< SYSTEM DESCRIPTION >[BCM]
SYSTEM
COMBINATION SWITCH READING SYSTEM
COMBINATION SWITCH READING
SYSTEM : System DiagramINFOID:0000000009461990
COMBINATION SWITCH READING SY STEM : System DescriptionINFOID:0000000009461991
OUTLINE
• BCM reads the status of the combination switch (light, turn signal, wiper and washer) and recognizes the
status of each switch.
• BCM has a combination of 5 output terminals (OUTPU T 1 - 5) and 5 input terminals (INPUT 1 - 5) and reads
a maximum of 20 switch states.
COMBINATION SWITCH MATRIX
Intelligent Key system/engine start sys-
tem Door lock function
•
DLK-24, "DOOR LOCK FUNCTIO N : System Description"
(door
request switch) (if equipped)
• DLK-24, "DOOR LOCK FUNCTIO N : System Description"
(In-
telligent Key)
Trunk open function DLK-37, "TRUNK LID OPENER SYS
TEM : System Description"

(Intelligent Key)
Warning function DLK-33, "WARNING FUNCTIO N : System Description"
Key reminder functionDLK-29, "KEY REMINDER FUNCTION : System Description"
Engine start functionSEC-11, "INTELLIGENT KEY SYSTEM/ENGINE START FUNC-TION : System Description"
Power window system
•
PWC-10, "System Description" (LH front only anti-pinch)
• PWC-72, "System Description"
(LH & RH front anti-pinch)
RAP (retained accessory power) system BCS-28, "RETAINED PWR : CONSULT Function (BCM - RE-
TAINED PWR)"
TPMS (tire pressure
monitoring system) WT-9, "System Description"
System Refer to
AWMIA1215GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BCS
SYSTEMBCS-11
< SYSTEM DESCRIPTION > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
• The circuits between OUTPUT 1 and INPUT 5 and bet
ween OUTPUT 4 and INPUT 5 are formed when the
TURN RH switch and TAIL LAMP switch are turned ON.
• BCM detects the combination switch status signal “5AD” when the signals of OUTPUT 1 and OUTPUT 4 are
input to INPUT 5.
• BCM judges that the TURN RH switch and TAIL LAMP switch are ON when the signal “5AD” is detected.
WIPER INTERMITTENT DIAL POSITION SETTING
BCM judges the wiper intermittent dial 1 - 7 by the status of INT VOLUME 1, 2, and 3 switches.
SIGNAL BUFFER SYSTEM
SIGNAL BUFFER SYSTEM : System DiagramINFOID:0000000009461992
AWMIA1218GB
Wiper intermittent
dial position Switch status
INT VOLUME 1 INT VOLUME 2 INT VOLUME 3
1ONONON
2ONONOFF
3ONOFFOFF
4 OFF OFF OFF
5OFFOFFON
6 OFF ON ON
7 OFF ON OFF
AWMIA1275GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BCS-12
< SYSTEM DESCRIPTION >[BCM]
SYSTEM
SIGNAL BUFFER SYSTEM : System Description
INFOID:0000000009461993
OUTLINE
BCM has the signal transmission function that output s/transmits each input/received signal to each unit.
Signal transmission function list
POWER CONSUMPTION CONTROL SYSTEM
POWER CONSUMPTION CONTROL SYSTEM : System DiagramINFOID:0000000009461994
POWER CONSUMPTION CONTROL SY STEM : System DescriptionINFOID:0000000009461995
OUTLINE
• BCM incorporates a power saving control function t hat reduces the power consumption according to the
vehicle status.
• BCM switches the status (control mode) by itself wit h the power saving control function. It performs the sleep
request to each unit (IPDM E/R and combination mete r) that operates with the ignition switch OFF.
Normal mode (wake-up)
- CAN communication is normally performed with other units
- Each control with BCM is operating properly
CAN communication sleep mode (CAN sleep)
- CAN transmission is stopped
- Control with BCM only is operating
Low power consumption mode (BCM sleep)- Low power consumption control is active
- CAN transmission is stopped
LOW POWER CONSUMPTION CONTROL WITH BCM
BCM reduces the power consumption with the follo wing operation in the low power consumption mode.
• The reading interval of each switch changes from 10 ms interval to 60 ms interval.
Sleep mode activation
Signal name Input Output Description
• Ignition switch ON signal
• Ignition switch signal Engine switch (push switch) IPDM E/R (CAN) Inputs the push-button ignition
switch (push switch) signal and
transmits the ignition switch sta-
tus judged with BCM via CAN
communication.
Door switch signal Any door switch • Combination meter (CAN)
• IPDM E/R (CAN) Inputs the door switch signal
and transmits it via CAN com-
munication.
ALCIA0030GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BCS
BCM
BCS-55
< WIRING DIAGRAM > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
WIRING DIAGRAM
BCM
Wiring DiagramINFOID:0000000009462020
ABMWA2163GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BCS-56
< WIRING DIAGRAM >[BCM]
BCM
ABMWA2164GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BCS
BCM
BCS-57
< WIRING DIAGRAM > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
ABMWA2165GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BCS-58
< WIRING DIAGRAM >[BCM]
BCM
ABMWA2170GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

BCS
BCM
BCS-59
< WIRING DIAGRAM > [BCM]
C
D E
F
G H
I
J
K L
B
A
O P
N
ABMWA2166GB
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
