Check the brake booster function as follows:
1. With the engine off, press and release the
brake pedal several times. When brake
pedal movement (distance of travel) re-
mains the same from one pedal application
to the next, continue on to the next step.
2. While depressing the brake pedal, start the
engine. The pedal height should drop a
little.
3. With the brake pedal depressed, stop the
engine. Keeping the pedal depressed for
about 30 seconds, the pedal height should
not change.
4. Run the engine for one minute without
depressing the brake pedal, then turn it off.
Depress the brake pedal several times. The
pedal travel distance will decrease gradu-
ally with each depression as the vacuum is
released from the booster.
If the brakes do not operate properly, see your
NISSAN dealer.Press the pedal by hand and be sure the free
travel is within the limits shown above. If free
travel is too little or too much, see your NIS-
SAN dealer.
Engine compartment
Never use a fuse of higher amperage
rating than that specified on the fuse
box cover. This could damage the elec-
trical system or cause a fire.
If any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition key and headlight
switch are ªOFFº.
DI1021MCSDI0126
BRAKE BOOSTER CLUTCH PEDAL FUSES
7-21
Z01.2.1/A32-DX

2. Open the engine hood.
3. Remove the fusible link cover.
4. Remove the fuse with the fuse puller.
5. If the fuse is open, replace it with a new
fuse.
6. If a new fuse also opens, have the electrical
system checked and repaired by your NIS-
SAN dealer.
Passenger compartment
Never use a fuse of higher amperage
rating than that specified on the fuse
box cover. This could damage the elec-
trical system or cause a fire.
If any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition key and the headlight
switch are ªOFFº.2. Pull to open the fuse box lid.
3. Remove the fuse with the fuse puller.
4. If the fuse is open, replace it with a new
fuse.
5. If a new fuse also opens, have the electrical
system checked and repaired by your
NISSAN dealer.
SDI0335
7-22
Z01.2.1/A32-DX

If any electrical equipment does not operate
and fuses are in good condition, check the
fusible links. If any of these fusible links are
melted, replace only with genuine NISSAN
parts.
HEADLIGHTS
The headlight is a semi-sealed beam type
which uses a replaceable headlight (halogen)
bulb. A bulb can be replaced from inside the
engine compartment without removing the
headlight assembly.
High pressure halogen gas is sealed
inside the halogen bulb. The bulb may
break if the glass envelope is scratched
or the bulb is dropped.
Hold the plastic base when handling the
bulb. Never touch the glass envelope.
Removing the headlight bulb
1. Disconnect the battery negative cable.
2. Disconnect the electrical connector from
the rear end of the bulb.
3. Turn the bulb retaining ring counterclock-
wise until it is free from the headlight reflec-
tor, then remove it.
4. Remove the headlight bulb. Do not shake
or rotate the bulb when removing it.
SDI0128
SDI0129
FUSIBLE LINKS LIGHT BULBS
7-23
Z01.2.1/A32-DX

