The rear window wiper and washer operate
when the ignition switch is in the ON position.
Turn the switch clockwise from the OFF position
to operate the wiper.1Intermittent — intermittent operation (not ad-
justable)
2Low — continuous low speed operation
Push the switch forward
3
to operate the
washer. Then the wiper will also operate several
times.
CAUTION
If the rear window wiper operation is
interrupted by snow etc., the wiper
may stop moving to protect its motor.
If this occurs, turn the wiper switch to
OFF and remove the snow etc. on
and around the wiper arms. After
about 1 minute, turn the switch ON
again to operate the wiper.
Do not operate the washer continu-
ously for more than 30 seconds.
Do not operate the washer if the
reservoir tank is empty.
WARNING
In freezing temperatures the washer so-
lution may freeze on the rear window
glass and obscure your vision. Warm the
rear window with the defroster before
you wash the rear window.To defog/defrost the rear window glass and
outside mirrors (if so equipped), start the engine
and push the switch on
1. The indicator light
A
will come on. Push the switch again to turn
the defroster off.
It will automatically turn off in approximately 15
minutes.
CAUTION
When cleaning the inner side of the rear
window, be careful not to scratch or
damage the rear window defroster.
SIC2666
SIC2046
REAR WINDOW WIPER AND
WASHER SWITCHREAR WINDOW AND OUTSIDE
MIRROR DEFROSTER SWITCH
Instruments and controls
2-21
04.8.3/Z50-D/V5.0
Page 96 of 321
The vehicle should be driven with the Vehicle
Dynamic Control (VDC) system ON for most
driving conditions.
If the vehicle is stuck in mud or snow, the VDC
system reduces the engine output to reduce
wheel spin. The engine speed will be reduced
even if the accelerator is depressed to the floor.
If maximum engine power is needed to free a
stuck vehicle, turn the VDC system off.
To turn off the Vehicle Dynamic Control (VDC)
system, push the VDC OFF switch. The
in-
dicator light will come on.
Push the VDC OFF switch again or restart the
engine to turn ON the system. See “Vehicledynamic control (VDC) system” in the “5. Start-
ing and driving” section.
SIC1881
SIC2066
VEHICLE DYNAMIC CONTROL
(VDC) OFF SWITCH (if so
equipped)POWER OUTLET
Instruments and controls
2-29
04.8.3/Z50-D/V5.0
Page 105 of 321
the sunroof as it moves to the front or tilts down,
the sunroof will immediately open backward or
tilt up.
The auto reverse function can be activated when
the sunroof is closed by automatic operation
when the ignition switch is in the ON position or
for about 45 seconds after the ignition switch is
turned to the OFF position.
Depending on the environment or driving
conditions, the auto reverse function may
be activated if an impact or load similar to
something being caught in the sunroof
occurs.
If the auto reverse function malfunctions and
repeats opening or tilting up the sunroof, keep
pushing toward the close position or keep push-
ing the tilt down switch within 5 seconds after it
happens, then the sunroof will fully close gradu-
ally. In this case, make sure nothing is caught in
the sunroof.
WARNING
There are some small distances imme-
diately before the closed position which
cannot be detected. Make sure that all
passengers have their hands, etc., in-side the vehicle before closing the
sunroof.
Sun shadeOpen or close the sun shade by sliding it
backward or forward.
The shade will open automatically when the
sunroof is opened. However, it must be closed
manually.Comfortable position (
A)
Depending on the driving speed and air recircu-
lating conditions, wind noise may occur when
the sunroof is fully opened. Closing the sunroof
one step toward the front position
A
from full
open will decrease the wind noise.
WARNING
In an accident you could be thrown
from the vehicle through an open
sunroof. Always use seat belts and
child restraints.
Do not allow anyone to stand up or
extend any portion of their body outof the sunroof opening while the ve-
hicle is in motion or while the sun-
roof is closing.
CAUTION
Remove water drops, snow, ice or
sand from the sunroof before open-
ing.
