key NISSAN MURANO 2014 2.G Quick Reference Guide
[x] Cancel search | Manufacturer: NISSAN, Model Year: 2014, Model line: MURANO, Model: NISSAN MURANO 2014 2.GPages: 28, PDF Size: 1.54 MB
Page 2 of 28
INSTRUMENT BRIGHTNESS CONTROL SWITCH*
TWIN TRIP ODOMETER SWITCHES*
HEADLIGHT AND TURN SIGNAL CONTROL
LOW TIRE PRESSURE WARNING LIGHT
VEHICLE INFORMATION DISPLAY
WINDSHIELD WIPER AND WASHER SWITCH STEERING WHEEL SWITCHES FOR
AUDIO* / BLUETOOTH
® / NAVIGATION
CRUISE CONTROL
TRUNK LID / LIFTGATE RELEASE SWITCH
FUEL-FILLER DOOR RELEASE SWITCH
INTELLIGENT KEY
® PORT VEHICLE DYNAMIC CONTROL (VDC)
OFF SWITCH*
ALL-WHEEL DRIVE (AWD) LOCK SWITCH*
REMOTE WALK-IN SWITCH
TILT / TELESCOPIC STEERING COLUMN*
HOOD RELEASE*
CONTROL PANEL DISPLAY* PUSH-BUTTON IGNITION SWITCH
AU D I O SYSTE M
AUTOMATIC CLIMATE CONTROLS
FRONT PASSENGER AIR BAG
STATUS LIGHT*
SOFT TOP OPENER SWITCH
*See your Owner’s Manual for information.010203040506
09
15
0710
1617
1819202122
0811
131214
1920
16
12
1014
09
02
05
0611
18
08
0301
04
15
13
07
17
21
22
Behind
steering wheel
Behind
steering wheel
1591421_14d_Murano_QRG_012714b.indd 31/27/14 3:11 PM
Page 3 of 28
Please see your Owner’s Manual for important safety
information, and system operation limitations.
• A cellular telephone should not be used for any purpose while
driving so full attention may be given to vehicle operation.
• Always wear your seat belt.
• Supplemental air bags do not replace proper seat belt usage.
•
Children 12 and under should always ride in the rear seat
properly secured in child restraints or seat belts according to
their age and weight.
• Do not drink and drive.
For more information, refer to the “Safety –– Seats, seat belts and
supplemental restraint system (section 1)”, the “Monitor, heater, air
conditioner, audio, phone and voice recognition systems (section 4)”
and the “Starting and driving (section 5)” of your Owner’s Manual.
TABLE OF CONTENTS
Additional information about your vehicle is also available in your Owner’s Manual, Navigation System Owner’s Manual and at www.nissanusa.com. To view detailed
instructional videos, go to
www.nissanownersinfo.mobi/ 2014/murano
or snap this barcode with an appropriate barcode reader.
NEW SYSTEM FEATURES
Heated Steering Wheel (if so equipped) ............................2
Moving Object Detection (MOD) (if so equipped) ....................2
Blind Spot Warning (BSW) System (if so equipped) ................. 2
Lane Departure Warning (LDW) System (if so equipped) ..............3
RearView Monitor (if so equipped) ................................. 3
ESSENTIAL INFORMATION
Tire Pressure Monitoring System (TPMS) ...........................4
Loose Fuel Cap ................................................ 4
Fuel-filler Door ................................................. 4
Towing Your Vehicle ............................................. 5
Clock Set/Adjustment ........................................... 5
Automatic Power Windows (CrossCabriolet models) .................5
FIRST DRIVE FEATURES
NISSAN Intelligent Key
® System .................................. 6
Power Liftgate Release (Hardtop models - if so equipped) ............ 7
Trunk Lid Release (CrossCabriolet models) .........................7
Soft Top Operation (CrossCabriolet models) ........................8
Front Seat Adjustments .......................................... 9
Automatic Drive Positioner (if so equipped) ......................... 9
Rear Seat Adjustments (Hardtop models) ......................... 10
Rear Seat Entry/Exit (CrossCabriolet models) ......................10
Outside Mirror Control Switch ................................... 11
Starting/Stopping the Engine .................................... 11
Headlight Control Switch ....................................... 12
Windshield Wiper and Washer Switch ............................ 13
Automatic Climate Controls (if so equipped) ....................... 14
FM/AM/SiriusXM
® Satellite Radio with CD/DVD Player (if so equipped) . 16
USB/iPod® Interface (if so equipped) ............................. 17
Cruise Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . 17
Front Armrest/Center Console Storage Box ........................17
SYSTEM GUIDE
Trip Computer ................................................ 18
Bluetooth
® Hands-free Phone System (if so equipped) ..............19
System Operating Tips ...................................... 19
Bluetooth
® System with Navigation (if so equipped) .................20
Bluetooth® System without Navigation (if so equipped) .............. 21
Bluetooth® Streaming Audio (with Navigation System - if so equipped) ....22
Navigation System (if so equipped) ............................... 23
HomeLink
® Universal Transceiver (if so equipped) ...................24
1591421_14d_Murano_QRG_012714b.indd 41/27/14 3:11 PM
Page 7 of 28
5
AUTOMATIC POWER WINDOWS
(CrossCabriolet models)
Your power windows have an automatic adjusting
function to ensure windows close completely to help
seal against wind noise and weather leaks.
