2-42 Cruise Control
The cruise control buttons are located on the
steering wheel.
With cruise control, you can maintain a speed of about
25 mph (40 km/h) or more without keeping your foot
on the accelerator. This can really help on long trips.
Cruise control does not work at speeds below
25 mph (40 km/h).
The cruise control will turn off when any of the
following occur:

The brakes are applied,

the clutch is applied (manual transaxle),
the parking brake is applied, or

the brake system warning light is on.
CAUTION:

Cruise control can be dangerous where
you can't drive safely at a steady speed.
So, don't use your cruise control on
winding roads or in heavy traffic.

Cruise control can be dangerous on
slippery roads. On such roads, fast changes
in tire traction can cause needless wheel
spinning, and you could lose control.
Don't use cruise control on slippery roads.
If your vehicle is in cruise control when the enhanced
traction system begins to limit wheel spin, the cruise
control will automatically disengage. See ªEnhanced
Traction Systemº in the Index. When road conditions
allow you to safely use it again, you may turn the cruise
control back on.

2-45
Using Cruise Control on Hills
How well your cruise control will work on hills depends
upon your speed, load and the steepness of the hills.
When going up steep hills, you may have to step on the
accelerator pedal to maintain your speed. When going
downhill, you may have to brake or shift to a lower gear to
keep your speed down. Of course, applying the brake takes
you out of cruise control. Many drivers find this to be too
much trouble and don't use cruise control on steep hills.
Ending Out of Cruise Control
There are five ways to turn off the cruise control:

Step on the brake pedal.

Press the cruise control CANCEL button.

Press the cruise control RES ACCL button and the
CST SET buttons at the same time.

Press the cruise control ON OFF button. The
indicator light above the cruise control button will
turn off.

Push the clutch pedal if your vehicle has a manual
transaxle.Erasing the Cruise Speed Memory
When you turn off the cruise control or the ignition,
your cruise control set speed memory is erased.
Exterior Lamps
The lever on the left side of the steering column
operates the exterior lamps.
: Turn the outside part of the lever with the symbol
on it, to operate the lamps.

3-3
Mode Buttons
A/C (Air Conditioning): Press A/C to operate the
air conditioning. The light will glow when the button is
pressed to indicate that the air conditioning system has
been turned on. The fan knob must be set to a speed for
the air conditioning to operate.
(Outside Air): Press this button to force the
system to use outside air.
Pressing this button will cancel the recirculation button.
(Recirculation): Press this button to limit the
amount of outside air entering your vehicle. This is
helpful when you are trying to limit odors entering
your vehicle. Press it again to turn off the recirculation.
Pressing this button will cancel the outside air button.
Recirculation is not available when the defog or front
defroster mode is selected, or when the fan is off. When
recirculation is selected, the air conditioning compressor
will run automatically to help dry the air in the vehicle.
Air Conditioning
The air conditioner and heater work best if you keep
your windows closed while using them. Your vehicle
also has the flow
-through ventilation system described
later in this section.
For normal cooling on hot days, use vent mode with the
temperature knob in the blue area and the A/C button
pressed in.
On very hot days, begin by opening the windows long
enough to let hot inside air escape. This reduces the time
it takes for your vehicle to cool down, which should
help fuel economy.
For quicker cool
-down on very hot days, use vent mode
with the temperature knob all the way in the blue area
and the A/C button pressed in. Begin with the outside air
button pressed for a few minutes, or until the vehicle
begins to feel cool. Then push the recirculation button.
If the recirculation setting is used for long periods of
time, the air in your vehicle may become too dry.

3-8
SCV (Speed-Compensated Volume): With SCV, your
audio system adjusts automatically to make up for road
and wind noise as you drive. Set the volume at the
desired level. Press this button to select MIN, MED or
MAX. Each higher choice allows for more volume
compensation at faster vehicle speeds. Then, as you
drive, SCV automatically increases the volume, as
necessary, to overcome noise at any speed. The volume
level should always sound the same to you as you drive.
If you don't want to use SCV, select OFF.
RCL (Recall): Press this button to display the time
with the ignition on or off. When the radio is playing,
press this knob to display the station frequency.
Finding a Station
BAND: Press this button to switch between AM, FM1
and FM2. The display shows your selection.
TUNE: Turn this knob to select radio stations.

