Page 163 of 443
Black plate (13,1)
4 Monitor, heater, air conditioner, audio,
phone and voice recognition systems
Model "Z51-D" EDITED: 2007/ 10/ 2
Safety note....................................................... 4-2
Center multi-function control panel
(models with color display screen)......................... 4-2
How to use multi-function controller................... 4-4
How to use touch screen
(models with navigation system)........................ 4-4
Start-up screen (models with navigation system) . . . 4-6
Start menu................................................... 4-6
How to select menus on the screen................... 4-7
Vehicle information and settings............................. 4-8
How to use STATUS button.............................. 4-8
How to use brightness control and display ON/
OFF button................................................... 4-8
How to use INFO button.................................. 4-8
How to use SETTING button..........................4-12
Rearview monitor (if so equipped)........................4-19
How to read the displayed lines.......................4-20
How to park with predicted course lines............4-20
Difference between predicted and actual
distances...................................................4-22
How to adjust the screen...............................4-24
Operating tips.............................................4-24
Ventilators......................................................4-25
Heater and air conditioner..................................4-26
Automatic operation......................................4-28
Manual operation.........................................4-29
To turn the system off...................................4-30Operating tips.............................................4-30
In-cabin microfilter........................................4-30
Servicing air conditioner................................4-30
Audio system..................................................4-31
Audio operation precautions...........................4-31
FM-AM radio with Compact Disc (CD)
changer.....................................................4-39
FM-AM-SAT radio with Compact Disc (CD)
changer.....................................................4-44
CompactFlash (CF) player operation
(models with navigation system)......................4-49
iPod
®player operation (if so equipped)..............4-51
Music box hard drive
(models with navigation system)......................4-52
CD/CF (CompactFlash) care and cleaning.........4-59
Steering-wheel-mounted controls for audio
(if so equipped)...........................................4-60
Antenna.....................................................4-61
NISSAN Mobile Entertainment System (MES)
(if so equipped)...............................................4-62
DVD player operation precautions....................4-63
Digital Versatile Disc (DVD) system
components...............................................4-64
Remote controller and headphones battery
replacement................................................4-67
Before operating the DVD entertainment
system.......................................................4-68
Page 232 of 443
Black plate (230,1)
Model "Z51-D" EDITED: 2007/ 10/ 2
firm local regulations for battery
disposal.
.When changing batteries, do not let
dust or oil get on the remote control
and headphones.
FCC Notice:
Changes or modifications not expressly
approved by the manufacturer compliance
could void the user’s authority to operate
the equipment. This device complies with
Part 15 of the FCC Rules and RSS-210 of
Industry Canada. Operation is subject to
the following two conditions: (1) This
device may not cause harmful interference,
and (2) this device must accept any inter-
ference received, including interference
that may cause undesired operation of
the device.
BEFORE OPERATING THE DVD EN-
TERTAINMENT SYSTEM
Precautions
Start the engine when using the DVD entertain-
ment system.
WARNING
The driver must not attempt to operate
the DVD system or wear the head-phones while the vehicle is in motion so
that full attention may be given to
vehicle operation.
CAUTION
.Only operate the DVD while the
vehicle engine is running. Operating
the DVD for extended periods of
time with the engine OFF can dis-
charge the vehicle battery.
.Do not allow the system to get wet.
Excessive moisture such as spilled
liquids may cause the system to
malfunction.
.While playing VIDEO-CD media, this
DVD player does not guarantee
complete functionality of all VI-
DEO-CD formats.
Copyright and trademark
.The technology protected by the U.S. patent
and other intellectual property rights owned
by Macrovision Corporation and other right
holders is adopted for this system.
.This copyright protected technology cannot
be used without a permit from Macrovision
Corporation. It is limited to be personal use,etc., as long as the permit from Macrovision
Corporation is not issued.
.Modifying or disassembling is prohibited.
.Dolby digital is manufactured under license
from Dolby Laboratories, Inc.
.Dolby and the double D mark “
” are
trademarks of Dolby Laboratories, Inc.
.DTS and DTS Digital Surround “
” are
registered trademarks of DTS, Inc.
