S Y STEM ON:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
The LDW indicator (white)inthe vehicle information
display willappear.
S Y STEM OFF:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
The LDW indicator (white)inthe vehicle information
display willoff.
Perform thefollowing stepstoenable ordisable the
LDW system.
1. Use the
button untilªSettingsº displaysinthe
vehicle information display.Use the
to select
ªDriver Assistanceº .Then press theENTER
button.
2. Select ªDriving Aidsº,and press theENTER
button.
3. To set the LDW system toon oroff, use the
buttons tonavigate inthe menu andusethe
ENTER buttontoselect ªLaneº andpress the
ENTER button.
WARNING:
. The camera unitmay notbeable todetect
properly underthefollowing conditions:
Ð On roads where therearemultiple
parallel lanemarkers; lanemarkers that
are faded ornot painted clearly;yellow
painted lanemarkers; nonstandard lane
markers; orlane markers coveredwith
water, dirt,snow, etc.
Ð On roads where thediscontinued lane
markers arestill detectable.
Ð On roads where therearesharp curves.
Ð On roads where therearesharply con-
trasting objects, suchasshadows,
snow, water, wheelruts,seams orlines remaining
afterroadrepairs. (TheLDW
system coulddetect theseitemsaslane
markers.)
Ð On roads where thetraveling lane
merges orseparates.
Ð When thevehicle's traveling direction
does notalign withthelane marker.
Ð When theroad surface isvery dark due
to weak ambient lightorimpaired tail
lamp.
. When driving onacurved road,warning will
be late onthe outside ofthe curve.
BSW/LDW TEMPORAR YDISABLED STA-
TUS
GUID-1B DDF44E-AF F2-4E00-9455-635AEAA 0FD68
Under thefollowing condition, theBSW and/or LDW
system isturned offtemporarily ,the BSW indicator
(white) and/orLDWindicator (white)willblink, andthe
following message willappear inthe vehicle informa-
tion display:
. ªBack DoorOpenº
When theabove condition iscorrected, theBSW and/
or LDW system willresume automatically .
BSW/LDW AUTOMA TICDEACTIV ATION
GUID-2F69D EE5-07A4-4D46-9DF 1-D415DC6 DE324
When dirt,rainorsnow accumulates onthe camera,
the BSW and/or LDWsystem willbeturned off
automatically andcannot beremoved bythe automatic
washer andblower. TheBSW indicator (white)and/or
LDW indicator (white)willblink, andtheªNot available
Clean RearCameraº message willappear inthe
vehicle information display.
Action totake:
If the message appears,parkthevehicle inasafe
place, cleanthecamera unitwith asoft cloth. Thenturn off
and restart theengine.
BSW/LDW MALFUNCTION
GUID-BE7 2994E-574 0-4BDE-86C 1-2EB349CD BE95
When theBSW and/or LDWsystem malfunctions,
they willbeturned offautomatically ,the BSW indicator
(orange) and/orLDWindicator (orange)willilluminate
and theªSystem faultºmessage willappear inthe
vehicle information display.
Action totake:
Stop thevehicle inasafe location, turnoffand restart
the engine. Ifthe BSW indicator (orange)and/orLDW
indicator (orange)continues toilluminate, havethe
BSW and/or LDWsystem checked byaNISSAN
dealer.
CAMERA UNITMAINTENANCE
GUID-0ED FD818-00A 6-4767-884 7-3673FFD 43878
JVS0393X
The rearview cameraunit
*
1
for the LDW/BSW
systems islocated abovetherear licence plate.To
maintain theproper operation ofthe LDW/BSW
systems andhelp keep thesystem functioning, be
sure toobserve thefollowing:
. Always keepthecamera unitclean. Becareful not
to damage thenozzle ofautomatic washerand
blower.
Starting anddriving
5-35
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
5-36
Starting anddriving
. Donot attach ªlicence plateaccessoriesº that
reflect light.
