NISSAN X-TRAIL 2018 Owners Manual
Manufacturer: NISSAN, Model Year: 2018, Model line: X-TRAIL, Model: NISSAN X-TRAIL 2018Pages: 400, PDF Size: 8.75 MB
Page 321 of 400
> ( G L W 0 R G H O 7 $ @
SCE0367A
Remove theclamp holding thespare tire.
Spare tire(Three rowmodel)
GUID-2B977 AFD-78CE-45B8-AD6A-5 1FC23CEF 1AF
JVE0166X
The spare tireislocated undertheluggage floor-
boards.
Fold thethird rowseats flatand then remove the
luggage floorboard
*
1
. For folding thethird row
seats, seeªThird rowseatsº (P.1-6) .
Pull thestrap
*
2
to raise theseat.
Remove thecover
*
3
.
SCE0367A
Remove theclamp holding thespare tire.
BL OCKING WHEELS
T32A130 827-6A7B1 011-550C-43 58-9F60-727 F236E60FB
MCE0001D
WARNING:
Be sure toblock theappropriate wheelto
prevent thevehicle frommoving, whichmay
cause personal injury.
Place suitable blocks
*
1
at both thefront andback of
the wheel diagonally oppositetheflattire
*
A
to
prevent thevehicle frommoving whenitis jacked up.
In case ofemergency
6-5
& R Q G L W L R Q
( [ F H S W I R U & K L Q D
Page 322 of 400
> ( G L W 0 R G H O 7 $ @
6-6
In case ofemergency
REMOVING WHEELCOVER (ifequipped)
GUID-367 4401C-151D -43A1-9DF6-7296428 8CB88
SCE0630
WARNING:
Never useyour hands toremove thewheel
cover. Thismaycause personal injury.
T o remove thewheel cover, usethejack rod
*
1
as
illustrated.
Apply cloth
*
2
between thewheel andjack rodto
prevent damaging thewheel andwheel cover.
REMOVING TIRE
T32A1308 27-A4847D3 3-094A-426F- AC3E-6A473AA5D 740
JVE0165X
Jack -uppoints
Jacking upvehicle
T32A1308 27-DBAE999 F-CE6C-44E9 -9569-9ED9 514CF77B
SCE0574
WARNING:
. Besure toread andfollow theinstructions in
this section.
. DO NOTGET UNDER AVEHICLE THATIS
SUPPORTED BY A JACK .
. Never useajack which isnot provided with
your vehicle.
. The jack, which isprovided withyour vehicle,
is designed onlytolift your vehicle duringa
tire change. Donot use thejack provided
with your vehicle onother vehicles.
. Never jackupthe vehicle atalocation other
than thejack -uppoint thatisspecified.
. Never liftthe vehicle morethannecessary.
. Never useblocks onorunder thejack.
. Never startorrun theengine whilethe
vehicle ison the jack. Thevehicle maymove
suddenly, andthismay cause anaccident.
. Never allowpassengers toremain inthe
vehicle whilethetire isoff the ground. .
Besure toread thecaution labelattached to
the jack body before using.
1. Place thejack directly underthejack-up point as
illustrated sothat thetop ofthe jack contacts the
vehicle atthe jack-up point.
The jack should beplaced onfirm level
ground.
2. Align thejack head between thetwo notches
located atthe jack-up point ofeither thefront or
the rear section.
3. Fitthe groove ofthe jack head between the
notches asshown.
4. Loosen eachwheel nut,counterclockwise, oneor
two turns withthewheel nutwrench.
Do not remove thewheel nutsuntil thetire is
off the ground.
5. Carefully raisethevehicle untiltheclearance
between thetireand ground isachieved.
6. To lift the vehicle, securely holdthejack lever and
rod with both hands andturn thejack lever.
& R Q G L W L R Q
( [ F H S W I R U & K L Q D
Page 323 of 400
> ( G L W 0 R G H O 7 $ @
Removing tire
T32A1308 27-9C9287 25-DE13-45 24-B106-43C BCA933524
1. Remove thewheel nuts.
2. Remove thedamaged tire.
CAUTION:
The tireisheavy. Besure thatyour feetareclear
from thetire and usegloves asnecessary to
avoid injury.
