Page 111 of 328
Portable devices
WARNING
Portable devices should not be used while
driving so full attention may be given to
vehicle operation.
For portable devices, such as cellular phones, a
power cord can be routed to the power outlet
inside the lower storage bin through the notch on
the side of the tray.
s1Open the lower storage bin. Plug the por-
table device charger into the power outlet
and into the portable device.
s2Open the storage tray.
s3Close the lower storage bin, using care not
to pinch the cord.
s4With the access hole coverssAremoved,
adjust the divider and insert the portable
device upright, allowing the portable device
connector to pass through the hole in the
storage tray.
To prevent damage to the portable device
cord, do not route the cord through the hole
in the storage tray or attempt to close the
storage tray with the portable device
charger connected.
Lower storage bin
Open the lower storage bin by pressing the but-
ton down.
Push the lid up to close.
LIC0731LIC0732WIC0840
Instruments and controls2-29
ZREVIEW COPYÐ2005 Quest(van)
Owners ManualÐUSA_English(nna)
07/21/04Ðdebbie
X
Page 112 of 328
GLOVE BOX
Open the glove box by pulling the handle. Use the
master key when locking
s1or unlockings2the
glove box. The valet key cannot be used to lock or
unlock the glove box.
WARNING
Keep glove box lid closed while driving to
help prevent injury in an accident or a
sudden stop.
SUNGLASSES HOLDER
To open the sunglasses holder, push and release.
WARNING
cThe sunglasses holder should not be
used while driving so full attention may
be given to vehicle operation.
cKeep the sunglasses holder closed
while driving to prevent an accident.
CAUTION
cDo not use for anything other than
sunglasses.cDo not leave sunglasses in the sun-
glasses holder while parking in direct
sunlight. The heat may damage the
sunglasses.
LIC0499LIC0508
2-30Instruments and controls
ZREVIEW COPYÐ2005 Quest(van)
Owners ManualÐUSA_English(nna)
07/21/04Ðdebbie
X
Page 113 of 328
CONVENIENCE HOOK
Use the convenience hook to store items such as
a purse, hat or small trash bag.
CAUTION
Do not apply a total load of more than 10
lbs (4.5 kg) to the convenience hook.
MAP POCKETS
LIC0502
Front door
LIC0519
Sliding door
LIC0520
Instruments and controls2-31
ZREVIEW COPYÐ2005 Quest(van)
Owners ManualÐUSA_English(nna)
07/21/04Ðdebbie
X
Page 114 of 328
SEATBACK POCKETS
The seatback pockets are located on the back of
the driver’s and passenger’s seats. The pockets
can be used to store maps.
GROCERY HOOKS
The grocery hooks allow for standard size plastic
grocery bags to hang side by side.
CAUTION
Do not apply a total load of more than 18
lbs (8 kg) to a single grocery hook.
UMBRELLA HOLDER
The net located on the back of the driver’s seat
can be used to hold an umbrella. Slide the um-
brella in and out of either end.
LIC0503LIC0504LIC0505
2-32Instruments and controls
ZREVIEW COPYÐ2005 Quest(van)
Owners ManualÐUSA_English(nna)
07/21/04Ðdebbie
X
Page 115 of 328
OVERHEAD CONSOLE
WARNING
Keep storage bins closed while driving to
help prevent injury in an accident or a
sudden stop.
Large storage bin
Push the button to open the storage bin. Use the
net to keep small items in place.
Push the lid up to close.
Small storage bin
Push the button to open the small storage bin.
Push the lid up to close.
LIC0513LIC0512
Instruments and controls2-33
ZREVIEW COPYÐ2005 Quest(van)
Owners ManualÐUSA_English(nna)
07/21/04Ðdebbie
X
Page 116 of 328
CUP HOLDERS
To open the front cup holders, push the button.
The lid springs open automatically. Push the lid to
the full open position.
Fold up the second cup holder ring, if desired.
To close, pull the entire cupholder unit up to the
original position.
WARNING
The cup holder should not be used while
driving so full attention may be given to
vehicle operation.
CAUTION
cAvoid abrupt starting and braking when
the cup holder is being used to prevent
spilling the drink. If the liquid is hot, it
can scald you or your passenger.