During the normal day-to-day operation of the
vehicle, general maintenance should be per-
formed regularly as prescribed in this section.
If you detect any unusual sounds, vibrations or
smell, be sure to check for the cause or have
your NISSAN dealer do it promptly. In addition,
you should notify your NISSAN dealer if you
think that repairs are required.
When performing any checks or maintenance
work, closely observe the precautions in the
ªDo-it-yourself operationsº section.
Additional information on the following
items with ª*º is found in the ªDo-it-
yourself operationsº section.
OUTSIDE THE VEHICLE
The maintenance items listed here should be
performed from time to time, unless otherwise
specified.
Tires*Check the pressure with a gauge peri-
odically when at a service station, including the
spare, and adjust to the specified pressure if
necessary. Check carefully for damage, cuts
or excessive wear.
Wheel nuts*When checking the tires, make
sure no nuts are missing, and check for any
loose nuts. Tighten if necessary.
Tire rotation*Tires should be rotated every7,500 miles (12,000 km).
Wheel alignment and balanceIf the vehicle
pulls to either side while driving on a straight
and level road, or if you detect uneven or
abnormal tire wear, there may be a need for
wheel alignment.
If the steering wheel or seat vibrates at normal
highway speeds, wheel balancing may be
needed.
Windshield wiper blades*Check for cracks
or wear if they do not wipe properly.
Doors and engine hoodCheck that all doors
and the engine hood operate smoothly as well
as the trunk lid or back hatch. Also make sure
that all latches lock securely. Lubricate if nec-
essary. Make sure that the secondary latch
keeps the hood from opening when the pri-
mary latch is released.
When driving in areas using road salt or other
corrosive materials, check lubrication fre-
quently.
INSIDE THE VEHICLE
The maintenance items listed here should be
checked on a regular basis, such as when
performing periodic maintenance, cleaning the
vehicle, etc.
Lights*Make sure that the headlights, stop
lights, tail lights, turn signal lights, and other
lights are all operating properly and installed
securely. Also check headlight aim.
Warning lights and buzzers/chimesMake
sure that all warning lights and buzzers/chimes
are operating properly.
Windshield wiper and washer*Check that
the wipers and washer operate properly and
that the wipers do not streak.
Windshield defrosterCheck that the air
comes out of the defroster outlets properly and
in good quantity when operating the heater or
air conditioner.
Steering wheelCheck that it has the specified
play. Be sure to check for changes in the
steering conditions, such as excessive play,
hard steering or strange noises.
SeatsCheck seat position controls such as
seat adjusters, seatback recliner, etc. to make
sure they operate smoothly and that all latches
lock securely in every position. Check that the
GENERAL MAINTENANCE
8-3
Z01.2.1/A32-DX

to the engine. If any of the above symptoms
are encountered, have your vehicle checked at
a NISSAN dealer or other competent service
facility.
However, now and then you may notice
light spark knock for a short time while
accelerating or driving up hills. This is no
cause for concern, because you get the
greatest fuel benefit when there is light
spark knock for a short time under heavy
engine load.
ENGINE OIL AND OIL FILTER
RECOMMENDATION
Selecting the correct oil
It is essential to choose the correct quality, and
viscosity oil to ensure satisfactory engine life
and performance. Nissan recommends the
use of a low friction oil (energy conserving oil)
in order to improve fuel economy and con-
serve energy. Oils which do not have the
specified quality label should not be used as
they could cause engine damage.
Only those engine oils with the American Pe-
troleum Institute (API) CERTIFICATIONMARK on the front of the container should be
used. This type of oil supersedes the existing
API SG or SH and Energy Conserving II
categories.
If you cannot find engine oil with the CERTI-
FICATION MARK, an API SG or SH and
Energy Conserving II oil with API Service
Symbol may be used. An oil with a single
designation ªSGº or ªSHº, or in combination
with other categories (for example, ªSG/CCº or
ªSG/CDº) may also be used if one with the API
CERTIFICATION MARK cannot be found.
Mineral based or synthetic type oils may be
used in your NISSAN vehicle. These oils must
STI0077
9-4
Z01.2.1/A32-DX

