Page 271 of 400
> ( G L W 0 R G H O 7 $ @
M1 ?
/ M2 ?
/ M3 ?
/ M4?
/ M5 ?
/ M6 ?
/ M7
. When shifting up,move theshift lever tothe +
(up) side. (Shifts tohigher range.)
. When shifting down,movetheshift lever tothe
Page 272 of 400
> ( G L W 0 R G H O 7 $ @
5-16
Starting anddriving
T ype A:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94A EAE0
JVS0392X
Example
1. Place theignition switchinthe ªOFFº orªLOCKº
position.
2. Apply theparking brake.
3. Remove theshift lockrelease cover(shown inthe
illustration above)usingasuitable tool.
4. Insert themechanical keyand push down theshift
lock release.
5. Press theshift lever button andmove theshift
lever tothe ªNº (Neutral) positionwhileholding
down theshift lockrelease. Replace theremoved
shift lockrelease coveraftertheoperation. T
ype B:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94A EAE0
JVS0466X
1. Place theignition switchinthe ªOFFº orªLOCKº
position.
2. Apply theparking brake.
3. Depress theshift lockrelease button.
4. Press theshift lever button andmove theshift
lever tothe ªNº (Neutral) positionwhileholding
down theshift lockrelease.
Place theignition switchinthe ªONº position to
release thesteering wheellock.
The vehicle maybemoved, bypushing, tothe desired
location.
If the shift lever cannot bemoved outofthe ªPº (Park)
position, haveaNISSAN dealerchecktheCVT system
as soon aspossible.
High fluidtemperature protectionmode
T32A1308 27-808BD 7D2-9BE0-4 70E-A660-24 B385D4FB8A
This transmission hasahigh fluidtemperature protec-
tion mode. Ifthe fluid temperature becomestoohigh
(for example, whenclimbing steepgrades inhigh
temperature withheavy loads),engine powerand,
under someconditions, vehiclespeedwillbede-
creased automatically toreduce thechance of
transmission damage.Vehicle speed canbecontrolled with
theaccelerator pedal,butengine andvehicle
speed maybelimited.
Fail-safe
T32A1308 27-5877C8 5B-EA11-4DD 6-9D52-6992317A74D 5
When thefail-safe operation occurs,theCVT willnot
be shifted tothe selected drivingposition.
If the vehicle isdriven underextreme conditions,
such asexcessive wheelspinning andsubse-
quent hardbraking, thefail-safe systemmaybe
activated. Thiswilloccur evenifall electrical
circuits arefunctioning properly.Inthis case,
turn theignition switchoffand wait for10
seconds. Thenplace theignition switchbackin
the ªONº position. Thevehicle shouldreturnto
its normal operating condition. Ifitdoes not
return toits normal operating condition, havea
NISSAN dealercheckthetransmission and
repair itifnecessary.
WARNING:
When thefail-safe operation occurs,vehicle
speed maybegradually reduced.Thereduced
speed maybelower thanother traffic,which
could increase thechance ofacollision. Be
especially carefulwhendriving. Ifnecessary, pull
to the side ofthe road atasafe place andallow
the transmission toreturn tonormal operation,
or have itrepaired ifnecessary.
& R Q G L W L R Q
( [ F H S W I R U & K L Q D
Page 273 of 400
> ( G L W 0 R G H O 7 $ @
DRIVING WITHMANUAL TRANSMISSION
(MT)
T32A1308 27-F9C2D0 EE-1C88-43FA-80B1 -BC9035D4 5F56
WARNING:
. Donot downshift abruptlyonslippery roads.
This maycause aloss ofvehicle control.
. Donot over-rev theengine whenshifting to
a lower gear.Thismay cause aloss of
vehicle control orengine damage.
CAUTION:
. Donot rest your footonthe clutch pedal
while driving. Thismay damage theclutch
system.
. Fully depress theclutch pedalbefore shift-
ing tohelp prevent transmission damage.
. Stop thevehicle completely beforeshifting
into theªRº(Reverse) position.
. When thevehicle isstopped foraperiod of
time, forexample waitingatstoplights, shift
to the ªNº (Neutral) positionandrelease the
clutch pedalwiththefoot brake pedal
depressed.
. Do not shift tothe ªNº (Neutral) position
while driving. Coasting withthetransmis-
sion inthe ªNº (Neutral) positionmaycause
serious damage tothe transmission.
