NISSAN LATIO 2007 Service Repair Manual

GW-66
DOOR MIRROR
Revision: June 20062007 Versa
Disassembly and AssemblyEIS0095P
DISASSEMBLY
1. Pull out all the terminals from the connector.
NOTE:
Before pulling out the terminal, note the connector terminal arrangement.
2. Turn the mirror glass surface upward.
3. Apply a protective tape A to the housing.
4. Insert a suitable tool B into the concave gap between mirror
holder (1) and power unit (2). Push up tabs (3) (2 locations) on
mirror holder to disengage lower part of mirror holder, and
remove mirror body assembly.
NOTE:
When pushing up the tabs, do not forcefully push up only 1 con-
cave position but try to push up 2 concave positions.
5. Remove the mirror body (1) from the mirror housing assembly
(2).
ASSEMBLY
1. Warm the lower tabs with a dryer or equivalent.
NOTE:
Warm the lower tabs sufficiently before installing the mirror body. The tabs may be broken if it is cold. Be
especially careful in the winter.
2. Engage upper tabs of mirror body (1) with power unit (2). Then,
press lower part of mirror glass down until the lower part snaps
to allow engagement of lower tabs.
NOTE:
After installation, visually check that the lower tabs are securely
engaged when viewed from the bottom of mirror surface.
3. Insert the harness terminals into the connector.
NOTE:
Make sure to insert the harness terminals into the correct con-
nector. Do not confuse the locations.
PIIB6317E
PIIB6096E
PIIB6316E

INSIDE MIRROR
GW-67
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: June 20062007 Versa
INSIDE MIRRORPFP:96321
Removal and InstallationEIS0095Q
REMOVAL
Slide the inside mirror upward, and then remove inside mirror (1)
from the mirror base (2).
CAUTION:

Do not use excessive force to remove the inside mirror
because it is inserted tightly into the mirror base.

Do not reuse the inside mirror disassembled from mirror
base.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
Be sure to insert the inside mirror to the mirror base until the pawl is engaged to the mirror base.
PIIB6289E

GW-68
INSIDE MIRROR
Revision: June 20062007 Versa

IDX-1
A
C
D
E
F
G
H
I
J
K
L B
IDX
ALPHABETICAL INDEX
M INDEX
SECTION IDX

IDX-2
ALPHABETICAL INDEX
A
A/C air flow ..................................................... MTC-22
A/C component layout .................................... MTC-17
A/C compressor mounting .............................. MTC-84
A/C compressor precaution .............................. MTC-8
A/C compressor special service tool ............... MTC-12
A/C control operation (manual A/C) ................ MTC-21
A/C controller .................................................. MTC-61
A/C evaporator ................................................ MTC-90
A/C HFC134a (R134a) system precaution ....... MTC-4
A/C HFC134a (R134a) system service procedure .......
MTC-80
A/C HFC134a (R134a) system service tools .. MTC-12
A/C HFC134a system service equipment precaution ...
