Scheduled Maintenance
7-11
90,000 Miles (150 000 km)
Check Oil Life Monitor. If engine oil and filter are changed, reset monitor.
See ªEngine Oilº in the Index.
An Emission Control Service. (See footnote *.)
Replace air cleaner filter.
An Emission Control Service.
Inspect fuel tank, cap and lines for damage or leaks. Inspect fuel cap gasket
for any damage. Replace parts as needed.
An Emission Control Service. (See footnote
.)
Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
97,500 Miles (162 500 km)
Check Oil Life Monitor. If engine oil and filter are changed, reset monitor.
See ªEngine Oilº in the Index.
An Emission Control Service. (See footnote *.)
Rotate tires. See ªTire Inspection and Rotationº in the Index for proper
rotation pattern and additional information. (See footnote +.)
ACTUAL
SERVICED BY:MILEAGE
DATE
ACTUAL
SERVICED BY:MILEAGE
DATE
ProCarManuals.com

yellowblue
7-13
Part B: Owner Checks and Services
Listed in this part are owner checks and services which
should be performed at the intervals specified to help
ensure the safety, dependability and emission control
performance of your vehicle.
Be sure any necessary repairs are completed at once.
Whenever any fluids or lubricants are added to your
vehicle, make sure they are the proper ones, as shown
in Part D.
At Each Fuel Fill
It is important for you or a service station attendant to
perform these underhood checks at each fuel fill.
Engine Oil Level Check
Check the engine oil level and add the proper oil if
necessary. See ªEngine Oilº in the Index for
further details.Engine Coolant Level Check
Check the engine coolant level and add DEX
-COOL

coolant mixture if necessary. See ªEngine Coolantº in
the Index for further details.
Windshield Washer Fluid Level Check
Check the windshield washer fluid level in the
windshield washer tank and add the proper fluid if
necessary. See ªWindshield Washer Fluidº in the
Index for further details.
At Least Once a Month
Tire Inflation Check
Make sure tires are inflated to the correct pressures.
See ªTiresº in the Index for further details.
Cassette Deck Service
Clean cassette deck. Cleaning should be done every
50 hours of tape play. See ªAudio Systemsº in the
Index for further details.
ProCarManuals.com

yellowblue
7-15
Starter Switch Check
CAUTION:
When you are doing this check, the vehicle could
move suddenly. If it does, you or others could be
injured. Follow the steps below.
1. Before you start, be sure you have enough room
around the vehicle.
2. Firmly apply both the parking brake (see ªParking
Brakeº in the Index if necessary) and the
regular brake.
NOTE: Do not use the accelerator pedal, and be
ready to turn off the engine immediately if it starts.
3. Try to start the engine in each gear. The starter
should work only in PARK (P) or NEUTRAL (N).
If the starter works in any other position, your
vehicle needs service.Brake
-Transaxle Shift Interlock (BTSI) Check
CAUTION:
When you are doing this check, the vehicle could
move suddenly. If it does, you or others could be
injured. Follow the steps below.
1. Before you start, be sure you have enough room
around the vehicle. It should be parked on a
level surface.
2. Firmly apply the parking brake (see ªParking Brakeº
in the Index if necessary).
NOTE: Be ready to apply the regular brake
immediately if the vehicle begins to move.
3. With the engine off, turn the key to the ON position,
but don't start the engine. Without applying the
regular brake, try to move the shift lever out of
PARK (P) with normal effort. If the shift lever
moves out of PARK (P), your vehicle's BTSI
needs service.
ProCarManuals.com

yellowblue
7-16
Ignition Transaxle Lock Check
While parked, and with the parking brake set, try to turn
the ignition key to OFF in each shift lever position.
The key should turn to OFF only when the shift lever
is in PARK (P).
On all vehicles, the key should come out only in OFF.
Parking Brake and Automatic Transaxle PARK (P)
Mechanism Check
CAUTION:
When you are doing this check, your vehicle
could begin to move. You or others could be
injured and property could be damaged. Make
sure there is room in front of your vehicle in case
it begins to roll. Be ready to apply the regular
brake at once should the vehicle begin to move.
Park on a fairly steep hill, with the vehicle facing
downhill. Keeping your foot on the regular brake, set the
parking brake.

To check the parking brake's holding ability: With
the engine running and transaxle in NEUTRAL (N),
slowly remove foot pressure from the regular brake
pedal. Do this until the vehicle is held by the parking
brake only.