When the front doors are opened, the windows
automatically lower slightly to avoid contact between
the windows and the side roof panels.
If your vehicle’s battery has been discharged or disconnected, the power window automatic
adjusting function will not operate.
Refer to your Owner’s Manual for information on how to initialize your power window system.
If the power window functions do not operate properly after initializing\
the system, have your
vehicle checked by a NISSAN dealer.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
TOWING YOUR VEHICLE
ALL-WHEEL DRIVE (AWD) VEHICLE
An all-wheel drive vehicle must be towed with all wheels off the ground.\
For proper towing and to avoid accidental damage to your vehicle, NISSAN recommends that
a service operator tow your vehicle after carefully reading the Owner’s Manual precautions.
For more information, refer to the “In case of emergency (section 6)” of your Owner’s Manual.
CLOCK SET/ADJUSTMENT
To adjust the time and the appearance of the clock
on the display:
1. Press the SETTING button on the control panel.
2. Touch the Others key.
3. Touch the Clock key.
The following settings can be adjusted:
• On-screen Clock: The clock in the upper right
corner of the display can be turned ON or OFF.
• Clock Format (24h): The clock can be set to 12 hours or 24 hours.
• Offset (hour): The time can be adjusted by increasing or decreasing per hour.
• Offset (min): The time can be adjusted by increasing or decreasing per minute.
• Daylight Savings Time: The application of daylight savings time can be turned ON or OFF.
• Time Zone: Adjust the time zone. Choose a time zone from the available list.
Press the BACK button to return to the previous screen.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4)” of
your Owner’s Manual.
1591421_14d_Murano_QRG_012714b.indd 51/27/14 3:11 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
Page 8 of 28
6
NISSAN INTELLIGENT KEY® SYSTE M
The NISSAN Intelligent Key® system allows you to lock
or unlock your vehicle, open your trunk lid and start the
engine. It is important to make sure the Intelligent Key is
with you (that is, in your pocket or purse).
The operating range of the Intelligent Key is within
31.5 in (80 cm) from each request switch.
To lock the vehicle, push either door handle
request switch
01 once or press the
button
02 on the key fob.
To unlock the vehicle, perform one of the
following procedures:
• Push either door handle request switch
01 once;
the corresponding door will unlock. Push the door
handle request switch
01 again within 1 minute; all
other doors will unlock, or
• Press the
button 03 on the key fob to unlock the
driver’s side door. Press the button again; all other doors will unlock.
The Intelligent Key can also be used to activate the panic alarm by pressing and holding \
the
button 04 for more than 1 second. Once activated, the panic alarm and headlights w\
ill stay on
for a period of time.
NISSAN INTELLIGENT KEY
® BATTERY DISCHARGE
If the battery in the Intelligent Key is almost discharged,
the guide light
05 of the Intelligent Key port blinks, and
the key battery discharge indicator 06 is displayed in
the vehicle information display.
To start the engine under these circumstances, insert
the Intelligent Key into the key port with the buttons
facing upward and the key ring end toward you until
it latches into place. Then push the ignition switch to
start the engine.
To remove the Intelligent Key from the port, push the
ignition switch to turn the engine off and then pull the
Intelligent Key out of the port.
The Intelligent Key port does not charge the Intelligent
Key battery. If you see the key battery discharge
indicator
06, replace the battery in the Intelligent Key.
Do not insert the mechanical key or other objects into the key port because they will damage
the key port.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” , the “Starting and driving (section
5)” and the “Maintenance and do-it yourself (section 8)” of your Owner’s Manual.
FIRST DRIVE FEATURES
F
02
03
04
01
06
05
1591421_14d_Murano_QRG_012714b.indd 61/27/14 3:11 PM
To view detailed instructional videos regarding features in this Quick Reference Guide, please go to www.nissanownersinfo.mobi.
Page 9 of 28
7
TRUNK LID RELEASE (CrossCabriolet models)
Use one of the following methods to unlatch the trunk lid,
then pull the lid up to open the trunk:
Press theHOLD button 01 on the NISSAN Intelligent
Key® for more than 1 second.
Push the trunk open request switch 02 while
carrying the Intelligent Key with you (that is,
in your pocket or purse).
From inside the vehicle, push the trunk lid
release switch
03, located on the instrument panel
to the left of the steering wheel.