MTC-9
A/C lubricant (R134a) ........................ MTC-5, MTC-18
A/C lubrication oil ............................................ MTC-96
A/C operational check ..................................... MTC-33
A/C service data specification ......................... MTC-96
A/C trouble diagnoses (manual A/C) .............. MTC-24
A/C unit assembly ........................................... MTC-64
A/C, M - Wiring diagram ................................. MTC-29
A/F - Wiring diagram ... EC-223, EC-229, EC-235, EC-
242, EC-542
A/FH - Wiring diagram ..................................... EC-162
A/T fluid checking .................................. AT-16, MA-22
A/T fluid replacement ............................. AT-17, MA-23
A/T fluid temperature sensor ........................... AT-106
A/T IND - Wiring diagram .................................... DI-38
A/T indicator ........................................................ DI-37
A/T shift control system ................................... AT-229
A/T shift lock system ........................................ AT-235
A/T shift lock system - Wiring diagram ............ AT-236
A/T trouble diagnoses ........................................ AT-43
ABS - Wiring diagram ..................................... BRC-13
ABS (anti-lock brake system) ........................... BRC-5
ABS sensor rotor .............................................. RAX-4
Accelerator pedal position (APP) sensor . EC-513, EC-
519, EC-532
Accelerator pedal released position learning ..... EC-77
Air bag .............................................................. SRS-3
Air bleeding (hydraulic clutch) .............................. CL-8
Air cleaner filter replacement ............................ MA-16
Air conditioner cut control .................................. EC-27
Air fuel ratio sensor 1 .. EC-220, EC-227, EC-233, EC-
239, EC-540
Air fuel ratio sensor 1 heater ............................ EC-161
Air mix door control linkage adjustment .......... MTC-70
Angular tightening application ............................. EM-4
Anti-lock brake system - See ABS .................... BRC-5
Anti-lock brake system - Wiring diagram ........ BRC-13
APPS1 - Wiring diagram .................................. EC-515
APPS2 - Wiring diagram .................................. EC-521
APPS3 - Wiring diagram .................................. EC-534
ASC/BS - Wiring diagram ................................ EC-475
ASC/SW - Wiring diagram ............................... EC-468
ASCBOF - Wiring diagram ............................... EC-550
ASCD ................................................................. EC-28
ASCD brake switch ........................... EC-473, EC-549
ASCD clutch switch ........................... EC-473, EC-549
ASCD steering switch ..................................... EC-466
ASCIND - Wiring diagram ............................... EC-560
AUDIO - Wiring diagram ...................................... AV-9
Auto anti-dazzling inside mirror ........................ GW-67
Axle ................................................................... MA-26
B
BA/FTS - Wiring diagram ................................. AT-171
BACK/L - Wiring diagram ................................... LT-73
Back-up lamp .......................................... LT-73, LT-87
Back-up lamp switch (M/T) ............................... MT-11
Basic inspection ................................................ EC-70
Battery ................................................................. SC-4
Battery/Starting/Charging System Tester SC-6, SC-18,
SC-26
Baulk ring (M/T) ................................................ MT-18
BCM (Body control module) .............................. BCS-3
Blower motor .................................... MTC-37, MTC-68
Blower resistor ................................................ MTC-72
Body alignment ................................................ BL-244
Body component parts ..................................... BL-232
Body construction ............................................ BL-243
Body exterior paint color .................................. BL-231
Body repair ....................................................... BL-231
Body sealing .................................................... BL-240
Brake booster .................................................... BR-19
Brake fluid level ................................................. MA-24
Brake inspection ............................................... MA-25
Brake lines and cables inspection ..................... MA-24
Brake pedal ......................................................... BR-6
Brake switch .................................................... EC-488
BRK/SW - Wiring diagram .............................. EC-489
Bulb specifications ........................................... LT-116
Bumper, front ...................................................... EI-14
C
Cabin air filter .................................................... MA-20
Camshaft ........................................................... EM-47
Camshaft inspection ......................................... EM-49
Camshaft position sensor (PHASE) ................ EC-327
CAN - Wiring diagram ........... EC-152, AT-95, CVT-69
CAN communication EC-30, EC-151, EC-154, AT-31,
AT-94
, CVT-25, CVT-68
CAN communication (EPS) ............................... STC-6
CHARGE - Wiring diagram ............................... SC-25
Charging system ............................................... SC-24
Chassis and body maintenance .............. MA-8, MA-20
CHIME - Wiring diagram ..................................... DI-50
Circuit breaker ................................................... PG-16
Closed loop control ............................. EC-24, EC-442
Clutch cover ....................................................... CL-13
Clutch disc ......................................................... CL-13
Clutch master cylinder ......................................... CL-9
Clutch pedal ......................................................... CL-5
Coil spring (rear) ............................................. RSU-11

IDX-3
A
C
D
E
F
G
H
I
J
K
L B
IDX
ALPHABETICAL INDEX
Collision diagnosis .......................................... SRS-54
Combination lamp, rear, removal and installation LT-87
