Page 11 of 1062
.While the battery is being charged, the
Climate Ctrl. Timer cannot be operated until
the Li-ion battery available charge gauge
reached the full mark. When the battery is
not being charged, the Climate Ctrl. Timer
can be operated, even if the Li-ion battery
available charge gauge has not reached the
full mark.
. When the climate control is set on first
priority, the Climate Ctrl. Timer works
regardless of the remaining battery energy.
. If the Climate Ctrl. Timer starts its operation
while the vehicle is being charged, the
charging time will be prolonged.
. Operating the Climate Ctrl. Timer or remote
climate control in an environment with low
temperature may decrease the rate of
battery charge.
. The Climate Ctrl. Timer settings cannot be
modified while it is operating. If timer
settings are modified while the Climate Ctrl.
Timer is operating, these changes will be
reflected the next time the Climate Ctrl.
Timer operates.
. When charging is set as the first priority, the
Climate Ctrl. Timer does not start until 10
segments of the LI-ION BATTERY AVAIL-
ABLE CHARGE GAUGE are illuminated. .
When the climate control is set as the first
priority, the climate control system will be
turned on as scheduled by the Climate Ctrl.
Timer regardless of the remaining battery
energy.
. Even when the climate control is set as the
first priority, the climate control system will
be turned off when the climate control
spends more electric than the charging Li-
ion battery.
. The Li-ion battery may not charge or may
even become discharged if the Climate Ctrl.
Timer or remote climate control is used in
low ambient temperatures.
REMOTE CLIMATE CONTROL
This vehicle incorporates a communication
device that is called a TCU (Telematics Com-
munication Unit). The communication connec-
tion between this unit and NISSAN CARWINGS
Data Center allows for various remote function
services.
Even when away from the vehicle, climate
control can be started by accessing the
NISSAN CARWINGS Data Center website
using a cellular phone or a personal computer.
When operation is started, or at the set start
time, the NISSAN CARWINGS Data Center accesses the vehicle. When the vehicle receives
a command for remote operation, the climate
control immediately turns ON and operates for
the specified period of time. Confirmation of the
ON/OFF of the climate control operation can be
checked by accessing the website or by e-mail.
Establishing the CARWINGS
TMservice is ne-
cessary before using the service. See LEAF
Navigation System Owner’s Manual.
Page 12 of 1062
high enough to cause severe or
possibly fatal injuries to people or
animals.
NOTE:
. To check the Li-ion battery charging
status using an internet enabled smart
phone or personal computer.
—The vehicle must be located in a
cellular phone coverage area.
— The cellular phone must be located
in an area with cellular phone
coverage.
— The computer must be connected to
the internet.
. Some cellular phones are not compa-
tible with this system and cannot be
used to check the Li-ion battery char-
ging status. Confirm this beforehand.
Operating tips
.When the charge connector is connected,
the climate control operates using electric
power. When the charge connector is
disconnected from the vehicle, the climate
control operates using vehicle battery elec-
tric power. .
The climate control can be operated for a
maximum of 2 hours when the charge
connector is connected to the vehicle, or a
maximum of 15 minutes when the charge
connector is disconnected.
. The remote climate control will only start to
operate when the power switch is in the
OFF position. Be sure to check that the
power switch is in the OFF position.
. Remote climate control operation is not
available when the vehicle is in an area of
cellular communication range.
. Communication becomes unavailable when
the vehicle is not used for two weeks or
more. When the power switch is placed in
the ON position, communication with the
NISSAN CARWINGS Data Center can be
restored.
. Air conditioning is limited to the capacity of
the electric power when the charge con-
nector is connected to the vehicle. There-
fore, the temperature may not reach a
comfortable level due to performance of
the air conditioning being limited, if the
outside temperature is excessively high or
low, or if the charge connector is connected
to a 120V outlet. .
If the power switch is in the ON position or
the charge connector is disconnected, while
the remote climate control is being oper-
ated, remote climate control operation is
automatically stopped and an e-mail is sent.
