Page 14 of 1062
decreases significantly or if windows fog
up easily when operating the climate
control system.
SERVICING CLIMATE CONTROL
The climate control system in your NISSAN is
charged with a refrigerant designed with the
environment in mind.This refrigerant will not
harm the earth’s ozone layer. Special char-
ging equipment and lubricant are required when
servicing your NISSAN climate control. Using
improper refrigerants or lubricants will cause
severe damage to your climate control system.
(See “Capacities and recommended lubricants”
in the “9. Technical and consumer information”
section for climate control system refrigerant
and lubricant recommendations.)
A NISSAN certified LEAF dealer will be able to
service your environmentally friendly climate
control system.
Page 18 of 1062
.Do not place metalized film or any
metal parts (antenna, etc.) on the
windows. This may cause poor re-
ception of the signals from the tire
pressure sensors, and the TPMS will
not function properly.
Some devices and transmitters may temporarily
interfere with the operation of the TPMS and
cause the low tire pressure warning light to
illuminate. Some examples are:
. Facilities or electric devices using similar
radio frequencies that are near the vehicle.
. If a transmitter set to similar frequencies is
being used in or near the vehicle.
. If a computer (or similar equipment) or a DC/
AC converter is being used in or near the
vehicle.
FCC Notice:
For USA:
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any interfer-
ence received, including interference that
may cause undesired operation. NOTE:
Changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s authority
to operate the equipment.
For Canada:
This device complies with RSS-210 of
Industry Canada. Operation is subject to
the following two conditions: (1) this
device may not cause interference, and
(2) this device must accept any interfer-
ence, including interference that may
cause undesired operation of the device.
TPMS with Easy Fill Tire Alert
When tire pressure is low, the low tire pressure
warning light illuminates.
This vehicle provides visual and audible signals
to help you inflate the tires to the recommended
COLD tire pressure.
Vehicle set-up:
1. Park the vehicle in a safe and level place.
2. Apply the parking brake and push the P
position switch on the selector lever.
3. Place the power switch in the ON position. Do not place in the READY to drive mode. Operation:
1. Add air to the tire.
2. After a few seconds, the hazard indicators
will start flashing.
3. When the designated pressure is reached, the horn beeps once and the hazard
indicators stop flashing.
4. Perform the above steps for each tire.
. If the tire is over-inflated more than approxi-
mately 4 psi (30 kPa), the horn beeps and
the hazard indicators flash 3 times. To
correct the pressure, push the core of the
valve stem on the tire briefly to release
pressure. When the pressure reaches the
designated pressure, the horn beeps once.
. If the hazard indicator does not flash within
approximately 15 seconds after starting to
inflate the tire, it indicates that the Easy Fill
Tire Alert is not operating.
. The TPMS will not activate the Easy Fill Tire
Alert under the following conditions:
— If there is interference from an external
device or transmitter.
— The air pressure from the inflation device is not sufficient to inflate the tire such as
those using a power socket.
Page 24 of 1062
Checking coolant level .......................................... 8-8
Cooling system.............................................................. 8-7
Corrosion protection .................................................... 7-7
Cruise control............................................................... 5-17
Cup holders.................................................................. 2-49
D
Defroster switch, Rear window and outside mirror
defroster switch........................................................... 2-40
Dimensions and weights............................................. 9-5
Dot matrix liquid crystal display............................... 2-22
Driving Cold weather driving........................................... 5-26
Driving vehicle....................................................... 5-11
Precautions when starting and driving .............. 5-2
Driving range.................................................................. 2-8
Driving vehicle.............................................................. 5-11
E
ECO indicator.............................................................. 2-10
Efficient use of your vehicle ................................. EV-22
Electric parking brake break-in................................ 5-23
Electric parking brake indicator light...................... 2-19
Electric power steering system ............................... 5-21
Emergency charge.................................................. CH-11
Emergency EV (Electric Vehicle) shut off...... 5-9, 6-2
Emergency shutoff system........................................ EV-9
Emission control information label............................ 9-7
EV Characteristics ..................................................... EV-9
EV system ..................................................................... EV-2
EV unique information............................................. EV-24
Event Data Recorder (EDR)..................................... 9-18
EVSE (Electric Vehicle Supply Equipment) ..... CH-11
EVSE (Electric Vehicle Supply
Equipment) cleaning..................................................... 7-6
F
F.M.V.S.S./C.M.V.S.S. certification label ................. 9-7
Flashers (See hazard warning flasher switch)..... 2-45
Flat tire............................................................................. 6-2
Flat towing .................................................................... 9-14
Floor mat cleaning ........................................................ 7-5
Fluid Brake fluid................................................................. 8-9
Capacities and recommended lubricants ......... 9-2
coolant ....................................................................... 8-7
Reduction gear fluid............................................... 8-9
Window washer fluid .......................................... 8-10
Fog light switch........................................................... 2-44
Front manual seat adjustment.................................... 1-3
Front passenger air bag and status light.............. 1-44
