diagnostic menu NISSAN TEANA 2003 Service Manual

AT-70
TROUBLE DIAGNOSIS

HOW TO ERASE SELF-DIAGNOSTIC RESULTS
1. Touch “SELF-DIAG RESULTS” on “SELECT DIAG MODE”
screen.
2. Touch “ERASE”. (The self-diagnostic results will be erased.)
DATA MONITOR MODE
Operation Procedure
1. Touch “DATA MONITOR” on “SELECT DIAG MODE” screen.
NOTE:
When malfunction is detected, CONSULT-II performs
“REAL-TIME DIAGNOSIS”. Also, any malfunction detected
while in this mode will be displayed at real time.
Display Items List
X: Standard, —: Not applicable, : Option
BCIA0031E
SCIA4849E
BCIA0031E
Monitor item (Unit)SELECT MONITOR ITEM
Remarks
TCM INPUT
SIGNALSMAIN SIG-
NALSSELEC-
TION FROM
MENU
VHCL/S SE-A/T (km/h) X — Revolution sensor
VHCL/S SE-MTR (km/h) X —Vehicle speed display may not be accu-
rate under approx. 10 km/h (6 mph). It
may not indicate 0 km/h (0 mph) when
vehicle is stationary.
THRTL POS SEN (V) X —
FLUID TEMP SE (V) X —
BATTERY VOLT (V) X —
ENGINE SPEED (rpm) X X
TURBINE REV (rpm) X —

AT-72
TROUBLE DIAGNOSIS

CAN DIAGNOSTIC SUPPORT MONITOR MODE
Operation Procedure
1. Touch “CAN DAIG SUPPORT MNTR” on “SELECT DIAG
MODE” screen. Refer to LAN-44, "
CAN Diagnostic Support
Monitor" .
DTC WORK SUPPORT MODE
Operation Procedure
1. Touch “DTC WORK SUPPORT” on “SELECT DIAG MODE”
screen.
2. Touch select item menu (1ST, 2ND, etc.).
Frequency (Hz) — —
The value measured by the pulse probe
is displayed. DUTY-HI (high) (%) — —
DUTY-LOW (low) (%) — —
PLS WIDTH-HI (ms) — —
PLS WIDTH-LOW (ms) — —Monitor item (Unit)SELECT MONITOR ITEM
Remarks
TCM INPUT
SIGNALSMAIN SIG-
NALSSELEC-
TION FROM
MENU
BCIA0031E
BCIA0031E
SAT018K

CVT-52
TROUBLE DIAGNOSIS

CAN DIAGNOSTIC SUPPORT MONITOR MODE
Operation Procedure
1. Touch “CAN DAIG SUPPORT MNTR” on “SELECT DIAG
MODE” screen. Refer to LAN-44, "
CAN Diagnostic Support
Monitor" .
SPORT MODE IND (ON/OFF) — — Not mounted but displayed.
MMODE IND (ON/OFF) — —
SMCOIL D (ON/OFF) — — Step motor coil “D” energizing status
SMCOIL C (ON/OFF) — — Step motor coil “C” energizing status
SMCOIL B (ON/OFF) — — Step motor coil “B” energizing status
SMCOIL A (ON/OFF) — — Step motor coil “A” energizing status
LUSEL SOL OUT (ON/OFF) — —
REV LAMP (ON/OFF) — X
STRTR RLY OUT (ON/OFF) — — Starter relay
LUSEL SOL MON (ON/OFF) — —
STRTR RLY MON (ON/OFF) — — Starter relay
VDC ON (ON/OFF) X — ESP (Electronic Stability Program)
TCS ON (ON/OFF) X —
ABS ON (ON/OFF) X —
ACC ON (ON/OFF) X — Not mounted but displayed
RANGE — XIndicates position is recognized by TCM. Indi-
cates a specific value required for control when
fail-safe function is activated
M GEAR POS — X
Voltage (V) — —Displays the value measured by the voltage
probe
Frequency (Hz) — —
The value measured by the pulse probe is dis-
played DUTY-HI (high) (%) — —
DUTY-LOW (low) (%) — —
PLS WIDTH-HI (ms) — —
PLS WIDTH-LOW (ms) — —Monitored item (Unit)Monitor item selection
Remarks ECU
INPUT
SIGNALSMAIN SIG-
NALSSELEC-
TION
FROM
MENU
BCIA0031E

CVT-58
DTC P0615 START SIGNAL CIRCUIT

TCM terminal data are reference values, measured between each terminal and ground.
Diagnostic ProcedureBCS001H4
1. CHECK STARTER RELAY
With CONSULT-II
1. Turn ignition switch ON. (Do not start engine.)
2. Select “SELECTION FROM MENU” in “DATA MONITOR” mode
for “TRANSMISSION” with CONSULT-II and check monitor
“STRTR RLY OUT”, “STRTR RLY MON”(PNP relay) ON/OFF.
Without CONSULT-II
1. Turn ignition switch ON. (Do not start engine.)
2. Check voltage between the TCM connector terminal and
ground.
OK or NG
OK >> GO TO 3.
NG >> GO TO 2.
2. DETECT MALFUNCTIONING ITEM
Check the following:

Starter relay. Refer to PG-77, "STANDARDIZED RELAY" .