To check the PARK (P) mechanism's holding ability:
With the engine running, shift to PARK (P). Then
release all brakes.
Underbody Flushing Service
At least every spring, use plain water to flush any
corrosive materials from the underbody. Take care to
clean thoroughly any areas where mud and other debris
can collect.
ProCarManuals.com

yellowblue
8-12
CURRENT PUBLICATIONS FOR 1999 OLDSMOBILE
SERVICE MANUALS
Service Manuals have the diagnosis and repair information
on engines, transmission, axle, suspension, brakes,
electrical, steering, body, etc.
RETAIL SELL PRICE: $90.00
TRANSMISSION, TRANSAXLE, TRANSFER CASE
UNIT REPAIR MANUAL
This manual provides information on unit repair service
procedures, adjustments and specifications for the
1999 GM transmissions, transaxles and transfer cases.
RETAIL SELL PRICE: $50.00
SERVICE BULLETINS
Service Bulletins give technical service information needed
to knowledgeably service General Motors cars and trucks.
Each bulletin contains instructions to assist in the
diagnosis and service of your vehicle.OWNER'S INFORMATION
Owner publications are written directly for Owners and
intended to provide basic operational information about the
vehicle. The owner's manual will include the Maintenance
Schedule for all models.
In-Portfolio: Includes a Portfolio, Owner's Manual and
Warranty Booklet.
RETAIL SELL PRICE: $20.00
Without Portfolio: Owner's Manual only.
RETAIL SELL PRICE: $15.00
CURRENT & PAST MODEL ORDER FORMS
Service Publications are available for current and past
model GM vehicles. To request an order form, please
specify year and model name of the vehicle.
PLEASE COMPLETE THE ORDER FORM SHOWN ON
THE FOLLOWING PAGE AND MAIL TO:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207OR ORDER TOLL FREE: 1-800-551-4123
Monday-Friday 8:00 AM ± 6:00 PM Eastern Time
For Credit Card Orders Only (VISA±MasterCard±Discover)
1999 OLDSMOBILE SERVICE PUBLICATIONS ORDERING INFORMATION
The following publications covering the operation and servicing of your vehicle can be purchased by filling out
the Service Publication Order Form in this book and mailing it in with your check, money order,
or credit card information to Helm, Incorporated (address below.)
ProCarManuals.com

yellowblue
9-2
Brake (Continued)
System Warning Light 2-56, 6-25 . . . . . . . . . . . . . . . . . . . .
Trailer 4-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transaxle Shift Interlock 2-29, 7-15 . . . . . . . . . . . . . . . . . .
Transaxle Shift Interlock Check 7-15 . . . . . . . . . . . . . . . . . .
Wear 6-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brakes, Anti-Lock 2-57, 4-7 . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking in Emergencies 4-11 . . . . . . . . . . . . . . . . . . . . . . . . . .
Break-In, New Vehicle 2-15 . . . . . . . . . . . . . . . . . . . . . . . . . .
BTSI 2-29, 7-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BTSI Check 7-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulb Replacement 6-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Back-Up Lamp 6-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CHMSL 6-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Turn Signal Lamps 6-32 . . . . . . . . . . . . . . . . . . . . . . .
Headlamps 6-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Turn Signal Lamp 6-33 . . . . . . . . . . . . . . . . . . . . . . . .
Stoplamp 6-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Taillamp 6-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Capacities and Specifications 6-59 . . . . . . . . . . . . . . . . . . . .
Carbon Monoxide 2-12, 2-30, 4-29 . . . . . . . . . . . . . . . . . . . .
Care of Your Compact Disc Player 3-24 . . . . . . . . . . . . . . . . .
Cassette Deck Service 7-13 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cassette Tape Player 3-9, 3-13 . . . . . . . . . . . . . . . . . . . . . . . .
Cassette Tape Player Care 3-23 . . . . . . . . . . . . . . . . . . . . . . . .
CD Player 3-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CD Player Theft-Deterrent Feature 3-19 . . . . . . . . . . . . . . . . .
Center Console Storage Area 2-46 . . . . . . . . . . . . . . . . . . . . . .
Center High-Mounted Stoplamp Bulb Replacement 6-32 . . . .
Center Rear Passenger Position 1-35 . . . . . . . . . . . . . . . . . . . .
Certification Label 4-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Chains, Safety 4
-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chains, Tire 6-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Change Oil Light 2-66 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing a Flat Tire 5-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Charging System Indicator Light 2-55 . . . . . . . . . . . . . . . . . . .
Check Engine Light 2-62 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking Your Restraint Systems 1-54 . . . . . . . . . . . . . . . . . .
Chemical Paint Spotting 6-50 . . . . . . . . . . . . . . . . . . . . . . . . . .
Child Restraints 1-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Securing in a Rear Outside Seat Position 1-45 . . . . . . . . . . .
Securing in the Center Rear Seat Position 1-47 . . . . . . . . . .
Securing in the Right Front Seat Position 1-48 . . . . . . . . . .
Top Strap 1-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Where to Put 1-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Circuit Breakers and Fuses 6-53 . . . . . . . . . . . . . . . . . . . . . . .
Cleaner, Air 6-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning 6-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Aluminum Wheels 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fabric 6-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glass 6-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside of Your Vehicle 6-44 . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument Panel 6-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leather 6-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside of Your Vehicle 6-48 . . . . . . . . . . . . . . . . . . . . . . . .
Special Fabric Problems 6-45 . . . . . . . . . . . . . . . . . . . . . . . .
Stains 6-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vinyl 6-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheels 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield and Wiper Blades 6-47 . . . . . . . . . . . . . . . . . . .
Climate Control System 3-2 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clock, Setting the 3-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Comfort Controls 3-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ProCarManuals.com