Combination meter ................................................ DI-5
Combination meter removal and installation - See Instru-
ment panel .......................................................... IP-11
COMBSW - Wiring diagram ............................... LT-67
Component Location (manual A/C) ................ MTC-25
Compression pressure ...................................... EM-62
Compressor mounting .................................... MTC-84
Compressor special service tool .................... MTC-12
Condenser ...................................................... MTC-88
Connecting rod .................................................. EM-97
Connecting rod bearing clearance .................. EM-101
Connecting rod bushing clearance .................... EM-97
CONSULT for ABS .......................................... BRC-20
CONSULT general information .......................... GI-37
CONSULT-II for engine ................................... EC-113
CONSULT-II function (EPS) ............................ STC-13
CONSULT-II Reference value (CVT) .............. CVT-57
Control lever (M/T) ............................................ MT-12
Control units (terminal arrangement) ................ PG-72
Control valve (CVT) ......................................... CVT-29
Converter housing installation ............ AT-254, AT-369
COOL/F - Wiring diagram ............................... EC-448
Coolant mixture ratio ......................................... MA-12
Cooling circuit (engine) ....................................... CO-7
Cooling fan ........................................................ CO-15
Cooling fan motor ............................................ EC-443
Corrosion protection ......................................... BL-237
Coupling sleeve (M/T) ....................................... MT-18
Crankcase ventilation system - See Positive crankcase
ventilation .......................................................... EC-44
Crankshaft ......................................................... EM-77
Crankshaft position sensor (POS) ................... EC-319
Crash zone sensor .......................................... SRS-49
CVT air breather hose ................................... CVT-205
CVT control system ......................................... CVT-22
CVT cross-sectional view ................................ CVT-21
CVT Electrical parts location ........................... CVT-40
CVT fluid checking ............... CVT-16, CVT-43, MA-20
CVT fluid cooler cleaning ................................ CVT-18
CVT fluid replacement ........................ CVT-17, MA-21
CVT fluid temparature sensor ......................... CVT-85
CVT hydraulic control system ......................... CVT-23
CVT indicator ...................................................... DI-42
CVT self-diagnoses ........................... CVT-60, CVT-67
CVT shift lock system .................................... CVT-197
CVT trouble diagnoses .................................... CVT-34
CVTIND - Wiring diagram ................................... DI-43
Cylinder block .................................................... EM-77
Cylinder head .................................................... EM-62
Cylinder head bolt tightening ............................. EM-65
D
D/LOCK - Wiring diagram ...................... BL-26
, BL-31
Data link connector ............. EC-115, EC-127, EC-592
DEF - Wiring diagram ....................................... GW-52
Diagnosis sensor unit ...................................... SRS-52
Diagnostic trouble code (DTC) for OBD system . EC-8,
EC-48
Diagnostic trouble code (DTC) inspection priority chart
EC-89
, CVT-34
Differential gear (FF M/T) .................................. MT-22
Differentil side oil seal .................................... CVT-206
DLC - Wiring diagram ...................................... EC-592
Door glass .......................................... GW-43, GW-47
Door glass Fitting Adjustment(Front) ................ GW-46
Door glass Fitting Adjustment(Rear) ................ GW-49
Door mirror ....................................................... GW-65
Door trim .............................................................. EI-27
Door, front ......................................................... GW-43
Door, rear ......................................................... GW-47
Drive shaft ......................................................... MA-27
Driver air bag ................................................... SRS-41
Dropping resistor (A/T) .................................... AT-150
DTC work support ............................................ EC-122
DTRL - Wiring diagram ....................................... LT-31
Duct and grilles ............................................... MTC-75
E
ECM input/output signal .................................. EC-105
ECM power supply .......................................... EC-144
ECTS - Wiring diagram .................................... EC-202
Electric sunroof .................................................. RF-10
Electric throttle control actuator .. EM-18, EC-499, EC-
506, EC-511
Electrical load signal circuit ............................. EC-562
Electrical unit ..................................................... PG-72
Electrical units location ...................................... PG-64
Electronic ignition (EI) system ........................... EC-25
Electronic key ..................................................... BL-80
ENG SS - Wiring diagram ................................ AT-114
Engine control circuit diagram ......................... EC-103
Engine control component parts location .......... EC-96
Engine control module (ECM) ......................... EC-427
Engine control system diagram ......................... EC-22
Engine coolant ..................................................... CO-8
Engine coolant temperature sensor (ECTS) ... EC-200,
EC-212
Engine fail-safe system ..................................... EC-91
Engine oil ............................................................. LU-5
Engine oil precautions .......................................... GI-7
Engine removal .................................................. EM-73
EPS - Wiring diagram ........................................ STC-9
EPS control unit input/output signal reference values ..