Starting vehicle
T32A130827- 79841C26-BFA7-47DD-85A1- 81CD1AE3CABD
1. After starting theengine, depress theclutch pedal
to the floor andmove theshift lever tothe ª1º(1st)
or ªRº (Reverse) position.
2. Slowly depress theaccelerator pedal,releasing
the clutch pedalandparking brakeatthe same
time.
Shifting gear
T32A1308 27-BA6FF761 -6916-4D57-ADC5-14 9CCFDB8A1 0
T o change gears,orwhen upshifting ordownshifting,
fully depress theclutch pedal, shiftintotheappropriate
gear, thenslowly andsmoothly releasetheclutch
pedal.
T o ensure smooth gearchanges, fullydepress the
clutch pedalbefore operating theshift lever. Ifthe
clutch pedalisnot fully depressed beforethe
transmission isshifted, agear noise maybeheard.
T ransmission damagecouldoccur.
Start thevehicle inthe ª1º(1st) position andshift to
the ª2º(2nd) ,ª3º (3rd) ,ª4º (4th) ,ª5º (5th) andª6º
(6th) gearinsequence according tothe vehicle speed.
If itis difficult tomove theshift lever intotheªRº
(Reverse) orª1º (1st) position, shifttothe ªNº (Neutral)
position, andthen release theclutch pedalonce.Fully
depress theclutch pedalagainandshift intoªRºorª1º
.
SSD0552
. To back up,stop thevehicle andmove theshift
lever intotheªNº (Neutral) position,andthen pull
the ring
*
1
upward toshift intotheªRº (Reverse)
position.
. The pullring returns toits original position when
the shift lever ismoved tothe ªNº (Neutral)
position.
Suggested maximumspeedineach gear
T32A1308 27-751BC2 BE-4FBE-40E4-87B2-7F6A039719B A
Downshift toalower gearifthe engine isnot running
smoothly ,or ifyou need toaccelerate.
Do not exceed themaximum suggested speed(shown
below) inany gear. Forlevel road driving, usethe
highest gearsuggested forthat speed. Always observe
posted speedlimits,anddrive according tothe road
conditions whichwillensure safeoperation. Donot
over-rev theengine whenshifting toalower gearasit
may cause engine damage orloss ofvehicle control.
MR20DD enginemodel:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
km/h (MPH)
1st 45
(28)
2nd 79
(49)
3rd 110
(68)
4th 143
(89)
5th &6th Ð
(Ð)
Starting anddriving
5-17
& R Q G L W L R Q
( [ F H S W I R U & K L Q D
Page 274 of 400
> ( G L W 0 R G H O 7 $ @
5-18
Starting anddriving
R9M engine model:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
km/h (MPH)
1st 35
(22)
2nd 63
(39)
3rd 98
(61)
4th 136
(85)
5th &6th Ð
(Ð)
GEAR SHIFTINDICA TOR (ifequipped)
GUID-AE4B 246D-E5F4-49 10-9BC9-04131765976 2
JVS0331X
Gear ShiftIndicator appearsinthe vehicle information
display whenthedriver should shiftintoahigher or
lower gearasindicated bythe upordown arrow.
The useofGear ShiftIndicator willhelp toreduce fuel
consumption.
When theuparrow appears, upshifting isrecom-
mended. Whenthedown arrow appears, downshifting
is recommended.
CAUTION:
Gear ShiftIndicator helpstoreduce fuelcon-
sumption. Itdoes notrecommend theappro-
priate gearshiftforalldriving situations. Ina
certain situations, onlythedriver canselect the correct
gear(forexample, whenovertaking,
driving upasteep gradient ortowing atrailer) .
GUID-EB9 25B64-34B7-44CF-8 DDB-6D26A0E20FE2
The Stop/Start SystemorIdling StopSystem is
designed toprevent unnecessary fuelconsumption,
exhaust emissions, andnoise during ajourney:
. When youstop thevehicle withthebrake pedal
depressed (CVT)orwith theshift lever inªNº
(Neutral) andclutch pedalreleased (MT),the
engine isturned offautomatically .
. When yourelease thebrake pedal(CVT) orpush
the clutch pedal(MT),the engine isautomatically
turned on.
CAUTION:
At the end ofthe journey theengine mustbe
stopped andignition turnedoff.Lock thevehicle
as normal. Turning theignition switchOFFwill
shut down allelectrical systems.Failuretodo
this may result inaflat battery.
