1 Instruments and controls
Meters and gauges ................................................... 1-3
Warning/indicator light and buzzer............................ 1-6
Theft warning (If so equipped) ................................ 1-10
Windshield wiper and washer switch ...................... 1-12
Rear window and outside mirror
defogger switch ....................................................... 1-13
Headlight and turn signal switch ............................. 1-14
Instrument brightness control .................................. 1-15
Front fog light switch (If so equipped) .................... 1-15
Hazard warning flasher switch ................................ 1-16
Heated seats (If so equipped)................................. 1-16Cigarette lighter and ash trays ................................ 1-17
Pocket ..................................................................... 1-18
Cup holder............................................................... 1-19
Power window ......................................................... 1-19
Sunroof (If so equipped) ......................................... 1-21
Clock ....................................................................... 1-22
Interior light ............................................................. 1-22
Front personal light ................................................. 1-23
Vanity mirror light .................................................... 1-23
Trunk light ............................................................... 1-23
Integrated HomeLink
transmitter
(If so equipped) ....................................................... 1-24
Z01.2.1/A32-DX

Windshield wiper/washer switch (P.1-12)
Instrument brightness control switch (P.1-15)
Meters/gauges (P.1-3)
Theft warning light (P.1-10)
Cruise control main switch (P.4-13)
Headlight, fog light and turn signal
switch (P.1-14)
Hood release handle (P.2-8)
Outside mirror remote control (P.2-39)
Fuse box cover (P.7-22)
Tilting steering wheel lock lever (P.2-38)
Driver supplemental air bag (P.2-17)
Ignition switch/steering lock (P.4-4)
Cruise control set switch (P.4-13)
Cigarette lighter (accessory) (P.1-17)Hazard warning flasher switch (P.1-16)
Ventilator (P.3-2)
Heater/air conditioner control (P.3-3)
Clock (P.1-22)
Radio/cassette player (P.3-11)/CD player (P.3-26)
Rear window and outside mirror defogger switch (P.1-13)
Passenger supplemental air bag (P.2-17)
Glove box (P.2-8)
Ash tray
(P.1-17)
Heated seat switch (P.1-16)
SIC0692
See the page indicated in parentheses for operating details.
1-2
Z01.2.1/A32-DX

To defog the rear window glass and outside
mirrors, start the engine and push the switch
on. (The indicator light will come on.) Push the
switch again to turn the defogger off.
It will automatically turn off in approximately 15
minutes.
When cleaning the inner side of the rear
window, be careful not to scratch or
damage the rear window defogger.
SIC0177
REAR WINDOW AND OUTSIDE
MIRROR DEFOGGER SWITCH
1-13
Z01.2.1/A32-DX

Passing signal
Pulling the lever toward you will turn on the
headlight high beam.
Turn signal
Move the lever up or down to signal the turning
direction. When the turn is completed, the turn
signals cancel automatically.
Lane change signal
To indicate a lane change, move the lever up
or down to the point where lights begin flash-
ing.
The instrument brightness control operates
when the light switch is in the ª
ºor
ªº position.
Turn the control to adjust the brightness of
instrument panel lights (except clock) and
power window switch lights.
When the control is turned to the right until a
click sound is heard, the light intensity will be
at maximum. When the control is turned to the
left until a click sound is heard, the light will be
turned off.To turn the fog lights on, turn the headlight
switch to the ªº position, then turn the
switch to the ªº position. To turn them off,
turn the switch to the ªOFFº position.
The headlights must be on for the fog lights to
operate.
IC1284MAIC1292
INSTRUMENT BRIGHTNESS
CONTROLFRONT FOG LIGHT SWITCH (If so
equipped)
1-15
Z01.2.1/A32-DX