STC-11
EPS system description ..................................... STC-5
EPS system diagram ......................................... STC-6
ETC1 - Wiring diagram .................................... EC-500
ETC2 - Wiring diagram .................................... EC-495
ETC3 - Wiring diagram .................................... EC-507
EVAP canister ................................................... EC-34
EVAP canister purge volume control solenoid valve ....
EC-354
, EC-362
EVAP canister vent control valve ...... EC-369, EC-376
EVAP control system (small leak) diagnosis .. EC-346,

IDX-4
ALPHABETICAL INDEX
EC-398, EC-406
EVAP control system pressure sensor .... EC-382, EC-
385, EC-391
EVAP control system purge flow monitoring diagnosis
EC-340
EVAP vapor lines inspection ............................. MA-19
Evaporative emission (EVAP) system ............... EC-31
Evaporator ...................................................... MTC-90
Exhaust manifold .............................................. EM-21
Exhaust system inspection ................... MA-20, MA-22
Expansion valve .............................................. MTC-91
F
F/FOG - Wiring diagram ..................................... LT-43
F/PUMP - Wiring diagram ................................ EC-571
Final drive (FF M/T) ........................................... MT-22
Floor trim ............................................................. EI-37
Flow charts ......................................................... GI-27
Fluid temparature sensor (CVT) ...................... CVT-85
Fluid temperature sensor (A/T) ........................ AT-106
Fluids ................................................................ MA-11
Fluorescent leak detector ............................... MTC-92
Flywheel (clutch) ................................................ CL-13
Flywheel runout .............................................. EM-103
Fork rod (M/T) .................................................... MT-21
Freeze frame data ............................... EC-52, EC-116
Front bumper ...................................................... EI-14
Front door ......................................................... GW-43
Front passenger air bag .................................. SRS-46
Front seat belt ...................................................... SB-3
Front seat belt pre-tensioner ..... SB-2, SRS-3, SRS-51
Front washer ...................................................... WW-4
Front wiper ......................................................... WW-4
FTS - Wiring diagram ......................... AT-103, CVT-86
FTTS - Wiring diagram ...................... EC-293, EC-298
FUEL - Wiring diagram ...................... EC-278, EC-286
Fuel cut control (at no load high engine speed) . EC-26
Fuel gauge ............................................................ DI-5
Fuel injection system ......................... EC-276, EC-284
Fuel injector ..................................................... EC-564
Fuel injector and fuel tube ................................ EM-33
Fuel level sensor ................. EC-415, EC-417, EC-419
Fuel line inspection .................................. FL-4, MA-15
Fuel precautions ................................................... GI-6
Fuel pressure check .......................................... EC-81
Fuel pressure release ........................................ EC-81
Fuel pump ........................................................ EC-570
Fuel systemCommercial Service Tools ................ FL-3
Fuel systemPREPARATION ................................. FL-3
Fuel tank temperature sensor ............ EC-291, EC-297
Fuel tank vacuum relief valve ............................ EC-34
Fuse ................................................................... PG-16
Fuse and fusible link box ................................... PG-77
Fusible link ......................................................... PG-16
G
Gauges ................................................................. DI-5
Gear components (M/T) .................................... MT-18
Generic scan tool (GST) ................................. EC-126