. Donot strike ordamage theareas around the
camera unit.
GUID-A E810235-F6F4 -41E0-95C7-57E6B64668A 9
The Blind SpotWarning (BSW) systemhelpsalertthe
driver ofother vehicles inadjacent laneswhen
changing lanes.
JVS0390X
The BSW system usestherearview cameraunit
*
1
with automatic washerandblower.
WARNING:
. The BSW system isnot areplacement for
proper driving procedure andisnot de-
signed toprevent contactwithvehicles or
objects. Whenchanging lanes,always use
the side andrear mirrors andturn andlook
in the direction youwillmove toensure itis
safe tochange lanes.Neverrelysolely on
the BSW system.
. The camera unitmay notfunction properly
under thefollowing conditions:
Ð When towing atrailer.
Ð When strong lightenters thecamera
unit. (Forexample, lightdirectly shines
on the rear ofthe vehicle atsunrise or
sunset.) Ð
When ambient brightness changessud-
denly. (Forexample, whenthevehicle
enters orexits atunnel orpasses under
a bridge.)
. Ifthe camera lensisexcessively dirty,the
automatic washermaynotbeable to
completely cleanthelens. Thiscould result
in the camera notdetecting vehiclesorlane
markers.
. Excessive noise(forexample, audiosystem
volume, openvehicle window) willinterfere
with thechime sound, anditmay notbe
heard.
BSW SYSTEM OPERA TION
GUID-1BE 5C541-A92F -45FC-8E28-F5276DC1762B
JVS0410X
Blind SpotIndicator light
BLIND SPOTWARNING (BSW)
S Y STEM (ifequipped forEurope)
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
SSD1029
BSW indicator (inthe Vehicle information display)
The BSW system operates aboveapproximately 32
km/h (20MPH) .
The BSW lightisshown inthe vehicle information
display ifthe Blind SpotWarning system isactive. To
switch thesystem onoroff, see thedescription laterin
this section.
When thecamera unitdetects vehicles inthe detection
zone, theBlind SpotIndicator lightlocated insidethe
outside mirrorswillilluminate. Ifthe turn signal isthen
activated, thesystem chimes (twice)andtheBlind
Spot Indicator lightflashes toalert thedriver.
The Blind SpotIndicator lightcontinues toflash until
the detected vehicle(s) leavethedetection zone.
Detection zone
GUID-2E5 8C740-C1EB -4970-9F18-8 C62C2600F46
SSD1026
The camera unitcan detect vehicles oneither sideof
your vehicle whenpartofanother vehicleiswithin the
detection zoneshown asillustrated.
This detection zonetypically startsfromtheoutside
mirror ofyour vehicle andextends approximately 3m
(10 ft)behind therear bumper, andapproximately 3m
(10 ft)sideways.
The brightness ofthe Blind SpotIndicator lightsis
adjusted automatically dependingonthe brightness of
the ambient light.
A chime sounds ifthe camera unithasalready
detected vehicleswhenthedriver activates theturn
signal. Ifa vehicle comesintothedetection zoneafter
the driver activates theturn signal, thenonlytheBlind
Spot Indicator lightflashes andnochime sounds. (See
ªBSW driving situationsº (P.5-33) .)
T urning onoroff the BSW system
GUID-14F6 DA85-8579-4 2BD-89B5-D01358F25 13E
The BSW system isturned onoroff using thesettings
menu inthe vehicle information display.
S Y STEM ON:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
The BSW indicator (white)inthe vehicle information
display willappear.
S Y STEM OFF:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
The BSW indicator inthe vehicle information display
will turn off.
Perform thefollowing stepstoenable ordisable the
BSW system.
1. Use the
button untilªSettingsº displaysinthe
vehicle information display.Use the
to select
ªDriver Assistanceº .Then press theENTER
button.
2. Select ªDriving Aidsº,and press theENTER
button.
