NISSAN LEAF 2012 Owners Manual

CHECKING COOLANT LEVEL
Check the coolant levelin the reservoir when
the high voltage parts are cold. If the coolant
level is below the MIN level
*2, open the
reservoir cap and add coolant up to the MAX
level
*1. If the reservoir is empty, check the
coolant level in the coolant tank when the high
voltage parts are cold. If there is insufficient
coolant in the coolant tank, fill the coolant tank
with coolant up to the reservoir cap opening and
also add it to the reservoir up to the MAX level
*1.
Tighten the cap securely after adding coolant. If the cooling system frequently requires
coolant, have it checked by a NISSAN
certified LEAF dealer.
CHANGING COOLANT
Major cooling system repairs should be per-
formed by a NISSAN certified LEAF dealer. The
service procedures can be found in the appro-
priate NISSAN Service Manual.
Improper servicing can result in reduced
heater performance.

1. Remove the cell plugs*A.
2. Add distilled water up to the UPPER LEVEL
*1line.
If the side of the 12-volt battery is not clear,
check the distilled water level by looking
directly above the cell; the condition
*1
indicates OK and the condition*2needs
more to be added.
3. Tighten cell plugs
*A.
Vehicles operated in high temperatures or under
severe conditions require frequent checks of the
12-volt battery fluid level.
JUMP STARTING
Jump starting provides power to the 12 volt
system to allow the electrical systems to
operate. The electrical systems must be operat-
ing to allow the Li-ion battery to be charged.
Jump starting does not charge the Li-ion battery.
The Li-ion battery must be charged before the
vehicle can be driven.
If jump starting is necessary, see “Jump starting”
in the “6. In case of emergency” section. If the
power switch does not switch to READY to drive
position by jump starting, the 12-volt battery
may have to be replaced. Contact a NISSAN
certified LEAF dealer.

the fascia.)
5. Insert grommets into the mounting holes on the fascia.
6. Insert a flat-blade screwdriver into the grommet hole and turn the part
*C908.
7. Insert a J-nut into the license plate bracket before placing the license plate bracket on
the fascia.
8. Install the license plate bracket with screws.
9. Install the license plate with bolts that are not longer than 0.55 in (14 mm).

4.The resulting figure equals the available
amount of cargo and luggage load
capacity. For example, if the XXX
amount equals 1400 lbs. and there will
be five 150 lb. passengers in your
vehicle, the amount of available cargo
and luggage load capacity is 650 lbs.
(1400−750 (5 x 150) = 650 lbs) or
(640 −340 (5 x 70) = 300 kg.)
5.Determine the combined weight of
luggage and cargo being loaded on
the vehicle. That weight may not safely
exceed the available cargo and luggage
load capacity calculated in Step 4.
Before driving a loaded vehicle, confirm
that you do not exceed the Gross Vehicle
Weight Rating (GVWR) or the Gross Axle
Weight Rating (GAWR) for your vehicle.
(See “Measurement of weights” later in this
section.)
Also check tires for proper inflation pres-
sures. See the Tire and Loading Information
label.
