FIRST DRIVE FEATURES
03
0506
02
01
FM/AM/SiriusXM®* SATELLITE RADIO WITH CD/DVD PLAYER
(if so equipped)
01 ON•OFF BUTTON/VOL (volume) CONTROL KNOB

Press the VOL/ON•OFF control knob to turn the system on or off.

Turn the knob right or left to increase or decrease the volume.
02 SEEK/CAT AND TRACK BUTTONS

To scan quickly through each broadcasting station, press the SEEK/CAT button or
the TRACK
button to stop at the previous or next broadcast station.

For satellite radio, to switch to the first channel of the previous or next category, press the
SEEK/CAT button or the TRACK button.

To change tracks on a CD, press the SEEK/CAT button or the TRACK button.

To rewind or fast forward a track on a CD, press and hold the SEEK/CAT button or
the TRACK
button.
03 AUDIO BUTTON/TUNE•FOLDER CONTROL KNOB

Press the AUDIO button to go to the audio settings screen.

To manually tune the radio, turn the TUNE/FOLDER knob left or right.
04 STATION PRESET BUTTONS

Twelve stations can be set for the FM band, six for the AM band and eighteen for
satellite radio.

To store a station in a preset, you must first select a radio band by pressing the
AM•FM button
05 or
S AT button
06, then tune to the desired AM, FM or XM
satellite radio station.

Then press and hold the desired station preset button (1-6) until the sound is briefly
muted. The channel indicator will then display and the sound will resume. Programing\
is
now complete.

To retrieve a previously set station, select the radio band where the preset was stored
then press the corresponding station select button (1-6).
*SiriusXM® Satellite Radio is only available on vehicles equipped with an optional s\
atellite radio subscription service.
For more information, refer to the “Monitor, heater, air conditioner, audio, phone and voice recognition systems (section
4)” of your Owner’s Manual.