. If remote climate control operation is started
while the vehicle is in normal charge mode,
the climate control operates in climate
control priority mode and charging is con-
tinued.
. If remote climate control operation is started
and charging is stopped while the vehicle is
in quick charge mode, climate control
operation is also stopped.
. If the quick charge connector is connected
and charging is not performed, remote
climate control operation starts using the
battery electric power of the vehicle.
Page 23 of 1062
10 Index
A
ABS (Anti-lock Braking System) ............................ 5-23
Advanced air bag system ......................................... 1-42
Air bag systemAdvanced air bag system .................................. 1-42
Front passenger air bag and status light....... 1-44
Front-seat mounted side-impact supplemental
air bag system....................................................... 1-47
Roof-mounted curtain side-impact
supplemental air bag system ............................ 1-47
Air bag warning labels............................................... 1-50
Air bag warning light...................................... 1-50, 2-18
Air conditioner Air conditioner specification label....................... 9-8
Air conditioning system refrigerant and
lubricant recommendations................................... 9-3
Alarm, How to stop alarm (see vehicle
security system)........................................................... 2-36
Alcohol, drugs and driving.......................................... 5-6
Anti-lock Braking System (ABS) ............................ 5-23
Anti-lock braking system (ABS) warning light..... 2-14
Appearance care Exterior appearance care ...................................... 7-2
Interior appearance care ....................................... 7-4
Audible reminders....................................................... 2-21
Autolight system.......................................................... 2-42
Automatic Door locks................................................................. 3-5
Automatic climate control ........................................... 4-6
Avoiding collision and rollover ................................... 5-5
B
Battery 12-volt battery....................................................... 8-11
Battery saver system........................................... 2-43
Intelligent Key battery.......................................... 8-18
Li-ion battery.......................................................... EV-2
Li-ion battery temperature gauge........................ 2-7
Before starting system............................................... 5-10
Booster seats............................................................... 1-33
Brake Anti-lock Braking System (ABS) ..................... 5-23
Brake fluid................................................................. 8-9
Brake system......................................................... 5-21
BRAKE system warning light (yellow) ............ 2-14
BRAKE warning light (red) ................................ 2-15
Brakes..................................................................... 8-15
Electric parking brake operation ...................... 5-15
BRAKE system warning light (yellow) ................... 2-14
BRAKE warning light (red) ....................................... 2-15
Bulb replacement........................................................ 8-20
C
Cabin air filter............................................................... 4-13
Capacities and recommended lubricants ............... 9-2
Cargo cover.................................................................. 2-51
Ceiling light................................................................... 2-57
Charging Charge port lid...................................................... 3-17
Charging related indicator light.................... CH-26
Charging timer .................................................. CH-19
Cleaning .................................................................... 7-6
Normal charge ..................................................... CH-9
Precautions on charging ................................... CH-2 Quick charge..................................................... CH-16
Specifications........................................................... 9-4
Tricklle charge................................................... CH-11
Charging methods .................................................. CH-19
Charging related indicator light........................... CH-26
Charging related remote function....................... CH-25
Charging status indicator light ............................ CH-26
Charging timer ......................................................... CH-19
Charging troubleshooting guide.......................... CH-30
Checking Checking bulbs..................................................... 2-13
Checking coolant level .......................................... 8-8
Child restraints............................................................. 1-19 Booster seats........................................................ 1-33
Precautions on child restraints......................... 1-19
Top tether strap.................................................... 1-22
Child safety................................................................... 1-17
Child safety rear door lock ......................................... 3-6
Circuit breaker, Fusible link...................................... 8-17
Cleaning exterior and interior............................ 7-2, 7-4
Climate control Climate control service....................................... 4-14
Climate control system refrigerant and
lubricant recommendations................................ 4-14
In-cabin microfilter ............................................... 4-13
Climate control system Climate control operation...................................... 4-3
Climate Ctrl. Timer........................................................ 4-7
Clock.............................................................................. 2-11
Cockpit ............................................................................ 2-3
Cold weather driving.................................................. 5-26
Console box ................................................................. 2-51
Coolant Capacities and recommended lubricants ......... 9-2
Changing coolant.................................................... 8-8
Page 24 of 1062