Do not place any heavy object on the
sunroof or surrounding area.If the sunroof does not closeHave a NISSAN dealer check and repair the
sunroof.
2-38
Instruments and controls
04.8.3/Z50-D/V5.0
Page 166 of 321
the selected zone will be displayed.
“Pacific” zone has been set as the initial (default)
setting.
Beep setting:
When Beep setting is on (indicator light on), a
beep will sound if any audio button is pushed.“DAY/NIGHT” BUTTONTo change the display brightness, push the
“DAY/NIGHT” button. Pushing the button again
will change the display to DAY or NIGHT dis-
play. Then, adjust the brightness moving the
joystick right or left.
If no operation is done within 10 seconds, or if
the “PREV” button is pushed, the display will
return to the previous display.When the shift lever is shifted into the R (Re-
verse) position, the monitor display shows view
to the rear of the vehicle.
The system is designed as an aid to the driver in
detecting large stationary objects to help avoid
damaging the vehicle. The system will not detect
small objects below the bumper and may not
detect objects close to the bumper or on the
ground.
WARNING
The rear view camera is a conve-
nience but it is not a substitute for
proper backing. Always turn and
check that it is safe to do so before
backing up. Always back up slowly.
Objects viewed in the rear view moni-
tor differ from actual distance be-
cause a wide-angle lens is used. Ob-
jects in the rear view monitor will
appear visually opposite like ones
viewed in the inside and outside mir-
rors.
Make sure that the back door is se-
curely closed when backing up.Underneath the bumper and the cor-
ner areas of the bumper cannot be
viewed on the rear view monitor be-
cause of its monitoring range limita-
tion.
Do not put anything on the rear view
camera. The rear view camera is in-
stalled above the license plate.
When washing the vehicle with high-
pressure water, be sure not to spray
it around the camera. Otherwise, wa-
ter may enter the camera unit caus-
ing water condensation on the lens, a
malfunction, fire or an electric shock.
Do not strike the camera. It is a pre-
cision instrument. Otherwise, it may
malfunction or cause damage result-
ing in a fire or an electric shock.
CAUTION
There is a plastic cover over the camera.
Do not scratch the cover when cleaning
dirt or snow from it.
REAR VIEW MONITOR (if so
equipped)
Display screen, heater, air conditioner and audio systems
4-17
04.8.3/Z50-D/V5.0
Page 167 of 321
HOW TO READ THE DISPLAYED
LINESLines which indicate the vehicle clearance and
distances to objects with reference to the
bumper line
A
are displayed on the monitor.
They are indicated as reference distances to
objects. Displayed lines indicate distances 1.5
feet (red)
1, 3 feet (yellow)
2, 7 feet (green)
3and 10 feet (green)
4from the lower part of
the bumper line
A.
The vehicle clearance lines are wider than
the actual clearance.
REAR VIEW MONITOR SETTING
WARNING
Do not adjust the Brightness, Contrast,
Tint and Color of the rear view monitor
while the vehicle is moving. Make sure
the parking brake is firmly applied and
the engine is not running.
To adjust the Brightness, Contrast, Tint and
Color of the rear view monitor, push the “SET-
TING” button with the rear view monitor on,
select the item key and adjust the level using the
joystick.OPERATING TIPSWhen the shift lever is shifted to R, the
monitor screen automatically changes to the
rear view monitor mode. However, the radio
can be heard.
It may take some time until the rear view
monitor is displayed after the shift lever has
been shifted to R. Objects may be distorted
momentarily until the rear view monitor
screen is displayed completely. When the
shift lever is returned to a position other than
R, it may take some time until the screenchanges. Objects on the screen may be
distorted until they are completely displayed.
When the temperature is extremely high or
low, the screen may not clearly display ob-
jects. This is not a malfunction.
When strong light directly enters the camera,
objects may not be displayed clearly.