yellowblue
9-3
Compact Disc Care 3-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compact Disc Player 3-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compact Disc Player Care 3-24 . . . . . . . . . . . . . . . . . . . . . . . .
Compact Spare Tire 5-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Control of a Vehicle 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Convenience Net 2-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Convex Outside Mirror 2-45 . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant 6-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding 6-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking 6-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Heater, Engine 2-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Surge Tank 5-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Surge Tank Pressure Cap 6-21 . . . . . . . . . . . . . . . . . . . . . . .
What to Use 6-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cooling System 5-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Courtesy Transportation 8-7 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cruise Control 2-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cruise Light 2-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Customer Assistance for Text Telephone Users 8-4 . . . . . . . . .
Customer Assistance Information 8-1 . . . . . . . . . . . . . . . . . . .
Customer Assistance Offices 8-4 . . . . . . . . . . . . . . . . . . . . . . .
Customer Satisfaction Procedure 8-2 . . . . . . . . . . . . . . . . . . . .
Damage, Finish 6-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Damage, Sheet Metal 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Daytime Running Lamps 2-40 . . . . . . . . . . . . . . . . . . . . . . . . .
Dead Battery 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Defects, Reporting Safety 8-10, 8-11 . . . . . . . . . . . . . . . . . . .
Defensive Driving 4-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Defogger, Rear Window 3-5 . . . . . . . . . . . . . . . . . . . . . . . . . .
Defogging 3-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Defrosting 3-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions, Vehicle 6-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dolby B Noise Reduction 3-12, 3-16 . . . . . . . . . . . . . . . . . . . Dome Lamp 2
-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Locks 2-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Drive, Automatic Over 2-24 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driver Position 1-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving
City 4
-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Defensive 4-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Drunken 4-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Freeway 4-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In a Blizzard 4-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In Foreign Countries 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
In the Rain 4-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Night 4-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
On Curves 4-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
On Grades While Towing a Trailer 4-40 . . . . . . . . . . . . . . .
On Hill and Mountain Roads 4-24 . . . . . . . . . . . . . . . . . . . .
On Snow and Ice 4-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Through Water 4-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wet Roads 4-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Winter 4-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
With a Trailer 4-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Drunken Driving 4-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical Equipment, Adding 2-19 2-48, 3-22, 6-53 . . . . . .
Electrical System 6-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine 6-9, 6-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant 6-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Heater 2-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Level Check 7-13 . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Temperature Gage 2-60 . . . . . . . . . . . . . . . . . . . . .
Exhaust 2-12, 2-30, 4-29 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse Block 6-56, 6-57, 6-58 . . . . . . . . . . . . . . . . . . . . . . . .
Identification 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil Level Check 7-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ProCarManuals.com