3. To set the BSW system toon oroff, use the
buttons tonavigate inthe menu andusethe
ENTER buttontoselect ªBlind Spotºandpress
the ENTER button.
WARNING:
. The camera unitmay notbeable todetect
when certain objects arepresent suchas:
Ð Pedestrians, bicycles,animals
Ð Some typesofsmall vehicles suchas
motorcycles andvery short length vehi-
cles
Ð Oncoming vehicles
Ð Avehicle approaching rapidlyfrombe-
hind. (SeeªBSW driving situationsº (P.5-
33) .)
Starting anddriving
5-37
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
5-38
Starting anddriving
Ð Avehicle whichyourvehicle overtakes
rapidly. (SeeªBSW driving situationsº
(P .5-33) .)
Ð Avehicle thatmerges orchanges lanes
rapidly directly nexttoyour vehicle.
. The camera unitmay notbeable todetect
properly whenyourvehicle travelsbeside
the middle section ofavehicle withlong
wheelbase (forexample, trailertruck,semi-
trailer, tractor) .
. The camera detection zoneisdesigned
based onastandard lanewidth. When
driving inawider lane,thecamera unit
may notdetect vehicles inan adjacent lane.
When driving inanarrow lane,thecamera
unit may detect vehicles drivingtwolanes
away.
. The camera unitisdesigned toignore most
stationary objects,however objectssuchas
guardrails, walls,foliage andparked vehi-
cles may occasionally bedetected. Thisisa
normal operating condition.
. The camera unitmay detect thereflected
image ofvehicles orroadside objectsthat
are not actually inthe detection zone,
especially whentheroad iswet.
BSW DRIVING SITUATIONS
GUID-56 B2F3F6-CF DC-4A10-B 36D-98124CD83D96
Another vehicleapproaching frombehind
GUID-913 52549-C58 1-44A5-8079 -C8EA3638803B
SSD1026
The Blind SpotIndicator lightilluminates ifa vehicle
enters thedetection zonefrombehind inan adjacent
lane.
However, ifthe overtaking vehicleistraveling much
faster thanyourvehicle, theindicator lightmaynot
illuminate beforethedetected vehicleisbeside your
vehicle. Alwaysusetheside andrear mirrors andturn
and look inthe direction yourvehicle willmove to
ensure itis safe tochange lanes.
SSD1031
If the driver activates theturn signal, thentheBlind Spot
Indicator lightflashes andachime willsound
twice.
NO TE:
If the driver activates theturn signal before a
vehicle entersthedetection zone,theBlind Spot
Indicator lightwillflash butnochime willsound
when theother vehicle isdetected.
Overtaking othervehicles
GUID-32BB 934C-0EFB-4E88-94D8 -B2B5C81EBD28
SSD1033
The Blind SpotIndicator lightilluminates ifyou
overtake avehicle andthat vehicle staysinthe
detection zoneforapproximately 3seconds.
The camera unitmay notdetect slower moving
vehicles ifthey arepassed quickly.
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
SSD1034
If the driver activates theturn signal whileanother
vehicle isin the detection zone,thentheBlind Spot
Indicator lightflashes andachime willsound twice.
BSW TEMPORAR YDISABLED STATUS
GUID-0F E9D3F1-03F 8-43CE-BFD8-03D453 EFDB97
Under thefollowing condition, theBSW system is
turned offtemporarily ,the BSW indicator willblink, and
the following message willappear inthe vehicle
information display:
. ªBack DoorOpenº
When theabove condition iscorrected, theBSW
system willresume automatically .
BSW AUTOMA TICDEACTIV ATION
GUID-260373 8E-FAAD-45D6 -AA7E-7BC6 5AFF2F97
When dirt,rainorsnow accumulates onthe camera,
the BSW system willbeturned offautomatically and
cannot beremoved bythe automatic washerand
blower. TheBSW indicator willblink andtheªNot
available CleanRearCameraº message willappear in
the vehicle information display.