SEEK
: Press the right or left arrow to go to the
next or previous station and stay there. The radio will
seek to stations with a strong signal only. The sound
will mute while seeking.


SCAN
: Press and hold either arrow for two
seconds until SC appears on the display and you hear
a beep. The radio will go to a station, play for a few
seconds, then go on to the next station. Press either
arrow again to stop scanning. The radio will scan to
stations with a strong signal only. The sound will mute
while scanning.
To scan preset stations, press and hold either SCAN
arrow for more than four seconds, PRESET SCAN will
appear on the display. You will hear a double beep and
the P will blink with the preset number. The radio will
go to the first preset station stored on your pushbuttons,
play for a few seconds, then go on to the next preset
station. Press either SCAN arrow again to stop scanning
presets. The radio will scan preset stations with a strong
signal only. The sound will mute while scanning.

3-9
Setting Preset Stations
The six numbered pushbuttons let you return to
your favorite stations. You can set up to 18 stations
(six AM, six FM1 and six FM2), by performing the
following steps:
1. Turn the radio on.
2. Press BAND to select AM, FM1 or FM2.
3. Tune in the desired station.
4. Press AUTO EQ to select the equalization that best
suits the type of station selected.
5. Press and hold one of the six numbered pushbuttons
until you hear a beep. Whenever you press that
numbered pushbutton, the station you set will return
and the equalization that you selected will also be
automatically selected for that pushbutton.
6. Repeat the steps for each pushbutton.Setting the Tone (Bass/Treble)
AUDIO: Press and release the AUDIO button until
BASS, MID or TREB appears on the display. Press the
knob above the AUDIO button to extend it, then turn the
knob to increase or decrease. When you use this knob,
the radio's tone setting will switch to manual. If a station
is weak or noisy, you may want to decrease the treble.
Pressing and holding the AUDIO button for at least
two seconds will return all tone settings, including
balance and fade, to flat.
AUTO EQ (Automatic Equalizer): This feature
allows you to choose preset bass, midrange and treble
equalization settings designed for country, jazz, talk,
pop, rock and classical program types.
The program type last chosen will appear on the display
when you first press AUTO EQ. Each time you press
this button, another program type will appear on the
display and AUTO EQ will switch to one of the preset
program types.
To return to the manual mode, press the AUTO EQ
button until MANUAL appears on the display. Then
you will be able to manually adjust the bass, midrange
and treble using the AUDIO button.

3-12
Setting PTY Preset Stations
The six numbered pushbuttons let you return to your
favorite Program Types (PTYs). These pushbuttons have
factory PTY presets. You can set up to 12 PTYs (six
FM1 and six FM2) by performing the following steps:
1. Press BAND to select FM1 or FM2.
2. Press the P
-TYPE button to activate program
type mode.
3. Turn the P
-TYPE knob to select a PTY.
4. Press and hold one of the six numbered pushbuttons
until you hear a beep. Whenever you press that
numbered pushbutton, the PTY you set will return.
5. Repeat the steps for each pushbutton.
RDS Messages
ALERT!: This message warns of national or local
emergencies. You will not be able to turn off alert
announcements. ALERT! appears on the display when
an alert announcement plays. When an alert
announcement comes on the current radio station, you
will hear it, even if the volume is muted or a compact
disc is playing. If the compact disc player is playing,
play will stop for the announcement and resume when
the announcement is finished.TRAF (Traffic): Press this button to receive traffic
announcements. The traffic announcement brackets will
appear on the display. TRAF will appear on the display
if the current station broadcasts traffic announcements.
If the current station does not broadcast traffic
announcements, the radio will seek to a station that
does. When the radio finds a station that broadcasts
traffic announcements, it will stop. If no station is found,
NO TRAFFIC will appear on the display.
When a traffic announcement comes on the current
radio station or a related network station, you will hear
it, even if the volume is muted or a compact disc is
playing. If the compact disc player was being used, the
compact disc will stay in the player and resume play at
the point where it stopped.
INFO (Information): If the current station has a
message, INFO will appear on the display. Press this
button to see the message. If the whole message does
not appear on the display, parts of the message will
appear every three seconds until the message is
completed. To see the parts of the message faster than
every three seconds, press this button again. A new
group of words will appear on the display. Once the
complete message has been displayed, INFO will
disappear from the display until another new message
is received.

