SETTING FREEWAY ENTRANCE/
EXIT
GUID-4515EF2C-9776-443B-97E6-E670C645B162It is possible to set the destination to an
entrance or exit of a freeway and have the
system calculate a route.
1. Push theMENUbutton and touch [Destina-
tion].
2. Touch [Next Page].
3. Touch [Freeway Entrance/Exit]. A character input screen is displayed.
LNE0080X
4. Enter the name of the freeway. After finishingthe entry, touch [List].
LNE0081X
5. Touch the freeway of the destination fromthe list.
LNE0082X
6. Touch [Entrance] or [Exit]. A list screen isdisplayed.
LNE0083X
7. Select the preferred destination from the list.The position of the selected location is
displayed in the preview on the right side
of the screen.
INFO:
Select [By Distance] to sort the list by the
nearest distance.
LNE0084X
8. The selected destination is displayed at the center of the map. Touch [Start] after
confirming the location of the displayed
Navigation3-35
Condition: NAM/

Black plate (88,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
3-36Navigation
destination. The system sets the destination
to the selected location and starts calculat-
ing a route.
INFO:
After setting a destination, the location of the
destination can be adjusted and the location can
be stored in the Address Book, etc.
“Operations after setting destination”
(page 3-36)
SETTING POINT ON MAPGUID-1CECA297-8DF7-4E58-9746-C408EB3A9FBDIt is possible to set a location scrolled to on the
map as the destination and have the system
calculate a route.
LNE0096X
1. Scroll the map, place the cross pointer over the preferred location, and touch [Map
Menu].
INFO:
.The map scale should be adjusted tosearch for a location more effectively.
.The point on the blinking road where thecenter of the cross pointer is located can
be set as a destination.
LNE0097X
2. Touch [New Dest.].
LNE0098X
3. The entire route is shown on the map. Touch [Start] after confirming the displayed route.
The system starts route guidance to the
selected destination.
INFO:
LNE0099X
.If a point on a freeway is set as the
destination, a confirmation message is dis-
played.
. Before starting route guidance, the route
condition can be changed and the route can
be stored in the Address Book, etc.
“Procedures after setting route”
(page 3-39)
OPERATIONS AFTER SETTING
DESTINATION
GUID-0BFBBD22-47CC-4CEB-8876-3CE84AFA02AAThe following operations are available after you
set a destination.
Condition: NAM/

Black plate (89,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
LNE0100X
Available items after setting destination
.[Start]:
Starts route guidance to the selected
destination.
“Starting route guidance” (page 3-37)
. [Route Details]:
Allows you to change the route search
conditions or to check the route information.
“Procedures after setting route”
(page 3-39)
. [Move Location]:
Displays a map screen. The location of the
destination can be adjusted.
“Moving location of destination”
(page 3-37)
. [Add to Route]:
Edits the route by adding a waypoint or a
destination.
“Adding additional destinations to a
route” (page 3-37) .
[Store Location]:
Stores the location in the Address Book.
“Storing location” (page 3-38)
. [Details]:
Displays information about the facility that
has been set as the destination, if it is
included in the map data.
“Viewing information about searched
location” (page 3-38)
Starting route guidanceGUID-D297E553-8059-4E30-B335-74138C3A09D9
LNE0101X
1. Touch [Start]. Route guidance starts. If the
route is already set, the location becomes
the new destination, and the route is
recalculated.
Moving location of destinationGUID-C2CECEB6-9A5F-45F2-B506-35ACD13501D4The location of the destination can be adjusted
by moving the cross pointer across the map.
LNE0108X
1. Touch [Move Location]. A map screen withthe destination located on the map center is
displayed.
2. Adjust the location by moving the cross pointer across the map and touch [OK]. The
location of the destination is modified.
INFO:
. The screen for adjusting the location also
changes when the map screen displayed on
the right side of the screen is touched.
. The map scale can be changed by touching
[ZOOM OUT] or [ZOOM IN].
Adding additional destinations to a
route
GUID-58148779-7ACA-421A-808E-CA2DBAA47C2BEven after the route is already set, you can add a
searched location as a new destination or
waypoint to that route.
If the route has not been set, [Add to Route]
Navigation3-37
Condition: NAM/

Black plate (90,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
3-38Navigation
cannot be selected.
LNE0109X
1. Touch [Add to Route].
2. Touch [Add Destination] or [Add Waypoint].The system starts calculating a route that
includes the added destination or waypoint.
When the calculation is finished, the route is
displayed.
Storing locationGUID-BC2D5B61-3800-40DA-8E7D-15B144C39062A searched location can be stored in the
Address Book. Then it can be easily retrieved
and set as a destination (or waypoint).
LNE0110X
1.Touch [Store Location]. A message is
displayed, the location is stored in the
Address Book. The corresponding icon is
displayed at the set location on the map.
Viewing information about searched
location
GUID-AC162096-1CF4-4FB0-874A-A7FEE3CD1848Information (street address and phone number)
about points of interest stored in the map data
can be displayed.
LNE0111X
1. Touch [Details]. Information about the loca-
tion is displayed.
2. Touch the item you would like to set. Available settings
.[Show Map]:Returns to the previous screen.
.[Call]:
Makes a call to the selected charging
station. A cellular phone needs to be
connected beforehand.
“Connecting cellular phone”
(page 1-13)
.[Details]:This appears only when a charging
station is set as a destination. Displays
detailed information including the type
and number of charging devices existing
at the selected charging station.
INFO:
Information about locations is not displayed
while driving.
Condition: NAM/