NO TE:
For model withStop/Start SystemorIdling Stop
System, usethespecial batterythatisenhanced
in regard tothe charge-discharge capacityand
life performance. Avoidusinganon-special
battery forthe Stop/Start SystemorIdling Stop
System, asthis may cause earlydeterioration of
the battery oramalfunction ofthe Stop/Start
System orIdling StopSystem. Forthebattery, it
is recommended touse Genuine NISSANparts.
For more information, contactaNISSAN dealer.
NO TE:
The Stop/Start SystemorIdling StopSystem
will notactivate underthefollowing conditions:
. when theengine iskept idling without any
driving aftertheengine isturned on.
ST OP/ST ARTSY STEM ORIDLING
ST OP SY STEM (ifequippe d)
& R Q G L W L R Q
( [ F H S W I R U & K L Q D
Page 275 of 400
> ( G L W 0 R G H O 7 $ @
. when theengine coolant temperature islow.
. when thebattery capacity islow.
. when thebattery temperature islow.
. when thevehicle ismoved.
. when thevacuum inthe brake servode-
creases.
. when theengine hoodisopened withthe
engine running.
. when theengine isturned onwith the
engine hoodopen.
. when thedriver's seatbeltisnot fastened.
. when thedriver's doorisopen.
. when thesteering wheelisoperated (for
CVT model) .
. when theStop/Start orIdling StopSystem
indicator blinksatalow speed.
. when thefan speed control isin any position
other thanªOFFº (0)while theairflow
control isin the front defogger position.
. when thefront defogger switchison.
. when thetemperature insidethevehicle is
too high orlow. (When theairconditioner is
off, theStop/Start SystemorIdling Stop
System willoperate.)
. when thefanspeed ofthe airconditioner is
set tothe maximum speed.
. when theStop/Start orIdling StopOFF
switch isturned on.
. when thepower consumption islarge.
. when thevehicle istraveling ataltitudes
higher than2,000 m(6,562 ft)(for MTmodel) .
. when thevehicle istravelling ataltitudes
higher than1500m (4922ft)(R9M engine in
combination withCVTmodels) . .
For Manual Transmission (MT)models
Ð when theshift lever isin any position
except theªNº(Neutral) position.
Ð when theclutch pedalisdepressed.
Ð when theIntelligent Keyisnot inthe
vehicle.
. For Continuously Variable Transmission
(CVT) models
Ð when theaccelerator pedalisdepressed.
Ð when theshift lever isin the ªRº(Reverse)
position.
Ð when thebrake pedalisnot firmly
depressed.
Ð when stopping thevehicle onsteep
sloping roads.
. when theelectric powersteering warning
light, theAnti-lock BrakingSystem(ABS)
warning light,orthe Vehicle Dynamic Con-
trol (VDC)/Electronic StabilityProgram
(ESP) warning lightilluminates.
NO TE:
The engine willnotrestart evenifthe brake
pedal isreleased (CVT)orclutch pedalis
pressed (MT)while theStop/Start Systemor
Idling StopSystem isactivated underthe
following condition:
. when theshift lever isin the ªPº(Park)
position (CVTmodel) .
. when theengine hoodisopened.
. when thedriver seatbeltisunfastened and
the driver's doorisopened (MTmodel) .
. when thegear shiftlever isnot inthe Neutral
position (MTmodels) . NO
TE:
It may take some timeuntil theStop/Start or
Idling StopSystem activates underthefollowing
conditions:
. when thebattery isdischarged.
. when theoutside temperature islow orhigh.
. when thebattery isreplaced orthe battery
terminal isdisconnected forextended peri-
ods and then reconnected.
NO TE:
When theStop/Start SystemorIdling Stop
indicator illuminates, theengine startsrunning
automatically underatleast oneofthe following
conditions:
. the brake pedalisreleased withtheshift
lever inthe ªDº(Drive) orªNº (Neutral)
position (forCVT model) .
. theshift lever isplaced inthe ªDº(Drive) or
ªRº (Reverse) positionfromtheªNº(Neutral)
or ªPº (Park) position (forCVT model) .
. the driver's seatbeltisunfastened, orthe
driver's doorisopen (forCVT model) .
. the battery voltage becomes low(due to
electrical loadfrom other vehicle systems
like headlights, heaters,etc.,or auxiliary
devices connected tothe 12volt socket
inside thevehicle) .
. the vehicle speedisabove about2km/h (1
MPH) .
. thefront defogger isoperated.
. when thetemperature insidethevehicle is
too high orlow. (When theairconditioner is
off, theStop/Start SystemorIdling Stop
System willoperate.)