Air recirculation button
OFF position
Outside air is drawn into the passenger com-
partment.
Use the off position for normal heater, or air
conditioner operation.
ON position (Indicator light ON)
Interior air is recirculated inside the vehicle.
Push the air recirculation button to the ªONº
position when driving on a dusty road or to
avoid traffic fumes and for maximum cooling
when using the air conditioner.
Air conditioning button
This button is provided only for vehicles with
air conditioner.
Start the engine, move the fan control dial to
the desired (1 to 4) position and push the air
conditioning button to turn on the air condi-
tioner. The indicator light will come on when
the air conditioner is on. To stop the air con-
ditioner, push the switch again to return it to
the original position.
The air conditioner cooling function oper-
ates only when the engine is running.
HEATER OPERATION
Heating
This mode is used to direct hot air from the
floor outlets. Some air will also come from the
defrost vents.
1. Push the air recirculation button to the
ªOFFº position for normal heating.
2. Push the ª
º button in.
3. Turn on the fan control dial.
4. Move the temperature control lever to the
desired position between the middle and
the ªHOTº position.
IFor quick heating, move the air recirculation
button to the ªONº position. Be sure to
return the air recirculation button to the
ªOFFº position for normal heating.
Ventilation
This mode directs outside air from the side and
center vents.
1. Push the air recirculation button to the
ªOFFº position.
2. Push the ª
º button in.
3. Turn on the fan control dial.4. Move the temperature control lever to the
desired position.
Defrosting or defogging
This mode is used to defrost/defog the win-
dows.
1. Push the ª
º button in.
2. Turn on the fan control dial.
3. Move the temperature control lever to the
desired position between the middle and
the ªHOTº position.
ITo quickly remove ice or fog from the
windows, turn on the fan control dial to ª4º
and the temperature control lever to the full
ªHOTº position.
IWhen the ª
º switch is pushed, the air
conditioner will automatically be turned on
to defog the windshield, and the air recircu-
late mode will automatically be turned off.
Outside air is drawn into the passenger
compartment to improve the defogging per-
formance.
3-4
Z01.2.1/A32-DX

Bi-level heating
This mode directs outside air from the side and
center vents and hot air from the floor outlets.
1. Push the air recirculation button to the
ªOFFº position.
2. Push the ª
º button in.
3. Turn on the fan control dial.
4. Normally move the temperature control le-
ver to the midpoint between ªHOTº and
ªCOLDº.
Heating and defogging
This mode heats the interior and defogs the
windshield.
1. Push the ª
º button in.
2. Turn on the fan control dial.
3. Move the temperature control lever to the
desired position between the middle and
the ªHOTº position.
Operating tips
IClear snow and ice from the wiper
blades and air inlet in front of the wind-
shield. This will improve heater opera-
tion.
IWhen the ª
º switch is pushed, the air
recirculate mode will automatically be
turned off.
Outside air is drawn into the passenger
compartment to improve the defogging per-
formance.
AIR CONDITIONER OPERATION
Start the engine, move the fan control dial to
the desired (1 to 4) position and push in the air
conditioning button to activate the air condi-
tioner. When the air conditioner is on, cooling
and dehumidifying functions will be added to
the heater operation.
Cooling
This mode is used to cool and dehumidify.
1. Push the air recirculation button to the
ªOFFº position.
2. Push the ª
º button in.
3. Turn on the fan control dial.
4. Push on the air conditioning button. The
indicator light will come on.
5. Move the temperature control lever to the
desired position.
IFor quick cooling when the outside tem-
perature is high, move the air recirculation
button to the ªONº position. Be sure to
return the air recirculation button to the
ªOFFº position for normal cooling.
3-5
Z01.2.1/A32-DX