INST ALLING SPARE TIRE
T32A1308 27-435AF232-C329 -432F-8AAD-7 473B8100EC 2
SCE0039
WARNING:
. Never usewheel nutswhich arenot provided
with your vehicle. Incorrect wheelnutsor
improperly tightenedwheelnutsmaycause
the wheel tobecome looseorcome off.This
could cause anaccident.
. Never useoilorgrease onthe wheel studs
or nuts. Thismaycause thewheel nutsto
become loose.
. The T-type spare tireisdesigned foremer-
gency useonly. 1.
Clean anymud ordirt from thesurface between
the wheel andhub.
2. Carefully putthespare tireonand tighten the
wheel nutswithyour fingers. Checkthatallthe
wheel nutscontact thewheel surface horizontally .
3. Tighten thewheel nutsalternately andevenly in
the sequence illustrated(
*
1
-
*
5
) , more than2
times withthewheel nutwrench, untilthey are
tight.
4. Lower thevehicle slowlyuntilthetire touches the
ground.
5. Tighten thewheel nutssecurely ,with thewheel
nut wrench, inthe sequence illustrated.
6. Lower thevehicle completely .
Tighten thewheel nutstothe specified torque
with atorque wrench assoon aspossible.
Wheel nuttightening torque:
108 N´m (11kg-m, 80ft-lb)
The wheel nutsmust bekept tightened to
specification atall times. Itis recommended
that thewheel nutsbetightened tospecification
at each lubrication interval.
WARNING:
Retighten thewheel nutswhen thevehicle has
been driven for1,000 km(600 miles) (alsoin
cases ofaflat tire, etc.).
For models equipped withTirePressure
Monitoring System(TPMS)
GUID-16DE 3A91-C3BF -444C-BA0B-738A18EB BE53
. After adjusting thetire pressure, theTPMS must
be reset. SeeªTire Pressure Monitoring System
(TPMS)º (P.6-2) ,ªTire Pressure Monitoring Sys-
tem (TPMS)º (P.5-4) andªTire Pressure Monitor-
ing System (TPMS)º (P.8-36) fordetails aboutthe
resetting procedure.
. After adjusting tirepressure tothe COLD tire
pressure, thedisplay ofthe tire pressures (if
equipped inthe vehicle information display)may
show higher pressure thantheCOLD tire
pressure afterthevehicle hasbeen driven more
than 1.6km(1mile) .This isbecause thetire
pressurizes asthe tire temperature rises.This
does notindicate asystem malfunction.
ST OWING DAMAGED TIREANDTOOLS
T32A1308 27-5EF8CC3 C-3891-4896-8173-496E49108424
WARNING:
. Besure thatthetire, jack andtools usedare
properly storedafteruse.Such items can
become dangerous projectilesinan accident
or sudden stop.
. The T-type spare tireisdesigned foremer-
gency useonly.
1. Securely storethedamaged tire,jack andtools
used inthe storage areainthe reverse orderof
removal. (SeeªPreparing toolsandspare tireº
(P .6-3) .)
2. Replace theluggage floorboards.
3. Close theback door.
In case ofemergency
6-7
& R Q G L W L R Q
( [ F H S W I R U & K L Q D
Page 324 of 400
> ( G L W 0 R G H O 7 $ @
6-8
In case ofemergency
NO TE:
When stowing thejack andtools, bundle and
fasten themusing theband included withthe
tool bag, before storing them.Otherwise the
tools maycontact eachother andproduce noise.
T32A130 827-A9A95 FA9-77F4-4C CA-AD10-3D 185CD2C553
WARNING:
. Incorrect jumpstarting canlead toabattery
explosion. Thebattery explosion mayresult
in severe injuryordeath. Itmay also result in
damage tothe vehicle. Besure tofollow the
instructions inthis section.
. Explosive hydrogengasisalways present in
the vicinity ofthe battery. Keepallsparks
and flames awayfromthebattery.
. Always wearsuitable eyeprotection and
remove rings,bracelets, andanyother jew-
elry whenever workingonornear abattery.
. Never leanover thebattery whilejump
starting.
. Never allowbattery fluidtocome into
contact witheyes, skin,clothes orthe
vehicle's paintedsurfaces. Batteryfluidisa
corrosive sulfuricacidwhich cancause
severe burns.Ifthe fluid comes intocontact
with anything, immediately flushthecon-
tacted areawithplenty ofwater.
. Keep thebattery outofthe reach ofchildren.