Glass ...................................... GW-11, GW-43, GW-47
Grille - See Exterior ............................................. EI-19
Ground distribution ............................................ PG-30
H
H/LAMP - Wiring diagram .................................... LT-8
H/PHON - Wiring diagram .................................. AV-52
Handling precautions for plastics ..................... BL-255
Harness connector ............................................ PG-68
Harness layout .................................................. PG-39
Hazard warning lamp ......................................... LT-51
Headlining - See Roof trim .................................. EI-39
Heated oxygen sensor 2 ..... EC-248, EC-257, EC-267
Heated oxygen sensor 2 heater ...................... EC-166
HEATER - Wiring diagram .............................. MTC-28
Heater system - Wiring diagram ..................... MTC-28
HFC134a (R134a) system precaution .............. MTC-4
HFC134a (R134a) system service procedure . MTC-80
HFC134a (R134a) system service tools ......... MTC-12
HFC134a system service equipment precaution MTC-9
HO2S2 - Wiring diagram ..... EC-251, EC-260, EC-270
HO2S2H - Wiring diagram .............................. EC-168
Horn ................................................................. WW-46
HORN - Wiring diagram ................................... WW-46
How to erase DTC for OBD system .................. EC-60
I
IATS - Wiring diagram ..................................... EC-197
Idle air volume learning ..................................... EC-78
Idle speed ......................................................... EC-75
Idle speed control (ISC) .................... EC-423, EC-425
Ignition coil ...................................................... EC-576
Ignition control system .................................... EC-576
Ignition timing .................................................... EC-75
IGNSYS - Wiring diagram ............................... EC-577
ILL - Wiring diagram ......................................... LT-111
Illumination control ........................................... LT-108
In-cabin Microfilter ............................................. MA-20
INJECT - Wiring diagram ................................ EC-565
Input shaft (FF M/T) .......................................... MT-18
Input/Output signal of TCM ............................. CVT-25
Instrument panel ................................................. IP-10
INT/L - Wiring diagram ....................................... LT-96
Intake air temperature sensor ........... EC-195, EC-215
Intake door control linkage adjustment ........... MTC-69
Intake manifold .................................................. EM-18
Intake valve timing control .............................. EC-156
Intake valve timing control solenoid valve ....... EC-173
Interior ................................................................. EI-32
Interior lamp ....................................................... LT-91
IPDM (Intelligent power distribution module engine
room) ................................................................. PG-17
IVC - Wiring diagram ....................................... EC-174

IDX-5
A
C
D
E
F
G
H
I
J
K
L B
IDX
ALPHABETICAL INDEX
K
KEYLES - Wiring diagram .................................. BL-57
Knock sensor (KS) .......................................... EC-315
KS - Wiring diagram ........................................ EC-316
L
L/USSV - Wiring diagram .............................. CVT-159
Line pressure and secondary pressure control CVT-26
Line pressure solenoid valve ......... CVT-113, CVT-118
Line pressure test (A/T) ...................................... AT-56
Liquid gasket application ................ EM-5, LU-2, CO-3
Location of electrical units ................................. PG-64
Lock-up and select control .............................. CVT-28
Lock-up select solenoid valve ....................... CVT-158
Low tire pressure warning system ....................... WT-7
Low tire pressure warning system - trouble diagnoses
WT-10
Low tire pressure warning system - Wiring diagram ....