Vertical lines may be seen in objects on the
screen. This is due to strong reflected light
from the bumper. This is not a malfunction.
The screen may flicker under fluorescent
light. This is not a malfunction.
The colors of objects on the rear view monitor
may differ somewhat from those of the actual
object.
When the contrast of objects is low at night,
pushing the “ENTER” button may not change
the brightness.
Objects on the monitor may not be clear in a
dark place or at night.
If dirt, rain or snow attaches to the camera,
the rear view monitor may not clearly display
objects. Clean the camera.
Do not use alcohol, benzine or thinner to
clean the camera. This will cause discolora-
tion. To clean the camera, wipe with a cloth
SAA0889
4-18
Display screen, heater, air conditioner and audio systems
04.8.3/Z50-D/V5.0
Page 188 of 321
5 Starting and drivingPrecautions when starting and driving ............................. 5-2
Exhaust gas (Carbon monoxide) .................................. 5-2
Three-way catalyst ........................................................... 5-3
Low tire pressure warning system
(if so equipped) ................................................................ 5-3
Avoiding collision and rollover ...................................... 5-5
On-pavement and offroad driving precautions
(AWD) ................................................................................. 5-5
Drinking alcohol/drugs and driving .............................. 5-5
Driving safety precautions.............................................. 5-6
Ignition switch (Except for Intelligent Key equipped
model) ....................................................................................... 5-8
Key positions ..................................................................... 5-9
NISSAN Vehicle Immobilizer System (NVIS) ............ 5-9
Ignition switch (Intelligent Key System equipped
model)..................................................................................... 5-10
Ignition switch positions .............................................. 5-10
NISSAN Vehicle Immobilizer System (NVIS) ......... 5-11
Before starting the engine ................................................ 5-11
Starting the engine ............................................................. 5-12
Driving the vehicle ............................................................... 5-12
CVT (Continuously Variable Transmission)............. 5-12
M-CVT (CVT with Manual shift mode)..................... 5-16
Parking brake........................................................................ 5-20Cruise control ....................................................................... 5-21
Precautions on cruise control .................................... 5-21
Cruise control operations ............................................ 5-21
Break-in schedule .............................................................. 5-23
Increasing fuel economy .................................................... 5-23
Using all wheel drive (AWD) (if so equipped)............. 5-24
AWD lock switch operations...................................... 5-24
AWD warning light ........................................................ 5-26
Parking/parking on hills...................................................... 5-28
Power steering ..................................................................... 5-29
Brake system ........................................................................ 5-29
Braking precautions ...................................................... 5-29
Anti-lock brake system (ABS) .................................... 5-30
Vehicle dynamic control (VDC) system
(if so equipped) .................................................................. 5-31
Cold weather driving .......................................................... 5-33
Freeing a frozen door lock .......................................... 5-33
Antifreeze ......................................................................... 5-33
Battery .............................................................................. 5-33
Draining of coolant water ............................................ 5-33
Tire equipment................................................................ 5-33
Special winter equipment ............................................ 5-34
Driving on snow or ice ................................................. 5-34
Engine block heater (if so equipped) ....................... 5-34
04.8.3/Z50-D/V5.0
Page 205 of 321
N (Neutral):
Neither forward or reverse gear is engaged. The
engine can be started in this position. You may
shift to N (Neutral) and restart a stalled engine
while the vehicle is moving.
D (Drive):
Use this position for all normal forward driving.Manual shift modeWhen the shift lever is shifted from D to the
manual shift gate with the vehicle stopped or
while driving, the transmission enters the manual
shift mode. Shift ranges can be selected manu-
ally.
In the manual shift mode, the shift range is
displayed on the position indicator in the meter.
Shift ranges up or down one by one as follows:M1→
←M2→
←M3→
←M4→
←M5→
←M6M6 (Sixth):
Use this position for all normal forward driving.
M5 (Fifth):
For driving up or down long slopes where engine
braking would be advantageous.M4 (Fourth), M3 (Third) and M2 (Second):
Use for hill climbing or engine braking on down-
hill grades.