. The booster batterymustberated at12
volts. Useofan incorrectly ratedbattery will
damage yourvehicle.
. Never attempt tojump startafrozen battery.
It could explode andcause serious
injury.
JVE0160X
QR25 engine model
JVE0161X
MR20 engine model
JVE0193X
R9M engine model
JUMP STARTING
& R Q G L W L R Q
( [ F H S W I R U & K L Q D
Page 325 of 400
> ( G L W 0 R G H O 7 $ @
1. Ifthe booster batteryisin another vehicle
*
B
,
position thetwo vehicles
*
A
and
*
B
to bring the
batteries intoclose proximity toeach other.
CAUTION:
If the battery ofvehicle
*
A
equipped withthe
Intelligent Keysystem isdischarged, theignition
switch cannot bemoved fromtheªLOCKº
position and,ifthe steering lockisengaged,
the steering wheelcannot bemoved. Connect
the jumper cablestothe booster vehicle
*
B
before turning orpushing theignition switchand
disengaging thesteering lock.
2. Apply theparking brake.
3. Continuously Variable Transmission (CVT)model:
Move theshift lever tothe ªPº (Park) position.
Manual Transmission (MT)model: Movetheshift
lever tothe ªNº (Neutral) position.
4. Switch offallunnecessary electricalsystems
(headlights, heater,airconditioner, etc.).
5. Place theignition switchinthe ªLOCKº position.
6. Remove thevent caps, ifequipped, onthe battery .
7. Cover thebattery withafirmly wrung outmoist
cloth toreduce thehazard ofan explosion.
8. Connect thejumper cablesinthe sequence as
illustrated (
*
1
,
*
2
,
*
3
,
*
4
) .
CAUTION:
. Always connect positive +topositive +and
negative 7tobody ground, NOTto the
battery's negative7.
. Besure thatthejumper cablesdonot touch
moving partsinthe engine compartment. .
Besure thatthejumper cable's clamps do
not contact anyother metal.
9. Start theengine ofthe booster vehicle
*
B
and let
it run forafew minutes.
10. Depress theaccelerator pedalofthe booster
vehicle
*
B
at about 2,000 rpm.
11. Start theengine ofthe jumped vehicle
*
A
in the
normal manner.
CAUTION:
Never keepthestarter motorengaged formore
than 10seconds. Ifthe engine doesnotstart
right away, placetheignition switchªOFFºand
wait atleast 10seconds beforetryingagain.
12. After theengine isstarted, carefully disconnect
the jumper cablesinthe opposite sequence from
that illustrated (
*
4
,
*
3
,
*
2
,
*
1
) .
13. Remove anddispose ofthe cloth asitmay be
contaminated withcorrosive acid.
14. Replace thevent caps, ifremoved.
NO TE:
. For model withStop/Start SystemorIdling
Stop System, usethespecial batterythatis
enhanced inregard tothe charge-discharge
capacity andlifeperformance. Avoidusinga
non-special batteryforthe Stop/Start Sys-
tem orIdling StopSystem, asthis may cause
early deterioration ofthe battery oramal-
function ofthe Stop/Start SystemorIdling
Stop System. Forthebattery, itis recom-
mended touse Genuine NISSANparts.For
more information, contactaNISSAN dealer. .
For model withStop/Start SystemorIdling
Stop System, itmay take some timeuntil
Stop/Start SystemorIdling StopSystem
activates whenthebattery isreplaced orthe
battery terminal isdisconnected forex-
tended periods andthen reconnected.
In case ofemergency
6-9
& R Q G L W L R Q
( [ F H S W I R U & K L Q D
Page 326 of 400
> ( G L W 0 R G H O 7 $ @
6-10
In case ofemergency
T32A1308 27-F123FE9 F-EA80-4BD 4-8400-0FE8 D527FD22
Do not attempt tostart theengine bypushing the
vehicle.
CAUTION:
. Continuously Variable Transmission (CVT)/
Manual Transmission (MT)model cannot be
started bypushing. Attempting todo somay
cause damage tothe transmission.
. Three-way catalystequipped modelshould
not bestarted bypushing. Attempting todo
so may cause damage tothe three-way
catalyst.
. Never trytostart theengine bytowing.
When theengine starts,theforward surge
could cause thevehicle tocollide withthe
towing vehicle.