Black plate (91,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
GUID-FD38A9D2-BD38-4915-90E1-EFF73D4DAEA9
PROCEDURES AFTER SETTING
ROUTE
GUID-E83C964B-BC32-48FB-AF85-60942AFE2170After performing a route search, route guidance
can be started. Also, it is possible to confirm or
change a route.
LNE0102X
1. Touch [Route Details].
2. Touch the item you would like to set.
Available items after setting route
.[Start]:
Starts route guidance to the selected
destination.
“Starting route guidance” (page 3-39)
. [More Routes]:
Displays 3 alternative routes.
“Changing route condition”
(page 3-39)
. [Route Info]:
Displays the route information. A calculated
route can also be stored in the Address Book.
“Confirming route” (page 3-40)
. [Add Way Pt.]:
Allows you to edit the route by adding a
destination or waypoint.
“Adding destination or waypoint”
(page 3-41)
Starting route guidanceGUID-1EF85A2A-776D-4337-A8E2-61492E7591D6
LNE0102X
1. Touch [Start]. Route guidance starts.
INFO:
If no operations have been performed on the
system for several seconds, [Start] is automati-
cally selected, and the system starts route
guidance. When the vehicle is being driven,
[Start] is automatically selected and the system
will start the route guidance function.
Changing route conditionGUID-9AD893FA-42BC-4477-9A9F-DD22625256AA1. Touch [More Routes].
LNE0906X
2. Touch the preferred route condition. When the route is selected, a preview is displayed
on the right side of the screen. After
selecting the route condition, touch [OK].
Available route conditions
.[ECO] (green):
Prioritizes the least amount of electrical
consumption.
.[Short. Time] (purple):Prioritizes the shortest time.
.[Min. Freeway] (orange):Minimizes the use of freeways.
.[Short. Dist.] (pink):Prioritizes the shortest distance.
Navigation3-39
ROUTE GUIDANCE
Condition: NAM/

Black plate (92,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
3-40Navigation
INFO:
.The 4 routes may not always be different..When using waypoints, [More Routes] isdisabled. After route guidance is started,
change the route between each way-
point.
“Editing route” (page 3-48)
3. Touch [OK].
INFO:
LNE0928X
The remaining battery power estimation function
cannot be used to confirm condition changes
that arise after driving starts. Utilize the function
as a reference when selecting driving routes.
. After starting to drive, refer to the driving
range on the meter and perform battery
charging allowing for some leeway. .
The remaining battery power estimation
function cannot be used confirm condition
changes that arise after driving starts. Utilize
the function as a reference when selecting
driving routes.
. In the following instances, the actual battery
power may differ from the remaining battery
power estimation.
— Frequent repetition of sudden accelera-
tion and sudden braking
— Change of air conditioner operating conditions
— Change of traffic conditions and driving routes that differ from the one used for
the estimation
— Strong wind, cold, and snow weather conditions
— Tires that do not comply with specifica- tions, low air pressure tires, worn tires,
studless tires, and others.
— Decreased capacity of the Li-ion battery
— Installation of equipment that does not comply with specifications (carriers and
others)
Confirming routeGUID-29CA1EE4-BF66-428E-8EEA-11FCA02818BA1. Touch [Route Info].
LNE0104X
2. Touch the preferred information item.
Available information
. [Turn List]:
Displays the details of the suggested route.
“Using turn list” (page 3-52)
. [Store Route]:
Stores a calculated route. A maximum of 5
routes can be stored. Stored routes can be
easily retrieved and set as the suggested
route. If no waypoints are set on the route,
the route cannot be stored.
“Storing route” (page 3-60)
. [Map Scroll]:
Displays a map screen where the location of
the destination can be confirmed.
Condition: NAM/