WT-10
LPSV - Wiring diagram .................... AT-146, CVT-114
Lubricant (R134a) A/C ...................... MTC-5, MTC-18
Lubrication circuit (engine) ................................... LU-4
Lubrication oil A/C .......................................... MTC-96
M
M/T major overhaul ........................................... MT-17
M/T removal and installation ............................. MT-15
MAFS - Wiring diagram ..................... EC-181, EC-189
Magnet clutch ................................................. MTC-41
MAIN - Wiring diagram ...................... EC-144, AT-183
Mainshaft (M/T) ................................................. MT-18
Maintenance ........................................................ MA-5
Malfunction indicator lamp (MIL) ....................... EC-61
Manual air conditioner - Wiring diagram ........ MTC-29
Mass air flow sensor (MAFS) ............ EC-178, EC-187
Master cylinder (clutch) ........................................ CL-9
Meter ..................................................................... DI-5
METER - Wiring diagram ...................................... DI-9
MIL data link connectors circuit ....................... EC-592
MIRROR - Wiring diagram ............................... GW-64
Mirror, door ....................................................... GW-65
Mirror, out side ................................................. GW-65
Misfire .............................................................. EC-308
Mode door control linkage adjustment ........... MTC-71
Molding - See Exterior .............................. EI-23, EI-24
Mud guard - See Exterior .................................... EI-26
Multiport fuel injection (MFI) system ................. EC-23
Multiport fuel injection precautions ....................... GI-6
Multi-remote control system - See Remote keyless entry
system ................................................................ BL-54
N
NATS - Wiring diagram .................................... BL-215
NATS (Nissan anti-theft system) precautions ...... GI-3
NONDTC - Wiring diagram ............. AT-193, CVT-176
NVH troubleshooting (BR) ................................... BR-5
NVH troubleshooting (RSU) ............................. RSU-4
NVIS (Nissan vehicle immobilizer system) ....... BL-212
O
Oil change (capacity) ......................................... MA-11
Oil cooler (engine) ............................................. EM-24
Oil filter ................................................................ LU-8
Oil pan (engine) ................................................. EM-24
Oil pressure (engine) ........................................... LU-5
Oil seal replacement (engine) . EM-24, EM-37, EM-59,
EM-66
On board diagnostic system .............................. EC-47
ORVR (On-board Refueling Vapor Recovery) ... EC-38
Out side mirror .................................................. GW-65
Overdrive control switch ..................... AT-186, AT-191
Overheat .......................................................... EC-443
OVRCSV - Wiring diagram .............................. AT-162
P
P/SCKT - Wiring diagram ................................ WW-44
Park/Neutral position switch ............................ EC-436
Park/neutral position switch (A/T) ......... AT-97, AT-186
Park/neutral position switch (CVT) .................. CVT-78
Park/neutral position switch (M/T) ..................... MT-11
Parking brake control ........................................... PB-4
PCV (positive crankcase ventilation) ................. EC-44
Periodic maintenance .......................................... MA-7
PGC/V - Wiring diagram .................... EC-356, EC-364
PHASE - Wiring diagram ................................. EC-329
Pilot bushing replacement ................................. EM-77
Piston assembly ................................................ EM-99
Piston pin inspection .......................................... EM-95
Piston ring inspection ........................................ EM-96
Piston to bore clearance .................................... EM-99
PNP/SW - Wiring diagram ..... EC-438, AT-98, CVT-80
POS - Wiring diagram ...................................... EC-321
POWER - Wiring diagram ................... CVT-146, PG-6
Power door lock .................................................. BL-23
Power socket ................................................... WW-44
Power steering gear .......................................... PS-12
Power supply routing ........................................... PG-4
Power window .................................................. GW-17
PRE/SE - Wiring diagram .................. EC-387, EC-393
Precations for Leak detection dye .................. MTC-10
Precautions (General) .......................................... GI-4
Pressure control solenoid valve A CVT-113, CVT-118
Pressure control solenoid valve B CVT-121, CVT-124
Pressure plate - See Clutch cover ..................... CL-13
Pressure test (CVT) ......................................... CVT-45
Primary pressure sensor ............................... CVT-137
Primary Speed Sensor .................................... CVT-90
PRIPS - Wiring diagram ................................ CVT-138