Checking coolant level .......................................... 8-8
Cooling system.............................................................. 8-7
Corrosion protection .................................................... 7-7
Cruise control............................................................... 5-17
Cup holders.................................................................. 2-49
D
Defroster switch, Rear window and outside mirror
defroster switch........................................................... 2-40
Dimensions and weights............................................. 9-5
Dot matrix liquid crystal display............................... 2-22
Driving Cold weather driving........................................... 5-26
Driving vehicle....................................................... 5-11
Precautions when starting and driving .............. 5-2
Driving range.................................................................. 2-8
Driving vehicle.............................................................. 5-11
E
ECO indicator.............................................................. 2-10
Efficient use of your vehicle ................................. EV-22
Electric parking brake break-in................................ 5-23
Electric parking brake indicator light...................... 2-19
Electric power steering system ............................... 5-21
Emergency charge.................................................. CH-11
Emergency EV (Electric Vehicle) shut off...... 5-9, 6-2
Emergency shutoff system........................................ EV-9
Emission control information label............................ 9-7
EV Characteristics ..................................................... EV-9
EV system ..................................................................... EV-2
EV unique information............................................. EV-24
Event Data Recorder (EDR)..................................... 9-18
EVSE (Electric Vehicle Supply Equipment) ..... CH-11
EVSE (Electric Vehicle Supply
Equipment) cleaning..................................................... 7-6
F
F.M.V.S.S./C.M.V.S.S. certification label ................. 9-7
Flashers (See hazard warning flasher switch)..... 2-45
Flat tire............................................................................. 6-2
Flat towing .................................................................... 9-14
Floor mat cleaning ........................................................ 7-5
Fluid Brake fluid................................................................. 8-9
Capacities and recommended lubricants ......... 9-2
coolant ....................................................................... 8-7
Reduction gear fluid............................................... 8-9
Window washer fluid .......................................... 8-10
Fog light switch........................................................... 2-44
Front manual seat adjustment.................................... 1-3
Front passenger air bag and status light.............. 1-44
Front seat, Front seat adjustment............................. 1-3
Fuses.............................................................................. 8-16
Fusible links.................................................................. 8-17
G
Garage door open, HomeLink®Universal
Transceiver............................................................. 2-58
Gauge .............................................................................. 2-5 Driving range............................................................ 2-8
ECO indicator....................................................... 2-10
Li-ion battery available charge gauge................ 2-9
Li-ion battery capacity level gauge.................. 2-10
Li-ion battery temperature gauge........................ 2-7
Odometer.................................................................. 2-6
Power meter ............................................................. 2-7
Speedometer............................................................ 2-6
General maintenance ................................................... 8-2
Glove box...................................................................... 2-51
H
Hazard warning flasher switch................................. 2-45
Head restraints .............................................................. 1-4
Headlights Bulb replacement................................................. 8-21
Headlight Aiming Control ................................. 2-44
Headlight switch................................................... 2-41
Heated seats................................................................ 2-46
Heated steering wheel............................................... 2-45
High voltage precautions .......................................... EV-7
HomeLink
®universal transceiver............................. 2-58
Hood release................................................................ 3-16
Horn................................................................................ 2-46
How to normal charge.............................................. CH-9
How to quick charge.............................................. CH-16
How to trickle charge ............................................ CH-11
I
If the Li-ion battery becomes
completely discharged............................................... 6-12
Immediate charge.................................................... CH-24
Immobilizer system...................................................... 2-36
In-cabin microfilter ...................................................... 4-13
indicator Electric parking brake indicator light............... 2-19
Indicator lights.............................................................. 2-19
Indicators for operation.............................................. 2-23
Inside rearview mirror................................................. 3-20
Instrument brightness control .................................. 2-41
Instrument panel............................................................ 2-4
Intelligent Key system ......................................... 3-6, 5-7 Key operating range ............................................... 3-8
Key operation ........................................................ 3-10
Remote keyless operation.................................. 3-13
Page 26 of 1062
Parking brake mechanically release ....................... 6-16
PowerElectric power steering system ........................ 5-21
Power door lock...................................................... 3-4
Power windows .................................................... 2-53
Power economy........................................................... 5-19
Power meter ................................................................... 2-7
Power outlet ................................................................. 2-48
Power switch......................................................... 5-7, 5-8
Precautions Braking precautions............................................. 5-21
Charging................................................................ CH-2
Child restraints...................................................... 1-19
Cruise control........................................................ 5-17
High voltage precautions ................................... EV-7
Maintenance ............................................................. 8-4
Road accident precautions................................ EV-8
Seat belt usage .................................................... 1-10
Supplemental restraint system.......................... 1-36
When starting and driving .................................... 5-2
Push starting ................................................................ 6-12
Q
Quick charge............................................................ CH-16
R
Rapid air pressure loss................................................ 5-5
Rear center seat belt ................................................. 1-16
Rear door lock, Child safety rear door lock........... 3-6
Rear hatch..................................................................... 3-17
Rear seats....................................................................... 1-4
Rear window and outside mirror
defroster switch........................................................... 2-40
Rear window wiper and washer switch ............... 2-39
Reduction gear fluid..................................................... 8-9 Remote charge ........................................................ CH-25
Remote climate control.............................................. 4-11
Remote keyless entry function, For Intelligent
Key system.................................................................... 3-13
Repairing flat tire........................................................... 6-3
Repairing tire.................................................................. 6-5
Reporting safety defects........................................... 9-15
Road accident precautions....................................... EV-8
Roadside assistance program ................................... 6-2
Rollover............................................................................ 5-5
S
Safety Child seat belts .................................................... 1-17
Reporting safety defects.................................... 9-15
Scene guide At home after driving......................................... EV-21
Before driving your vehicle .............................. EV-13
Charging the Li-ion battery.............................. EV-10
Driving the vehicle.............................................. EV-17
Parking the vehicle............................................. EV-20
Starting your vehicle.......................................... EV-16
Seat adjustment Front manual seat adjustment.............................. 1-3
Front seats................................................................ 1-3
Seat belt(s) Child safety............................................................ 1-17
Infants...................................................................... 1-17
Injured persons..................................................... 1-12
Larger children...................................................... 1-18
Precautions on seat belt usage........................ 1-10
Pregnant women .................................................. 1-12
Rear center seat belt .......................................... 1-16
Seat belt cleaning................................................... 7-6
Seat belt extenders.............................................. 1-16
Seat belt hooks .................................................... 1-15 Seat belt maintenance........................................ 1-16
Seat belt warning light........................................ 2-18
Seat belts............................................................... 1-10
Seat belts with pretensioners........................... 1-49
Shoulder belt height adjustment...................... 1-15
Small children........................................................ 1-18
Three-point type................................................... 1-12
Seat(s) , Seats................................................................ 1-2 Heated seats......................................................... 2-46
Security system (NISSAN Vehicle Immobilizer
System) , EV system start.......................................... 2-36
Servicing climate control........................................... 4-14
Shifting Electric shift control system .............................. 5-11
Shoulder belt height adjustment, For
front seats..................................................................... 1-15
Soft bottle holders...................................................... 2-50
Solar cell module .......................................................... 7-3
Speedometer.................................................................. 2-6
Starting .......................................................................... 5-11 Before starting system........................................ 5-10
Jump starting............................................................ 6-9
Precautions when starting and driving .............. 5-2
Push starting ......................................................... 6-12
Status light, Front passenger air bag .................... 1-44
Steering Electric power steering system ........................ 5-21
Heated steering wheel........................................ 2-45
Tilting steering column........................................ 3-19
Stopping the vehicle .................................................... 6-4
Storage .......................................................................... 2-49
Stowing golf bags....................................................... 2-53
Sun visors ..................................................................... 3-20
Supplemental air bag warning labels..................... 1-50
Supplemental air bag warning light............ 1-50, 2-18
Supplemental restraint system................................. 1-36
Page 126 of 1062
10 Index
A
ABS (Anti-lock Braking System) ............................ 5-23
Advanced air bag system ......................................... 1-42
Air bag systemAdvanced air bag system .................................. 1-42
Front passenger air bag and status light....... 1-44
Front-seat mounted side-impact supplemental
air bag system....................................................... 1-47
Roof-mounted curtain side-impact
supplemental air bag system ............................ 1-47
Air bag warning labels............................................... 1-50
Air bag warning light...................................... 1-50, 2-18
Air conditioner Air conditioner specification label....................... 9-8
Air conditioning system refrigerant and
lubricant recommendations................................... 9-3
Alarm, How to stop alarm (see vehicle
security system)........................................................... 2-36
Alcohol, drugs and driving.......................................... 5-6
Anti-lock Braking System (ABS) ............................ 5-23
Anti-lock braking system (ABS) warning light..... 2-14
Appearance care Exterior appearance care ...................................... 7-2
Interior appearance care ....................................... 7-4
Audible reminders....................................................... 2-21
Autolight system.......................................................... 2-42
Automatic Door locks................................................................. 3-5
Automatic climate control ........................................... 4-6
Avoiding collision and rollover ................................... 5-5
B
Battery 12-volt battery....................................................... 8-11
Battery saver system........................................... 2-43
Intelligent Key battery.......................................... 8-18
Li-ion battery.......................................................... EV-2
Li-ion battery temperature gauge........................ 2-7
Before starting system............................................... 5-10
Booster seats............................................................... 1-33
Brake Anti-lock Braking System (ABS) ..................... 5-23
Brake fluid................................................................. 8-9
Brake system......................................................... 5-21
BRAKE system warning light (yellow) ............ 2-14
BRAKE warning light (red) ................................ 2-15
Brakes..................................................................... 8-15
Electric parking brake operation ...................... 5-15
BRAKE system warning light (yellow) ................... 2-14
BRAKE warning light (red) ....................................... 2-15
Bulb replacement........................................................ 8-20
C
Cabin air filter............................................................... 4-13
Capacities and recommended lubricants ............... 9-2
Cargo cover.................................................................. 2-51
Ceiling light................................................................... 2-57
Charging Charge port lid...................................................... 3-17
Charging related indicator light.................... CH-26
Charging timer .................................................. CH-19
Cleaning .................................................................... 7-6
Normal charge ..................................................... CH-9
Precautions on charging ................................... CH-2 Quick charge..................................................... CH-16
Specifications........................................................... 9-4
Tricklle charge................................................... CH-11
Charging methods .................................................. CH-19
Charging related indicator light........................... CH-26
Charging related remote function....................... CH-25
Charging status indicator light ............................ CH-26
Charging timer ......................................................... CH-19
Charging troubleshooting guide.......................... CH-30
Checking Checking bulbs..................................................... 2-13
Checking coolant level .......................................... 8-8
Child restraints............................................................. 1-19 Booster seats........................................................ 1-33
Precautions on child restraints......................... 1-19
Top tether strap.................................................... 1-22
Child safety................................................................... 1-17
Child safety rear door lock ......................................... 3-6
Circuit breaker, Fusible link...................................... 8-17
Cleaning exterior and interior............................ 7-2, 7-4
Climate control Climate control service....................................... 4-14
Climate control system refrigerant and
lubricant recommendations................................ 4-14
In-cabin microfilter ............................................... 4-13
Climate control system Climate control operation...................................... 4-3
Climate Ctrl. Timer........................................................ 4-7
Clock.............................................................................. 2-11
Cockpit ............................................................................ 2-3
Cold weather driving.................................................. 5-26
Console box ................................................................. 2-51
Coolant Capacities and recommended lubricants ......... 9-2
Changing coolant.................................................... 8-8
Page 127 of 1062
Checking coolant level .......................................... 8-8
Cooling system.............................................................. 8-7
Corrosion protection .................................................... 7-7
Cruise control............................................................... 5-17
Cup holders.................................................................. 2-49