. Stop/Start SystemorIdling StopSystem
equipped modelcannot bestarted bypush-
ing the vehicle.
T32A130827- 0650D05A-CC 67-40AA-8C96-B273BCC7A50B
WARNING:
. Never continue drivingifyour vehicle over-
heats. Doingsocould cause avehicle fire.
. Never openthehood ifsteam iscoming out.
. Never remove theradiator orcoolant reser-
voir capwhile theengine ishot. Ifthe
radiator orcoolant reservoir capisremoved
when theengine ishot, pressurized hot
water willspurt outand possibly cause
burning, scalding orserious injury.
. Ifsteam orcoolant iscoming fromthe
engine, standclearofthe vehicle toprevent
getting burned.
. The engine cooling fancan start atany time
when thecoolant temperature exceedspre-
set degrees.
. Becareful nottoallow yourhands, hair,
jewelry orclothing tocome intocontact with,
or toget caught inthe cooling fanordrive
belts.
If your vehicle isoverheating (indicatedbythe high
temperature indicator),or ifyou feel alack ofengine
power, detectunusual noise,etc.,takethefollowing
steps:
1. Safely movethevehicle offthe road away from
traffic.
2. Turn onthe hazard indicator flasherlights.
3. Apply theparking brake.
4. Continuously Variable Transmission (CVT)model:
Move theshift lever tothe ªPº (Park) position.
Manual Transmission (MT)model: Movetheshift
lever tothe ªNº (Neutral) position.
DO NOTST OP THE ENGINE . 5.
Open allthe windows.
6. Turn offthe airconditioner. Movethetemperature
control tomaximum hotand thefancontrol tohigh
speed.
7. Get outfrom thevehicle.
8. Visually inspectandlisten forsteam orcoolant
escaping fromtheradiator beforeopening the
hood. Wait until nosteam orcoolant canbeseen
before proceeding.
9. Open theengine hood.
10. Visually inspectifthe cooling fanisrunning.
11. Visually inspecttheradiator andradiator hosesfor
leakage.
If the cooling fanisnot running orthe coolant is
leaking, stoptheengine.
12. After theengine coolsdown, checkthecoolant
level inthe reservoir withtheengine running. Do
not open theradiator cap.
13. Add coolant tothe reservoir ifnecessary .
Have yourvehicle inspected/repaired ataNISSAN
dealer.
PUSH STARTING IFYOUR VEHICLE OVERHEA TS
& R Q G L W L R Q
( [ F H S W I R U & K L Q D
Page 327 of 400
> ( G L W 0 R G H O 7 $ @
T32A1308 27-5ADBFD CE-C556-495F-8294-4EF D4BFC5099
When towing yourvehicle, localregulations fortowing
must befollowed. Incorrecttowingequipment could
damage yourvehicle. To assure propertowing andto
prevent accidental damagetoyour vehicle, NISSAN
recommends thatyouhave professional roadassis-
tance personnel towyour vehicle. Itis advisable to
have theprofessional roadassistant carefullyreadthe
following precautions.
T OWING PRECAUTIONS
T32A1308 27-7E42C15 2-10BF-4374-A885-0A3 D89794DC3
. Besure thatthetransmission, steeringsystem,
and drivetrain areinworking condition before
towing. Ifany units aredamaged, thevehicle must
be towed usingadolly orflatbed towtruck. (Two-
Wheel Drive(2WD) model)
. NISSAN recommends thatyour vehicle betowed
with thedriving (front)wheels offthe ground.
(T wo-Wheel Drive(2WD) model)
. Always attachsafetychains beforetowing.
. Never towFour-Wheel Drive(4WD) modelwith
any ofthe wheels onthe ground asthis may cause
serious andexpensive damagetothe drivetrain.
T OWING RECOMMENDED BY NISSAN
T32A1308 27-4F07BA 95-CC62-4AA4-95CD-C7 5F7896FA0C
T owing Two-Wheel Drive(2WD) model
T32A1308 27-20FA02AA-F81 7-48A2-B25 D-1D1DCBE 00315
JVE0167X
2WD model
JVE0168X
2WD model
Front wheels onthe ground:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
NISSAN recommends thattowing dolliesbeused
under thefront wheels whentowing yourvehicle orthe
vehicle beplaced onaflatbed towtruck asillustrated.
