NISSAN SENTRA 2008 B16 / 6.G User Guide

1. Rear seat (P. 1-3)
2. Moonroof (if so equipped) (P. 2-33)
3. Interior lights, illuminated entry,
moonroof switch (if so equipped)
(P. 2-36, P. 2-19, P. 2-33)
4. Sun visors (P. 3-26)
5. Inside mirror (P. 3-27)
6. Glove box (P. 2-27)
7. Cupholders (P. 2-27)
8. Parking brake, parking on hills
(P. 5-17, P. 5-21)
9. Front seat (P. 1-2)
10. Front console (P. 2-28)
11. Rear armrest, cupholders
(P. 1-7, P 2-27)
See the page number indicated in paren-
theses for operating details.
LII0091
PASSENGER COMPARTMENT
Illustrated table of contents0-5
ZREVIEW COPYÐ2008 Sentra(sen)
Owners ManualÐUSA_English(nna)
01/22/08Ðdebbie
X

1. Headlight/fog light (if so equipped)/turn
signal switch (P. 2-19); Manual shift
paddles (if so equipped) (P.5-13 )
2. Steering wheel switch for audio control
and BluetoothTHands-Free Phone
System (if so equipped) (P. 4-35, 4-37)3. Driver’s supplemental air bag/Horn
(P. 1-43, 2-23)
4. Meters and gauges (P. 2-3)
5. Instrument brightness control (P. 2-21)
6. Cruise control main/set switches
(if so equipped) (P. 5-18)7.
Windshield wiper/washer switch (P. 2-18)8. Storage bin (if so equipped) (P. 2-24)
9. Audio system (P. 4-15)
10. Center ventilator (P. 4-6)
11. Passenger’s supplemental air bag
(P. 1-43)
12. Control panel display (if so equipped)
(P. 4-2)
13. Side ventilator (P. 4-6)
14. Engine oil pressure gauge
(if so equipped) (P. 2-6)
15. g (gravity) -force gauge (if so equipped)
(P. 2-5)
16. Hazard warning flasher switch
(if so equipped) (P. 2-22)
17. Hazard warning flasher switch (if so
equipped) (P. 2-22); Manual shift mode
switch (if so equipped) (P.5-13 )
18. Glove box (P. 2-27)
19. Passenger air bag status light (P. 1-43)
20. Climate control (P. 4-7)
21. Shift selector lever (P. 5-11)
22. Power outlet (P. 2-23)
23. Ignition switch (P. 5-6)
24. Tilt steering (P.3-26)
25. Sunglasses holder (P. 2-26)
26. Hood release lever (P. 3-22)
See the page number indicated in paren-
theses for operating details.
WIC1115
INSTRUMENT PANEL
0-6Illustrated table of contents
ZREVIEW COPYÐ2008 Sentra(sen)
Owners ManualÐUSA_English(nna)
01/22/08Ðdebbie
X

MR20DE engine
1. Engine coolant reservoir (P. 8-8)
2. Engine oil filler cap (P. 8-9)
3. Brake fluid reservoir/Clutch fluid
reservoir (M/T model) (P. 8-13)
4. Battery (P. 8-15)
5. Air cleaner (P. 8-19)
6. Fuse/fusible link box (P. 8-22)
7. Radiator cap (P. 8-8)
8. Engine oil dipstick (P. 8-9)
9. Drive belt location (P.8-17)
10. Windshield washer fluid reservoir
(P. 8-14)
See the page number indicated in paren-
theses for operating details.
WDI0587
ENGINE COMPARTMENT CHECK
LOCATIONS
Illustrated table of contents0-7
ZREVIEW COPYÐ2008 Sentra(sen)
Owners ManualÐUSA_English(nna)
01/22/08Ðdebbie
X

QR25DE engine
1. Engine coolant reservoir (P. 8-8)
2. Engine oil filler cap (P. 8-9)
3. Brake fluid reservoir/Clutch fluid
reservoir (M/T model) (P. 8-13)
4. Battery (P. 8-15)
5. Air cleaner (P. 8-19)
6. Fuse/fusible link box (P. 8-22)
7. Radiator cap (P. 8-8)
8. Engine oil dipstick (P. 8-9)
9. Drive belt location (P.8-17)
10. Windshield washer fluid reservoir
(P. 8-14)
*Engine cover removed for clarity.
See the page number indicated in paren-
theses for operating details.
WDI0637
0-8Illustrated table of contents
ZREVIEW COPYÐ2008 Sentra(sen)
Owners ManualÐUSA_English(nna)
01/22/08Ðdebbie
X

Warning
lightName Page
or
Anti-lock Braking
System (ABS) warn-
ing light (if so
equipped)2-9
or
Brake warning light 2-9
Charge warning light 2-9
Door open warning
light2-9
Electric power
steering warning
light2-10
Engine oil pressure
warning light2-10
Warning
lightName Page
Intelligent Key sys-
tem warning light
(CVT models) (if so
equipped)2-10
Low fuel warning
light2-11
Low tire pressure
warning light (if so
equipped)2-11
Low windshield
washer fluid warning
light (if so equipped)2-12
P position selecting
warning light (CVT
models) (if so
equipped)2-12
Seat belt warning
light and chime2-12
Supplemental air
bag warning light2-12
Indicator
lightName Page
Continuously Vari-
able Transmission
(CVT) position indi-
cator light2-13
Cruise main switch
indicator light (if so
equipped)2-13
Cruise set switch
indicator light (if so
equipped)2-13
or
Front passenger air
bag status light2-13
High beam indicator
light (blue)2-13
Malfunction Indica-
tor Light (MIL)2-13
WARNING/INDICATOR LIGHTS
Illustrated table of contents0-9
ZREVIEW COPYÐ2008 Sentra(sen)
Owners ManualÐUSA_English(nna)
01/22/08Ðdebbie
X