Parental level (parental control)
DVDs with the parental control setting can be
played with this system. Please use your own
judgement to set the parental control with the
system.
Disc selection
You can play the following disc formats with the
DVD drive:
.DVD-VIDEO
.VIDEO-CD
.CD-DA (Conventional Compact Disc) (CD
with MP3/WMA cannot be played.)
Use DVDs with a region code “1”, “ALL” or “1
included” for your DVD entertainment system.
(The region code is displayed as a small symbol
printed on the top of the DVD.) This vehicle-
4-68Monitor, heater, air conditioner, audio, phone and voice recognition systems
Page 233 of 443
Black plate (231,1)
Model "Z51-D" EDITED: 2007/ 10/ 2
installed DVD player cannot play DVDs with a
region code other than “1” or “ALL”.
Display settings
Front display:
To adjust the front display mode, press the
SETTING button while the DVD is being played,
select the “Display” key with the multi-function
controller, and then press the ENTER button.
To adjust the display ON/OFF, brightness, tint,
color, contrast and black level select each key
using the multi-function controller and press the
ENTER button.
Then you can adjust each item using the multi-
function controller. After changes have been
made press the BACK button to save the
settings.
Rear display:
To adjust the rear display mode, push the “DISP”
(Display) button on the remote controller.
To adjust the display brightness, tint, color and
contrast, select each key using the joystick on
the remote controller and tilt the joystick to right
or left.
Push the BACK button to apply the settings and
return to the previous display.
SAA1829
PLAYING A DIGITAL VERSATILE DISC
(DVD)
DISC button
Park the vehicle in a safe location for the
front seat occupants to operate the DVD
drive while watching the images.
Push the “DISC” button on the instrument panel
to turn the display to the DVD mode.
When a DVD is loaded, it will be replayed
automatically.
The operation screen will be turned on when the
“DISC” button located on the instrument panel
is pushed while a DVD is being played, and itwill turn off automatically after a period of time.
To turn it on again, push the “DISC” button once
more.
DVD operation keys
To operate the DVD drive, select the preferred
key displayed on the operation screen using the
multi-function controller.
PAUSE:
Select the “
” key and push theENTER
button to pause the DVD. To resume playing the
DVD, use the “PLAY” key.
To pause the DVD, it is also possible to push the
“
” button on the keypad of the remote
controller.
PLAY:
Select the “
” key and push theENTER
button to start playing the DVD, for example,
after pausing the DVD.
To start playing the DVD, it is also possible to
push the “
” button on the keypad of the
remote controller.
STOP:
Select the “
” key and push theENTER
button to stop playing the DVD.
Monitor, heater, air conditioner, audio, phone and voice recognition systems4-69
Page 340 of 443
Black plate (340,1)
Model "Z51-D" EDITED: 2007/ 10/ 2
speed and be especially careful
when driving and cornering on slip-
pery surfaces and always drive care-
fully.
.Do not modify the vehicle’s suspen-
sion. If suspension parts such as
shock absorbers, struts, springs,
stabilizer bars and bushings and
wheels are not NISSAN approved
or are extremely deteriorated the
VDC system may not operate prop-
erly. This could adversely affect
vehicle handling performance, and
the “VDC OFF” indicator or “SLIP”
indicator or both indicator lights
may illuminate.
.If brake related parts such as brake
pads, rotors and calipers are not
standard equipment or are extre-
mely deteriorated, the “VDC OFF”
indicator or “SLIP” indicator or both
indicator lights may illuminate.
.If engine related parts such as
muffler are not standard equipment
or are extremely deteriorated, the
“VDC OFF” indicator or “SLIP” in-
dicator or both indicator lights may
illuminate..When driving on extremely inclined
surfaces such as higher banked
corners, the VDC system may not
operate properly and the “VDC OFF”
indicator or “SLIP” indicator or both
indicator lights may illuminate. Do
not drive on these types of roads.
.When driving on unstable surfaces
such as a turntable, ferry, elevator
or ramp, the “VDC OFF” indicator or
“SLIP” indicator or both indicator
lights may illuminate. This is not a
malfunction. Restart the engine
after driving onto a stable surface.
