NISSAN LEAF 2012 Repair Manual

NOTE:
.While the electric parking brake is
applied or released, an operating
sound is heard from the lower side of
the rear seat. However, this is not a
malfunction.
. When the electric parking brake is
frequently applied and released in a
short period of time, the electric park-
ing brake may not operate in order to
prevent the electric parking brake sys-
tem from overheating. If this occurs,
operate the electric parking brake
again after approximately 1 minute.
. The electric parking brake can be
released with the power switch in the
ON or READY to drive position.
. If the electric parking brake must be
applied while driving in an emergency,
pull up and hold the electric parking
brake switch. When you release the
parking brake switch, the parking
brake will be released.
. While pulling up on the electric parking
brake switch, the electric parking brake
is applied and a chime sounds. The
electric parking brake indicator light in
the meter and parking brake switch operation indicator illuminate. This
does not indicate a malfunction. The
electric parking brake indicator light
and parking switch operation indicator
turn off when the electric parking brake
switch is released.
. Pull up on the electric parking brake
switch twice so that the maximum
electric parking brake force can be
applied to the vehicle.
. When operating the electric parking
brake switch with the power switch in
the ON position, the electric parking
brake indicator light in the meter and
the electric parking brake switch op-
eration indicator turn on.
. Do not start driving while the parking
brake is applied. Doing so may cause
the parking brake to overheat or re-
duce its effectiveness, which could
result in an accident.
. When pulling the electric parking brake
switch with the power switch in the
OFF or ACC position, the electric park-
ing brake switch operation indicator
will continue to illuminate for a short
period of time.

7 Appearance and care
Cleaning exterior ...................................................................... 7-2Washing ................................................................................ 7-2
Waxing .................................................................................. 7-2
Removing spots .................................................................. 7-3Underbody ............................................................................ 7-3
Glass ..................................................................................... 7-3
Solar cell module (if so equipped) ................................ 7-3
Wheels .................................................................................. 7-3
Chrome parts ...................................................................... 7-4
Tire dressing ........................................................................ 7-4 Cleaning interior ...................................................................... 7-4
Air fresheners .................................................................... 7-5Floor mats .......................................................................... 7-5
Seat belts ........................................................................... 7-6
Electric Vehicle Supply Equipment (EVSE) .............. 7-6
Corrosion protection ............................................................... 7-7
Most common factors contributing to
vehicle corrosion .............................................................. 7-7
Environmental factors influence the rate
of corrosion ....................................................................... 7-7
To protect your vehicle from corrosion ...................... 7-7

Machine compound or aggressive polishing on a
base coat/clear coat paint finish may dull the
finish or leave swirl marks.
REMOVING SPOTS
Remove tar and oil spots, industrial dust,
insects, and tree sap as quickly as possible
from the paint surface to avoid lasting damage
or staining. Special cleaning products are
available at a NISSAN certified LEAF dealer or
any automotive accessory stores.
UNDERBODY
In areas where road salt is used in winter, the
underbody must be cleaned regularly. This will
prevent dirt and salt from building up and
causing the acceleration of corrosion on the
underbody and suspension. Before the winter
period and again in the spring, the underseal
must be checked and, if necessary, re-treated.
GLASS
Use glass cleaner to remove smoke and dust
film from the glass surfaces. It is normal for glass
to become coated with a film after the vehicle is
parked in the hot sun. Glass cleaner and a soft
cloth will easily remove this film.

wheel temperature should be the
same as ambient temperature.
. Rinse the wheel to completely re-
move the cleaner within 15 minutes
after the cleaner is applied.
CHROME PARTS
Clean chrome parts regularly with a non-
abrasive chrome polish to maintain the finish.
TIRE DRESSING
NISSAN does not recommend the use of tire
dressings. Tire manufacturers apply a coating to
the tires to help reduce discoloration of the
rubber. If a tire dressing is applied to the tires, it
may react with the coating and form a com-
pound. This compound may come off the tire
while driving and stain the vehicle paint.
If you choose to use a tire dressing, take the
following precautions:
.Use a water-based tire dressing. The coat-
ing on the tire dissolves more easily with an
oil-based tire dressing.
. Apply a light coat of tire dressing to help
prevent it from entering the tire tread/
grooves (where it would be difficult to
remove) . .
Wipe off excess tire dressing using a dry
towel. Make sure the tire dressing is
completely removed from the tire tread/
grooves.
. Allow the tire dressing to dry as recom-
mended by tire dressing manufacturer.

CAUTION
.Never use benzine, thinner, or any
similar material.
. Small dirt particles can be abrasive
and damaging to the leather sur-
faces and should be removed
promptly. Do not use saddle soap,
car waxes, polishes, oils, cleaning
fluids, solvents, detergents or am-
monia-based cleaners as they may
damage the leather’s natural finish.
. Never use fabric protectors unless
recommended by the manufacturer.
. Do not use glass or plastic cleaner
on meter or gauge lens covers. It
may damage the lens cover.
AIR FRESHENERS
Most air fresheners use a solvent that could
affect the vehicle interior. If you use an air
freshener, take the following precautions:
.Hanging-type air fresheners can cause
permanent discoloration when they contact
vehicle interior surfaces. Place the air
freshener in a location that allows it to hang
free and not contact an interior surface. .
Liquid-type air fresheners typically clip on
the vents. These products can cause
immediate damage and discoloration when
spilled on interior surfaces.
Carefully read and follow the manufacturer’s
instructions before using air fresheners.
FLOOR MATS

Floor mat positioning aid (driver’s
side only)
This vehicle includes front floor mat brackets to
act as floor mat positioning aid. NISSAN floor
mats have been specially designed for your
vehicle model. The driver’s side floor mat has
grommet holes incorporated in it. Position the
mat by placing the floor mat bracket hook
through the floor mat grommet hole while
centering the mat in the floorwell.
Periodically check to make certain the mats are
properly positioned.