CAUTION:
Never towContinuously Variable Transmission
(CVT) model withthefront wheels onthe
ground. Doingsowill cause serious andexpen- sive
damage tothe drivetrain.
Manual Transmission (MT)model:
If you have totow aMT vehicle withfront wheel onthe
ground, perform thefollowing procedures.
1. Place theignition switchinthe ªOFFº position.
2. Secure thesteering wheelinastraight-ahead
position withrope orasimilar device.
3. Move theshift lever tothe ªNº (Neutral) position.
4. Release theparking brake.
5. Attach thesafety chains whenever towing.
Rear wheels onthe ground:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
1. Place theignition switchinthe ªOFFº position.
2. Move theshift lever tothe ªNº (Neutral) position.
3. Release theparking brake.
4. Attach safetychains whenever towing.
All four wheels onthe ground:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
NISSAN recommends thatthevehicle beplaced ona
flatbed towtruck asillustrated.
CAUTION:
Never towCVT model withallfour wheels onthe
ground. Doingsowill cause serious andexpen-
sive damage tothe drivetrain.
Manual Transmission (MT)model:
If you have totow aMT vehicle withallfour wheels on
the ground, perform thefollowing procedures.
CAUTION:
. Never towamanual transmission model
backward withallfour wheels onthe
ground.
In case ofemergen cy
6-11
T
OWING YOUR VEHICLE
& R Q G L W L R Q
( [ F H S W I R U & K L Q D
Page 328 of 400
> ( G L W 0 R G H O 7 $ @
6-12
In case ofemergency
1. Place theignition switchinthe ªOFFº position.
2. Move theshift lever tothe ªNº (Neutral) position.
3. Release theparking brake.
T owing Four-Wheel Drive(4WD) model
T32A130827- 693E447E-03E7-4D37-A2 93-4348DD 8C9B5B
JVE0169X
4WD model
JVE0170X
4WD model
NISSAN recommends thattowing dolliesbeused
under thefront orrear wheels whentowing your
vehicle orthe vehicle beplaced onaflatbed towtruck
as illustrated.
CAUTION:
Never tow4WD withanyofthe wheels onthe
ground. Doingsowill cause serious andexpen-
sive damage tothe drivetrain.
Freeing trapped vehicle
GUID-12A4 552C-8AF3 -492C-8958-3 AD857FAAFD4
WARNING:
. Never allowanyone tostand nearthetowing
line during thepulling operation.
. Never spinthetires athigh speed. Thiscould
cause themtoexplode andresult inserious
injury. Partsofthe vehicle couldalsoover-
heat andbedamaged.
. Donot pull thevehicle usingtherear hook
(except forEurope andIndonesia) .The rear
hook isnot designed topull thevehicle out
in the event thatthevehicle becomes
trapped.
In the event thatyour vehicle's tiresbecome trappedin
sand, snow,or mud, andthevehicle isunable tofree
itself without beingpulled, usetherecovery hooks.
. Use therecovery hooksonly.Do not attach the
pulling devicetoany other partofthe vehicle body.
Otherwise, thevehicle bodymaybedamaged.
. Use therecovery hookstofree avehicle only.
. The recovery hooksareunder tremendous stress
when usedtofree atrapped vehicle.Alwayspull
the pulling devicestraight outfrom thevehicle.
Never pullonthe recovery hooksatan angle. Front
:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94A EAE0
JVE0158X
Front
SCE0833
Front
*
1
Remove thehook cover fromthebumper witha
suitable tool.
*
2
Securely installtherecovery hookasillustrated.
(The hook isstored inthe storage area.)
Make surethattherecovery hookisproperly secured
in its storage areaafter use.
& R Q G L W L R Q
( [ F H S W I R U & K L Q D
Page 329 of 400
> ( G L W 0 R G H O 7 $ @
Rear:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94A EAE0
JVE0159X
Except forEurope andIndonesia
Except forEurope andIndonesia: Donot use therear
hook topull the
vehicle.
JVE0192X
For Europe andIndonesia
The rear hook isdesigned asthe recovery hook.
In case ofemergen cy
6-13
& R Q G L W L R Q
( [ F H S W I R U & K L Q D
Page 330 of 400
> ( G L W 0 R G H O 7 $ @
6-14
In case ofemergency
MEMO
& R Q G L W L R Q
( [ F H S W I R U & K L Q D