Starting anddriving
5-19
& R Q G L W L R Q
( [ F H S W I R U & K L Q D
Page 276 of 400
> ( G L W 0 R G H O 7 $ @
5-20
Starting anddriving
. when thefront defogger isturned on.(The
engine maynotstarts depending onthe
outside temperature.)
. when morethan3minutes haveelapsed
since theStop/Start SystemorIdling Stop
System wasactive (forCVT model) .
. when theaccelerator pedalisdepressed (for
CVT model) .
. when thesteering wheelisoperated. (The
steering wheeloperation maybecome hea-
vy, but this isnot amalfunction.) (forCVT
model)
. when thebattery capacity islow.
. when thepower consumption ishigh.
. when theshift lever isplaced inthe ªRº
(Reverse) position(forCVT model) .
. when theclutch pedalisdepressed (forMT
model) .
CAUTION:
Only engage gearwhen theclutch pedalisfully
depressed (forMTmodel) .
NO TE:
The following conditions willprevent theStop/
Start System orIdling StopSystem fromauto-
matically restarting theengine. Starting the
engine withtheignition switchoperation isthen
necessary:
. the driver's seatbeltisunfastened, and
driver's doorisopen (forMTmodel) .
. thehood isopen.
Use thissystem whilewaiting atstoplight, etc.When
the vehicle isstopped forlong periods oftime, turnoff
the engine. When
theengine isstopped bythe Stop/Start System
or Idling StopSystem, heating,coolinganddehumi-
difying functions willbedeactivated. To avoid theair
conditioning functionsfrombeing deactivated, turnoff
the Idling Stopmode bypressing theStop/Start or
Idling StopOFFswitch.
ST OP/ST ARTSYSTEM ORIDLING STOP
S YSTEM DISPLA Y
GUID-D5 6CB066-F 6D6-49D2-8 2F7-415D89 07262F
Engine stop
GUID-78FE A13F-8F8D-4B 8D-BC97-67B76FF15 251
JVS0341X
When theengine isstopped theinformation is
displayed forafew seconds.
Stop/Start systemorIdling StopSystem ON
or OFF
GUID-6BC 66795-C2D6 -4F71-9A5B-5ECF0E05 EDF2
JVS0342X
If the Stop/Start SystemorIdling StopSystem is
activated ordeactivated usingtheStop/Start System
or Idling StopSystem OFFswitch, themessage is
shown.
CO2 orfuel saved andengine stoptime
GUID-D9 5A9EFA-4A9B-4 F92-9873-69 DBB336EB8 7
JVS0430X
The CO2 orfuel saved andtheengine stoptimemode
shows thefollowing items:
. The CO2 saved shows theestimated quantityof
CO2 exhaust emissions thatwere prevented by
the Stop/Start SystemorIdling StopSystem every
& R Q G L W L R Q
( [ F H S W I R U & K L Q D
Page 277 of 400
> ( G L W 0 R G H O 7 $ @
time theengine isautomatically stopped.(for
Europe andSouth Africa)
. The fuelsaved shows theestimated quantityof
fuel that were saved bythe Idling StopSystem
every timetheengine isautomatically stopped.(for
Australia andNew Zealand)
. The engine stoptimeshows thetime thatthe
engine hasbeen stopped forbythe Stop/Start
System orIdling StopSystem.
For more information, seeªStop/Start SystemorIdling
Stop Systemº (P.5-18) .
Auto startdeactivation
GUID-78F50 5B8-38CC-4 27B-9D35-5D4561F762 DD
JVS0344X
If the engine stopswhentheStop/Start Systemor
Idling StopSystem isactivated, andwillnotstart
automatically ,the message isshown.
K ey LOCK warning
GUID-64 20A844-934 9-439B-BBEA -8269875 E380C
JVS0345X
The information isdisplayed andabuzzer sounded to
remind thedriver toturn theignition switchOFFto
avoid aflat battery .
The message canonly becleared byturning or
pushing theignition switchOFF(orrestarting the
engine) .
System fault
GUID-A 7C9F39F-37 0C-4A3E-A35 A-DFC86 7451452
JVS0346X
This message isdisplayed whentheStop/Start
System orIdling StopSystem ismalfunctioning.
Have thesystem checked byaNISSAN dealer.
