For your safety, read carefully and keep in this vehicle.OWNER'S MANUAL
REVISED
2011 LEAF
2011 NISSAN LEAF ZE0-D
ZE0-D
K100PANTONE
297CPANTONE 299CPANTONE289CPANTONE102C
Page 34 of 1062
yourself” section.
TIRE EQUIPMENT
SUMMER tires have a tread designed to provide
superior performance on dry pavement. How-
ever, the performance of these tires will be
substantially reduced in snowy and icy condi-
tions. If you operate your vehicle on snowy or icy
roads, NISSAN recommends the use of MUD &
SNOW or ALL SEASON tires on all four wheels.
Consult a NISSAN certified LEAF dealer for the
tire type, size, speed rating and availability
information.
For additional traction on icy roads, studded
tires may be used. However, some U.S. states
and Canadian provinces prohibit their use.
Check local, state and provincial laws before
installing studded tires.
Skid and traction capabilities of studded
snow tires, on wet or dry surfaces, may be
poorer than that of non-studded snow
tires.
Tire chains may be used. For details, see “Tire
chains” in the “8. Maintenance and do-it-
yourself” section.
SPECIAL WINTER EQUIPMENT
It is recommended that the following items be
carried in the vehicle during winter:
.A scraper and stiff-bristled brush to remove
ice and snow from the windows and wiper
blades.
. A shovel to dig the vehicle out of snow-
drifts.
. Extra window washer fluid to refill the
reservoir tank.
DRIVING ON SNOW OR ICE
Page 35 of 1062
Page 36 of 1062
6 In case of emergency
Roadside assistance program .............................................. 6-2
Emergency EV (Electric Vehicle) shut off .......................... 6-2 Flat tire ........................................................................................ 6-2
Tire Pressure Monitoring System (TPMS) ................... 6-2
Repairing flat tire ................................................................ 6-3
Jump starting ............................................................................. 6-9
If the Li-ion battery becomes completely discharged ... 6-11 Push starting .......................................................................... 6-12
Tools ........................................................................................ 6-12
Towing your vehicle ............................................................. 6-13
Towing recommended by NISSAN .......................... 6-14
Vehicle recovery (freeing stuck vehicle) ................. 6-15
Parking brake mechanical release ................................... 6-16
Page 37 of 1062
Page 38 of 1062
and increase the likelihood of tire
failure. Serious vehicle damage
could occur and may lead to an
accident and could result in serious
personal injury. Check the tire pres-
sure for all four tires. Adjust the tire
pressure to the recommended COLD
tire pressure shown on the Tire and
Loading Information label to turn
the low tire pressure warning light
OFF. If the light still illuminates
while driving after adjusting the tire
pressure, a tire may be flat. If you
have a flat tire, repair it as soon as
possible.
. When a wheel is replaced, the TPMS
will not function and the low tire
pressure warning light will flash for
approximately 1 minute. The light
will remain on after 1 minute. Con-
tact a NISSAN certified LEAF dealer
as soon as possible for tire replace-
ment and/or system resetting.
. Replacing tires with those not ori-
ginally specified by NISSAN could
affect the proper operation of the
TPMS. .
If you used the Emergency Tire
Sealant to repair a minor tire punc-
ture, your NISSAN certified LEAF
dealer will also need to replace the
TPMS sensor in addition to repair-
ing or replacing the tire.
. NISSAN recommends using only
NISSAN Genuine Emergency Tire
Sealant provided with your vehicle.
Other tire sealants may damage the
valve stem seal which can cause the
tire to lose air pressure.
REPAIRING FLAT TIRE
Page 39 of 1062
If you have a flat tire, follow the instructions
below.
Page 40 of 1062
Getting emergency tire puncture
repair kit
Take out the emergency tire puncture repair kit
located under the cargo area. The repair kit
consists of the following items:
*1Tire sealant bottle
*2Air compressor
*3Speed restriction sticker
Before using emergency tire punc-
ture repair kit
.If any foreign object (for example, a screw or
nail) is embedded in the tire, do not remove
it. .
Check the expiration date of the sealant
(shown on the label attached to the bottle) .
Never use a sealant whose expiration date
has passed.
Repairing tire:
