EI-44
REAR PARCEL SHELF FINISHER

REMOVAL
1. Remove rear seatback and rear seat cushion. Refer to SE-112, "REAR SEAT" .
2. Remove rear seat belt floor anchor bolt and rear seat belt shoulder anchor bolt. Refer to SB-5, "
Removal
and Installation of Rear Seat Belt" .
3. Disengage child anchor cover front pawls, and then pull out child
anchor cover (LH/RH center) toward front of vehicle.(Models
with rear window sunshade)
4. Remove rear kicking plate inner, rear seatback finisher, rear pillar finisher. Refer to EI-38, "
BODY SIDE
TRIM" .
5. Disconnect high-mounted stop lamp harness connector from
trunk room side. (Models without rear window sunshade)
6. Disconnect high-mounted stop lamp harness connector from
front side of rear parcel shelf finisher. (Models with rear window
sunshade)
7. Remove rear parcel shelf finisher mounting clip using a clip clamp remover.
8. Remove rear parcel shelf finisher while disengaging dual-lock fastener on back of rear parcel shelf fin-
isher. (Models with rear window sunshade)
9. Remove the following parts after removing rear parcel shelf finisher.

Rear speaker grille (for woofer)

High-mounted stop lamp
INSTALLATION
Install in the reverse order of removal.
7. Screw 8.Rear parcel shelf finisher (with sun-
shade)9. Child anchor cover (LH/RH center)
10. Rear window sunshade 11. Bolt 12. Locating pin
PIIA9530E
PIIA9531E
PIIA9535E
