fuse NISSAN PATHFINDER 1998 R50 / 2.G Owners Manual

Driver's supplemental air bag (P.1-9)
Cruise control
set switch
(P.5-16)
Outside mirror remote control
(P.3-14) Headlight/dimmer/turn signal switch (P.2-17)
Front fog light switch (P.2-19)Meter/gauge (P.2-3)
Windshield wiper/washer switch (P.2-15)
Hazard warning flasher switch (P.2-19)
Center ventilator (P.4-2)
Heater/air conditioner control (P.4-3)Compass/outside air temperature display (P.2-5)
Passenger supplemental air bag (P.1-9)
Side ventilator (P.4-2)
Glove box (P.2-25)
Cigarette lighter (P.2-22)
Radio/CD player (P.4-14)/clock (P.2-33)
Rear window wiper/washer switch (P.2-16)
Rear window/outside mirror defroster switch (P.2-16)Ignition switch/steering lock (P.5-6)Heated seat switch (P.2-20)
Tilting steering wheel adjust lever (P.3-13)Hood release handle (P.3-8)Fuse box cover (P.8-21)
Coin tray (P.2-23) Theft warning light (P.2-14) Cruise control main switch (P.5-16)
Instrument brightness control
(P.2-18)
SIC0682
See the page indicated in parentheses for operating details.
INSTRUMENT PANEL2-2
Instruments and controls
Z
01.1.31/R50-D
X

IUse this power socket with the en-
gine running. (If the engine is
stopped, this could result in a dis-
charged battery.)
IAvoid using when the air conditioner,
headlights or rear window defogger
is on.
IBefore inserting or disconnecting a
plug, be sure to turn off the power
switch of electrical accessory being
used or the ACC power of the vehicle.
IPush the plug in as far as it will go. If
good contact is not made, the plug
may overheat or the internal tempera-
ture fuse may blow.
IWhen not in use, be sure to close the
cap. Do not allow water to contact the
socket.
The cigarette lighter operates when the igni-
tion switch is in ACC or ON.
Push the lighter in all the way. When the lighter
is heated, it will spring out.
Replace the lighter in its original position after
use.The cigarette lighter should not be used
while driving in order that full attention
may be given to the driving operation.The cigarette lighter socket is a power
source for the cigarette lighter element
only. The use of the cigarette lighter
socket as a power source for any other
accessory is not recommended.
SIC0685
CIGARETTE LIGHTER AND
ASHTRAYS
2-22
Instruments and controls
Z
01.1.31/R50-D
X

TUNE (Tuning):
The radio should not be tuned while
driving in order that full attention may be
given to the driving operation.Push either manual tuning button
or
.SEEK/SCAN tuning:
Push the SEEK/SCAN tuning button
for less than 1.5 seconds. SEEK tuning begins
from low to high frequencies and stops at the
next broadcasting station. Pushing the button
again continues the SEEK function. Once the
highest broadcasting station is reached, the
radio continues in the SEEK mode at the
lowest broadcast station.
Push the SEEK/SCAN tuning buttonfor more than 1.5 seconds. SCAN illuminates
in the display window. SCAN tuning begins
from low to high frequencies and stops at each
broadcasting station for 5 seconds. Pushing
the button again during this 5 second period
stops SCAN tuning and the radio remains
tuned to that station.Station memory operations:
Six stations can be set for the AM band. 12
stations can be set for the FM band (six for
FM1, six for FM2).
1. Push the
to select AM, FM1, or FM2.The selected band illuminates in the dis-
play.
2. Tune to the desired station.
3. Push the desired select button for more
than 2 seconds. For example, in the illus-
trations ch2 is to be memorized. The radio
mutes when the select button is pushed.
4. When the sound resumes, memorizing is
complete.
5. Other station select buttons can be set in
the same manner.
If the battery cable is disconnected, or if the
radio fuse opens, the radio memory is can-
celled. In that case, reset the desired stations.
Cassette tape player operationTurn the ignition key to ACC or ON, then
carefully insert a cassette tape into the tape
door.
The cassette tape automatically pulls into the
player. The word TAPE and moving digital
squares illuminate on the right side of the
display window.
SAA0259
4-16
Heater, air conditioner and audio systems
Z
01.1.31/R50-D
X