Action totake:
If the message appears,parkthevehicle inasafe
place, cleanthecamera unitwith asoft cloth. Thenturn
off and restart theengine.
BSW MALFUNCTION
GUID-DC9E 6DEC-176C-4 D78-A22D-716327A49A9 2
When theBSW system malfunctions, theywillbe
turned offautomatically ,the BSW indicator will
illuminate andtheªSystem faultºmessage willappear
in the vehicle information display.
Action totake:
Stop thevehicle inasafe location, turnoffand restart
the engine. Ifthe BSW indicator continues to
illuminate, havetheBSW system checked bya
NISSAN dealer.
CAMERA UNITMAINTENANCE
GUID-DB 9BD0F8-43C8-4F10 -BC52-E7E5A6 42BDCB
JVS0393X
The rearview cameraunit
*
1
for the BSW system is
located abovetherear licence plate.To maintain the
proper operation ofthe BSW system andhelp keep
the system functioning, besure toobserve the
following:
. Always keepthecamera unitclean. Becareful not
to damage thenozzle ofautomatic washerand
blower.
. Donot attach ªlicence plateaccessoriesº that
reflect light.
. Donot strike ordamage theareas around the
camera unit.
GUID-360 9F050-5091- 4101-96DB-2D 85C79F4D76
The Lane Departure Warning (LDW) system helps
alert thedriver whenthevehicle istraveling closeto
either theleftorthe right ofatraveling lane.
JVI0975X
The LDW system usesthemulti-sensing frontcamera
unit situated onthe windshield infront ofthe inside
rearview mirror
*
1
.
WARNING:
. This system isonly awarning deviceto
inform thedriver ofapotential unintended
lane departure. Itwill notsteer thevehicle or
prevent lossofcontrol. Itis the driver's
responsibility tostay alert, drivesafely, keep
the vehicle inthe traveling lane,andbein
control ofthe vehicle atall times.
. The system willnotoperate atspeeds below
approximately 60km/h (37MPH) orifit
cannot detectlanemarkers.
. Ifthe LDW system malfunctions, itwill
cancel automatically, andtheLDW ªSystem
faultº message willappear inthe vehicle
information display.
. Ifthe LDW ªSystem faultºmessage appears,
pull offthe road toasafe location andstop
Starting anddriving
5-39
LANE
DEPARTURE WARNING (LDW)
S Y STEM (ifequipped forEurope)
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
5-40
Starting anddriving
the vehicle. Turn theengine offand restart
the engine. Ifthe LDW ªSystem faultº
message continues toappear, havethe
system checked byaNISSAN dealer.
. Excessive noisewillinterfere withthewarn-
ing chime sound, andthechime maynotbe
heard.
The system maynotfunction properly underthe
following conditions:
. Onroads where therearemultiple parallellane
markers; lanemarkers thatarefaded ornot
painted clearly;yellowpainted lanemarkers;
non-standard lanemarkers; orlane markers
covered withwater, dirt,snow ,etc.
. Onroads where thediscontinued lanemarkers are
still detectable.
. Onroads where therearesharp curves.
. On roads where therearesharply contrasting
objects, suchasshadows, snow,water, wheel
ruts, seams orlines remaining afterroad repairs.
(The Lane Departure Warning (LDW) system
could detect theseitemsaslane markers.)
. On roads where thetraveling lanemerges or
separates.
. When thevehicle's travelingdirection doesnot
align withthelane marker.
. When traveling closetothe vehicle infront ofyou,
which obstructs thelane camera unitdetection
range.
. When rain,snow ordirt adheres tothe windshield
in front ofthe lane camera unit.
. When theheadlights arenot bright duetodirt on
the lens orifthe aiming isnot adjusted properly.
. When strong lightenters thelane camera unit.
(For example, thelight directly shinesonthe front of
the vehicle atsunrise orsunset.)