Open or short-circuit in the harness between TCM and the stater relay. Refer to CVT-57, "Wiring Diagram
— CVT — STSIG" .

Ground circuit for the starter relay. Refer to SC-15, "Wiring Diagram — START —" .
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3. CHECK DTC
Perform “DTC Confirmation Procedure”. Refer to CVT-56, "
DTC Confirmation Procedure" .
OK or NG
OK >>INSPECTION END
NG >> GO TO 4.
TerminalWire
colorItem Condition Data (Approx.)
24 R/B Starter relaySelector lever in “N”, “P” positions. Battery voltage
Selector lever in other positions. 0 V
Item name Condition Display value
STRTR RLY OUTSelector lever in “P”, “N” positions. ON
Selector lever in other positions. OFF
STRTR RLY MONSelector lever in “P”, “N” positions. ON
Selector lever in other positions. OFF
Terminal Item Condition Data (Approx.)
24Starter
relaySelector lever in “N”, “P”
positions.Battery voltage
Selector lever in other posi-
tions.0 V
SCIA2274E
SCIA2022E

CVT-142
DTC P1722 ESTM VEHICLE SPEED SIGNAL

Diagnostic ProcedureBCS001L4
1. CHECK CAN COMMUNICATION LINE
Perform the self-diagnosis check. Refer to CVT-47, "
SELF-DIAGNOSTIC RESULT MODE" .
Is any malfunction of the
“U1000 CAN COMM CIRCUIT” indicated?
YES >> Check CAN communication line. Refer to CVT-53, "DTC U1000 CAN COMMUNICATION LINE" .
NO >> GO TO 2.
2. CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
Perform ABS actuator and electric unit (control unit) self-diagnosis check. Refer to BRC-17, "
Self-Diagnosis" .
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3. CHECK INPUT SIGNAL
With CONSULT-II
1. Start engine.
2. Select “SELECTION FROM MENU” in “DATA MONITOR” mode
for “TRANSMISSION” with CONSULT-II.
3. Drive vehicle and read out the value of “VEHICLE SPEED” and
“ESTM VSP SIG”.
4. Check if there is a great difference between the two values.
OK or NG
OK >> GO TO 5.
NG >> GO TO 4.
4. CHECK TCM
Check TCM input/output signal. Refer to CVT-40, "
TCM Input/Output Signal Reference Values" .
OK or NG
OK >> GO TO 5.
NG >> Repair or replace damaged parts.
5. CHECK DTC
Perform “DTC Confirmation Procedure”. Refer to CVT-141, "
DTC Confirmation Procedure" .
OK or NG
OK >>INSPECTION END
NG >> GO TO 2.
Item name Condition Display value
ESTM VSP SIG
During drivingApproximately matches
the speedometer reading
VEHICLE SPEED
SCIA4510E

DTC P1740 LOCK-UP SELECT SOLENOID VALVE CIRCUIT
CVT-149
D
E
F
G
H
I
J
K
L
MA
B
CVT

TCM terminal data are reference values, measured between each terminal and ground.
Diagnostic ProcedureBCS001LL
1. CHECK INPUT SIGNAL
With CONSULT-II
1. Turn ignition switch ON.
2. Select “SELECTION FROM MENU” in “DATA MONITOR” mode
for “TRANSMISSION” with CONSULT-II.
3. Read out the value of “LUSEL SOL OUT”.
Without CONSULT-II
1. Turn ignition switch ON.
2. Check voltage between TCM connector terminal and ground.
3. Turn ignition switch OFF.
4. Disconnect the TCM connector.
5. Check if there is continuity between connector terminal and ground.
OK or NG
OK >> GO TO 5.
NG >> GO TO 2.
2. CHECK LOCK-UP SELECT SOLENOID VALVE CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check resistance between TCM connector terminal and ground.
OK or NG
OK >> GO TO 5.
NG >> GO TO 3.
Terminal Wire color Item Condition Data (Approx.)
4LLock-up select
solenoid valveSelector lever in “P”, “N” positions Battery voltage
Wait at least for 5 seconds with the selector
lever in “R”, “D” positions0 V
Item name Condition Display value
LUSEL SOL OUTSelector lever in “P”, “N”
positions ON
Wait at least for 5 seconds
with the selector lever in
“R”, “D” positionsOFF
SCIA4512E
Name Connector Terminal ConditionVoltage
(Approx.)
Lock-up
select sole-
noid valveF106 4 - GroundSelector lever in “P”, “N”
positions Battery
voltage
Wait at least for 5 sec-
onds with the selector
lever in “R”, “D” positions0 V
SCIA4513E
Solenoid valve Connector TerminalResistance
(Approx.)
Lock-up select solenoid valve F106 4 - Ground 6 - 19 Ω
SCIA4692E

