Nissan supports efforts towards cleaner air
and suggests that you use reformulated gaso-
line when available.
Gasoline containing oxygenates
Some fuel suppliers sell gasoline containing
oxygenates such as ethanol, MTBE and
methanol with or without advertising their pres-
ence. Nissan does not recommend the use of
fuels of which the oxygenate content and the
fuel compatibility for your NISSAN cannot be
readily determined. If in doubt, ask your ser-
vice station manager.
If you use oxygenate-blend gasoline, please
take the following precautions as the usage of
such fuels may cause vehicle performance
problems and/or fuel system damage.
IThe fuel should be unleaded and have
an octane rating no lower than that rec-
ommended for unleaded gasoline.
IIf an oxygenate-blend, excepting a
methanol blend, is used, it should con-
tain no more than 10% oxygenate.
(MTBE may, however, be added up to
15%.)
IIf a methanol blend is used, it should
contain no more than 5% methanol (me-
thyl alcohol, wood alcohol). It should
also contain a suitable amount of appro-priate cosolvents and corrosion inhibi-
tors. If not properly formulated with ap-
propriate cosolvents and corrosion
inhibitors, such methanol blends may
cause fuel system damage and/or ve-
hicle performance problems. At this
time, sufficient data is not available to
ensure that all methanol blends are suit-
able for use in Nissan vehicles.
If any undesirable driveability problems such
as engine stalling and hard hot starting are
experienced after using oxygenate-blend fu-
els, immediately change to a non-oxygenate
fuel or a fuel with a low blend of MTBE.
Take care not to spill gasoline during refu-
eling. Gasoline containing oxygenates can
cause paint damage.
Aftermarket fuel additives
Nissan does not recommend the use of any
fuel additives (i.e. fuel injector cleaner, octane
booster, intake valve deposit removers, etc.)
which are sold commercially. Many of these
additives intended for gum, varnish or deposit
removal may contain active solvent or similar
ingredients that can be harmful to the fuel
system and engine.Octane rating tips
In most parts of North America, you should use
unleaded gasoline with an octane rating of at
least 87 or 91 AKI (Anti-Knock Index) number.
However, you may use unleaded gasoline with
an octane rating as low as 85 AKI (Anti-Knock
Index) number in these high altitude areas
[over 4,000 ft (1,219 m)] such as: Colorado,
Montana, New Mexico, Utah, Wyoming, north-
eastern Nevada, southern Idaho, western
South Dakota, western Nebraska, and that
part of Texas which is directly south of New
Mexico.
Using unleaded gasoline with an octane
rating lower than stated above can cause
persistent, heavy ªspark knockº. (ªSpark
knockº is a metallic rapping noise.) If se-
vere, this can lead to engine damage. If you
detect a persistent heavy spark knock even
when using gasoline of the stated octane
rating, or if you hear steady spark knock
while holding a steady speed on level
roads, have your dealer correct the condi-
tion. Failure to correct the condition is
misuse of the vehicle, for which NISSAN is
not responsible.
Incorrect ignition timing will result in knocking,
after-run or overheating. This in turn may
cause excessive fuel consumption or damage
9-3
Z01.2.1/A32-DX

Model VQ30DE
Type Gasoline, 4-cycle
Cylinder arrangement 6-cylinder, V-slanted at 60É
Bore x Stroke in (mm) 3.66 x 2.886 (93.0 x 73.3)
Displacement cu in (cm
3) 182.33 (2,988)
Firing order 1-2-3-4-5-6*
Idle speed rpm
See the ªEmission Control Labelº
on the underside of the hood. Ignition timing (B.T.D.C.) degree/rpm
CO percentage at idle speed [No air] %
Spark plugStandard PFR5G-11
Service option PFR4G-11, PFR6G-11
Spark plug gap in (mm) Ð
Camshaft operation Timing chain
Alternator belt size
Width x Length in (mm) 0.8409 x 43.11 (21.36 x 1,095)
The spark ignition system of this vehicle
meets all requirements of the Canadian
Interference-Causing Equipment Regula-
tions.
TI1009-A
ENGINE
9-8
Z01.2.1/A32-DX

S
Safety
Child safety rear door lock .......................... 2-3
Reporting safety defects (For U.S.A.) ....... 9-19
Seat adjustment .............................................. 2-12
Seat belt
2-point type without retractor .................... 2-29
3-point type seat belt with ......................... 2-26
Precautions on seat belt usage ................ 2-24
Seat belt extenders ................................... 2-30
Seat belt maintenance .............................. 2-31
Seat belts .................................................. 2-24
Seats ............................................................... 2-12
Spark plug replacement .................................. 7-15
Speedometer .................................................... 1-4
Starting
Before starting the engine ........................... 4-6
Jump starting ..................................... 5-7, 7-14
Precautions when starting and driving ........ 4-2
Push starting ............................................... 5-9
Starting the engine ...................................... 4-6
Steering
Power steering fluid................................... 7-11
Power steering system .............................. 4-17
Tilting steering wheel ................................ 2-38
Sunroof (If so equipped) ................................. 1-21
Supplemental air bag warning light ................ 2-22
Supplemental restraint system (Supplemental air
bag system) .................................................... 2-17
Switch
Front fog light switch (If so equipped) ...... 1-15
Hazard warning flasher switch .................. 1-16
Headlight and turn signal switch ............... 1-14Ignition switch .............................................. 4-4
Rear window and outside mirror defogger
switch......................................................... 1-13
Windshield wiper and washer switch ........ 1-12
T
Tachometer ....................................................... 1-4
Theft warning (If so equipped)........................ 1-10
Three way catalyst ............................................ 4-2
Tilting steering wheel ...................................... 2-38
Timing chain ..................................................... 9-8
Tire
Flat tire ........................................................ 5-2
Tire chains ................................................. 7-31
Tire placard ............................................... 9-12
Tire pressure ............................................. 7-30
Uniform tire quality grading ....................... 9-18
Wheels and tires ................................ 7-30, 9-9
Tow truck towing ............................................. 5-10
Towing
Tow truck towing ....................................... 5-10
Towing load/specification chart ................. 9-15
Trailer towing ............................................. 9-14
Trailer towing .................................................. 9-14
Transmission
Automatic transmission fluid ..................... 7-10
Driving with automatic transmission............ 4-7
Driving with manual transmission ............. 4-10
Trip odometer ................................................... 1-4
Trunk lid lock .................................................... 2-9
Trunk lid opener operation ............................... 2-6
Trunk light ....................................................... 1-23U
Uniform tire quality grading............................. 9-18
V
Vanity mirror light ............................................ 1-23
Vehicle identification ....................................... 9-10
Vehicle identification number (Chassis
number) ..................................................... 9-10
Vehicle identification number plate ........... 9-10
Vehicle loading information............................. 9-13
Vehicle recovery (Freeing a stuck
vehicle)............................................................ 5-12
Ventilator ........................................................... 3-2
W
Warning
Hazard warning flasher switch .................. 1-16
Supplemental air bag warning labels ........ 2-22
Supplemental air bag warning light........... 2-22
Theft warning (If so equipped) .................. 1-10
Warning/indicator light and buzzer.............. 1-6
Wheels and tires ..................................... 7-30, 9-9
Window washer fluid ....................................... 7-12
Windshield wiper and washer switch.............. 1-12
Wiper
Windshield wiper and washer switch ........ 1-12
Wiper blades ............................................. 7-18
10-4
Z01.2.1/A32-DX