.If wheels or tires other than those
recommended are used, the VDC
system may not operate properly
and “VDC OFF” indicator or “SLIP”
indicator or both indicator lights
may illuminate.
.The VDC system is not a substitute
for winter tires or tire chains on a
snow covered road.FREEING A FROZEN DOOR LOCK
To prevent a door lock from freezing, apply
deicer through the key hole. If the lock becomes
frozen, heat the key before inserting it into the
key hole or use the remote keyless entry keyfob.
ANTI-FREEZE
In the winter when it is anticipated that the
outside temperature will drop below 328F(08C) ,
check the anti-freeze to assure proper winter
protection. For additional information, see “EN-
GINE COOLING SYSTEM” in the “8. Main-
tenance and do-it-yourself” section.
BATTERY
If the battery is not fully charged during
extremely cold weather conditions, the battery
fluid may freeze and damage the battery. To
maintain maximum efficiency, the battery should
be checked regularly. For additional information,
see “BATTERY” in the “8. Maintenance and do-
it-yourself” section.
DRAINING OF COOLANT WATER
If the vehicle is to be left outside without anti-
freeze, drain the cooling system, including the
engine block. Refill before operating the vehicle.
For details, see “ENGINE COOLING SYSTEM”
in the “8. Maintenance and do-it-yourself”
section.
COLD WEATHER DRIVING
5-28Starting and driving
Page 436 of 443
Black plate (3,1)
FM-AM-SAT radio with Compact Disc (CD)
changer............................................. 4-44
Fog light switch.................................... 2-36
Front manual seat adjustment....................... 1-3
Front passenger air bag and status light........ 1-48
Front power seat adjustment....................... 1-4
Front seat adjustment ............................... 1-3
Front-seat active head restraints................... 1-9
Fuel
Capacities and recommended
fuel/lubricants.................................... 9-2
Distance to empty............................. 2-23
Fuel economy.................................. 5-20
Fuel economy information (display)............. 4-9
Fuel octane rating................................ 9-3
Fuel recommendation............................ 9-3
Fuel-filler cap................................... 3-23
Fuel-filler door.................................. 3-23
Gauge ............................................ 2-7
Fuses ............................................... 8-20
Fusible links........................................ 8-20
G
Garage door opener, HomeLink
®Universal
Transceiver......................................... 2-57
Gas cap ............................................ 3-23
Gauge ................................................ 2-4
Engine coolant temperature gauge............. 2-6
Fuel gauge....................................... 2-7
Odometer......................................... 2-5
Speedometer..................................... 2-5
Tachometer....................................... 2-6
Trip computer .................................. 2-21
General maintenance................................ 8-2Glove box........................................... 2-43
H
Hands-free phone system, Bluetooth
®
(with navigation system for Canada)............. 4-85
Hands-free phone system, Bluetooth®
(with navigation system for U.S.)................. 4-75
Hazard warning flasher switch.................... 2-36
Head restraints....................................... 1-8
Headlights
Aiming control.................................. 2-34
Bulb replacement.............................. 8-25
Headlight switch ............................... 2-32
Xenon headlights .............................. 2-32
Headphones (See NISSAN mobile
entertainment system)...................... 4-65, 4-72
Heated seats....................................... 2-37
Heater
Engine block heater........................... 5-29
Heater and air conditioner operation......... 4-26
HomeLink
®Universal Transceiver................. 2-57
Hood release....................................... 3-18
Hook
Coat hooks..................................... 2-49
Luggage hook.................................. 2-47
Horn ................................................ 2-37
I
Ignition switch (Push-button)....................... 5-8
Immobilizer system................................. 2-27
In-cabin microfilter................................. 4-30
Indicator lights..................................... 2-15
Indicator, Dot matrix display....................... 2-17
INFO button.......................................... 4-8Inside mirror........................................ 3-27
Inspection/maintenance (I/M) test................ 9-25
Instrument brightness control..................... 2-35
Instrument panel..................................... 2-2
Intelligent Key system......................... 3-3, 3-7
Key operating range............................. 3-8
Key operation.................................. 3-10
Warning light................................... 2-12
Warning signals................................ 3-13
Intelligent Key warning light....................... 2-12
Interior light control switch........................ 2-54
Interior light replacement.......................... 8-27
