2 Instruments and controls
Instrument panel ....................................................2-2
Meters and gauges ................................................2-3
Speedometer and odometer .............................2-3
Tachometer ........................................................2-5
Engine coolant temperature gauge ...................2-5
Fuel gauge ........................................................2-6
Compass and outside temperature display
(if so equipped) ......................................................2-6
Outside temperature display .............................2-6
Compass display ...............................................2-7
Warning/indicator lights and audible
reminders..............................................................2-10
Checking bulbs ................................................2-10
Warning lights .................................................. 2-11
Indicator lights .................................................2-13
Audible reminders............................................2-14
Security system ....................................................2-15
Vehicle security system (if so equipped).........2-15
Windshield wiper and washer switch ...................2-18
Switch operation ..............................................2-18
Rear window wiper and washer switch................2-19
Rear window defogger switch ..............................2-20Headlight and turn signal switch ..........................2-20
Headlight switch ..............................................2-20
Turn signal switch............................................2-21
Front fog light switch (if so equipped)..................2-22
Hazard warning flasher switch .............................2-22
Horn ......................................................................2-23
Cigarette lighter and ash tray (accessories) ........2-23
Power point (if so equipped) ................................2-24
Storage .................................................................2-25
Map pocket ......................................................2-25
Cup holders .....................................................2-26
Glove box ........................................................2-27
Console box (if so equipped) ..........................2-27
Luggage hooks (if so equipped) .....................2-28
Tonneau cover (if so equipped).......................2-29
Windows .............................................................2-30
Power windows (if so equipped) .....................2-30
Manual windows ..............................................2-31
Sunroof (if so equipped).......................................2-32
Tilting the sunroof ............................................2-32
Removing/installing..........................................2-33
Interior light...........................................................2-33
ZX

TILTING THE SUNROOF
Pull the handle down, then push the handle
up to the fully tilted position.The sunroof
cannot be removed.
WARNING
In an accident you could be thrown
from the vehicle through an open sun-
roof. Always use seat belts and child
restraints.
CAUTION
ODo not open sunroof when gear bas-
ket is in place.
OAlways remove the gear basket be-
fore opening sunroof. The sunroof
may be scratched if it is opened with
the gear basket in place.
For instructions to remove the gear
basket, refer to ``Roof rack with gear
basket'' in the ``Pre-driving checks
and adjustments'' section of this
manual.
ODo not allow anyone to stand up or
extend any portion of their body out
of the sunroof opening while the
vehicle is in motion.
ORemove water drops, snow, ice or
sand from the sunroof before open-
ing.
ODo not place heavy objects on the
sunroof or surrounding area.Pull the handle forward to unlock, then push
the handle up completely to lock the sunroof
closed.
A I C 1111AIC1112
SUNROOF
(if so equipped)
2-32Instruments and controls
ZX

REMOVING/INSTALLING
WARNING
Do not remove or install the sun shade
while driving so full attention may be
given to vehicle operation.
Sun shade
1. Turn each lock bolt counterclockwise
while supporting the sun shade.
2. Slide the shade backward to remove it.
3. Insert the two hooks on the front edge of
sun shade into holders on the sunroof.4. Align the two lock bolts on the rear edge
of sun shade with the lock nuts. Turn
each lock bolt clockwise to securely lock
the sun shade in place.
The dome light has a three-position switch
and operates regardless of ignition key
position.
OWhen the switch is in the OFF position,
the dome light does not illuminate, re-
gardless of door position.
OWhen the switch is in the centerjor
DOOR position, the dome light illumi-
nates by opening a door.
OWhen the switch is in the ON position,
the dome light illuminates regardless of
door position.
AIC1083IC1235M
INTERIOR LIGHT
Instruments and controls2-33
ZX