For more information, refer to the “Pre-driving checks and adjustments
(section 3)” of your Owner’s Manual.
03
01
POWER LIFTGATE RELEASE (Hardtop models - if so equipped)
Use one of the following methods to unlatch the liftgate,
then pull the liftgate up to open:
Press thebutton 01 on the NISSAN Intelligent
Key® for more than 1 second.
Push the liftgate opener switch 02
while carrying the Intelligent Key with
you (that is, in your pocket or purse).
From inside the vehicle, push the power liftgate switch
03, located on the instrument panel to the left of the
steering wheel.
For more information, refer to the “Pre-driving checks and adjustments
(section 3)” of your Owner’s Manual.
01
03
02
02
1591421_14d_Murano_QRG_012714b.indd 71/27/14 3:11 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
Page 10 of 28
8
SOFT TOP OPERATION (CrossCabriolet models)
The soft top can be operated only when the trunk is separated by the lugg\
age cover. The luggage
cover must be pulled out and hung on both hooks or the top will not oper\
ate. Before opening or
closing your soft top, refer to the Owner’s Manual for detailed warnings and cautions regarding
soft top operation.
BEFORE OPERATING THE SOFT TOP
Do not place anything in the top storage area. Cargo that contacts the top could damage the
top and/or the vehicle body. See the Caution label in the trunk.
Do not place anything on the soft top, rear parcel shelf, inner flaps,\
storage lid or trunk lid.
Even small items may interfere with the top operation and could cause da\
mage to the top or
the vehicle body.
In case of low battery or low temperature, the top may temporarily stop \
moving during
operation. This function is to protect the top control mechanism. This is not a malfunction.
SOFT TOP OPERATION
1. Make sure the area around the vehicle is clear of
obstructions and that there is more than 10 feet (3 m)
of clearance from the ground and more than 4.9 feet
(1.5 m) of clearance from the rear of the vehicle.
2. Pull out the luggage cover and hang on both
hooks
01.
3. Apply the parking brake and move the shift lever to
the P (PARK) position.
4. Depress the brake pedal.
5. Start the engine.
6. Push and hold the soft top operating switch, located
on the center console, to OPEN
02 or CLOSE 03
until the top is fully opened or closed.
OPENING THE SOFT TOP USING THE INTELLIGENT KEY
It is important to make sure the NISSAN Intelligent
Key® is on you (that is, in your pocket or purse).
The soft top can be opened from outside the vehicle
using the door handle request switch
04 as follows:
• The luggage cover must be pulled out and hung on
both hooks.
• The ignition switch must be in the OFF position.
•
Push and hold the door handle request switch
04 until the soft top is fully opened.
For more information, refer to the “Instruments and controls (section 2)” and the “Pre-driving checks and adjustments
(section 3)” of your Owner’s Manual.
02
03
01
04
FIRST DRIVE FEATURES
1591421_14d_Murano_QRG_012714b.indd 81/27/14 3:11 PM
To view detailed instructional videos regarding features in this Quick Reference Guide, please go to www.nissanownersinfo.mobi.
Page 11 of 28
9
AUTOMATIC DRIVE POSITIONER (if so equipped)
Two positions for the driver’s seat and outside
mirrors can be stored in the automatic drive
positioner memory.
Follow these procedures to set the memory positions:
• Confirm the shift lever is in the P (PARK) position.
• Push the ignition switch to the ON position.
• Adjust the driver’s seat and outside mirrors to the desired positions using the adjusting
switches for each feature.
• Push the SET switch and within 5 seconds push the memory switch (1 or 2) for at
least 1 second.
• The indicator light on the memory switch you select will illuminate for approximately
5 seconds.
• The driver’s seat and outside mirror positions are now set to your preference.
These memorized positions can also be linked to your NISSAN Intelligent Key®.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
FRONT SEAT ADJUSTMENTS
MANUAL SEATS (Passenger’s side only)
To slide the seat forward or backward, pull up on
the lever 01 under the front of the seat and slide
forward or backward. Release the lever to lock the
seat in position.
To adjust your seatback forward or backward, lift the
lever 02 on the side of the seat.
Release the lever when you have found a comfortable
angle and the seat belt fits properly.
POWER SEATS (Driver’s side only)
To slide the seat forward or backward, push the control switch
03
forward or backward.
To recline the seatback, push the switch
04 forward or backward.
SEAT LIFTER
To adjust the angle of the front seat cushion or
height of the seat, push the front or rear end of the
switch
03 up or down.
LUMBAR SUPPORT
To adjust the seat lumbar support, push the front or back end of the switch
05.
For more information, refer to the “Safety –– Seats, seat belts and supplemental restraint system (section 1)”\
of your
Owner’s Manual.