Interior lights....................................... 2-54
iPod
®player operation............................. 4-51
ISOFIX child restraint.............................. 1-23
J
Jump starting......................................... 6-9
K
Keyless entry (See remote keyless entry
system)............................................. 3-15
Keys................................................... 3-2
Keys, For Intelligent Key system.............. 3-3, 3-7
L
Labels
Air bag warning labels......................... 1-54
Air conditioner specification label............ 9-10
Emission control information label............ 9-10
Engine serial number ............................ 9-9
F.M.V.S.S./C.M.V.S.S. certification label........ 9-9
Tire and Loading Information label.... 8-31, 9-10
10-3
Model "Z51-D" EDITED: 2007/ 10/ 2
Page 438 of 443
Black plate (5,1)
Parking
Brake break-in.................................. 5-25
Parking brake operation....................... 5-17
Parking on hills................................. 5-24
Personal lights ..................................... 2-54
Phone
Bluetooth
®Hands-Free Phone System
(with navigation system for Canada)......... 4-85
Bluetooth
®Hands-Free Phone System
(with navigation system for U.S.)............. 4-75
Car phone or CB radio........................ 4-74
Power
Front seat adjustment........................... 1-4
Power door lock................................. 3-4
Power outlet.................................... 2-39
Power steering fluid........................... 8-11
Power steering system........................ 5-25
Power windows................................ 2-49
Precautions
Audio operation................................ 4-31
Braking precautions........................... 5-25
Child restraints................................. 1-22
Cruise control.................................. 5-18
Driving safety..................................... 5-6
Maintenance...................................... 8-5
On-pavement and off-road driving............. 5-5
Seat belt usage ................................ 1-10
Supplemental restraint system................ 1-41
When starting and driving....................... 5-2
Push starting....................................... 6-10
Push-button ignition switch......................... 5-8R
Radio ........................................ 4-31, 4-60
Car phone or CB radio........................ 4-74
FM-AM radio with Compact Disc (CD)
changer.................................. 4-39, 4-44
Rain-sensing auto wiper system.................. 2-29
Readiness for inspection/maintenance (I/M)
test.................................................. 9-25
Rear center seat belt.............................. 1-18
Rear door lock, Child safety rear door lock........ 3-7
Rear power point.................................. 2-39
Rear seats............................................ 1-6
Rear window and outside mirror defroster
switch............................................... 2-31
Rear window wiper and washer switch.......... 2-30
Rearview monitor.................................. 4-19
Recorders, Event data............................. 9-26
Registering your vehicle in another country........ 9-8
Remote controller (DVD).......................... 4-72
Remote keyless entry system..................... 3-15
Reporting safety defects (US only)............... 9-25
Rollover............................................... 5-5
Roof, Roof rack.................................... 2-48
S
Safety
Child seat belts................................ 1-13
Reporting safety defects (US only)........... 9-25
Towing safety.................................. 9-19
Satellite radio operation........................... 4-45
Seat adjustment
Front manual seat adjustment................... 1-3
Front power seat adjustment................... 1-4Front seats ....................................... 1-3
Seat belt(s)
Child safety..................................... 1-13
Infants........................................... 1-13
Injured persons................................. 1-14
Larger children ................................. 1-13
Precautions on seat belt usage............... 1-10
Pregnant women............................... 1-14
Rear center seat belt.......................... 1-18
Seat belt cleaning............................... 7-5
Seat belt extenders............................ 1-21
Seat belt hooks................................ 1-17
Seat belt maintenance......................... 1-21
Seat belt warning light........................ 2-14
Seat belts...................................... 1-10
Seat belts with pretensioners................. 1-53
Shoulder belt height adjustment.............. 1-17
Small children.................................. 1-13
Three-point type ............................... 1-14
Seat(s)
Driver-side memory............................ 3-30
Heated seats................................... 2-37
Seats.............................................. 1-2
Security system
(NISSAN Vehicle Immobilizer System) ,
Engine start ........................................ 2-27
Security system, Vehicle security system........ 2-25
Selector lever, Shift lock release................. 5-16