Front seat, Front seat adjustment............................. 1-3
Fuses.............................................................................. 8-16
Fusible links.................................................................. 8-17
G
Garage door open, HomeLink®Universal
Transceiver............................................................. 2-58
Gauge .............................................................................. 2-5 Driving range............................................................ 2-8
ECO indicator....................................................... 2-10
Li-ion battery available charge gauge................ 2-9
Li-ion battery capacity level gauge.................. 2-10
Li-ion battery temperature gauge........................ 2-7
Odometer.................................................................. 2-6
Power meter ............................................................. 2-7
Speedometer............................................................ 2-6
General maintenance ................................................... 8-2
Glove box...................................................................... 2-51
H
Hazard warning flasher switch................................. 2-45
Head restraints .............................................................. 1-4
Headlights Bulb replacement................................................. 8-21
Headlight Aiming Control ................................. 2-44
Headlight switch................................................... 2-41
Heated seats................................................................ 2-46
Heated steering wheel............................................... 2-45
High voltage precautions .......................................... EV-7
HomeLink
®universal transceiver............................. 2-58
Hood release................................................................ 3-16
Horn................................................................................ 2-46
How to normal charge.............................................. CH-9
How to quick charge.............................................. CH-16
How to trickle charge ............................................ CH-11
I
If the Li-ion battery becomes
completely discharged............................................... 6-12
Immediate charge.................................................... CH-24
Immobilizer system...................................................... 2-36
In-cabin microfilter ...................................................... 4-13
indicator Electric parking brake indicator light............... 2-19
Indicator lights.............................................................. 2-19
Indicators for operation.............................................. 2-23
Inside rearview mirror................................................. 3-20
Instrument brightness control .................................. 2-41
Instrument panel............................................................ 2-4
Intelligent Key system ......................................... 3-6, 5-7 Key operating range ............................................... 3-8
Key operation ........................................................ 3-10
Remote keyless operation.................................. 3-13
Page 26 of 1062
Parking brake mechanically release ....................... 6-16
PowerElectric power steering system ........................ 5-21
Power door lock...................................................... 3-4
Power windows .................................................... 2-53
Power economy........................................................... 5-19
Power meter ................................................................... 2-7
Power outlet ................................................................. 2-48
Power switch......................................................... 5-7, 5-8
Precautions Braking precautions............................................. 5-21
Charging................................................................ CH-2
Child restraints...................................................... 1-19
Cruise control........................................................ 5-17
High voltage precautions ................................... EV-7
Maintenance ............................................................. 8-4
Road accident precautions................................ EV-8
Seat belt usage .................................................... 1-10
Supplemental restraint system.......................... 1-36
When starting and driving .................................... 5-2
Push starting ................................................................ 6-12
Q
Quick charge............................................................ CH-16
R
Rapid air pressure loss................................................ 5-5
Rear center seat belt ................................................. 1-16
Rear door lock, Child safety rear door lock........... 3-6
Rear hatch..................................................................... 3-17
Rear seats....................................................................... 1-4
Rear window and outside mirror
defroster switch........................................................... 2-40
Rear window wiper and washer switch ............... 2-39
Reduction gear fluid..................................................... 8-9 Remote charge ........................................................ CH-25
Remote climate control.............................................. 4-11
Remote keyless entry function, For Intelligent
Key system.................................................................... 3-13
Repairing flat tire........................................................... 6-3
Repairing tire.................................................................. 6-5
Reporting safety defects........................................... 9-15
Road accident precautions....................................... EV-8
Roadside assistance program ................................... 6-2
Rollover............................................................................ 5-5
S
Safety Child seat belts .................................................... 1-17
Reporting safety defects.................................... 9-15
Scene guide At home after driving......................................... EV-21
Before driving your vehicle .............................. EV-13
Charging the Li-ion battery.............................. EV-10
Driving the vehicle.............................................. EV-17
Parking the vehicle............................................. EV-20
Starting your vehicle.......................................... EV-16
Seat adjustment Front manual seat adjustment.............................. 1-3
Front seats................................................................ 1-3
Seat belt(s) Child safety............................................................ 1-17
Infants...................................................................... 1-17
Injured persons..................................................... 1-12
Larger children...................................................... 1-18
Precautions on seat belt usage........................ 1-10
Pregnant women .................................................. 1-12
Rear center seat belt .......................................... 1-16
Seat belt cleaning................................................... 7-6
Seat belt extenders.............................................. 1-16
Seat belt hooks .................................................... 1-15 Seat belt maintenance........................................ 1-16
Seat belt warning light........................................ 2-18
Seat belts............................................................... 1-10
Seat belts with pretensioners........................... 1-49
Shoulder belt height adjustment...................... 1-15
Small children........................................................ 1-18
Three-point type................................................... 1-12
Seat(s) , Seats................................................................ 1-2 Heated seats......................................................... 2-46
Security system (NISSAN Vehicle Immobilizer
System) , EV system start.......................................... 2-36
Servicing climate control........................................... 4-14
Shifting Electric shift control system .............................. 5-11
Shoulder belt height adjustment, For
front seats..................................................................... 1-15
Soft bottle holders...................................................... 2-50
Solar cell module .......................................................... 7-3
Speedometer.................................................................. 2-6
Starting .......................................................................... 5-11 Before starting system........................................ 5-10
Jump starting............................................................ 6-9
Precautions when starting and driving .............. 5-2
Push starting ......................................................... 6-12
Status light, Front passenger air bag .................... 1-44
Steering Electric power steering system ........................ 5-21
Heated steering wheel........................................ 2-45
Tilting steering column........................................ 3-19
Stopping the vehicle .................................................... 6-4
Storage .......................................................................... 2-49
Stowing golf bags....................................................... 2-53
Sun visors ..................................................................... 3-20
Supplemental air bag warning labels..................... 1-50
Supplemental air bag warning light............ 1-50, 2-18
Supplemental restraint system................................. 1-36
Page 27 of 1062
Precautions on supplemental
restraint system..................................................... 1-36
Switch Autolight switch.................................................... 2-42
Fog light switch.................................................... 2-44
Hazard warning flasher switch.......................... 2-45
Headlight Aiming Control ................................. 2-44
Headlight switch................................................... 2-41
Power door lock switch......................................... 3-5
Rear window and outside mirror
defroster switch.................................................... 2-40
Turn signal switch ................................................ 2-44
Vehicle dynamic control (VDC) off switch..... 2-48
T
Telematics overview.................................................... 9-16
Temperature Li-ion battery temperature gauge........................ 2-7
Theft (NISSAN Vehicle Immobilizer System) ,
traction motor start ..................................................... 2-36
Tilt steering column .................................................... 3-19
Tire Low tire pressure warning light........................ 2-16
Tires Flat tire....................................................................... 6-2
Low tire pressure warning system...................... 5-2
Tire and Loading information label ......... 8-27, 9-8
Tire chains.............................................................. 8-31
Tire dressing............................................................. 7-4
Tire pressure ......................................................... 8-28
Tire pressure monitoring
system (TPMS) ............................................... 5-2, 6-2
Tire rotation............................................................ 8-32
Types of tires......................................................... 8-30
Uniform tire quality grading ............................... 9-14
Wheel/tire size......................................................... 9-5 Wheels and tires.................................................. 8-25
Tools............................................................................... 6-13
To p Tether strap child restraints............................... 1-22
Towing Flat towing ............................................................. 9-14
Tow truck towing.................................................. 6-13
Towing a trailer ..................................................... 9-13
TPMS, Tire pressure monitoring system................. 5-2
TPMS, Tire pressure warning system...................... 6-2
Traction motor Traction motor serial number ............................... 9-7
Trailer towing................................................................ 9-13
Transceiver, HomeLink
®Universal
Transceiver............................................................. 2-58
Transmitter, With Intelligent Key system
(See Intelligent Key system)..................................... 3-13
Trickle charge........................................................... CH-11
Trip computer............................................................... 2-27
Turn signal switch ....................................................... 2-44
Type of charge and how to charge the
Li-ion battery................................................................ CH-5
U
Underbody cleaning ..................................................... 7-3
Uniform tire quality grading ...................................... 9-14
Unplugged status.................................................... CH-25
V
Vanity mirror.................................................................. 3-22
Vehicle Dimensions and weights....................................... 9-5
Identification number (VIN)................................... 9-6
Loading information ............................................. 9-10
Recovery (freeing stuck vehicle) ...................... 6-15 Security system .................................................... 2-35
Vehicle dynamic control (VDC) off switch..... 2-48
Vehicle dynamic control (VDC) system.......... 5-24
Vehicle Dynamic Control (VDC)
warning light.......................................................... 2-19
Vehicle Dynamic Control (VDC) warning light .... 2-19
Vehicle security system ............................................. 2-35
Ventilators........................................................................ 4-2
W
Warning Hazard warning flasher switch.......................... 2-45
Indicators for operation....................................... 2-23
Tire pressure monitoring
system (TPMS) ............................................... 5-2, 6-2
Warning information displays............................ 2-31
Warning lights....................................................... 2-13
Warning/indicator lights and
audible reminders................................................. 2-12
Warning and indicator lights.................................... 0-10
Warning information displays................................... 2-31
Warning labels, Air bag warning labels................. 1-50
Warning light Air bag warning light................................ 1-50, 2-18
Anti-lock braking system (ABS)
warning light.......................................................... 2-14
BRAKE system warning light (yellow) ............ 2-14
BRAKE warning light (red) ................................ 2-15
Low tire pressure warning light........................ 2-16
Seat belt warning light........................................ 2-18
Vehicle Dynamic Control (VDC)
warning light.......................................................... 2-19
Washer switch Rear window wiper and washer switch ......... 2-39
Windshield wiper and washer switch............. 2-38
Washing........................................................................... 7-2
Index10-5
Page 72 of 1062
8 Maintenance and do-it-yourself
Maintenance requirement ....................................................... 8-2Scheduled maintenance ................................................... 8-2
General maintenance ........................................................ 8-2
Where to go for service ................................................... 8-2
General maintenance .............................................................. 8-2 Explanation of maintenance items ................................. 8-2
Maintenance precautions ....................................................... 8-4
Motor compartment check locations .................................. 8-6
Cooling system ......................................................................... 8-7 Checking coolant level ..................................................... 8-8
Changing coolant ............................................................... 8-8
Reduction gear fluid ................................................................ 8-9
Brake fluid .................................................................................. 8-9
Window washer fluid ........................................................... 8-10
12-volt battery ........................................................................ 8-11 Jump starting .................................................................... 8-12
Windshield wiper blades .................................................... 8-12 Cleaning ............................................................................ 8-12
Replacing .......................................................................... 8-12 Rear window wiper blade .................................................. 8-15
Brakes ..................................................................................... 8-15
Brake pad wear warning ............................................. 8-15
Fuses ....................................................................................... 8-16 Motor compartment ...................................................... 8-16
Passenger compartment ............................................. 8-17
Intelligent Key battery replacement .................................. 8-18
Lights ....................................................................................... 8-20 Headlights ....................................................................... 8-21Exterior and interior lights ........................................... 8-22
Wheels and tires .................................................................. 8-25 Tire pressure .................................................................. 8-25
Tire labeling .................................................................... 8-28
Types of tires .................................................................. 8-30
Tire chains ...................................................................... 8-31
Changing wheels and tires ......................................... 8-32
Emergency tire puncture repair kit ........................... 8-34
Page 74 of 1062
TIRE EQUIPMENT
SUMMER tires have a tread designed to provide
superior performance on dry pavement. How-
ever, the performance of these tires will be
substantially reduced in snowy and icy condi-
tions. If you operate your vehicle on snowy or icy
roads, NISSAN recommends the use of MUD &
SNOW or ALL SEASON tires on all four wheels.
Consult a NISSAN certified LEAF dealer for the
tire type, size, speed rating and availability
information.
For additional traction on icy roads, studded
tires may be used. However, some U.S. states
and Canadian provinces prohibit their use.
Check local, state and provincial laws before
installing studded tires.
Skid and traction capabilities of studded
snow tires, on wet or dry surfaces, may be
poorer than that of non-studded snow
tires.
Tire chains may be used. For details, see “Tire
chains” in the “8. Maintenance and do-it-
yourself” section.
SPECIAL WINTER EQUIPMENT
It is recommended that the following items be
carried in the vehicle during winter:
.A scraper and stiff-bristled brush to remove
ice and snow from the windows and wiper
blades.
. A shovel to dig the vehicle out of snow-
drifts.
. Extra window washer fluid to refill the
reservoir tank.
DRIVING ON SNOW OR ICE
Page 127 of 1062
Checking coolant level .......................................... 8-8
Cooling system.............................................................. 8-7
Corrosion protection .................................................... 7-7
Cruise control............................................................... 5-17
Cup holders.................................................................. 2-49
D
Defroster switch, Rear window and outside mirror
defroster switch........................................................... 2-40
Dimensions and weights............................................. 9-5
Dot matrix liquid crystal display............................... 2-22
Driving Cold weather driving........................................... 5-26
Driving vehicle....................................................... 5-11
Precautions when starting and driving .............. 5-2
Driving range.................................................................. 2-8
Driving vehicle.............................................................. 5-11
E
ECO indicator.............................................................. 2-10
Efficient use of your vehicle ................................. EV-22
Electric parking brake break-in................................ 5-23
Electric parking brake indicator light...................... 2-19
Electric power steering system ............................... 5-21
Emergency charge.................................................. CH-11
Emergency EV (Electric Vehicle) shut off...... 5-9, 6-2
Emergency shutoff system........................................ EV-9
Emission control information label............................ 9-7
EV Characteristics ..................................................... EV-9
EV system ..................................................................... EV-2
EV unique information............................................. EV-24
Event Data Recorder (EDR)..................................... 9-18
EVSE (Electric Vehicle Supply Equipment) ..... CH-11
EVSE (Electric Vehicle Supply
Equipment) cleaning..................................................... 7-6
F
F.M.V.S.S./C.M.V.S.S. certification label ................. 9-7
Flashers (See hazard warning flasher switch)..... 2-45
Flat tire............................................................................. 6-2
Flat towing .................................................................... 9-14
Floor mat cleaning ........................................................ 7-5
Fluid Brake fluid................................................................. 8-9
Capacities and recommended lubricants ......... 9-2
coolant ....................................................................... 8-7
Reduction gear fluid............................................... 8-9
Window washer fluid .......................................... 8-10
Fog light switch........................................................... 2-44
Front manual seat adjustment.................................... 1-3
Front passenger air bag and status light.............. 1-44
Front seat, Front seat adjustment............................. 1-3
Fuses.............................................................................. 8-16
Fusible links.................................................................. 8-17
G
Garage door open, HomeLink®Universal
Transceiver............................................................. 2-58
Gauge .............................................................................. 2-5 Driving range............................................................ 2-8
ECO indicator....................................................... 2-10
Li-ion battery available charge gauge................ 2-9
Li-ion battery capacity level gauge.................. 2-10
Li-ion battery temperature gauge........................ 2-7
Odometer.................................................................. 2-6
Power meter ............................................................. 2-7
Speedometer............................................................ 2-6
General maintenance ................................................... 8-2
Glove box...................................................................... 2-51
H
Hazard warning flasher switch................................. 2-45
Head restraints .............................................................. 1-4
Headlights Bulb replacement................................................. 8-21
Headlight Aiming Control ................................. 2-44
Headlight switch................................................... 2-41
Heated seats................................................................ 2-46
Heated steering wheel............................................... 2-45
High voltage precautions .......................................... EV-7
HomeLink
®universal transceiver............................. 2-58
Hood release................................................................ 3-16
Horn................................................................................ 2-46
How to normal charge.............................................. CH-9
How to quick charge.............................................. CH-16
How to trickle charge ............................................ CH-11
I
If the Li-ion battery becomes
completely discharged............................................... 6-12
Immediate charge.................................................... CH-24
Immobilizer system...................................................... 2-36
In-cabin microfilter ...................................................... 4-13
indicator Electric parking brake indicator light............... 2-19
Indicator lights.............................................................. 2-19
Indicators for operation.............................................. 2-23
Inside rearview mirror................................................. 3-20
Instrument brightness control .................................. 2-41
Instrument panel............................................................ 2-4
Intelligent Key system ......................................... 3-6, 5-7 Key operating range ............................................... 3-8
Key operation ........................................................ 3-10
Remote keyless operation.................................. 3-13
Page 129 of 1062
Parking brake mechanically release ....................... 6-16
PowerElectric power steering system ........................ 5-21
Power door lock...................................................... 3-4
Power windows .................................................... 2-53
Power economy........................................................... 5-19
Power meter ................................................................... 2-7
Power outlet ................................................................. 2-48
Power switch......................................................... 5-7, 5-8
Precautions Braking precautions............................................. 5-21
Charging................................................................ CH-2
Child restraints...................................................... 1-19
Cruise control........................................................ 5-17
High voltage precautions ................................... EV-7
Maintenance ............................................................. 8-4
Road accident precautions................................ EV-8
Seat belt usage .................................................... 1-10
Supplemental restraint system.......................... 1-36
When starting and driving .................................... 5-2
Push starting ................................................................ 6-12
Q
Quick charge............................................................ CH-16
R
Rapid air pressure loss................................................ 5-5
Rear center seat belt ................................................. 1-16
Rear door lock, Child safety rear door lock........... 3-6
Rear hatch..................................................................... 3-17
Rear seats....................................................................... 1-4
Rear window and outside mirror
defroster switch........................................................... 2-40
Rear window wiper and washer switch ............... 2-39
Reduction gear fluid..................................................... 8-9 Remote charge ........................................................ CH-25
Remote climate control.............................................. 4-11
Remote keyless entry function, For Intelligent
Key system.................................................................... 3-13
Repairing flat tire........................................................... 6-3
Repairing tire.................................................................. 6-5
Reporting safety defects........................................... 9-15
Road accident precautions....................................... EV-8
Roadside assistance program ................................... 6-2
Rollover............................................................................ 5-5
S
Safety Child seat belts .................................................... 1-17
Reporting safety defects.................................... 9-15
Scene guide At home after driving......................................... EV-21
Before driving your vehicle .............................. EV-13
Charging the Li-ion battery.............................. EV-10
Driving the vehicle.............................................. EV-17
Parking the vehicle............................................. EV-20
Starting your vehicle.......................................... EV-16
Seat adjustment Front manual seat adjustment.............................. 1-3
Front seats................................................................ 1-3
Seat belt(s) Child safety............................................................ 1-17
Infants...................................................................... 1-17
Injured persons..................................................... 1-12
Larger children...................................................... 1-18
Precautions on seat belt usage........................ 1-10
Pregnant women .................................................. 1-12
Rear center seat belt .......................................... 1-16
Seat belt cleaning................................................... 7-6
Seat belt extenders.............................................. 1-16
Seat belt hooks .................................................... 1-15 Seat belt maintenance........................................ 1-16
Seat belt warning light........................................ 2-18
Seat belts............................................................... 1-10
Seat belts with pretensioners........................... 1-49
Shoulder belt height adjustment...................... 1-15
Small children........................................................ 1-18
Three-point type................................................... 1-12
Seat(s) , Seats................................................................ 1-2 Heated seats......................................................... 2-46
Security system (NISSAN Vehicle Immobilizer
System) , EV system start.......................................... 2-36
Servicing climate control........................................... 4-14
Shifting Electric shift control system .............................. 5-11
Shoulder belt height adjustment, For
front seats..................................................................... 1-15
Soft bottle holders...................................................... 2-50
Solar cell module .......................................................... 7-3
Speedometer.................................................................. 2-6
Starting .......................................................................... 5-11 Before starting system........................................ 5-10
Jump starting............................................................ 6-9
Precautions when starting and driving .............. 5-2
Push starting ......................................................... 6-12
Status light, Front passenger air bag .................... 1-44