CAUTION
cUse only soft cups in the cup holder.
Hard objects can injure you in an
accident.
Front row
WIC0833
2nd row
LIC0509
2-34Instruments and controls
ZREVIEW COPYÐ2005 Quest(van)
Owners ManualÐUSA_English(nna)
07/21/04Ðdebbie
X
Page 117 of 328
CAUTION
cDo not use bottle holder for any other
objects that could be thrown about in
the vehicle and possibly injure people
during sudden braking or an accident.
cDo not use bottle holder for open liquid
containers.
3RD ROW ARMREST BIN
Raise the lid to open the 3rd row armrest bin.
Sliding door bottle holder
LIC0521
3rd row
LIC0507LIC0506
Instruments and controls2-35
ZREVIEW COPYÐ2005 Quest(van)
Owners ManualÐUSA_English(nna)
07/21/04Ðdebbie
X
Page 118 of 328
CARGO AREA STORAGE BIN
To open the cargo area storage bin, turn the knob
counterclockwise
s1. The lid can be removed.
To close, replace the lid and turn the knob clock-
wise
s2.
GARMENT HOOK
To store garments, pull the garment hook down to
the use position.
CAUTION
Do not apply a total load of more than 55
lbs (25 kg) to the hook.
LIC0514
Type A
LIC0511
Type B
WIC0831
2-36Instruments and controls
ZREVIEW COPYÐ2005 Quest(van)
Owners ManualÐUSA_English(nna)
07/21/04Ðdebbie
X
Page 119 of 328
HEAD RESTRAINT STORAGE
The storage bag can be used to store up to three
head restraints or other items.
The bag can be retained on the universal fasten-
ers located on the trim in the cargo area.
CAUTION
cThe cargo contained in the storage bag
must not exceed 5 lbs (2.2 kg) .
cDo not apply a total load of more than
55 lbs (25 kg) to the universal fasteners.ROOF RACK
Always distribute the luggage evenly on the roof
rack. Do not load more than 125 lb (56 kg) . Be
careful that your vehicle does not exceed the
Gross Vehicle Weight Rating (GVWR) or its
Gross Axle Weight Rating (GAWR front andrear) . The GVWR and GAWR are located on the
Safety Compliance Certification Label (located
on the driver’s door pillar) . For more information
regarding GVWR and GAWR, refer to “Vehicle
loading information” in the “Technical and con-
sumer information” section later in this manual.
LIC0522
LIC0530
Instruments and controls2-37
ZREVIEW COPYÐ2005 Quest(van)
Owners ManualÐUSA_English(nna)
07/21/04Ðdebbie
X
Page 120 of 328
The front and rear cross bars (if so equipped) can
be adjusted forward and backward by loosening
the TorxThead fastener
s1with the tool provided
in the jack tool kit. Place your luggage on the
bars, adjust the bars, and secure the luggage
with rope to the utility loops
s2on the bars.
Always check the tightness of the crossbar TorxT
head fasteners.
WARNING
Properly secure all cargo with ropes or
straps to help prevent it from sliding or
shifting. In a sudden stop or collision, un-
secured cargo could cause personal
injury.
CAUTION
Use care when placing or removing items
from the roof rack. If you cannot comfort-
ably lift the items onto the roof rack from
the ground, use a ladder or stool.
POWER WINDOWS
WARNING
cMake sure that all passengers have
their hands, etc. inside the vehicle while
it is in motion and before closing the
windows. Use the window lock switch
to prevent unexpected use of the power
windows.
cDo not leave children unattended inside
the vehicle. They could unknowingly ac-
tivate switches or controls and become
trapped in a window. Unattended chil-
dren could become involved in serious
accidents.
1. Window lock button
2. Power door lock switch
3. Front passenger side automatic switch
4. Right rear power vent window switch (if
so equipped)
5. Left rear power vent window switch (if
so equipped)
6. Driver side automatic switch
Driver’s side power window switch
The driver’s side control panel is equipped with
switches to open or close all of the windows.
The power windows operate when the ignition
switch is in the ON position, or for about 45
LIC0489
WINDOWS
2-38Instruments and controls
ZREVIEW COPYÐ2005 Quest(van)
Owners ManualÐUSA_English(nna)
07/21/04Ðdebbie
X