Servicing air conditioner........................... 4-30
SETTING button................................... 4-12
Shift lock release, Transmission.................. 5-16
Shifting, CVT
(Continuously Variable Transmission)............. 5-13
Shoulder belt height adjustment.................. 1-17
Spare tire...................................... 8-39, 9-7
10-5
Model "Z51-D" EDITED: 2007/ 10/ 2
Page 439 of 443
Black plate (6,1)
10-6
Spark plugs ........................................ 8-16
Speedometer......................................... 2-5
Starting
Before starting the engine.................... 5-12
Jump starting..................................... 6-9
Precautions when starting and driving......... 5-2
Push starting................................... 6-10
Starting the engine............................ 5-12
STATUS button...................................... 4-8
Status light, Front passenger air bag............ 1-48
Steering
Power steering fluid........................... 8-11
Power steering system........................ 5-25
Steering lock release malfunction
indicator........................................ 2-18
Steering-wheel-mounted controls for
audio............................................ 4-60
Tilting telescopic steering column............ 3-25
Storage ............................................. 2-41
Storage box ........................................ 2-45
Sun visors.......................................... 3-26
Sunglasses holder................................. 2-42
Supplemental air bag warning labels............. 1-54
Supplemental air bag warning light ....... 1-54, 2-14
Supplemental restraint system.................... 1-41
Precautions on supplemental restraint
system.......................................... 1-41
Switch
Autolight switch................................ 2-33
Fog light switch................................ 2-36
Hazard warning flasher switch................ 2-36
Headlight aiming control ...................... 2-34
Headlight switch............................... 2-32
Overdrive OFF switch......................... 5-15
Power door lock switch......................... 3-6Rear window and outside mirror defroster
switch........................................... 2-31
Turn signal switch.............................. 2-36
Vehicle dynamic control (VDC) off switch . . . 2-39
T
Tachometer........................................... 2-6
Temperature display............................... 2-23
Temperature gauge, Engine coolant
temperature gauge................................... 2-6
Theft (NISSAN Vehicle Immobilizer System) ,
Engine start........................................ 2-27
Three-way catalyst................................... 5-2
Tilting telescopic steering column................ 3-25
Tire
Pressure, Low tire pressure warning light . . . 2-13
Tire replacement indicator..................... 2-20
Tires
Flat tire............................................ 6-2
Low tire pressure warning system.............. 5-3
Tire and Loading information label........... 8-31
Tire and Loading Information label........... 9-10
Tire chains...................................... 8-36
Tire dressing..................................... 7-3
Tire pressure................................... 8-30
Tire pressure monitoring system
(TPMS)..................................... 5-3, 6-2
Tire rotation.................................... 8-37
Types of tires................................... 8-35
Uniform tire quality grading................... 9-24
Wheel/tire size................................... 9-7
Wheels and tires............................... 8-30
Tonneau cover (see cargo cover)................. 2-46
Top tether strap child restraints.................. 1-25Touch screen system................................ 4-4
Towing
Flat towing...................................... 9-23
Tow truck towing............................... 6-12
Towing a trailer................................. 9-15
Towing load/specification chart............... 9-15
Towing safety .................................. 9-19
TPMS, Tire pressure monitoring system........... 5-3
TPMS, Tire pressure warning system.............. 6-2
Trailer towing....................................... 9-15
Transceiver, HomeLink
®Universal
Transceiver ......................................... 2-57
Transmission
Continuously Variable Transmission (CVT)
fluid............................................. 8-11
Driving with CVT
(Continuously Variable Transmission)......... 5-13
Transmission selector lever lock release..... 5-16
Transmitter (See remote keyless
entry system)....................................... 3-15
Traveling or registering your vehicle in another
country................................................ 9-8
Trip computer...................................... 2-21
Trip odometer...................................... 2-22
Turn signal switch.................................. 2-36
U
Underbody cleaning................................. 7-3
Uniform tire quality grading....................... 9-24
V
Vanity mirror........................................ 3-29
Vanity mirror lights................................. 2-56
Variable voltage control system................... 8-15
Model "Z51-D" EDITED: 2007/ 10/ 2
