NISSAN PATROL 2004 Electronic Repair Manual

TEL107N
POWER DOOR LOCK/WAGON AND HARDTOP MODELS
Wiring Diagram Ð D/LOCK Ð/RHD Models
With Theft Warning System (Cont'd)EL-4256

TEL108N
POWER DOOR LOCK/WAGON AND HARDTOP MODELS
Wiring Diagram Ð D/LOCK Ð/RHD Models
With Theft Warning System (Cont'd)EL-4257

Schematic Ð Super Lock Ð
TEL109N
POWER DOOR LOCK/WAGON AND HARDTOP MODELS
EL-4258

Wiring Diagram Ð S/LOCK Ð
TEL110N
POWER DOOR LOCK/WAGON AND HARDTOP MODELS
EL-4259

TEL111N
POWER DOOR LOCK/WAGON AND HARDTOP MODELS
Wiring Diagram Ð S/LOCK Ð (Cont'd)EL-4260

TEL112N
POWER DOOR LOCK/WAGON AND HARDTOP MODELS
Wiring Diagram Ð S/LOCK Ð (Cont'd)EL-4261

TEL113N
POWER DOOR LOCK/WAGON AND HARDTOP MODELS
Wiring Diagram Ð S/LOCK Ð (Cont'd)EL-4262

TEL114N
POWER DOOR LOCK/WAGON AND HARDTOP MODELS
Wiring Diagram Ð S/LOCK Ð (Cont'd)EL-4263

Wiring Diagram Ð MULTI Ð/LHD Models
Except for Europe, The Middle East and With
Theft Warning System
TEL829M
MULTI-REMOTE CONTROL SYSTEM/WAGON AND HARDTOP MODELS
EL-4264

TEL721M
MULTI-REMOTE CONTROL SYSTEM/WAGON AND HARDTOP MODELS
Wiring Diagram Ð MULTI Ð/LHD Models
Except for Europe, The Middle East and With
Theft Warning System (Cont'd)EL-4265