Indicator
lightName Page
Overdrive off indica-
tor light (CVT mod-
els)2-14
Security indicator
light2-14
Turn signal/hazard
indicator lights2-14
0-10Illustrated table of contents
ZREVIEW COPYÐ2008 Sentra(sen)
Owners ManualÐUSA_English(nna)
01/22/08Ðdebbie
X

1 Safety—Seats, seat belts and
supplemental restraint system
Seats............................................1-2
Front manual seat adjustment....................1-2
Rear folding seat system (if so equipped).........1-3
Front-Seat Active Head Restraints................1-7
Head restraint adjustment.......................1-8
Seat belts........................................1-9
Precautions on seat belt usage...................1-9
Child safety...................................1-12
Pregnant women..............................1-13
Injured persons................................1-13
Three-point type seat belt with retractor..........1-13
Three-point type seat belt with retractor
(Rear center seat, all models except SE-R).......1-16
Three-point type seat belt with retractor
(SE-R rear center seat).........................1-20
Shoulder belt height adjustment
(Front seats)..................................1-22
Seat belt extenders............................1-22Seat belt maintenance.........................1-23
Child restraints...................................1-23
Precautions on child restraints..................1-23
Lower Anchors and Tethers for CHildren
System (LATCH)..............................1-25
Top tether strap child restraint..................1-27
Child restraint installation using LATCH..........1-28
Child restraint installation using the seat
belts.........................................1-32
Booster seats....................................1-38
Precautions on booster seats...................1-38
Booster seat installation........................1-41
Supplemental restraint system.....................1-43
Precautions on supplemental restraint
system.......................................1-43
Supplemental air bag warning labels.............1-58
Supplemental air bag warning light..............1-58
ZREVIEW COPYÐ2008 Sentra(sen)
Owners ManualÐUSA_English(nna)
01/22/08Ðdebbie
X

WARNING
cDo not ride in a moving vehicle when
the seatback is reclined. This can be
dangerous. The shoulder belt will not
be against your body. In an accident,
you could be thrown into it and receive
neck or other serious injuries. You
could also slide under the lap belt and
receive serious internal injuries.cFor the most effective protection when
the vehicle is in motion, the seat should
be upright. Always sit well back in the
seat with both feet on the floor and
adjust the seat properly. See “Precau-
tions on Seat Belt Usage” later in this
section.
cAfter adjustment, gently rock in the seat
to make sure it is securely locked.
cDo not leave children unattended inside
the vehicle. They could unknowingly ac-
tivate switches or controls. Unattended
children could become involved in seri-
ous accidents.
FRONT MANUAL SEAT
ADJUSTMENT
ARS1152
SEATS
1-2Safety—Seats, seat belts and supplemental restraint system
ZREVIEW COPYÐ2008 Sentra(sen)
Owners ManualÐUSA_English(nna)
01/22/08Ðdebbie
X

Forward and backward
Pull the lever up and hold it while you slide the
seat forward or backward to the desired position.
Release the lever to lock the seat in position.
Reclining
To recline the seatback, pull the lever up and lean
back. To bring the seatback forward, pull the lever
up and lean your body forward. Release the lever
to lock the seatback in position.
The reclining feature allows adjustment of the
seatback for occupants of different sizes for
added comfort and to help obtain proper seat
belt fit. See “Precautions on seat belt usage” later
in this section. Also, the seatback can be reclined
to allow occupants to rest when the vehicle is
stopped and the shift selector lever (CVT) is in P
(Park) or the manual transmission is in N (Neutral)
with the parking brake applied.
Seat lifter (if so equipped for driver’s
seat)
Repeatedly pull up or push down the adjusting
lever to adjust the seat height until the desired
position is achieved.
REAR FOLDING SEAT SYSTEM (if so
equipped)
WRS0719WRS0720WRS0721
Safety—Seats, seat belts and supplemental restraint system1-3
ZREVIEW COPYÐ2008 Sentra(sen)
Owners ManualÐUSA_English(nna)
01/22/08Ðdebbie
X

Interior trunk access (if so equipped)
The trunk can be accessed from the rear seat for
loading and unloading, as shown.
1. Stow outboard seat belts with clip before
folding rear seat backs.
When folding the passenger’s side rear seat
back, first disconnect and stow the center seat
belt. See “Stowing the rear center seat belt” later
in this section.2. Pull up on the strap
sAlocated on the top
outboard side of the seat to be folded.
3. Fold seat back down.
WARNING
cNever allow anyone to ride in the cargo
area or on the rear seat when it is in the
fold-down position. Use of these areas
by passengers without proper restraints
could result in serious injury in an acci-
dent or sudden stop.cProperly secure all cargo with ropes or
straps to help prevent it from sliding or
shifting. Do not place cargo higher than
the seatbacks. In a sudden stop or col-
lision, unsecured cargo could cause
personal injury.
cWhen returning the seatbacks to the
upright position, be certain they are
completely secured in the latched posi-
tion. If they are not completely secured,
passengers may be injured in an acci-
dent or sudden stop.
cClosely supervise children when they
are around cars to prevent them from
playing and becoming locked in the
trunk where they could be seriously in-
jured. Keep the car locked, with the rear
seatback and trunk lid securely latched
when not in use, and prevent children’s
access to car keys.
LRS0728WRS0726
1-4Safety—Seats, seat belts and supplemental restraint system