1. Tune to the desired station.
2. Push the desired select button for more
than 1.5 seconds. (For example, in the
diagram ch2 is to be memorized. The radio
mutes when the select button is pushed.)
3. The indicator ch2 will then come on and the
sound will resume. Memorizing is now com-
plete.
4. Other buttons can be set in the same
manner.
If the battery cable is disconnected, or if the
fuse blows, the radio memory will be can-
celled. In that case, reset the desired stations.Cassette tape player operationTurn the ignition key to ACC or ON, and then
lightly insert the cassette tape into the tape
door. The cassette tape will be automatically
pulled into the player.
The radio or CD will turn off (if it is on) and the
cassette tape will begin to play.
Do not force the cassette tape into the
tape door.
This could cause player damage.If the system is turned off by pushing the
Power/Volume control knob with the cassette
tape still in the player, the tape will resume
playing when the Power/Volume control knob
is pushed again.
Precautions on cassette player operation:
ITo maintain good quality sound,
NISSAN recommends that you use cas-
sette tapes of 60 minutes or shorter in
length.
ICassette tapes should be removed from
the player when not in use. Store cas-
settes in their protective cases and away
from direct sunlight, heat, moisture or
magnetic sources.
Direct sunlight can cause the cassette to
become deformed. The use of deformed
cassettes may cause the cassette to jam
in the player.
IDo not use cassettes that have peelingor loose labels. If used, the label could
jam in the player.
IIf a cassette has loose tape, insert a
pencil through one of the cassette hubs
and rewind the tape firmly. Loose tape
may cause jamming and wavering
sound quality.
IOver a period of time, the playback
head, capstan and pinch roller may
gather a tape coating residue as the tape
passes over the head. This residue ac-
cumulation can cause a weak or waver-
ing sound and should be removed peri-
odically with a head cleaning tape.
If the residue is not removed periodi-
cally, the player may need to be disas-
sembled for cleaning.
PLAY/STOP:
IWhen this button is pushed with the system
turned off and a tape loaded, the system
will come on and the tape will play.
IWhen this button is pushed with either the
radio or compact disc turned on and the
tape loaded, the compact disc or the radio
will automatically be turned off and the tape
will play.
While the tape is playing, pushing the TAPE
4-22
Heater, air conditioner and audio systems
Z
01.1.31/R50-D
X

8 Do-it-yourselfMaintenance precautions .......................................... 8-2
Engine compartment check locations ....................... 8-3
Engine cooling system .............................................. 8-4
Engine oil .................................................................. 8-7
Automatic transmission fluid ..................................... 8-9
Power steering fluid ................................................ 8-11
Brake and clutch fluid ............................................. 8-11
Window washer fluid ............................................... 8-12
Battery ..................................................................... 8-13
Drive belts ............................................................... 8-14
Spark plugs ............................................................. 8-14
Air cleaner ............................................................... 8-16
Windshield wiper blades ......................................... 8-17
Parking brake and brake pedal ............................... 8-18
Clutch pedal ............................................................ 8-20
Fuses....................................................................... 8-20
Lights ....................................................................... 8-21
Tires and wheels ..................................................... 8-26
Clutch housing drain ................................... 8-30
Z
01.1.31/R50-D
X

Press the pedal by hand and be sure the free
travel is within the above limit. If free travel is
out of the range shown above, see your
NISSAN dealer.
ENGINE COMPARTMENTNever use a fuse of higher amperage
rating than that specified on the fuse
box cover. This could damage the elec-
trical system or cause a fire.If any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition key and the headlight
switch are OFF.2. Open the engine hood.
3. Remove the fusible link cover.
4. Remove the fuse with the fuse puller.
5. If the fuse is open, replace it with a new
fuse.
6. If a new fuse opens again, have the elec-
trical system checked and repaired by your
NISSAN dealer.
DI0070-B
SDI0395
CLUTCH PEDAL FUSES8-20
Do-it-yourself
Z
01.1.31/R50-D
X

