NISSAN LATIO 2007  Service Repair Manual PREPARATION
RSU-3
C
D
F
G
H
I
J
K
L
MA
B
RSU
Revision: June 20062007 Versa
PREPARATIONPFP:00002
Commercial Service ToolsEES002CV
To o l  n a m eDescription
Power toolRemoving wheel nuts
PBIC0190E

Page 2652 of 2896

NISSAN LATIO 2007  Service Repair Manual RSU-4
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
Revision: June 20062007 Versa
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTINGPFP:00003
NVH Troubleshooting ChartEES002CW
Use chart below

Page 2653 of 2896

NISSAN LATIO 2007  Service Repair Manual REAR SUSPENSION ASSEMBLY
RSU-5
C
D
F
G
H
I
J
K
L
MA
B
RSU
Revision: June 20062007 Versa
REAR SUSPENSION ASSEMBLYPFP:55020
On-Vehicle Inspection and ServiceEES002CX
Make sure the mounting conditions (l

Page 2654 of 2896

NISSAN LATIO 2007  Service Repair Manual RSU-6
REAR SUSPENSION ASSEMBLY
Revision: June 20062007 Versa
CAMBER INSPECTION
Measure camber of both right and left wheels with a suitable
alignment gauge.
If it is out of the specification value,

Page 2655 of 2896

NISSAN LATIO 2007  Service Repair Manual REAR SUSPENSION ASSEMBLY
RSU-7
C
D
F
G
H
I
J
K
L
MA
B
RSU
Revision: June 20062007 Versa
TOE-IN INSPECTION
Measure toe-in using following procedure. If it is out of the specification, inspect and repla

Page 2656 of 2896

NISSAN LATIO 2007  Service Repair Manual RSU-8
REAR SUSPENSION ASSEMBLY
Revision: June 20062007 Versa
ComponentsEES002CZ
WAIA0110E
1. Washer (upper) 2. Bushing (upper) 3. Bushing (lower)
4. Washer (lower) 5. Distance tube 6. Bound bumper cov

Page 2657 of 2896

NISSAN LATIO 2007  Service Repair Manual SHOCK ABSORBER
RSU-9
C
D
F
G
H
I
J
K
L
MA
B
RSU
Revision: June 20062007 Versa
SHOCK ABSORBERPFP:56210
Removal and InstallationEES002D0
REMOVAL
1. Remove rear tires from vehicle using power tool.
2. Re

Page 2658 of 2896

NISSAN LATIO 2007  Service Repair Manual RSU-10
SHOCK ABSORBER
Revision: June 20062007 Versa
INSTALLATION
Installation is in the reverse order of removal. For tightening torque, refer to RSU-8, "Components"  .
When installing body side bus

Page 2659 of 2896

NISSAN LATIO 2007  Service Repair Manual COIL SPRING
RSU-11
C
D
F
G
H
I
J
K
L
MA
B
RSU
Revision: June 20062007 Versa
COIL SPRINGPFP:55020
Removal and InstallationEES002D1
REMOVAL
1. Remove rear tires from vehicle using power tool.
2. Remove

Page 2660 of 2896

NISSAN LATIO 2007  Service Repair Manual RSU-12
REAR SUSPENSION BEAM
Revision: June 20062007 Versa
REAR SUSPENSION BEAMPFP:55501
Removal and InstallationEES002D2
REMOVAL
1. Remove rear tires from vehicle using power tool.
2. Separate parking