M1 (First):
Use this position when climbing steep hills
slowly or driving slowly through deep snow,
sand or mud, or for maximum engine braking on
steep downhill grades.
Remember not to drive at high speeds for
extended periods of time in lower than M6
range. This reduces fuel economy.
When shifting up, move the shift lever to the
+ (up) side. (Shifts to higher range.)
When shifting down, move the shift lever to
the − (down) side. (Shifts to lower range.)
Moving the shift lever to the same side twice
will shift the ranges in succession. However,
if this motion is rapidly done, the second
shifting may not be completed properly.
In the manual shift mode, the transmis-
sion automatically shifts down to M1
(First) before the vehicle comes to a
stop. When accelerating again, it is nec-
essary to shift up to the desired range.
When canceling the manual shift mode, re-
turn the shift lever to the D position. Thetransmission returns to the normal driving
mode.
In the manual shift mode, the transmis-
sion may not shift to the selected gear.
This helps maintain driving performance
and reduces the chance of vehicle dam-
age or loss of control.
When the CVT fluid temperature is extremely
low, the manual shift mode may not work and
automatically shift as a drive mode. This is not
a malfunction. In this case, return the shift
lever to D range and drive for a while and then
shift to the manual shift mode.
When the CVT fluid temperature is high, the
shift range may upshift in lower rpm than
usual. This is not a malfunction.5-18
Starting and driving
04.8.3/Z50-D/V5.0
Page 208 of 321
WARNING
Do not use the cruise control when driv-
ing under the following conditions:
When it is not possible to keep the
vehicle at a set speed.
In heavy traffic or in traffic that varies
in speed.
On winding or hilly roads.
On slippery roads (rain, snow, ice,
etc.).
In very windy areas.
Doing so could cause a loss of vehicle
control and result in an accident.PRECAUTIONS ON CRUISE
CONTROLIf the cruise control system malfunctions, it
cancels automatically. The SET indicator light
on the meter panel then blinks to warn the
driver.
If the SET indicator light blinks, turn the
cruise control main switch off and have the
system checked by a NISSAN dealer.The SET indicator light may blink when the
cruise control main switch is turned on while
pushing the RESUME/ACCELERATOR,
SET/COAST, or CANCEL switch. To prop-
erly set the cruise control system, perform the
preceding steps in the order indicated.
1. RESUME/ACCELERATOR switch
2. SET/COAST switch
3. MAIN (ON/OFF) switch
4. CANCEL switch
CRUISE CONTROL OPERATIONSThe cruise control allows driving at a speed
between 25 to 89 MPH (40 to 144 km/h)
without keeping your foot on the accelerator
pedal.
To turn on the cruise control,push the main
switch on. The CRUISE indicator light on the
meter panel will come on.
SSD0297
CRUISE CONTROL
Starting and driving
5-21
04.8.3/Z50-D/V5.0
Page 218 of 321
cidents resulting from careless or dan-
gerous driving techniques. It can help
maintain vehicle control during braking
on slippery surfaces, but remember that
the stopping distance on slippery sur-
faces will be longer than on normal
surfaces even with the anti-lock brake
system. Stopping distances may also be
longer on rough, gravel or snow covered
roads, or if you are using tire chains.
Always maintain a safe distance from
the vehicle in front of you. Ultimately,
the responsibility for safety of self and
others rests in the hands of the driver.
Tire type and condition of tires may also
affect braking effectiveness.
When replacing tires, install the
specified size of tires on all four
wheels.
When installing a spare tire, make
sure it is the proper size and type as
specified on the tire placard. See
“Vehicle identification” in the “9.
Technical and consumer informa-
tion” section for tire placard location.When accelerating or driving on a slippery sur-
faces, the tires may spin or slide. With the
Vehicle Dynamic Control (VDC) system, sensors
detect these movements and control the braking
and engine output to help improve vehicle sta-
bility.