PASSENGER COMPARTMENTNever use a fuse of higher amperage
rating than that specified on the fuse
box cover. This could damage the elec-
trical system or cause a fire.If any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition key and the headlight
switch are OFF.2. Pull to open the fuse box cover/coin tray.
3. Pull the fuse box cover/coin tray horizon-
tally to remove it.
4. Remove the fuse with the fuse puller.
5. If the fuse is open, replace it with a new
fuse.
6. If a new fuse opens again, have the elec-
trical system checked and repaired by your
NISSAN dealer.
HEADLIGHTSThe headlight is a semi-sealed beam type
which uses a replaceable headlight (halogen)
bulb. A bulb can be replaced inside the engine
compartment without removing the headlight
assembly.High pressure halogen gas is sealed
inside the halogen bulb. The bulb may
break if the glass envelope is scratched
or the bulb is dropped.
SDI0447
DI0156
LIGHTS
Do-it-yourself
8-21
Z
01.1.31/R50-D
X

Front
Fog light switch ......................................... 2-19
Manual seat adjustment .............................. 1-2
Power seat adjustment................................ 1-4
Fuel
Economy.................................................... 5-19
Filler cap .................................................... 3-11
Filler lid ...................................................... 3-11
Gauge .......................................................... 2-5
Recommendation ...................................... 10-4
Fuse ................................................................ 8-20
GGarage door opener, Integrated
HomeLink
...................................................... 2-35
Gas cap, Fuel filler ......................................... 3-11
Gas economy, Fuel ........................................ 5-19
Gauge ............................................................... 2-3
Engine coolant temperature ........................ 2-4
Fuel.............................................................. 2-5
Speedometer and odometer ....................... 2-3
Tachometer ................................................. 2-4
General maintenance ....................................... 9-2
Glass, Cleaning ................................................ 7-3
Glasses case .................................................. 2-23
Glove box........................................................ 2-25
H
Hazard warning flasher switch........................ 2-19
Head restraint adjustment ................................ 1-8
Headlamp, Replacement ................................ 8-21Headlight
Replacement ............................................. 8-22
Switch ........................................................ 2-17
Heated seat .................................................... 2-20
Heater and air conditioner
(Manual) ...................................................... 4-3
(Semiautomatic) .......................................... 4-9
Heater operation
Manual air conditioner ................................. 4-4
Semiautomatic air conditioner ................... 4-10
HomeLink
...................................................... 2-35
Hood ................................................................. 3-8
Hook, Luggage ............................................... 2-27
Horn ................................................................ 2-20
How to stop alarm, Theft warning .................. 2-15
How to use multi-remote control system .......... 3-4
I
Identification, Vehicle .................................... 10-12
Ignition switch ................................................... 5-6
Indicator light .................................................. 2-12
Infants and small children, Seat belt .............. 1-19
Information label, Emission........................... 10-13
Injured persons, Seat belt .............................. 1-19
Inside mirror .................................................... 3-14
Instrument panel ............................................... 2-2
Integrated HomeLink
transmitter .................. 2-35
Interior light ..................................................... 2-34
Replacement ............................................. 8-23J
Jump starting .................................................... 6-7
KKey .................................................................... 3-2
Position, Ignition switch ............................... 5-8
Key operation, Back door ................................. 3-9
Keyless entry, Multi-remote control .................. 3-4
LLabel, Air bag warning .................................... 1-15
Lamp, Replacement ........................................ 8-22
Larger children, Seat belt ............................... 1-19
Light
Air bag warning ......................................... 1-15
Front fog light switch ................................. 2-19
Headlight replacement .............................. 8-21
Headlight switch ........................................ 2-17
Indicator ..................................................... 2-12
Interior ....................................................... 2-34
Personal .................................................... 2-35
Replacement ............................................. 8-22
Vanity......................................................... 2-35
Warning ....................................................... 2-9
Loading information, Vehicle ........................ 10-14
Loading tips .................................................. 10-15
Lock
Back door .................................................... 3-9
Door ............................................................. 3-2
Locking with
Inside lock knob .......................................... 3-3
Z
01.1.31/R50-D
X
11-3