Dehumidified heating
This mode is used to heat and dehumidify.
1. Push the air recirculation button to the
ªOFFº position.
2. Push the ª
º button in.
3. Turn on the fan control dial.
4. Push on the air conditioning button. The
indicator light will come on.
5. Move the temperature control lever to the
desired position.
Dehumidified defogging
This mode is used to defog the windows and
dehumidify.
1. Push the ª
º button in.
2. Turn on the fan control dial.
3. Push on the air conditioning button. The
indicator light will come on.
4. Move the temperature control lever to the
desired position.
When the ª
º button is pushed, the air
conditioner will automatically be turned on
to defog the windshield, and the air recircu-
late mode will automatically be turned off.Outside air is drawn into the passenger com-
partment to improve the defogging perfor-
mance.
Operating tips
IKeep the windows and sun roof closed
while the air conditioner is in operation.
IAfter parking in the sun, drive for two or
three minutes with the windows open to
vent hot air from the passenger compart-
ment. Then, close the windows. This will
allow the air conditioner to cool the interior
more quickly.
IThe air conditioning system should be
operated for about ten minutes at least
once a month. This helps prevent dam-
age to the system due to lack of lubrica-
tion.
IIf the coolant temperature gauge exceeds
the HOT position, turn the air conditioning
off. See ªIf your vehicle overheatsº in the ªIn
case of emergencyº section for additional
information.
AIR FLOW CHART
The chart below shows the switch and lever
positions forMAXIMUM and QUICKheating,
cooling or defrosting.
The air recirculation switch should be in
the ªOFFº position for normal cooling,
heating and defrosting.
3-6
Z01.2.1/A32-DX

2. Push the temperature set button
ªºªº to set the desired tempera-
ture.
IThe temperature of the passenger compart-
ment will be maintained automatically. Air
flow distribution and fan speed are also
controlled automatically.
IDo not set the temperature lower than the
outside air temperature. Otherwise the sys-
tem may not work properly.
INot recommended if windows fog up.
Dehumidified defogging
1. Push the DEF ªº button on. (The
indicator light on the button will come on.)
2. Push the temperature set button
ª
ºªº to set the desired tempera-
ture.
ITo quickly remove ice or fog from the
outside of the windows, push the manual
fan control button ª
º and set to the
maximum position ªº.
IAs soon as possible after the windshield is
clean, push the AUTO button to return to
the auto mode.
IWhen the DEF ª
º button is pushed,
the air conditioner will automatically beturned on at outside temperatures above
35ÉF (2ÉC) to defog the windshield, and the
air recirculate mode will automatically be
turned off.
Outside air is drawn into the passenger
compartment to improve the defogging per-
formance.
Manual fan speed control
Push the fan control button ªº to manu-
ally control the fan speed.
IPush the AUTO button to return to auto-
matic control of the fan speed.
Air recirculation button
Push the air recirculation button ªºto
recirculate interior air inside the vehicle. The
indicator light on the switch will come on.
Push it again to draw outside air into the
passenger compartment. The indicator will go
out.
IThe air recirculation button will not be acti-
vated when the air conditioner is in DEF
mode.
Manual air flow control button
ªMODEº
Pushing the manual air flow control buttonselects the air outlet to:
: Air flows from center and side ventila-
tors.
: Air flows from center and side ventila-
tors and foot outlets.
: Air flows mainly from foot outlets.
To turn system off
Push the OFF button.
Operating tips
IWhen the engine coolant temperature and
outside air temperature are low, the air flow
from the foot outlets may not operate for a
maximum of 150 seconds. However, this is
not a malfunction. After the coolant tem-
perature warms up, the air flow from the
foot outlets will operate normally.
3-10
Z01.2.1/A32-DX

