at high speed. This could cause them to explode and result in serious injury.
Parts of the vehicle could also overheat and be damaged.

Install removable recovery hook securely using wheel nut wrench.
PIIB6801E

TIGHTENING TORQUE OF STANDARD BOLTS
GI-45
C
D
E
F
G
H
I
J
K
L
MB
GI
Revision: June 20062007 Versa
TIGHTENING TORQUE OF STANDARD BOLTSPFP:00000
Tightening Torque Table EAS00203
*: Nominal diameter
1.Special parts are excluded.
2.This standard is applicable to bolts having the following marks embossed on the bolt head. Grade Bolt sizeBolt diam-
eter *
mmPitch
mmTightening torque (Without lubricant)
Hexagon head bolt Hexagon flange bolt
N·m kg-m ft-lb in-lb N·m kg-m ft-lb in-lb
4TM6 6.0 1.0 5.1 0.52 3.8 45.1 6.1 0.62 4.5 53.8
M8 8.01.25 13 1.3 9 — 15 1.5 11 —
1.0 13 1.3 9 — 16 1.6 12 —
M10 10.01.5252.518— 293.022—
1.25 25 2.6 19 — 30 3.1 22 —
M12 12.01.75 42 4.3 31 — 51 5.2 38 —
1.25 46 4.7 34 — 56 5.7 41 —
M14 14.0 1.5 74 7.5 54 — 88 9.0 65 —
7TM6 6.0 1.0 8.4 0.86 6.2 74.6 10 1.0 7 87
M8 8.01.25 21 2.1 15 — 25 2.5 18 —
1.0222.216— 262.720—
M10 10.01.5414.230— 484.935—
1.25 43 4.4 32 — 51 5.2 38 —
M12 12.01.75 71 7.2 52 — 84 8.6 62 —
1.25 77 7.9 57 — 92 9.4 68 —
M14 14.0 1.5 127 13.0 94 — 147 15.0 108 —
9TM6 6.0 1.0 12 1.2 9 — 15 1.5 11 —
M8 8.01.25 29 3.0 22 — 35 3.6 26 —
1.0313.223— 373.827—
M10 10.01.5596.043— 707.151—
1.25 62 6.3 46 — 74 7.5 54 —
M12 12.01.75 98 10.0 72 — 118 12.0 87 —
1.25 108 11.0 80 — 137 14.0 101 —
M14 14.0 1.5 177 18.0 130 — 206 21.0 152 —
MGI044A

GI-46
RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS
Revision: June 20062007 Versa
RECOMMENDED CHEMICAL PRODUCTS AND SEALANTSPFP:00000
Recommended Chemical Products and SealantsEAS0021Q
Refer to the following chart for help in selecting the appropriate chemical product or sealant.
Product Description PurposeNissan North America
Part No. (USA)Nissan Canada Part
No. (Canada)Aftermarket Cross-
reference Part Nos.
1Rear View Mirror
AdhesiveUsed to permanently
remount rear view mirrors
to windows.999MP-AM000P 99998-50505 Permatex 81844
2Anaerobic Liquid Gas-
ketFor metal-to-metal flange
sealing.
Can fill a 0.38 mm (0.015
inch) gap and provide
instant sealing for most
powertrain applications.999MP-AM001P 99998-50503Permatex 51813 and
51817
3High Performance
Thread SealantProvides instant sealing on
any threaded straight or
parallel threaded fitting.
(Thread sealant only, no
locking ability.)

Do not use on plastic.999MP-AM002P 999MP-AM002P Permatex 56521
4 Silicone RTVGasket Maker999MP-AM003P
(Ultra Grey)99998-50506
(Ultra Grey)Permatex Ultra Grey
82194;
Three Bond
1207,1215, 1216,
1217F and 1217G;
Nissan RTV Part No.
999MP-A7007
Gasket Maker for Maxima/
Quest 5-speed automatic
transmission
(RE5F22A)––Three Bond 1281B
or exact equivalent
in its quality
5High Temperature,
High Strength Thread
Locking Sealant (Red)Threadlocker 999MP-AM004P 999MP-AM004PPermatex 27200;
Three Bond 1360,
1360N, 1305 N&P,
1307N, 1335,
1335B, 1363B,
1377C, 1386B, D&E
and 1388
6Medium Strength
Thread Locking Seal-
ant (Blue)Threadlocker (service tool
removable)999MP-AM005P 999MP-AM005PPermatex 24200,
24206, 24240,
24283 and 09178;
Three Bond 1322,
1322N, 1324 D&N,
1333D, 1361C,
1364D, 1370C and
1374

IDENTIFICATION INFORMATION
GI-47
C
D
E
F
G
H
I
J
K
L
MB
GI
Revision: June 20062007 Versa
IDENTIFICATION INFORMATIONPFP:00010
Model Variation EAS00204
Model code designations:
Body Engine Transmission GradeDestination
USA Canada
Hatchback MR18DE6 M/T
SFDSALDY-EUA FDSALAY-ENA
4 A/T FDSALDA-EUA FDSALAA-ENA
6 M/T
SLFDSALGY-EUA FDSALDY-ENA
CVT FDSALGZ-EUA FDSALDZ-ENA
Position (Left to
Right)Character Qualifier Definition
1 F Body type F: Hatchback
2
DS Engine DS: MR18DE
3
4 A Axle A: 2WD model
5 L Handle L: LH drive
6DGradeD: 1.8 S LEV2-ULEV (USA), 1.8 SL (CANADA)
G: 1.8 SL LEV2-ULEV (USA)
A: 1.8 S (CANADA)
7YTransmissionY: 6 M/T
A: 4 A/T
Z: CVT
8
C11 Model C11: Versa 9
10
11 E Intake E: EGI
12 U Zone N: Federal (50 state) and Canada
13 A Equipment A: Standard
14
xxxxx Option Codes 15
16
17

GI-48
IDENTIFICATION INFORMATION
Revision: June 20062007 Versa
IDENTIFICATION NUMBER
VEHICLE IDENTIFICATION NUMBER ARRANGEMENT
1. Chassis number 2. Emissions control label 3. VIN number
4. FMVSS/CMVSS certification and
tire placard labels
LAIA0073E
VIN Position
(Left to Right)Character Qualifier Definition
1
3N1Country code and vehicle
manufacturer3N1: Mexico 2
3
4 B Engine B: MR18DE
5 C Vehicle type C: NISSAN Versa
6 1 Model change 0 to 9
7 3 Body type 4-door hatchback
8 E Restraint systemA: Driver and front passenger SRS air bag, SRS side air
bags and 3 point manual seat belts
E: Driver and front passenger SRS air bag, SRS side air
bags, SRS side curtain air bags and 3 point manual seat
belts
9 * Check digit 0 to 9 or X
10 7 Model year 7: 2007 Model year
11 L Manufacturing Plant L: Aguascalientes, Mexico
12
XXXXXX Vehicle serial number Chassis number 13
14
15
16
17

IDENTIFICATION INFORMATION
GI-49
C
D
E
F
G
H
I
J
K
L
MB
GI
Revision: June 20062007 Versa
IDENTIFICATION PLATE
ENGINE SERIAL NUMBER
AUTOMATIC TRANSAXLE NUMBER
MANUAL TRANSAXLE NUMBER
LAIA0027E
STI0429
SGI113A
PCIB1612E