D
Defroster switch, Rear window and outside mirror
defroster switch........................................................... 2-40
Dimensions and weights............................................. 9-5
Dot matrix liquid crystal display............................... 2-22
Driving Cold weather driving........................................... 5-26
Driving vehicle....................................................... 5-11
Precautions when starting and driving .............. 5-2
Driving range.................................................................. 2-8
Driving vehicle.............................................................. 5-11
E
ECO indicator.............................................................. 2-10
Efficient use of your vehicle ................................. EV-22
Electric parking brake break-in................................ 5-23
Electric parking brake indicator light...................... 2-19
Electric power steering system ............................... 5-21
Emergency charge.................................................. CH-11
Emergency EV (Electric Vehicle) shut off...... 5-9, 6-2
Emergency shutoff system........................................ EV-9
Emission control information label............................ 9-7
EV Characteristics ..................................................... EV-9
EV system ..................................................................... EV-2
EV unique information............................................. EV-24
Event Data Recorder (EDR)..................................... 9-18
EVSE (Electric Vehicle Supply Equipment) ..... CH-11
EVSE (Electric Vehicle Supply
Equipment) cleaning..................................................... 7-6
F
F.M.V.S.S./C.M.V.S.S. certification label ................. 9-7
Flashers (See hazard warning flasher switch)..... 2-45
Flat tire............................................................................. 6-2
Flat towing .................................................................... 9-14
Floor mat cleaning ........................................................ 7-5
Fluid Brake fluid................................................................. 8-9
Capacities and recommended lubricants ......... 9-2
coolant ....................................................................... 8-7
Reduction gear fluid............................................... 8-9
Window washer fluid .......................................... 8-10
Fog light switch........................................................... 2-44
Front manual seat adjustment.................................... 1-3
Front passenger air bag and status light.............. 1-44
Front seat, Front seat adjustment............................. 1-3
Fuses.............................................................................. 8-16
Fusible links.................................................................. 8-17
G
Garage door open, HomeLink®Universal
Transceiver............................................................. 2-58
Gauge .............................................................................. 2-5 Driving range............................................................ 2-8
ECO indicator....................................................... 2-10
Li-ion battery available charge gauge................ 2-9
Li-ion battery capacity level gauge.................. 2-10
Li-ion battery temperature gauge........................ 2-7
Odometer.................................................................. 2-6
Power meter ............................................................. 2-7
Speedometer............................................................ 2-6
General maintenance ................................................... 8-2
Glove box...................................................................... 2-51
H
Hazard warning flasher switch................................. 2-45
Head restraints .............................................................. 1-4
Headlights Bulb replacement................................................. 8-21
Headlight Aiming Control ................................. 2-44
Headlight switch................................................... 2-41
Heated seats................................................................ 2-46
Heated steering wheel............................................... 2-45
High voltage precautions .......................................... EV-7
HomeLink
®universal transceiver............................. 2-58
Hood release................................................................ 3-16
Horn................................................................................ 2-46
How to normal charge.............................................. CH-9
How to quick charge.............................................. CH-16
How to trickle charge ............................................ CH-11
I
If the Li-ion battery becomes
completely discharged............................................... 6-12
Immediate charge.................................................... CH-24
Immobilizer system...................................................... 2-36
In-cabin microfilter ...................................................... 4-13
indicator Electric parking brake indicator light............... 2-19
Indicator lights.............................................................. 2-19
Indicators for operation.............................................. 2-23
Inside rearview mirror................................................. 3-20
Instrument brightness control .................................. 2-41
Instrument panel............................................................ 2-4
Intelligent Key system ......................................... 3-6, 5-7 Key operating range ............................................... 3-8
Key operation ........................................................ 3-10
Remote keyless operation.................................. 3-13
Page 129 of 1062
Parking brake mechanically release ....................... 6-16
PowerElectric power steering system ........................ 5-21
Power door lock...................................................... 3-4
Power windows .................................................... 2-53
Power economy........................................................... 5-19
Power meter ................................................................... 2-7