Steering Electric power steering system ........................ 5-21
Heated steering wheel........................................ 2-45
Tilting steering column........................................ 3-19
Stopping the vehicle .................................................... 6-4
Storage .......................................................................... 2-49
Stowing golf bags....................................................... 2-53
Sun visors ..................................................................... 3-20
Supplemental air bag warning labels..................... 1-50
Supplemental air bag warning light............ 1-50, 2-18
Supplemental restraint system................................. 1-36
Page 130 of 1062
Precautions on supplemental
restraint system..................................................... 1-36
Switch Autolight switch.................................................... 2-42
Fog light switch.................................................... 2-44
Hazard warning flasher switch.......................... 2-45
Headlight Aiming Control ................................. 2-44
Headlight switch................................................... 2-41
Power door lock switch......................................... 3-5
Rear window and outside mirror
defroster switch.................................................... 2-40
Turn signal switch ................................................ 2-44
Vehicle dynamic control (VDC) off switch..... 2-48
T
Telematics overview.................................................... 9-16
Temperature Li-ion battery temperature gauge........................ 2-7
Theft (NISSAN Vehicle Immobilizer System) ,
traction motor start ..................................................... 2-36
Tilt steering column .................................................... 3-19
Tire Low tire pressure warning light........................ 2-16
Tires Flat tire....................................................................... 6-2
Low tire pressure warning system...................... 5-2
Tire and Loading information label ......... 8-27, 9-8
Tire chains.............................................................. 8-31
Tire dressing............................................................. 7-4
Tire pressure ......................................................... 8-28
Tire pressure monitoring
system (TPMS) ............................................... 5-2, 6-2
Tire rotation............................................................ 8-32
Types of tires......................................................... 8-30
Uniform tire quality grading ............................... 9-14
Wheel/tire size......................................................... 9-5 Wheels and tires.................................................. 8-25
Tools............................................................................... 6-13
To p Tether strap child restraints............................... 1-22
Towing Flat towing ............................................................. 9-14
Tow truck towing.................................................. 6-13
Towing a trailer ..................................................... 9-13
TPMS, Tire pressure monitoring system................. 5-2
TPMS, Tire pressure warning system...................... 6-2
Traction motor Traction motor serial number ............................... 9-7
Trailer towing................................................................ 9-13
Transceiver, HomeLink
®Universal
Transceiver............................................................. 2-58
Transmitter, With Intelligent Key system
(See Intelligent Key system)..................................... 3-13
Trickle charge........................................................... CH-11
Trip computer............................................................... 2-27
Turn signal switch ....................................................... 2-44
Type of charge and how to charge the
Li-ion battery................................................................ CH-5
U
Underbody cleaning ..................................................... 7-3
Uniform tire quality grading ...................................... 9-14
Unplugged status.................................................... CH-25
V
Vanity mirror.................................................................. 3-22
Vehicle Dimensions and weights....................................... 9-5
Identification number (VIN)................................... 9-6
Loading information ............................................. 9-10
Recovery (freeing stuck vehicle) ...................... 6-15 Security system .................................................... 2-35
Vehicle dynamic control (VDC) off switch..... 2-48
Vehicle dynamic control (VDC) system.......... 5-24
Vehicle Dynamic Control (VDC)
warning light.......................................................... 2-19
Vehicle Dynamic Control (VDC) warning light .... 2-19
Vehicle security system ............................................. 2-35
Ventilators........................................................................ 4-2
W
Warning Hazard warning flasher switch.......................... 2-45
Indicators for operation....................................... 2-23
Tire pressure monitoring
system (TPMS) ............................................... 5-2, 6-2
Warning information displays............................ 2-31
Warning lights....................................................... 2-13
Warning/indicator lights and
audible reminders................................................. 2-12
Warning and indicator lights.................................... 0-10
Warning information displays................................... 2-31
Warning labels, Air bag warning labels................. 1-50
Warning light Air bag warning light................................ 1-50, 2-18
Anti-lock braking system (ABS)
warning light.......................................................... 2-14
BRAKE system warning light (yellow) ............ 2-14
BRAKE warning light (red) ................................ 2-15
Low tire pressure warning light........................ 2-16
Seat belt warning light........................................ 2-18
Vehicle Dynamic Control (VDC)
warning light.......................................................... 2-19
Washer switch Rear window wiper and washer switch ......... 2-39
Windshield wiper and washer switch............. 2-38
Washing........................................................................... 7-2
Index10-5