. When asudden changeinbrightness occurs.(For
example, whenthevehicle entersorexits atunnel
or under abridge.)
LDW SYSTEM OPERA TION
GUID-5D2 78735-FB2A-4 876-B549-D059C0E4D 50E
JVS0439X
SSD0672
LDW indicator (inthe Vehicle information display)
The LDW system provides alane departure warning
function whenthevehicle isdriven atspeeds
approximately 60km/h (37MPH) andabove.
When thevehicle approaches eithertheleftorthe right
side ofthe traveling lane,awarning chimewillsound
and theLDW indicator inthe vehicle information
display willblink toalert thedriver. The
warning function willstop when thevehicle returns
inside ofthe lane markers.
The LDW system isnot designed towarn under the
following conditions.
. When youoperate thelane change signaland
change traveling lanesinthe direction ofthe
signal. (TheLDW system willbecome operable
again approximately 2seconds afterthelane
change signalisturned off.)
. When thevehicle speedlowers toless than
approximately 60km/h (37MPH) .
After theabove conditions havefinished andthe
necessary operatingconditions aresatisfied, theLDW
functions willresume.
T urning onoroff the LDW system
GUID-32550F 0C-0E6C-49C3-92BB -00578BDFA0E5
The LDW system isturned onoroff using thesettings
menu inthe vehicle information display.
S Y STEM ON:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
The LDW indicator inthe vehicle information display
will appear.
S Y STEM OFF:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
The LDW indicator inthe vehicle information display
will off.
Perform thefollowing stepstoenable ordisable the
LDW system.
1. Use the
button untilªSettingsº displaysinthe
vehicle information display.Use the
to select
ªDriver Assistanceº .Then press theENTER
button.
2. Select ªDriving Aidsº,and press theENTER
button.
3. To set the LDW system toon oroff, use the
buttons tonavigate inthe menu andusethe
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
ENTER buttontoselect ªLaneº andpress the
ENTER button.
TEMPORAR YDISABLED STATUS AT HIGH
TEMPERA TURE
GUID-67A7 ECBE-6ACC- 40A7-9D0F-1C44280C8D 44
If the vehicle isparked indirect sunlight underhigh
temperature conditions(overapproximately 408C
(1048F) andthen started, theLDW system maybe
deactivated automatically .The ªHigh cabintempera-
tureº warning message willappear inthe vehicle
information display.
When theinterior temperature isreduced, theLDW
system willresume operating automatically .
MUL TI-SENSING CAMERAUNITMAINTE-
NANCE
GUID-C19 E3F82-C5B C-4AC8-B5 4F-DD97FCD DFBCC
JVI0975X
The multi-sensing cameraunit
*
1
for the LDW system
is located onthe windshield infront ofthe inside
rearview mirror.To maintain theproper operation ofthe
LDW system andprevent asystem malfunction besure
to observe thefollowing:
. Always keepthewindshield clean.
. Donot attach asticker (including transparent
material) orinstall anaccessory nearthemulti-
sensing lanecamera unit. .
Donot place reflective materials, suchaswhite
paper oramirror, onthe instrument panel.The
reflection ofsunlight mayadversely affectthe
multi-sensing cameraunit'sdetection capability.
. Donot strike ordamage theareas around the
camera unit.Donot touch thecamera lensor
remove thescrew located onthe camera unit.If
the camera unitisdamaged duetoan accident,
contact aNISSAN dealer.
GUID-790 A193B-4EB1 -4E55-89F5-8BFBAFBA 326A
The speed limiterallows youtoset the desired vehicle
speed limit.While thespeed limiterisactivated, the
driver canperform normalbraking andacceleration,
but thevehicle willnot exceed thesetspeed.
WARNING:
. Always observe postedspeedlimits.Donot
set the speed overthem.
. Always confirm thesetting statusofthe
speed limiter onthe vehicle information
display.