3-16
To scan preset stations, press and hold either SCAN
arrow for more than four seconds, PRESET SCAN will
appear on the display. You will hear a double beep and
the P will blink with the preset number. The radio will
go to the first preset station stored on your pushbuttons,
play for a few seconds, then go on to the next preset
station. Press either SCAN arrow again to stop scanning
presets. The radio will scan preset stations with a strong
signal only. The sound will mute while scanning.
Setting Preset Stations
The six numbered pushbuttons let you return to your
favorite stations. You can set up to 18 stations (six AM,
six FM1 and six FM2), by performing the following steps:
1. Turn the radio on.
2. Press BAND to select AM, FM1 or FM2.
3. Tune in the desired station.
4. Press AUTO EQ to select the equalization that best
suits the type of station selected.
5. Press and hold one of the six numbered pushbuttons
until you hear a beep. Whenever you press that
numbered pushbutton, the station you set will return
and the equalization that you selected will also be
automatically selected for that pushbutton.
6. Repeat the steps for each pushbutton.Setting the Tone (Bass/Treble)
AUDIO: Press and release the AUDIO button until
BASS, MID or TREB appears on the display. Press the
knob above the AUDIO button to extend it, then turn the
knob to increase or decrease. When you use this knob,
the radio's tone setting will switch to manual. If a station
is weak or noisy, you may want to decrease the treble.
Pressing and holding the AUDIO button for at least two
seconds will return all tone settings, including balance
and fade to flat.
AUTO EQ (Automatic Equalizer): This feature allows
you to choose preset bass, midrange and treble
equalization settings designed for country, jazz, talk,
pop, rock and classical program types.
The program type last chosen will appear on the display
when you first press AUTO EQ. Each time you press
this button, another program type will appear on the
display and AUTO EQ will switch to one of the preset
program types.
To return to the manual mode, press the AUTO EQ
button until MANUAL appears on the display. Then
you will be able to manually adjust the bass, midrange
and treble using the AUDIO button.

3-19
Setting PTY Preset Stations
The six numbered pushbuttons let you return to your
favorite Program Types (PTYs). These pushbuttons have
factory PTY presets. You can set up to 12 PTYs
(six FM1 and six FM2) by performing the following steps:
1. Press BAND to select FM1 or FM2.
2. Press the P
-TYPE button to activate program
type mode.
3. Turn the P
-TYPE knob to select a PTY.
4. Press and hold one of the six numbered pushbuttons
until you hear a beep. Whenever you press that
numbered pushbutton, the PTY you set will return.
5. Repeat the steps for each pushbutton.
RDS Messages
ALERT!: This message warns of national or local
emergencies. You will not be able to turn off alert
announcements. ALERT! appears on the display when an
alert announcement plays. When an alert announcement
comes on the current radio station, you will hear it, even if
the volume is muted or a cassette tape or compact disc is
playing. If the cassette tape or compact disc player is
playing, play will stop for the announcement and resume
when the announcement is finished.TRAF (Traffic): Press this button to receive traffic
announcements. The traffic announcement brackets will
appear on the display. TRAF will appear on the display
if the current station broadcasts traffic announcements.
If the current station does not broadcast traffic
announcements, the radio will seek to a station that
does. When the radio finds a station that broadcasts
traffic announcements, it will stop. If no station is found,
NO TRAFFIC will appear on the display.
When a traffic announcement comes on the current
radio station or a related network station, you will
hear it, even if the volume is muted or a cassette tape
or compact disc is playing. If the cassette tape or
compact disc player was being used, the tape or compact
disc will stay in the player and resume play at the point
where it stopped.
INFO (Information): If the current station has a
message, INFO will appear on the display. Press this
button to see the message. If the whole message does
not appear on the display, parts of the message will
appear every three seconds until the message is completed.
To see the parts of the message faster than every three
seconds, press this button again. A new group of words
will appear on the display. Once the complete message has
been displayed, INFO will disappear from the display until
another new message is received.