DTC P1777 STEP MOTOR - CIRCUIT
CVT-155
D
E
F
G
H
I
J
K
L
MA
B
CVT

TCM terminals data are reference values.
Diagnostic ProcedureBCS001LY
1. CHECK INPUT SIGNAL
With CONSULT-II
1. Start engine.
2. Select “SELECTION FROM MENU” in “DATA MONITOR” mode
for “TRANSMISSION” with CONSULT-II.
3. Start vehicle and read out the value of “STM STEP”, “SMCOIL
A”, “SMCOIL B”, “SMCOIL C”, and “SMCOIL D”.
OK or NG
OK >> GO TO 4.
NG >> GO TO 2.
2. CHECK HARNESS BETWEEN TCM AND STEP MOTOR
1. Turn ignition switch OFF.
2. Disconnect CVT unit connector and TCM connector.
3. Check continuity between TCM connector terminals and CVT
unit harness connector terminals.
4. If OK, check harness for short to ground and short to power.
5. If OK, check continuity between body ground and CVT assembly.
6. Reinstall any part removed.
OK or NG
OK >> GO TO 3.
NG >> Repair open circuit or short to ground or short to power in harness or connectors.
Terminal Wire color Item Condition Data (Approx.)
11 G/R Step motor A Within 2 seconds after ignition switch ON, the time measure-
ment by using the pulse width measurement function (Hi level) of
CONSULT-II.*1
CAUTION:
Connect the diagnosis data link cable to the vehicle diagno-
sis connector.
*1: A circuit tester cannot be used to test this item.30.0 msec
12 O/B Step motor B10.0 msec
20 R Step motor C30.0 msec
21 R/G Step motor D10.0 msec
Item name Condition Display value (Approx.)
STM STEP
During driving−20 step - 190 step
SMCOIL A
Changes ON⇔OFF SMCOIL B
SMCOIL C
SMCOIL D
SCIA4516E
Item Connector Terminal Continuity
TCM F106 11
Ye s
CVT unit harness connector F49 6
TCM F106 12
Ye s
CVT unit harness connector F49 7
TCM F106 20
Ye s
CVT unit harness connector F49 8
TCM F106 21
Ye s
CVT unit harness connector F49 9
SCIA4695E

WARNING CHIME
DI-65
C
D
E
F
G
H
I
J
L
MA
B
DI

Terminals and Reference Value for Combination MeterBKS001T5
CONSULT-II FunctionBKS001T6
CONSULT-II performs the following functions communicating with the BCM.
DIAGNOSTIC ITEMS DESCRIPTION
CONSULT-II BASIC OPERATION PROCEDURE
Refer to GI-34, "CONSULT-II Start Procedure" .
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which performs CAN communication.
DATA MONITOR
Operation procedure
1. Touch “BUZZER” on “SELECT TEST ITEM” screen.
2. Touch “DATA MONITOR” on “SELECT DIAG MODE” screen.
3. Touch “ALL SIGNALS” or “SELECTION FROM MENU” on “DATA MONITOR” screen.
4. If “SELECTION FROM MENU” is selected, touch the desired monitor item. If “ALL SIGNALS” is selected,
all items required to control are monitored.
5. Touch “START”.
6. During monitoring, touching “RECORD” can start recording the monitored item status.
TerminalWire
colorItem Measuring condition
Reference value
Ignition
switchOperation or condition
7 Y/R Battery power supply OFF — Battery voltage
8 P Ignition switch ON or START ON — Battery voltage
10
B Ground ON — Approx. 0V 11
12
18 G/BTX communication line (To
unified meter and A/C amp.)ON —
19 RRX communication line
(From unified meter and A/C
amp.)ON —
SKIA3361E
SKIA3362E
System Test Item Diagnosis mode Description
BCM BUZZERData monitor The input data to the BCM control unit is displayed in real time.
Active test Operation of electrical loads can be checked by sending driving signal to them.
ALL SIGNALS Monitors main items.
SELECTION FROM MENU Selects and monitors items.