the defrost outlets to defrost/defog the win-
dows.
1. Turn the air control dial to the
posi-
tion.
2. Turn the fan control dial to the desired
position.
3. Push on the air conditioner button. The
indicator light comes on.
4. Turn the temperature control dial to the
desired position.
When the
,or positions in between
are selected, the air conditioner automati-
cally turns on (however the indicator light
will not illuminate) if the outside temperature
is more than 45ÉF(7ÉC). This dehumidifies
the air which helps defog the windshield.
The
mode automatically turns off, al-
lowing outside air to be drawn into the
passenger compartment to further improve
the defogging performance.
Operating tips
OKeep windows and sunroof closed while
the air conditioner is in operation.
OAfter parking in the sun, drive for two or
three minutes with the windows open tovent hot air from the passenger compart-
ment. Then, close the windows. This
allows the air conditioner to cool the
interior more quickly.
OThe air conditioning system should be
operated for approximately ten min-
utes at least once a month. This helps
prevent damage to the system due to
lack of lubrication.
OIf the engine coolant temperature
gauge indicates engine coolant tem-
perature over the normal range, turn
the air conditioner off. See ``If your
vehicle overheats'' in the ``In case of
emergency'' section of this manual.
AIR FLOW CHARTS
The following charts show the button and
dial positions forMAXIMUM AND QUICK
heating, cooling or defrosting.The air recir-
culation switch should always be in the
OFF position for heating and defrosting.
4-6Heater, air conditioner and audio systems
ZX

Steering wheel audio control switch .......... 4-30
Step rail...................................................... 3-12
Sun shade.................................................. 2-33
Sunroof ...................................................... 2-32
Supplemental restraint system
(Supplemental air bag system).................... 1-7
Switch
Automatic power window switch .......... 2-31
Hazard warning flasher switch ............. 2-22
Headlight and turn signal switch .......... 2-20
Ignition switch ......................................... 5-6
Rear window defogger switch .............. 2-20
Rear window wiper and washer
switches ................................................ 2-19
Windshield wiper and washer switch ... 2-18
T
Tachometer .................................................. 2-5
Theft warning ............................................. 2-15
Three-way catalyst....................................... 5-3
Tie down hooks.......................................... 2-28
Tilting steering wheel ................................. 3-14
Tire
Tire chains ............................................ 8-38
Tire placard ........................................... 9-14
Tire pressure......................................... 8-37
Tire rotation........................................... 8-39
Tires of 4-wheel drive ........................... 8-41
Types of tires ........................................ 8-38Uniform tire quality grading .................. 9-25
Wheels and tires................................... 8-37
Wheel/tire size ...................................... 9-10
Towing
2-wheel drive models ........................... 6-12
4-wheel drive models ........................... 6-13
Tow truck towing ................................... 6-11
Towing load/specification chart ............. 9-21
Trailer towing ........................................ 9-19
Transfer case ............................................. 5-18
Transmission
Automatic transmission fluid (ATF)....... 8-15
Driving with automatic transmission ....... 5-9
Driving with manual transmission ......... 5-13
Selector lever lock release ................... 5-12
Travel (See registering your vehicle in
another country)......................................... 9-12
Turn signal switch (See headlight and
turn signal switch) ...................................... 2-20
U
Uniform tire quality grading ....................... 9-25
V
Vehicle dimensions and weights................ 9-11
Vehicle identification number (VIN)
(chassis number) ....................................... 9-12Vehicle identification number (VIN) plate .. 9-12
Vehicle loading information........................ 9-15
Vehicle recovery ........................................ 6-14
Ventilators .................................................... 4-2
W
Warning
Air bag warning light............................. 1-14
Hazard warning flasher switch ............. 2-22
Theft warning ........................................ 2-15
Warning labels (for SRS)...................... 1-14
Warning/indicator lights and audible
reminders .............................................. 2-10
Weights (See dimensions and weights) .... 9-11
Wheels and tires ........................................ 8-37
Wheel/tire size ........................................... 9-10
When traveling or registering your vehicle
in another country ...................................... 9-12
Window washer fluid.................................. 8-18
Windows
Manual windows ................................... 2-31
Power windows..................................... 2-30
Windshield wiper and washer switch ........ 2-18
Wiper
Rear window wiper and washer
switches ................................................ 2-19
Windshield wiper and washer switch ... 2-18
Wiper blades......................................... 8-25
10-5
ZX