PRSCVT - Wiring diagram ............................... CVT-91
PT/SEN - Wiring diagram ................................ AT-177

IDX-6
ALPHABETICAL INDEX
R
Radiator ............................................................ CO-11
Rear axle .......................................................... RAX-4
Rear combination lamp removal and installation LT-87
Rear door .......................................................... GW-47
Rear seat belt ...................................................... SB-6
Rear suspension ............................................... RSU-5
Rear washer .................................................... WW-30
Rear window defogger ...................................... GW-50
Rear wiper ....................................................... WW-30
Refrigerant connection precaution .................... MTC-5
Refrigerant discharging evacuating charging . MTC-80
Refrigerant general precaution ......................... MTC-5
Refrigerant lines .............................................. MTC-80
Refrigerant pressure sensor ............. EC-586, MTC-88
Refrigeration cycle .......................................... MTC-16
Remote keyless entry system ............................ BL-54
Removal and installation (A/T) ......................... AT-253
Reverse idler shaft (M/T) ................................... MT-18
Reverse lamp switch (M/T) - See Back-up lamp switch
(M/T) .................................................................. MT-11
Reverse main gear (M/T) ................................... MT-18
Road test ......... AT-58, AT-61, AT-64, AT-65, CVT-46
Room lamp - See Interior lamp ........................... LT-91
RP/SEN - Wiring diagram ................................ EC-587
S
SAE J1979 - Service $01 - 09 ........................... EC-47
Seat belt inspection ................................ SB-8, MA-27
Seat belt, front ..................................................... SB-3
Seat belt, rear ...................................................... SB-6
Secondary pressure sensor ........................... CVT-129
Secondary Speed Sensor ................................ CVT-95
SECPS - Wiring diagram ............................... CVT-130
SECPSV - Wiring diagram ............................. CVT-125
Self-diagnostic results .......................... EC-64, EC-116
SEN/PW - Wiring diagram ............................... EC-431
SESCVT - Wiring diagram ............................... CVT-96
SHIFT - Wiring diagram ................... AT-236, CVT-198
Shift control ...................................................... CVT-26
Shift control components (M/T) .......................... MT-21
Shift control system ....................................... CVT-191
Shift fork (M/T) ................................................... MT-21
Shift lever ........................................................... MT-12
Shift lock system .............................................. AT-235
Shift schedule ..................... AT-67, CVT-53, CVT-210
Shock absorber (rear) ....................................... RSU-9
Side air bag (satellite) sensor ......................... SRS-50
Side curtain air bag ......................................... SRS-47
Side trim .............................................................. EI-32
SMJ (super multiple junction) ............................ PG-75
Specification value ........................................... EC-133
Speedometer ........................................................ DI-5
Spiral cable ..................................................... SRS-44
Spot lamp .......................................................... LT-107
SPSW - Wiring diagram ................................. CVT-171
SROOF - Wiring diagram ................................... RF-13
SRS - See Supplemental Restraint System ...... SRS-4
SRS - Wiring diagram ..................................... SRS-13
SRS Trouble diagnoses .................................... SRS-9
SSV/A - Wiring diagram ................................... AT-152
SSV/B - Wiring diagram ................................... AT-157
Stall Test ......................................................... CVT-43
Stall test (A/T) .................................................... AT-53
START - Wiring diagram ................................... SC-12
Starting system ................................................. SC-10
Steering linkage ................................................. PS-12
Steering wheel and column ........................ PS-6, PS-9
Steering wheel turning force ................................ PS-6
Step motor .................................... CVT-164, CVT-168
STM - Wiring diagram ................................... CVT-165
Stop lamp ................................................ LT-71, LT-87
Stop lamp switch ............................................. EC-488
STOP/L - Wiring diagram ................................... LT-71
STSIG - Wiring diagram .................................. CVT-73
Sun roof, electric ................................................ RF-10
Sunroof .................................................. RF-10, RF-22
Supplemental Restraint System ........................ SRS-4
Suspension ....................................................... MA-26
