NISSAN LATIO 2007  Service Repair Manual FRONT SEAT
SE-13
C
D
E
F
G
H
J
K
L
MA
B
SE
Revision: June 20062007 Versa
3. Remove seat cushion trim and seat cushion pad from the seat cushion frame.
Assembly
Assembly is the reverse order of removal

Page 2722 of 2896

NISSAN LATIO 2007  Service Repair Manual SE-14
REAR SEAT
Revision: June 20062007 Versa
REAR SEATPFP:88300
Component Parts DrawingEIS0097N
60:40 SPLIT FOLD DOWN SEAT
WIIA1231E

Page 2723 of 2896

NISSAN LATIO 2007  Service Repair Manual REAR SEAT
SE-15
C
D
E
F
G
H
J
K
L
MA
B
SE
Revision: June 20062007 Versa
Removal and InstallationEIS0097O
CAUTION:
When removing and installing, use shop cloths to protect parts from damage.
60:40 SPLI

Page 2724 of 2896

NISSAN LATIO 2007  Service Repair Manual SE-16
REAR SEAT
Revision: June 20062007 Versa
4. Remove the seatback mounting bolts from the left rear seat
back brackets.
5. Remove the seatback from the vehicle.
6. Remove the kicking plate rear inn

Page 2725 of 2896

NISSAN LATIO 2007  Service Repair Manual REAR SEAT
SE-17
C
D
E
F
G
H
J
K
L
MA
B
SE
Revision: June 20062007 Versa
1. Install the rear seatback side bracket in the vehicle.
2. Temporarily tighten the seatback assembly and rear seatback side br

Page 2726 of 2896

NISSAN LATIO 2007  Service Repair Manual SE-18
REAR SEAT
Revision: June 20062007 Versa
Assembly of Armrest
Assembly in the reverse order of disassembly.
Disassembly of Seatback Trim and Pad
1. Remove the headrest.
2. Remove the retainer unde

Page 2727 of 2896

NISSAN LATIO 2007  Service Repair Manual REAR SEAT
SE-19
C
D
E
F
G
H
J
K
L
MA
B
SE
Revision: June 20062007 Versa
Assembly of Seatback Trim and Pad
Assembly is the reverse order of disassembly. Be careful of the following one point.
Before i

Page 2728 of 2896

NISSAN LATIO 2007  Service Repair Manual SE-20
REAR SEAT
Revision: June 20062007 Versa

Page 2729 of 2896

NISSAN LATIO 2007  Service Repair Manual SRS-1
SUPPLEMENTAL RESTRAINT SYSTEM (SRS)
H  RESTRAINTS
CONTENTS
C
D
E
F
G
I
J
K
L
M
SECTION SRS
A
B
SRS
Revision: June 20062007 Versa PRECAUTIONS .....................................................

Page 2730 of 2896

NISSAN LATIO 2007  Service Repair Manual SRS-2Revision: June 20062007 Versa DIAGNOSIS SENSOR UNIT  ..................................... 52
Removal and Installation  ........................................ 52
REMOVAL .......................