When thespeed limiterison, the cruise control system
cannot beoperated.
SPEED LIMITER OPERATIONS
GUID-7D727D 12-89FC-4770-A277-89 9333D04B46
The speed limitercanbeset ataspeed between 30to
200 km/h (20to124 MPH)
.
JVS0427X
The speed limitersetswitches arelocated onthe
steering wheel.
1. CANCEL switch
2. RES/+ switch
3. SET/


> (GLW    0RGHO 7$@
5-42
Starting anddriving
5. Speed limiterMAINswitch
(When thisswitch ispushed, thespeed limiter
enters thestandby mode.Ifthe cruise control
system ison, the system willturn offand the
speed limiterenters thestandby
mode.)
JVS0284X
The speed limiteroperating conditionisshown onthe
vehicle information display.
1. Speed limiterindicator
2. Setspeed indicator
The speed unitcanbeconverted betweenªkm/hºand
ªMPHº .(See ªVehicle information displayº(P.2-20) .)
When thevehicle speedexceeds thesetspeed limit,
the setspeed indicator blinksandtheaccelerator
pedal operation willnotwork untilthevehicle speed
slows downtothe setspeed limit.
The speed limiter willnotautomatically reduce
the vehicle speedtothe setspeed limit.
T urning onspeed limiter
GUID-E3 6A4E9E-7B02 -40E6-850F-C E30FD8CA1A8
Push thespeed limiterMAINswitch. Thespeed limiter
and thesetspeed indicators illuminateonthe vehicle
information display.
Setting speedlimit
GUID-207 6BDD2-77 12-4CD9-9E7 B-EA71752B2BC2
1. Push theSET/


> (GLW    0RGHO 7$@
set speed isexceeded anddriver intervention isnot
detected.
T urning thespeed limiteroff
GUID-604082 45-BB35-4F90-884A-8 3477F15BB08
The speed limitersystem willbeturned offwhen oneof
the following operations isperformed:
. Push thespeed limiterMAINswitch. Thespeed
limiter indicator andthesetspeed indicator onthe
vehicle information displaywillbeturned off.
. Push thecruise control MAINswitch. Thespeed
limiter information onthe vehicle information will
be replaced withthecruise control information.
For details seeªCruise controlº (P.5-43) .
. When thevehicle isstopped andtheignition is
placed tothe offposition.
T urning offthe speed limiterwillerase thesetspeed
limit memory .
Speed limitermalfunction
GUID-56D 8A157-AB4B- 4429-9C83-5333E82C8D98
If the speed limitermalfunctions, thespeed limiteron
the vehicle information displaywillflash.
T urn thespeed limiterMAINswitch offand have the
system checked byaNISSAN dealer.
T32A130 827-FF5B4 88B-DD40- 465E-8AD4-B D88C01B8 0E9
JVS0180X
Models without speedlimiter
JVS0427X
Models withspeed limiter
1. CANCEL switch
2. ACCELERA TE/RESUME switch
3. COAST/SET switch
4. Cruise control MAINswitch
5. Speed limiterMAINswitch
WARNING:
. Always observe theposted speedlimitsand
do not setthe speed overthem.
. Donot use thecruise control whendriving
under thefollowing conditions. Doingso
could cause aloss ofvehicle control and result
inan accident.
Ð When itis not possible tokeep the
vehicle ataconstant speed
Ð When driving inheavy traffic
Ð When driving intraffic thatvaries speed
Ð When driving inwindy areas
Ð When driving onwinding orhilly roads
Ð When driving onslippery (rain,snow, ice,
etc .)roads
CAUTION:
On manual Transmission (MT)model, donot
shift tothe ªNº (Neutral) positionwithout
depressing theclutch pedalwhenthecruise
control isoperated. Shouldthisoccur, depress
the clutch pedalandturn thecruise control MAIN
switch offimmediately. Failuretodo somay
cause engine damage.