Swirl control valve ........................................... EC-592
Symbols and abbreviations ...................... GI-10, GI-23
Symptom matrix chart ....................................... EC-92
Synchronizer (M/T) ........................................... MT-18
System readiness test (SRT) code ................... EC-52
T
Tachometer ........................................................... DI-5
Tail lamp ............................................................ LT-87
TAIL/L - Wiring diagram ..................................... LT-78
TCM circuit diagram ........................................ CVT-42
TCM function ................................................... CVT-24
TCM inspection table ........................... AT-78, CVT-54
TCV - Wiring diagram ...................... AT-135, CVT-106
Telephone .......................................................... AV-49
Theft warning system - See Vehicle security (Theft warn-
ing) system ....................................................... BL-193
Thermo control amp ........................................ MTC-63
Thermostat ........................................................ CO-18
Three way catalyst function ............................ EC-334
Three way catalyst precautions ............................ GI-5
Throttle control motor relay ............................. EC-493
Throttle position sensor (TPS) .. EC-206, EC-302, EC-
460, EC-462, EC-526
Throttle valve closed position learning .............. EC-78
Tie-rod ................................................................ PS-12
Timing chain ...................................................... EM-37
TLID - Wiring diagram ...................................... BL-177
Torque converter installation .... AT-254, AT-369, CVT-
208
Torque convertor clutch solenoid valve CVT-105, CVT-
110
TPS1 - Wiring diagram .................................... EC-304
TPS2 - Wiring diagram .................................... EC-208
TPS3 - Wiring diagram .................................... EC-528
Transmission case (M/T) .................................. MT-17

IDX-7
A
C
D
E
F
G
H
I
J
K
L B
IDX
ALPHABETICAL INDEX
Trouble diagnoses .............................................. GI-11
TURN - Wiring diagram ...................................... LT-55
Turn signal lamp ................................................. LT-51
Two trip detection logic ..................................... EC-47
V
Vacuum hose (brake system) ........................... BR-22
Vacuum hose drawing (Engine control) .......... EC-102
Valve clearance ................................................. EM-55
Valve guide ....................................................... EM-68
Valve lifter ......................................................... EM-51
Valve seat ......................................................... EM-70
Valve spring ...................................................... EM-71
Vehicle recovery (freeing a stuck vehicle) .......... GI-44
Vehicle security (theft warning) system ............ BL-193
Vehicle speed sensor (VSS) EC-421, EC-485, EC-486
VEHSEC - Wiring diagram ............................... BL-197
VENT/V - Wiring diagram .................. EC-371, EC-378
Ventilation air filter .......................................... MTC-74
VIN registration ................................................. EC-77
Viscosity number (SAE) .................................... MA-12
VSS A/T - Wiring diagram ................................ AT-109
VSSMTR - Wiring diagram ............................... AT-167
W
WARN - Wiring diagram ...................................... DI-25
Warning chime .................................................... DI-47
Warning lamps .................................................... DI-24
Washer, front ..................................................... WW-4
Washer, rear ................................................... WW-30
Water control valve ........................................... CO-20
Water pump ....................................................... CO-17
Water temperature gauge ..................................... DI-5
Wheel alignment (front) ..................................... FSU-6
Wheel alignment (rear) ...................................... RSU-5
Wheel balance ....................................... WT-6, MA-24
Wheel bearing (rear) ......................................... RAX-4
Wheel hub (rear) ............................................... RAX-4
Wheel sensor (VDC) ....................................... BRC-33
Wheel sensors (ABS) ...................................... BRC-11
WINDOW - Wiring diagram .............................. GW-23
Window, door ...................................... GW-43, GW-47
Windshield ........................................................ GW-11
WIP/R - Wiring diagram .................................. WW-33
WIPER - Wiring diagram ................................... WW-9
Wiper, front ........................................................ WW-4
Wiper, rear ...................................................... WW-30
Wiring Diagram (Cell code) list .......................... PG-61
Wiring diagrams ................................................. GI-15