Power outlet ................................................................. 2-48
Power switch......................................................... 5-7, 5-8
Precautions Braking precautions............................................. 5-21
Charging................................................................ CH-2
Child restraints...................................................... 1-19
Cruise control........................................................ 5-17
High voltage precautions ................................... EV-7
Maintenance ............................................................. 8-4
Road accident precautions................................ EV-8
Seat belt usage .................................................... 1-10
Supplemental restraint system.......................... 1-36
When starting and driving .................................... 5-2
Push starting ................................................................ 6-12
Q
Quick charge............................................................ CH-16
R
Rapid air pressure loss................................................ 5-5
Rear center seat belt ................................................. 1-16
Rear door lock, Child safety rear door lock........... 3-6
Rear hatch..................................................................... 3-17
Rear seats....................................................................... 1-4
Rear window and outside mirror
defroster switch........................................................... 2-40
Rear window wiper and washer switch ............... 2-39
Reduction gear fluid..................................................... 8-9 Remote charge ........................................................ CH-25
Remote climate control.............................................. 4-11
Remote keyless entry function, For Intelligent
Key system.................................................................... 3-13
Repairing flat tire........................................................... 6-3
Repairing tire.................................................................. 6-5
Reporting safety defects........................................... 9-15
Road accident precautions....................................... EV-8
Roadside assistance program ................................... 6-2
Rollover............................................................................ 5-5
S
Safety Child seat belts .................................................... 1-17
Reporting safety defects.................................... 9-15
Scene guide At home after driving......................................... EV-21
Before driving your vehicle .............................. EV-13
Charging the Li-ion battery.............................. EV-10
Driving the vehicle.............................................. EV-17
Parking the vehicle............................................. EV-20
Starting your vehicle.......................................... EV-16
Seat adjustment Front manual seat adjustment.............................. 1-3
Front seats................................................................ 1-3
Seat belt(s) Child safety............................................................ 1-17
Infants...................................................................... 1-17
Injured persons..................................................... 1-12
Larger children...................................................... 1-18
Precautions on seat belt usage........................ 1-10
Pregnant women .................................................. 1-12
Rear center seat belt .......................................... 1-16
Seat belt cleaning................................................... 7-6
Seat belt extenders.............................................. 1-16
Seat belt hooks .................................................... 1-15 Seat belt maintenance........................................ 1-16
Seat belt warning light........................................ 2-18
Seat belts............................................................... 1-10
Seat belts with pretensioners........................... 1-49
Shoulder belt height adjustment...................... 1-15
Small children........................................................ 1-18
Three-point type................................................... 1-12
Seat(s) , Seats................................................................ 1-2 Heated seats......................................................... 2-46
Security system (NISSAN Vehicle Immobilizer
System) , EV system start.......................................... 2-36
Servicing climate control........................................... 4-14
Shifting Electric shift control system .............................. 5-11
Shoulder belt height adjustment, For
front seats..................................................................... 1-15
Soft bottle holders...................................................... 2-50
Solar cell module .......................................................... 7-3
Speedometer.................................................................. 2-6
Starting .......................................................................... 5-11 Before starting system........................................ 5-10
Jump starting............................................................ 6-9
Precautions when starting and driving .............. 5-2
Push starting ......................................................... 6-12
Status light, Front passenger air bag .................... 1-44
Steering Electric power steering system ........................ 5-21
Heated steering wheel........................................ 2-45
Tilting steering column........................................ 3-19
Stopping the vehicle .................................................... 6-4
Storage .......................................................................... 2-49
Stowing golf bags....................................................... 2-53
Sun visors ..................................................................... 3-20
Supplemental air bag warning labels..................... 1-50
Supplemental air bag warning light............ 1-50, 2-18
Supplemental restraint system................................. 1-36
Page 270 of 1062
— Do not use if a malfunctionoccurs or if charger has been
damaged in any manner. Return
to a NISSAN certified LEAF deal-
er for replacement.