yellowblue
9-4
Engine (Continued)
Overheating 5-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Running While Parked 2-30 . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications 6-59 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting Your 2-17, 2-18 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Oil 6-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding 6-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Additives 6-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking 6-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pressure Light 2-64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Used 6-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
When to Change 6-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Oil, What Kind to Use 6-14 . . . . . . . . . . . . . . . . . . . . .
Exterior Lamps 2-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fabric Cleaning 6-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filling a Portable Fuel Container 6-7 . . . . . . . . . . . . . . . . . . . .
Filling Your Tank 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filter, Air 6-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Finish Care 6-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Finish Damage 6-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
First Gear, Automatic Transaxle 2-25 . . . . . . . . . . . . . . . . . . .
Flashers, Hazard Warning 5-2 . . . . . . . . . . . . . . . . . . . . . . . . .
Flash-to-Pass 2-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Flat Tire, Changing 5-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluids and Lubricants 7-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog Lamps 2-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Following Distance with a Trailer 4-39 . . . . . . . . . . . . . . . . . .
Foreign Countries, Fuel 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel 6-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filling Your Tank 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gage 2-68 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In Foreign Countries 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses and Circuit Breakers 6-53 . . . . . . . . . . . . . . . . . . . . . . .
Gages
Engine Coolant Temperature 2-60 . . . . . . . . . . . . . . . . . . . .
Fuel 2-68 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GAWR 4-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gear Positions, Automatic Transaxle 2-22 . . . . . . . . . . . . . . . .
Glove Box 2-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GM Mobility Program 8-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GM Vehicle Care 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gross Axle Weight Rating 4-33 . . . . . . . . . . . . . . . . . . . . . . . .
Gross Vehicle Weight Rating 4-33 . . . . . . . . . . . . . . . . . . . . . .
GVWR 4-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Halogen Bulbs 6-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hazard Warning Flashers 5-2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Head Restraints 1-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlamp Aiming 6-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlamps 2-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulb Replacement 6-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High/Low Beam Changer 2-34 . . . . . . . . . . . . . . . . . . . . . .
On Reminder 2-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hearing Impaired, Customer Assistance 8-4 . . . . . . . . . . . . . .
Heating 3-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High-Beam Headlamps 2-34 . . . . . . . . . . . . . . . . . . . . . . . . . .
Highway Hypnosis 4-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hill and Mountain Roads 4-24 . . . . . . . . . . . . . . . . . . . . . . . . .
Hitches, Trailer 4-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hood
Checking Things Under 6
-7 . . . . . . . . . . . . . . . . . . . . . . . . .
Release 6-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horn 2-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hydroplaning 4-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ProCarManuals.com

yellowblue
9-5
Ignition Positions 2-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Transaxle Lock Check 7-16 . . . . . . . . . . . . . . . . . . . .
Illuminated Entry/Exit 2-42 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inflation, Tire 6-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside Day/Night Rearview Mirror 2-44 . . . . . . . . . . . . . . . . .
Inspections 7-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake System 7-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Cooling System 7-17 . . . . . . . . . . . . . . . . . . . . . . . .
Exhaust System 7-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Drive Axle Boot 7-17 . . . . . . . . . . . . . . . . . . . . . . . . .
Front Drive Axle Seal 7-17 . . . . . . . . . . . . . . . . . . . . . . . . .
Radiator and Heater Hose 7-17 . . . . . . . . . . . . . . . . . . . . . .
Steering 7-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Suspension 7-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Throttle System 7-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument Panel 2-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning 6-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cluster 2-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse Block 6-53, 6-54, 6-55 . . . . . . . . . . . . . . . . . . . . . . . .
Intensity Control 2-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior Lamps 2-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jack, Tire 5-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jump Starting 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key Lock Cylinders Service 7-14 . . . . . . . . . . . . . . . . . . . . .
Keys 2-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Labels
Certification 4-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Parts Identification 6-52 . . . . . . . . . . . . . . . . . . . . . Tire
-Loading Information 4-32 . . . . . . . . . . . . . . . . . . . . . .
Vehicle Identification Number 6-52 . . . . . . . . . . . . . . . . . . .
Lamps 2-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exterior 2-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog 2-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior 2-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mirror Reading 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
On Reminder 2-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leaving Your Vehicle 2-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leaving Your Vehicle with the Engine Running 2-28 . . . . . . .
Lights
Air Bag Readiness 1
-25, 2-55 . . . . . . . . . . . . . . . . . . . . . . .
Anti-Lock Brake System Warning 2-57, 4-7 . . . . . . . . . . . .
Brake System Warning 2-52, 6-25 . . . . . . . . . . . . . . . . . . . .
Change Oil 2-66 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Charging System Indicator 2-55 . . . . . . . . . . . . . . . . . . . . . .
Check Engine 2-62 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cruise 2-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Oil Pressure Light 2-64 . . . . . . . . . . . . . . . . . . . . . .
Enhanced Traction System Active 2-59 . . . . . . . . . . . . . . . .
Enhanced Traction System Warning 2-58 . . . . . . . . . . . . . .
Interior 2-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Low Coolant Warning 2-60, 6-21 . . . . . . . . . . . . . . . . . . . .
Low Oil 2-65, 6-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Low Tire Pressure 2-61 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Low Wash 2-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil Pressure 2-64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Belt Reminder 1-8, 2-54 . . . . . . . . . . . . . . . . . . . . . .
Security 2-66 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Engine Soon 2-62 . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Vehicle Soon 2-67 . . . . . . . . . . . . . . . . . . . . . . . . . .
Loading Your Vehicle 4-32 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lock Out Switch 2-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ProCarManuals.com