10 Index
A
Air bag system (See ªSupplemental restraint
systemº) .......................................................... 2-17
Air bag warning light (See ªSupplemental air bag
warning lightº) ................................................. 2-22
Air cleaner filter ............................................... 7-17
Air conditioner
Air conditioner operation ............................. 3-5
Air conditioner specification label.............. 9-12
Automatic air conditioner (If so equipped) .. 3-9
Air conditioning system refrigerant and lubricant
recommendations ............................................. 9-6
Air flow chart ..................................................... 3-6
Antenna........................................................... 3-28
Anti-lock brake system (ABS) (If so equipped) .. 4-
18
Audio main operation ...................................... 3-23
Automatic
Automatic air conditioner (If so equipped) .. 3-9
Automatic transmission fluid ..................... 7-10
Driving with automatic transmission............ 4-7
Avoiding collision and rollover .......................... 4-3
B
Battery............................................................. 7-13
Battery replacement.......................................... 2-7
Before starting the engine ................................ 4-6Brake
Anti-lock brake system (ABS) (If so
equipped)................................................... 4-18
Brake and clutch fluid................................ 7-12
Brake booster ............................................ 7-21
Brake pedal ............................................... 7-20
Brake system............................................. 4-17
Brake wear indicators ........................ 1-9, 7-20
Parking brake ................................... 4-12, 7-19
Break-in schedule ........................................... 4-15
C
Capacities and recommended fuel/lubricants... 9-2
Cargo (See ªVehicle loading
information) ..................................................... 9-13
Cassette tape player operation....................... 3-25
CB radio or car phone .................................... 3-29
Changing
Changing engine coolant ............................ 7-6
Changing engine oil .................................... 7-8
Changing oil filter ........................................ 7-9
Checking engine coolant level .......................... 7-5
Checking engine oil level .................................. 7-7
Child restraints for infants and small children .... 2-
31
Child safety rear door lock................................ 2-3
Cigarette lighter and ash trays ....................... 1-17
Cleaning exterior and interior ........................... 6-2
Clearing the programming information ........... 1-26Clock ............................................................... 1-22
Clutch pedal .................................................... 7-21
Cold weather driving ....................................... 4-19
Compact disc (CD) player operation .............. 3-26
Controls............................................................. 3-3
Coolant
Changing engine coolant ............................ 7-6
Checking engine coolant level .................... 7-5
Engine coolant temperature gauge ............. 1-4
Corrosion protection ......................................... 6-5
Cruise control.................................................. 4-13
Cup holder ...................................................... 1-19
D
Defogger switch
Rear window and outside mirror defogger
switch......................................................... 1-13
Dimensions and weights ................................... 9-9
Door lock operation .......................................... 2-6
Door locks ......................................................... 2-2
Door unlock operation ...................................... 2-6
Drinking alcohol/drugs and driving ................... 4-4
Drive belts ....................................................... 7-15
Driving
Cold weather driving ................................. 4-19
Drinking alcohol/drugs and driving .............. 4-4
Driving with automatic transmission............ 4-7
Driving with manual transmission ............. 4-10
Z01.2.1/A32-DX

Precautions when starting and driving ........ 4-2
E
Economy hints ................................................ 4-15
Emission control information label .................. 9-11
Emission control system warranty .................. 9-19
Engine ............................................................... 9-8
Before starting the engine ........................... 4-6
Changing engine coolant ............................ 7-6
Changing engine oil .................................... 7-8
Checking engine coolant level .................... 7-5
Checking engine oil level ............................ 7-7
Engine coolant temperature gauge ............. 1-4
Engine cooling system ................................ 7-5
Engine oil..................................................... 7-7
Engine oil and oil filter
recommendation .......................................... 9-4
Engine serial number ................................ 9-11
Starting the engine ...................................... 4-6
Exhaust gas (Carbon monoxide) ...................... 4-2
Explanation of maintenance items.................. 8-10
F
Flat tire .............................................................. 5-2
Fluid
Automatic transmission fluid ..................... 7-10
Brake and clutch fluid................................ 7-12
Power steering fluid................................... 7-11
Window washer fluid ................................. 7-12
FM/AM radio with cassette player .................. 3-12
FM-AM radio with cassette player .................. 3-16FM-AM radio with cassette player and
compact disc player ........................................ 3-22
F.M.V.S.S. certification label........................... 9-11
Foldable outside mirrors ................................. 2-39
Front fog light switch (If so equipped) ............ 1-15
Front personal light ......................................... 1-23
Fuel
Capacities and recommended
fuel/lubricants .............................................. 9-2
Fuel filler cap ............................................. 2-10
Fuel filler lid lock ....................................... 2-10
Fuel gauge .................................................. 1-5
Fuel recommendation.................................. 9-2
Fuses .............................................................. 7-21
Fusible links .................................................... 7-23
G
Gauge
Engine coolant temperature gauge ............. 1-4
Fuel gauge .................................................. 1-5
Meters and gauges ..................................... 1-3
General maintenance ....................................... 8-3
Glove box lock .................................................. 2-8
H
Hazard warning flasher switch........................ 1-16
Head restraint ................................................. 2-15
Headlight and turn signal switch..................... 1-14
Headlights ....................................................... 7-23
Heated seats (If so equipped) ........................ 1-16
Heater operation ............................................... 3-4Hood release .................................................... 2-8
I
If your vehicle is ever stolen ........................... 1-26
If your vehicle overheats .................................. 5-9
Ignition switch ................................................... 4-4
Injured persons ............................................... 2-26
Inside mirror .................................................... 2-40
Installing license plate .................................... 9-12
Instrument brightness control ......................... 1-15
Integrated HomeLink
transmitter
(If so equipped).......................................... 1-24
Interior light ..................................................... 1-22
J
Jump starting ........................................... 5-7, 7-14
K
Key .................................................................... 2-2
L
License plate
Installing license plate ............................... 9-12
Light
Front fog light switch (If so
equipped)................................................... 1-15
Front personal light ................................... 1-23
Headlight and turn signal switch ............... 1-14
Headlights.................................................. 7-23
Interior light................................................ 1-22
10-2
Z01.2.1/A32-DX