ST OP/ST ARTORIDLING STOP OFF
SWIT CH
GUID-FF12 3EDF-F41B -49DE-9498 -48D12056 2EA4
JVS0433X
The system canbetemporarily deactivated bypressing
the Stop/Start orIdling StopOFFswitch. Pressing the
switch againorrestarting theengine byusing the
ignition switchwillreactivate theStop/Start Systemor
Idling StopSystem.
. When theStop/Start SystemorIdling Stop
System isdeactivated whiletheengine isrunning,
the engine isprevented fromautomatically stop-
ping.
. When theStop/Start SystemorIdling Stop
System isdeactivated aftertheengine hasbeen
automatically stoppedbythe Stop/Start System
or Idling StopSystem, theengine willimmediately
restart ifsuitable conditions arepresent. The
engine willthen beprevented fromautomatically
stopping duringthesame journey .
. Whenever theStop/Start SystemorIdling Stop
System isdeactivated theindicator light
*
1
on
the Stop/Start orIdling StopOFFswitch illumi-
nates. Inthis condition theStop/Start Systemor
Idling StopSystem cannotprevent unnecessary
fuel consumption, exhaustemissions, ornoise
during yourjourney .
Starting anddriving
5-21
& R Q G L W L R Q
( [ F H S W I R U & K L Q D
Page 278 of 400
> ( G L W 0 R G H O 7 $ @
5-22
Starting anddriving
. Ifthe Stop/Start SystemorIdling StopSystem is
malfunctioning, theindicator light
*
1
on the Stop/
Start orIdling StopOFFswitch illuminates.
NO TE:
The Stop/Start SystemONorOFF messages
displayed forafew seconds inthe vehicle
information displaywhentheStop/Start or
Idling StopOFFswitch ispressed. SeeªStop/
Start system orIdling StopSystem ONorOFFº
(P .5-20) .
T32A1308 27-E8C4648 E-2B44-40A2 -A9F1-CD8F04FAE545
FOUR-WHEEL DRIVE(4WD) MODE
SWIT CHOPERA TIONS
T32A130827-E 9652442-23D3-4F57-A 857-6752C 8B9C890
JVS0401X
4WD mode switch
The Four-Wheel Drive(4WD) system isused toselect
the 2WD (Two-Wheel Drive),AUT Oor LOCK mode
depending onthe driving conditions.
T urn the4WD mode switch, located onthe center
console, toselect 2WD,AUTOor LOCK.
AUT O:Turn the4WD mode switch tothe neutral
(AUT O)position. TheFour-Wheel Drive(4WD) AUTO
indicator light
in the meter illuminates.
2WD: Turn the4WD mode switch clockwise tothe
2WD position.
L OCK: To engage theLOCK mode, turnthe4WD
mode switch counterclockwise tothe LOCK position.
The switch willreturn tothe AUTOposition auto-
matically andtheFour-Wheel Drive(4WD) LOCK
indicator light
in the meter illuminates. To
disengage theLOCK mode, turntheswitch tothe
L OCK position again.Theswitch willreturn tothe
AUT Oposition automatically ,and the4WD LOCK
indicator lightturns off.
FOUR-WHE ELDRIVE (4WD)(if
equipped)
& R Q G L W L R Q
( [ F H S W I R U & K L Q D
Page 279 of 400
> ( G L W 0 R G H O 7 $ @
4WD mode Wheelsdriven 4WD
mode indicator light (
,
) Use
conditions
2WD Front
wheels:
The wheel drivemode isin
T wo-Wheel Drive(2WD)
when driving onanormal road.
*1 T
urn off For
driving ondry,
paved roads
AUT O Distribution
oftorque tothe
front andrear wheels changes
automatically ,depending on
road conditions encountered
[ratio; 100:0 (2WD) ?50 :
50 (4WD)]. Thisresults in
improved drivingstability . Illuminates
For driving onpaved or
slippery roads
L OCK Four-Wheel
Drive(4WD)
*2*3* Illuminate
/
For driving onrough
roads
*1: The2WD mode maychange tothe 4WD mode automatically dependingonthe driving condition. The4WD
mode indicator lightdoes notilluminate.
*2: TheLOCK mode willchange tothe AUT Omode automatically whenthevehicle hasbeen driven atahigh
speed. The4WD LOCK indicator lightturns off.
*3: TheLOCK mode willautomatically becancelled whentheignition switchisplaced inthe ªOFFº position.
4WD shifttips
T32A130827- 36A0B76C-CF 6C-4546-B388-BD02E B8DB6F1
. Ifthe 4WD mode switch isoperated whilemaking
a turn, accelerating ordecelerating, orifthe
ignition switchisturned offwhile inthe AUT Oor
L OCK mode, youmay feelajolt. This isnormal.