— The charger contains no user serviceable parts. Do not at-
tempt to repair the charger,
doing so will void your warranty.
CAUTION
. Only charge using a standard 110 -
120 volt, 15A dedicated electrical
outlet (For example do not use an
electric generator) . Failure to do so
may cause charging to fail and could
cause damage to the Li-ion battery
charging equipment due to power
surges.
. NISSAN recommends using genuine
NISSAN charging equipment to
charge the vehicle. Using non-
NISSAN equipment could cause
the Li-ion battery to not charge
correctly and may damage the Li-
ion battery.
. Trickle charging is performed using an AC
110 - 120 volt, 15A dedicated electrical
outlet using the EVSE (Electric Vehicle
Supply Equipment) provided with the vehi-
cle.
. The genuine NISSAN EVSE (Electric Vehi-
cle Supply Equipment) charging equipment or trickle charge cable performs a commu-
nication function with the vehicle before Li-
ion charging starts. If this communication
does not occur because other equipment is
used, the Li-ion battery will not charge.
. Immediate charge, charging timer and re-
mote charge can be performed in the trickle
charge mode. See “Charging timer” and
“Charging related remote function” later in
this section.
Page 367 of 1062
.While the battery is being charged, the
Climate Ctrl. Timer cannot be operated until
the Li-ion battery available charge gauge
reached the full mark. When the battery is
not being charged, the Climate Ctrl. Timer
can be operated, even if the Li-ion battery
available charge gauge has not reached the
full mark.
. When the climate control is set on first
priority, the Climate Ctrl. Timer works
regardless of the remaining battery energy.
. If the Climate Ctrl. Timer starts its operation
while the vehicle is being charged, the
charging time will be prolonged.
. Operating the Climate Ctrl. Timer or remote
climate control in an environment with low
temperature may decrease the rate of
battery charge.
. The Climate Ctrl. Timer settings cannot be
modified while it is operating. If timer
settings are modified while the Climate Ctrl.
Timer is operating, these changes will be
reflected the next time the Climate Ctrl.
Timer operates.
. When charging is set as the first priority, the
Climate Ctrl. Timer does not start until 10
segments of the LI-ION BATTERY AVAIL-
ABLE CHARGE GAUGE are illuminated. .
When the climate control is set as the first
priority, the climate control system will be
turned on as scheduled by the Climate Ctrl.
Timer regardless of the remaining battery
energy.
. Even when the climate control is set as the
first priority, the climate control system will
be turned off when the climate control
spends more electric than the charging Li-
ion battery.
. The Li-ion battery may not charge or may
even become discharged if the Climate Ctrl.
Timer or remote climate control is used in
low ambient temperatures.
REMOTE CLIMATE CONTROL
This vehicle incorporates a communication
device that is called a TCU (Telematics Com-
munication Unit). The communication connec-
tion between this unit and NISSAN CARWINGS
Data Center allows for various remote function
services.
Even when away from the vehicle, climate
control can be started by accessing the
NISSAN CARWINGS Data Center website
using a cellular phone or a personal computer.
When operation is started, or at the set start
time, the NISSAN CARWINGS Data Center accesses the vehicle. When the vehicle receives
a command for remote operation, the climate
control immediately turns ON and operates for
the specified period of time. Confirmation of the
ON/OFF of the climate control operation can be
checked by accessing the website or by e-mail.
Establishing the CARWINGS
TMservice is ne-
cessary before using the service. See LEAF
Navigation System Owner’s Manual.