yellowblue
9-6
Locks 2-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cylinders 7-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door 2-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key Lock Cylinder Service 7-14 . . . . . . . . . . . . . . . . . . . . .
Power Door 2-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Door Security 2-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Low Coolant Warning Light 2-60, 6-21 . . . . . . . . . . . . . . . . .
Low Oil Light 2-65, 6-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Low Tire Pressure Light 2-61 . . . . . . . . . . . . . . . . . . . . . . . . . .
Lubricants and Fluids 7-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lubrication Service, Body 7-14 . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance, Normal Replacement Parts 6-60 . . . . . . . . . . .
Maintenance Record 7-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance Schedule 7-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Introduction 7-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Owner Checks and Services 7-13 . . . . . . . . . . . . . . . . . . . . .
Periodic Maintenance Inspections 7-17 . . . . . . . . . . . . . . . .
Recommended Fluids and Lubricants 7-18 . . . . . . . . . . . . .
Scheduled Maintenance Services 7-4 . . . . . . . . . . . . . . . . . .
Maintenance, Underbody 6-50 . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance When Trailer Towing 4-41 . . . . . . . . . . . . . . . . .
Making Turns with a Trailer 4-39 . . . . . . . . . . . . . . . . . . . . . .
Malfunction Indicator Lamp 2-62 . . . . . . . . . . . . . . . . . . . . . .
Manual Front Seat 1-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual Remote Control Mirror 2-44 . . . . . . . . . . . . . . . . . . . .
Methanol 6-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mirror Reading Lamps 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mirrors 2-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Convex Outside 2-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside Day/Night Rearview 2-44 . . . . . . . . . . . . . . . . . . . . .
Manual Remote Control 2-44 . . . . . . . . . . . . . . . . . . . . . . . .
Outside 2-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Power Remote Control 2
-45 . . . . . . . . . . . . . . . . . . . . . . . . .
Visor Vanity 2-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mountain Roads 4-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Multifunction Lever 2-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Net, Convenience 2-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Neutral, Automatic Transaxle 2-23 . . . . . . . . . . . . . . . . . . . . .
New Vehicle ªBreak-Inº 2-15 . . . . . . . . . . . . . . . . . . . . . . . . .
Night Vision 4-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Odometer 2-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Odometer, Trip 2-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Off-Road Recovery 4-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil, Engine 6-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil Pressure Light 2-64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside Mirror 2-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overheating Engine 5-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Owner Checks and Services 7-13 . . . . . . . . . . . . . . . . . . . . . . .
Owner Publications, Ordering 8-11, 8-12, 8-13 . . . . . . . . . . .
Paint Spotting, Chemical 6-50 . . . . . . . . . . . . . . . . . . . . . . . .
Park
Shifting Into 2
-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shifting Out of 2-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Park, Automatic Transaxle 2-22 . . . . . . . . . . . . . . . . . . . . . . . .
Parking
At Night 2
-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake 2-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake Mechanism Check 7-16 . . . . . . . . . . . . . . . . . . . . . . .
Lots 2-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Over Things That Burn 2-29 . . . . . . . . . . . . . . . . . . . . . . . .
With a Trailer 4-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ProCarManuals.com