01
02
030405
1591421_14d_Murano_QRG_012714b.indd 91/27/14 3:11 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
Page 13 of 28
11
OUTSIDE MIRROR CONTROL SWITCH
To select the right or left side mirror, turn the control
switch
01 right or left.
To adjust the mirror angle, move the control switch up,
down, right or left.
To prevent accidentally moving the mirror, turn and set
the switch to the middle (neutral) position.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
01
STARTING/STOPPING THE ENGINE
It is important to make sure the NISSAN Intelligent
Key® is with you (that is, in your pocket or purse).
Depress the brake pedal.
Press the ignition switch START/STOP button to
start the engine.
TURNING THE ENGINE OFF
Move the shift lever to the P (PARK) position and
apply the parking brake.
Press the ignition switch START/STOP button to turn the engine off.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
04
05
06
PASSENGER’S SIDE
To fold down the front passenger’s seatback and
unlock the seat position, push the front passenger’s
seatback switch
04.
Manually slide the seat to the forward most position.
Enter or exit the back seat.
To slide the front passenger’s seat back into position,
push the bottom half of the seatback
05 until it
locks. Next, adjust the seatback by pulling the
seatback lever
06 up. Release the lever to lock the
seatback into position.
For more information, refer to the “Safety – Seats, seat belts and
supplemental restraint system (section 1)” of your Owner’s Manual.
1591421_14d_Murano_QRG_012714b.indd 111/27/14 3:11 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
Page 22 of 28
20
SYSTEM GUIDE
Bluetooth® System with Navigation (if so equipped)
Bluetooth® Streaming Audio allows you to use a
compatible Bluetooth® phone to play audio files on
your device. Your compatible cellular phone can be
connected to the vehicle’s audio system, allowing audio files to play through the vehicle’s speakers.
CONNECTING PROCEDURE
The vehicle must be stationary when connecting
the phone.
1. Press the PHONE button on the instrument panel
or the
button on the steering wheel and select the
“Connect Phone” key.
2. Initiate connecting from the phone.
• The connecting procedure varies according to each
cellular phone model. For detailed connecting instructions and a list of compatible phones, please
visit www.nissanusa.com/bluetooth.
• When prompted for a PIN code, enter “1234” from
the handset. (The PIN code is assigned by NISSAN
and cannot be changed.)
3. When the connecting is complete, the screen will
return to the “Phone” menu display.
PHONEBOOK SETUP
Depending on your cellular phone, the system may
automatically download your cellular phone’s entire phonebook to the vehicle’s Bluetooth
® system.
If the phonebook does not download automatically,
the vehicle phonebook may be set for up to
40 entries.
To manually download entries:
1. Press the
button and select the
“Quick Dial” key.
2. Select the “Add New” key at the top of
the display. There are different methods
to input a phone number. Select one of
the following options:
•
“Copy from Call History” to save a number from the Outgoing, Incoming or Missed
Calls lists.
• “Copy from the Phonebook” to save a number that has been downloaded from your
handset to the vehicle.
•
“Enter Number by Keypad” to input the number and name manually.
1591421_14d_Murano_QRG_012714b.indd 201/27/14 3:12 PM
To view detailed instructional videos regarding features in this Quick Reference Guide, please go to www.nissanownersinfo.mobi.
Page 23 of 28
21
MAKING A CALL
To make a call, follow this procedure: 1. Press the PHONE button on the instrument panel
or the
button on the steering wheel. The “Phone”
menu will appear on the control panel display.
2. Select the “Quick Dial”, “Call History”, “Phonebook” or
“Dial Number” key.
3. Select the desired entry from the list.
4. Select “Call” to start dialing the number.
RECEIVING/ENDING A CALL
To accept the call, press the PHONE button on
the instrument panel or the
button on the steering
wheel or touch the “Answer” key on the display.
To reject the call, touch the “Reject Call” key on the
display or press the
button on the steering wheel.
To hang-up, press the PHONE button on the
instrument panel or the
button on the steering
wheel or touch the “Hang up” key on the display.
Bluetooth® System without Navigation (if so equipped)
PAIRING PROCEDURE
1. Press the
button on the steering wheel. The
system announces the available commands.
2. Say: “Connect Phone”. The system acknowledges
the command and announces the next set of
available commands.
3. Say: “Add Phone”. The system acknowledges the
command and asks you to initiate connecting from the phone handset.
4. Initiate pairing from the phone.
• The connecting procedure varies according to each cellular phone model. For
detailed connecting instructions and a list of compatible phones, please vi\
sit
www.nissanusa.com/bluetooth.
• When prompted for a PIN code, enter “1234” from the handset. (The PIN code is
assigned by NISSAN and cannot be changed.)
5. Say a name for the phone when the system asks you to provide one. You can give the phone a
name of your choice.
1591421_14d_Murano_QRG_012714b.indd 211/27/14 3:12 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