When the VDC system is operating, the
“SLIP” indicator in the instrument panel
blinks.
When only the Traction Control System
(TCS) portion of the VDC system is operat-
ing, the “SLIP” indicator in the instrument
panel blinks.
If the “SLIP” indicator blinks, the road condi-
tions are slippery. Be sure to adjust your
speed and driving to these conditions. Be
sure to drive carefully. See “Slip indicator
light”, and “Vehicle Dynamic Control (VDC)
OFF indicator light” in the “2. Instruments and
controls” section.
Indicator light
If a malfunction occurs in the system, the
“SLIP” and “VDC OFF” indicator lights illumi-
nate in the instrument panel. As long as these
indicators are illuminated, the VDC system
function is canceled.
The VDC system uses an Active Brake Limited
Slip (ABLS) system to improve vehicle traction.The ABLS system works when one of the driving
wheels is spinning on a slippery surface. The
ABLS system brakes the spinning wheel, which
distributes the driving power to the other driving
wheel. If the vehicle is operated with the VDC
system turned off, all VDC system functions and
TCS functions will be turned off. The ABLS
system and ABS will still operate with the VDC
system off. When the ABLS system is activated,
the “SLIP” indicator light will blink and you may
hear a clunk noise and/or feel a pulsation in the
brake pedal. This is normal and is not an indica-
tion of a malfunction.
While the VDC system is operating, you may feel
a pulsation in the brake pedal and hear a noise or
feel a vibration from under the hood. This is
normal and indicates that the VDC system is
working properly.
The VDC system computer has a built-in diag-
nostic feature that tests the system each time
you start the engine and move the vehicle for-
ward or backward. When the self-test occurs,
you may hear a clunk noise and/or feel a pulsa-
tion in the brake pedal. This is normal and is not
an indication of a malfunction.
VEHICLE DYNAMIC CONTROL
(VDC) SYSTEM (if so equipped)
Starting and driving
5-31
04.8.3/Z50-D/V5.0
Page 219 of 321
WARNING
The VDC system is designed to help
improve driving stability but does not
prevent accidents due to abrupt
steering operation at high speeds or
due to careless or dangerous driving
techniques. Reduce vehicle speed
and be especially careful when driv-
ing and cornering on slippery sur-
faces and always drive carefully.
If engine related parts such as a muf-
fler are not standard equipment or
are extremely deteriorated, the “VDC
OFF” indicator or “SLIP” indicator or
both indicator lights may illuminate.
Do not modify the vehicle’s suspen-
sion. If suspension parts such as
shock absorbers, struts, springs, sta-
bilizer bars and bushings are not
NISSAN-approved or are extremely
deteriorated the VDC system may not
operate properly. This could ad-
versely affect vehicle handling per-
formance, and the “VDC OFF” indica-tor or “SLIP” indicator or both indica-
tor lights may illuminate.
If brake related parts such as brake
pads, rotors and calipers are not
standard equipment or are extremely
deteriorated, the “VDC OFF” indica-
tor or “SLIP” indicator or both indica-
tor lights may illuminate.
When driving on extremely inclined
surfaces such as higher banked cor-
ners, the VDC system may not oper-
ate properly and the “VDC OFF” indi-
cator or “SLIP” indicator or both
indicator lights may illuminate. Do
not drive on these types of roads.
When driving on an unstable surface
such as a turntable, ferry, elevator or
ramp, the “VDC OFF” indicator or
“SLIP” indicator or both indicator
lights may illuminate. This is not a
malfunction. Restart the engine after
driving onto a stable surface.
If wheels or tires other than those
recommended are used, the VDC sys-tem may not operate properly and the
“VDC OFF” indicator or “SLIP” indi-
cator or both indicator lights may
illuminate.
The VDC system is not a substitute
for winter tires or tire chains on a
snow-covered road.5-32
Starting and driving
04.8.3/Z50-D/V5.0