Black plate (93,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
INFO:
The stored route includes only locations (desti-
nation and waypoints) and route calculation
conditions, not the route itself. Therefore, when
the destination is set using a stored route, a
different route may be suggested if the current
vehicle location is different from the one when
the route was stored.
Adding destination or waypointGUID-64FE064C-91B6-4DF2-9502-FFC30B666095Before starting route guidance, destinations
and/or waypoints can be added. A total of 6
destinations or waypoints can be set.
1. Touch [Add Way Pt.].
LNE0105X
2. Set additional destinations or waypoints. The method of searching for a location is the
same as the one for a destination.
“Setting destination” (page 3-17)
LNE0244X
3. Touch [Add to Route].
LNE0106X
4. Touch [Add Destination] or [Add Waypoint].
LNE0107X
5. The system starts calculating a route thatincludes the added destination or waypoint.
When the calculation is finished, the route is
displayed.
INFO:
.If a waypoint was added, [More Routes]cannot be selected.
.If a destination was added, the priordestination becomes a waypoint.
ABOUT ROUTE GUIDANCEGUID-FD5538DC-DAD3-4D25-9388-EEEB98B01107After setting the route, select [Start] to begin
route guidance.
Throughout route guidance, the system navi-
gates you through the guide points using visual
and voice guidance.
CAUTION
. The navigation system’s visual and
voice guidance is for reference pur-
poses only. The contents of the
guidance may be inappropriate de-
pending on the situation.
. Follow all traffic regulations when
driving along the suggested route
(e.g., one-way traffic) .
Navigation3-41
Condition: NAM/

Black plate (94,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
3-42Navigation
“Route guidance” (page 10-34)
Voice guidance during route gui-
dance
GUID-B9542D5E-9818-4B43-8BA0-4E1F33E37BDBWhen approaching a guide point (intersection or
corner) , destination, etc. during route guidance,
voice guidance announces the remaining dis-
tance and/or turning direction. Push and hold
theVOICE button to repeat voice guidance.
INI0119
Example of voice guidance:
*1"In about one quarter mile (400 meters) , right
(left) turn." "Right (left) turn ahead."*2"In about one quarter mile (400 meters) freeway
entrance on your right onto (road number anddirection) ."
"Freeway entrance on your right onto (road
number and direction) ."
*3"In about one mile (2 kilometers) , exit on your
right."
"Exit on your right."
*4"You have arrived at your destination. Ending
route the guidance."
Guidance screens and preview
mode
GUID-1EC15C97-38ED-4C88-9336-8B6A6573F8DERoute guidance displays map screens and
various information according to the situation.
LNE0112X
Condition: NAM/

Black plate (95,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
Enlarged intersection view:
LNE0113X
When approaching a guide point, the system
automatically changes to the split screen and
shows an enlarged view of the intersection on
the left screen. To switch to the full screen mode
while the enlarged intersection view is dis-
played, push theMAPbutton. Pushing the
MAP button again displays the enlarged inter-
section view. Junction guidance:
LNE0114X
While driving on a freeway, when the vehicle is
approximately 1 mile (approximately 2 km) from a
junction, the system automatically switches to
the split screen and displays an enlarged view of
the junction on the left screen. After passing the
junction, the system automatically returns to the
full screen mode. To switch to the full screen
mode while the enlarged junction view is
displayed, push the
MAPbutton. Pushing the
MAP button again displays the enlarged junc-
tion view. Turn list:
LNE0115X
Depending on the setting, the system can
constantly display the split screen and show
the turn list on the left screen. When approach-
ing a guide point, the left screen automatically
switches to an enlarged view of the intersection.
To switch to the full screen mode, push the
MAP
button. Pushing the MAPbutton again
displays the turn list.
GUIDANCE SCREEN SETTINGSGUID-42B56FA1-7B98-44F1-BC40-014EF5BDBC53The guidance screen can be displayed at all
times even when the vehicle is located away
from the guide point. Various types of screens
can be set.
Split screen settingsGUID-6FFF7521-6286-4DF6-884B-0E9101ECFB85The display setting on the left-hand side screen
shown during route guidance can be changed.
Navigation3-43
Condition: NAM/

Black plate (96,1)
[ Edit: 2013/ 10/ 7 Model: Navi-EV ]
3-44Navigation
1. Touch [Map Menu] while the current locationmap screen is displayed.
LNE0930X
2. Touch [Map View].
LNE0931X
3. Touch [View Settings].
4. Touch the preferred screen. The indicator of
the selected screen illuminates.
. Intersection
LNE0932X
The map screen and the enlarged intersection
view can be displayed at the same time.
Push the MAPbutton to switch to the full map
screen.
. Turn list
LNE0119X
The list screen for showing the guide points to
the destination and the map screen can be
displayed at the same time. An enlarged
intersection view is automatically displayed
when the vehicle approaches the guide point.
The turn list can be scrolled by touching [
] or [
] on the screen.
Push the MAPbutton to switch to the full map
screen. Push the MAPbutton again to display
the turn list.
. Full map
LNE0120X
The current location map is displayed. An
enlarged intersection view is automatically dis-
played when the vehicle approaches the guide
point.
When an enlarged intersection view is dis-
played, pushing the MAPbutton returns to the
map screen.
Show exit information on freewaysGUID-B9EFEE0B-9D82-4FCA-8BED-AEEC5111CA62When the vehicle travels on a highway or a toll
road, the display automatically provides exit
information in the turn list.
1. Touch [Map Menu] while the current location map screen is displayed.
Condition: NAM/