Replacing the headlight bulb
1. Insert the bulb into the headlight reflector
with the flat side of the plastic base facing
upward.
2. Install the bulb retaining ring and turn it
clockwise until it stops.
3. Push the electrical connector into the bulb
plastic base until it snaps and stops.
4. Connect the battery negative cable.
DO NOT TOUCH THE BULB.
IUse the same number and wattage as
originally installed:
Wattage 65/45
Bulb no. 9004
IAiming is not necessary after replac-
ing the bulb. When aiming adjust-
ment is necessary, contact your
NISSAN dealer.
IDo not leave the bulb out of the head-
light reflector for a long period of time
as dust, moisture, and smoke may
enter the headlight body and affect
the performance of the headlight.
OTHER LIGHTS
Item Wattage (W) Bulb No.
Clearance 27/8 1157
Front turn signal light 27 1156
Front side marker light 3.8 194
Front fog light 55
Rear combination light
Turn signal 27 1156
Stop/Tail 27/8 1157
Back-up 18 921
Rear side marker light 3.8 194
License plate light 5
High-mounted stop light 27 1156
Interior light 10
Front personal light 10
Step light 2.7 161
Trunk light 3.4 158
Vanity mirror light 1.4 Ð
7-24
Z01.2.1/A32-DX

10 Index
A
Air bag system (See ªSupplemental restraint
systemº) .......................................................... 2-17
Air bag warning light (See ªSupplemental air bag
warning lightº) ................................................. 2-22
Air cleaner filter ............................................... 7-17
Air conditioner
Air conditioner operation ............................. 3-5
Air conditioner specification label.............. 9-12
Automatic air conditioner (If so equipped) .. 3-9
Air conditioning system refrigerant and lubricant
recommendations ............................................. 9-6
Air flow chart ..................................................... 3-6
Antenna........................................................... 3-28
Anti-lock brake system (ABS) (If so equipped) .. 4-
18
Audio main operation ...................................... 3-23
Automatic
Automatic air conditioner (If so equipped) .. 3-9
Automatic transmission fluid ..................... 7-10
Driving with automatic transmission............ 4-7
Avoiding collision and rollover .......................... 4-3
B
Battery............................................................. 7-13
Battery replacement.......................................... 2-7
Before starting the engine ................................ 4-6Brake
Anti-lock brake system (ABS) (If so
equipped)................................................... 4-18
Brake and clutch fluid................................ 7-12
Brake booster ............................................ 7-21
Brake pedal ............................................... 7-20
Brake system............................................. 4-17
Brake wear indicators ........................ 1-9, 7-20
Parking brake ................................... 4-12, 7-19
Break-in schedule ........................................... 4-15
C
Capacities and recommended fuel/lubricants... 9-2
Cargo (See ªVehicle loading
information) ..................................................... 9-13
Cassette tape player operation....................... 3-25
CB radio or car phone .................................... 3-29
Changing
Changing engine coolant ............................ 7-6
Changing engine oil .................................... 7-8
Changing oil filter ........................................ 7-9
Checking engine coolant level .......................... 7-5
Checking engine oil level .................................. 7-7
Child restraints for infants and small children .... 2-
31
Child safety rear door lock................................ 2-3
Cigarette lighter and ash trays ....................... 1-17
Cleaning exterior and interior ........................... 6-2
Clearing the programming information ........... 1-26Clock ............................................................... 1-22
Clutch pedal .................................................... 7-21
Cold weather driving ....................................... 4-19
Compact disc (CD) player operation .............. 3-26
Controls............................................................. 3-3
Coolant
Changing engine coolant ............................ 7-6
Checking engine coolant level .................... 7-5
Engine coolant temperature gauge ............. 1-4
Corrosion protection ......................................... 6-5
Cruise control.................................................. 4-13
Cup holder ...................................................... 1-19
D
Defogger switch
Rear window and outside mirror defogger
switch......................................................... 1-13
Dimensions and weights ................................... 9-9
Door lock operation .......................................... 2-6
Door locks ......................................................... 2-2
Door unlock operation ...................................... 2-6
Drinking alcohol/drugs and driving ................... 4-4
Drive belts ....................................................... 7-15
Driving
Cold weather driving ................................. 4-19
Drinking alcohol/drugs and driving .............. 4-4
Driving with automatic transmission............ 4-7
Driving with manual transmission ............. 4-10
Z01.2.1/A32-DX