PRECAUTIONS ONCRUISE CONTROL
T32A1308 27-DF670F 83-9B80-4A99-B18B-0 4CB9B1ECB D9
. Ifthe cruise control system malfunctions, itwill
cancel automatically .The CRUISE indicator inthe
vehicle information displaywillthen blink towarn
the driver.
. Ifthe CRUISE indicator blinks,turnthecruise
control MAINswitch offand have thesystem
checked byaNISSAN dealer.
. The CRUISE indicator mayblink when thecruise
control MAINswitch isturned ONwhile pushing
the ACCELERA TE/RESUME, COAST/SETor
CANCEL switch.To properly setthe cruise control
system, perform thefollowing procedures.
Starting anddriving
5-43
CRUISE
CONTROL (ifequippe d)
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
5-44
Starting anddriving
CRUISE CONTROL OPERATIONS
T32A1308 27-4BD70 071-615A-4B E0-8E01-02D3FB02318A
The cruise control allowsdriving atspeeds above40
km/h (25MPH) without keeping yourfootonthe
accelerator pedal.
For gasoline enginemodels, thecruise control will
automatically becanceled ifthe vehicle slowsdown
more thanapproximately 13km/h (8MPH) below the
set speed.
For diesel engine models, thecruise control will
automatically becanceled ifthe vehicle speedslows
to less than approximately 35km/h (22MPH) .
Moving theshift lever tothe ªNº (Neutral) positionwill
cancel andtheCRUISE indicator willoff.
T urning oncruise control
T32A1308 27-D9A26350-0978 -4C2D-81F7 -A433A8DD2D61
Push theMAIN switch. TheCRUISE indicator inthe
vehicle information displaywillappear.
Setting cruising speed
T32A1308 27-C830EB 0E-975B-4C 65-891B-9EDAAA4D8E3 E
1. Accelerate tothe desired speed.
2. Push theCOAST/SET switchandrelease it.
3. Take your footoffthe accelerator pedal.
The vehicle willmaintain thesetspeed.
Passing anothervehicle:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
Depress theaccelerator pedaltoaccelerate. After
releasing theaccelerator pedal,thevehicle willreturn
to the previously setspeed.
The vehicle maynotmaintain thesetspeed when
going upordown steep hills.Insuch cases, drive
without thecruise control. Resetting
toslower speed:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
Use anyone ofthe following methodstoreset toa
slower speed.
. Lightly tapthefoot brake pedal. When thevehicle
reaches thedesired speed,pushandrelease the
COAST/SET switch.
. Push andhold theCOAST/SET switch.Whenthe
vehicle reaches thedesired speed,release the
COAST/SET switch.
. Quickly pushandrelease theCOAST/SET switch.
This willreduce thevehicle speedbyabout 1km/h
or 1MPH.
Resetting tofaster speed:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
Use anyone ofthe following methodstoreset toa
faster speed.
. Depress theaccelerator pedal.Whenthevehicle
reaches thedesired speed,pushandrelease the
COAST/SET switch.
. Push andhold theACCELERA TE/RESUME
switch. Whenthevehicle reaches thedesired
speed, release theACCELERA TE/RESUME
switch.
. Quickly pushandrelease theACCELERA TE/
RESUME switch.Thiswillincrease thevehicle
speed byabout 1km/h or1MPH.
Resuming atpreset speed:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
Push andrelease theACCELERA TE/RESUME switch.
The vehicle willresume thelast setcruising speed
when thevehicle speedisover 40km/h (25MPH) .
Cancelling cruisingspeed
T32A130 827-D50DF32 4-B09E-4323-8AC9-3 5C0187CD15 A
Use anyone ofthe following methodstocancel theset
speed.
. Push theCANCEL switch.
. Tap the foot brake pedal.
. Push thecruise control MAINswitch. TheCRUISE
indicator willturn off.
&RQGLWLRQ
([FHSWIRU&KLQD