ACTIVE AFS
LT-83
C
D
E
F
G
H
I
J
L
MA
B
LT

Operation Procedure (without VDC)
1. Stop the vehicle at the straight-ahead position under the unladen condition (seat 1 person on the driver's
seat).
2. Touch ADAPTIVE LIGHT” on “SELECT SYSTEM” screen.
3. Touch “WORK SUPPORT” on “SELECT DIAG MODE” screen.
4. Touch “ST ANG SEN ADJUSTMENT” on “SELECT WORK ITEM” screen.
5. Touch “START”.
CAUTION:
Never touch steering wheel while adjusting steering angle
sensor.
6. When “ADJUSTMENT COMPLETE” is displayed, touch “END”.
7. Touch “SELF-DIAG RESULTS” on “SELECT DIAG MODE”
screen.
8. Make sure that “NO DTC” is displayed.
When “ [B2520] ST ANGLE SEN CALIB” is displayed

If the steering is turned during the adjustment, perform the
adjustment again.

If any condition other than above exists, check the connection
conditions between steering angle sensor, AFS control unit,
CONSULT-II and harnesses, and then perform the adjustment
again. After the adjustment is completed, replace AFS control
unit if [B2520] is not erased from self-diagnostic results.
CAUTION:
If [U1000] CAN COMM CIRCUIT or [B2515] ST ANG SEN SIG is displayed, first refer to LT- 8 4 ,
"SELF-DIAG RESULTS" of self-diagnostic results, and then perform the diagnosis.
9. Turn ignition switch OFF, and then turn ON again.
CAUTION:
Never skip this step.
10. Drive the vehicle to the straight-ahead position, and then stop it.
11. Select “ST ANG SEN SIG” on “SELECTION FROM MENU” screen of “DATA MONITOR” of CONSULT-II.
Make sure that “ST ANG SEN SIG” is within 0 ± 2.5°. If it is other than 0 ± 2.5°, perform steps 1 to 10
again.
PKIA6818E
PKIB8781E

LT-162
TURN SIGNAL AND HAZARD WARNING LAMPS

CONSULT-II Functions (BCM)BKS001PV
CONSULT-II can display each diagnostic item using the diagnostic test mode shown following.
CONSULT-II BASIC OPERATION
Refer to GI-34, "CONSULT-II Start Procedure" .
DATA MONITOR
Operation Procedure
1. Touch “FLASHER” on “SELECT TEST ITEM” screen.
2. Touch “DATA MONITOR” on “SELECT DIAG MODE” screen.
3. Touch either “ALL SIGNALS” or “SELECTION FROM MENU” on “SELECT MONITOR ITEM” screen.
4. When “ALL SIGNALS” is selected, all the items will be monitored. When “SELECTION FROM MENU” is
selected, touch individual items to be monitored.
5. Touch “START”.
6. Touch “RECORD” while monitoring, then the status of the monitored item can be recorded. To stop
recording, touch “STOP”.
Display Item List
ACTIVE TEST
Operation Procedure
1. Touch “FLASHER” on “SELECT TEST ITEM” screen.
2. Touch “ACTIVE TEST” on “SELECT DIAG MODE” screen.
3. Touch item to be tested and check operation of the selected item.
4. During the operation check, touching “OFF” deactivates the operation.
Display Item List
BCM diagnosis part Diagnosis mode Description
FLASHERDATA MONITOR Displays BCM input data in real time.
ACTIVE TEST Operation of electrical loads can be checked by sending driving signal to them.
ALL SIGNALS Monitors all the items.
SELECTION FROM MENU Selects items and monitor them.
Monitor item Contents
IGN ON SW “ON/OFF” Displays “IGN position (ON)/OFF, ACC position (OFF)” judged from the ignition switch signal.
HAZARD SW “ON/OFF” Displays “hazard ON (ON)/hazard OFF (OFF)” status, determined from hazard switch signal.
TURN SIGNAL R “ON/OFF” Displays “turn right (ON)/other (OFF)” status, determined from lighting switch signal.
TURN SIGNAL L “ON/OFF” Displays “turn left (ON)/other (OFF)” status, determined from lighting switch signal.
CONSULT-II
screen displayTest item Description
FLASHER Turn signal lamp RH and LH
operation Turn signal lamp RH and LH are operated by switching operation (OFF, RH, LH).
(It is not blinking operation.)