. The oiltemperature ofpower trainparts will
increase ifthe vehicle iscontinuously operated
under conditions wherethedifference inrotation
between thefront andrear wheels islarge (wheel
slip) ,such aswhen driving thevehicle onrough
roads through sandormud orwhen freeing a
stuck vehicle. Inthese cases, theª4WD High
T emp. Stopvehicleº warning appears andthe
4WD mode changes tothe 2WD mode toprotect
the power trainparts. Ifyou stop driving withthe
engine idlinginasafe place andwait until the
ª4WD HighTemp. Stopvehicleº warning disap-
pears, the4WD returns tothe mode previously
selected.
. Brake distance inthe 4WD mode isthe same as
2WD.
CAUTION:
. Depending onthe driving condition, the4WD
mode mayautomatically changefrom2WD
to 4WD even when the2WD mode is
selected. Ifthis occurs whiledriving, the
4WD mode indicator lightwillnotilluminate.
. Donot start theengine withthe4WD mode
switch inany mode inthe following cases:
Ð when thevehicle isplaced onafree-
roller orjacking upthe vehicle withthe
front tiresraised andtherear tires on
the ground.
Starting anddriving
5-23
& R Q G L W L R Q
( [ F H S W I R U & K L Q D
Page 280 of 400
> ( G L W 0 R G H O 7 $ @
5-24
Starting anddriving
Ð when towing thevehicle withtherear
tires raised fromtheground.
. Operate the4WD mode switch onlywhen
driving straight. Donot operate the4WD
mode switch whenmaking aturn orbacking
up.
. Donot operate the4WD mode switch with
the front wheel spinning.
. Engine idlingspeed ishigh while warming
up the engine. Beespecially carefulwhen
starting ordriving onslippery surfaces with
the 4WD mode switch setinthe AUT Omode.
4WD WARNING
GUID-237 09BED-21 E1-4D10-B8 89-D097C5F3D412
If any malfunction occursinthe Four-Wheel Drive
(4WD) system whiletheengine isrunning, warning
messages appearinthe vehicle information display
.
JVS0411X
If the ª4WD system faultºwarning
*
1
appears, there
may beamalfunction inthe 4WD system. Reduce
vehicle speedandhave yourvehicle checked bya
NISSAN dealerassoon aspossible.
The ª4WD HighTemp. Stopvehicleº (hightempera-
ture) warning
*
2
may appear whiletrying tofree a
stuck vehicle duetoincreased oiltemperature. The
driving modemaychange toTwo-Wheel Drive(2WD) .
If this warning isdisplayed, stopthevehicle withthe
engine idling,assoon asitis safe todo so. Then ifthe
warning turnsoff,you can continue driving.
The ªTyre size incorrectº warning
*
3
may appear ifthere
isalarge difference betweenthediameters of
front andrear wheels. Pulloffthe road inasafe area,
with theengine idling.Check thatalltire sizes arethe
same, thatthetirepressure iscorrect andthat thetires
are not excessively worn.Change the4WD mode
switch tothe 2WD mode anddonot drive fast.
If any warning message continues tobe displayed,
have yourvehicle checked byaNISSAN dealeras
soon aspossible.
CAUTION:
. Donot operate theengine onafree roller
when anyofthe wheels raised.
. Ifthe ª4WD system faultºwarning appears
while driving, theremaybeamalfunction in
the 4WD system. Reducethevehicle speed
and have yourvehicle checked byaNISSAN
dealer assoon aspossible. Beespecially
careful whendriving.
. The power trainmaybedamaged ifyou
continue drivingwiththeª4WD system faultº
warning on.
4WD MODE INDICATOR LIGHTS
T32A130 827-36969 1F0-AE85-4F0 2-8C65-5AED24075D5A
The 4WD mode indicator lights(
,
) are
located inthe meter.
The 4WD mode indicator lights(
,
) illuminate
when theignition switchisplaced inthe ªONº position.
The indicator lightsturnoffwithin 1second.
The 4WD mode indicator lightswilldisplay themode
selected bythe 4WD mode switch whileengine is
running.
The 4WD LOCK indicator light
illuminates
simultaneously alongwiththe4WD AUTOindicator
light
when selecting theLOCK mode.
& R Q G L W L R Q
( [ F H S W I R U & K L Q D