Light bulbs ................................................. 7-23
Supplemental air bag warning light........... 2-22
Trunk light.................................................. 1-23
Vanity mirror light ...................................... 1-23
Warning/indicator light and buzzer.............. 1-6
Lock
Anti-lock brake system (ABS) (If so
equipped)................................................... 4-18
Child safety rear door lock .......................... 2-3
Door lock operation ..................................... 2-6
Door locks ................................................... 2-2
Door unlock operation ................................. 2-6
Fuel filler lid lock ....................................... 2-10
Glove box lock............................................. 2-8
Power door lock .......................................... 2-4
Trunk lid lock ............................................... 2-9
Luggage (ªSee Vehicle loading informationº) . 9-13
M
Maintenance
Explanation of maintenance items ............ 8-10
General maintenance .................................. 8-3
Maintenance precautions ............................ 7-2
Periodic maintenance .................................. 8-5
Readiness for inspection/maintenance (I/M)
test (For U.S.A.) ........................................ 9-19
Seat belt maintenance .............................. 2-31
Meters and gauges ........................................... 1-3
Mirror
Foldable outside mirrors............................ 2-39
Inside mirror .............................................. 2-40
Outside mirror remote control ................... 2-39Rear window and outside mirror defogger
switch......................................................... 1-13
Vanity mirror light ...................................... 1-23
Multi-remote control system (If so equipped) ... 2-5
O
Odometer .......................................................... 1-4
Oil
Changing engine oil .................................... 7-8
Changing oil filter ........................................ 7-9
Checking engine oil level ............................ 7-7
Engine oil..................................................... 7-7
Engine oil and oil filter
recommendation .......................................... 9-4
Opener cancel lever for trunk lid .................... 2-10
Opening the driver's and front passenger's
window .............................................................. 2-6
Operating the transmitter ................................ 1-25
Outside mirror remote control ......................... 2-39
Overheat
If your vehicle overheats ............................. 5-9
P
Panic alarm operation ....................................... 2-6
Parking
Parking brake ................................... 4-12, 7-19
Parking/parking on hills ............................. 4-16
Periodic maintenance ....................................... 8-5
Pocket ............................................................. 1-18
Power
Power antenna .......................................... 3-29
Power door lock .......................................... 2-4Power steering fluid................................... 7-11
Power steering system .............................. 4-17
Power support seat (If so equipped)......... 2-14
Power window ........................................... 1-19
Precautions
Maintenance precautions ............................ 7-2
Precautions on seat belt usage ................ 2-24
Precautions when starting and driving ........ 4-2
Pregnant women............................................. 2-26
Programming problem diagnosis .................... 1-25
Programming the HomeLink
transmitter .................................................. 1-24Push starting ..................................................... 5-9
R
Radio............................................................... 3-11
CB radio or car phone............................... 3-29
FM/AM radio with cassette player............. 3-12
FM-AM radio with cassette
player ......................................................... 3-16
FM-AM radio with cassette player and
compact disc player .................................. 3-22
Radio operation ......................................... 3-23
Readiness for inspection/maintenance (I/M) test
(For U.S.A.)..................................................... 9-19
Rear seat ........................................................ 2-16
Rear window and outside mirror defogger
switch .............................................................. 1-13
Recommended SAE viscosity number ............. 9-6
Refrigerant recommendation ............................ 9-6
Reporting safety defects (For U.S.A.) ............ 9-19
Rolling codes (If so equipped) ........................ 1-26
10-3
Z01.2.1/A32-DX
