0 Your vehicle is equipped with a crash sensing and
diagnostic module, which records information about
the air bag system. The module records information
about the readiness of the system, when the sensors
are activated and driver’s safety belt usage at
deployment.
Let only qualified technicians work on your air bag
system. Improper service can mean that your air bag
system won’t work properly. See your retailer for Servicing Your Air Bag-Equipped Aurora
Air bags affect how your Aurora should be serviced.
There are parts of the air bag system in several places
around your vehicle. You don’t want the system to
inflate while someone is working on your vehicle. Your
Aurora retailer and the Aurora Service Manual have
information about servicing your vehicle and the air bag
system.
To purchase a service manual, see “Service and
Owner Publications’’ in the Index.
service.
NOTICE:
~
If you damage the cover for the driver’s or the
right front passenger’s air bag, they may not
work properly.
You may have to replace the air
bag module in the steering wheel or both the air
bag module and the instrument panel for the
right front passenger’s air bag.
Do not open or
break the air bag covers. For up to
10 minutes after the
ignition key is
turned off and the battery is disconnected, an air
bag can still inflate during improper service.
You
can be injured if you are close to an air bag when
it inflates. Avoid wires wrapped with yellow tape
or yellow connectors. They are probably part of
the air bag system. Be sure to follow proper
service procedures, and make sure the person
performing work for
you is qualified to do so.
The air bag system does not need regular maintenance.
ProCarManuals.com

Windshield Washer
The lever on the right side of your steering column also
controls your windshield washer. To spray washer fluid
on the windshield, pull the lever toward you. The wipers
will clear the window and then either stop or return to
your preset speed. For more washer cycles, pull and
hold the lever.
If the fluid level in the windshield washer bottle is low,
the message LOW WASHER
FLUID will appear in the
Driver Information Center. See “Windshield Washer
Fluid”
in the Index.
Driving without washer fluid can be dangerous. A bad
mud splash can block your vision.
You could hit another
vehicle or go
off the road. Check your washer fluid
level often.
In freezing weather, don’t use your washer until
the windshield is warmed. Otherwise the washer
fluid can
form ice on the windshield, blocking
your vision.
Lamps
Headlamps
See “Turn Signal/Multifunction Lever” in the Index.
Daytime Running Lamps
Daytime Running Lamps (DRL) can make it easier for
others to see the front of your vehicle during the day.
DRL can be helpful in many different driving
conditions, but they can be especially helpful in the
short periods after dawn and before sunset.
A light sensor on top
of the instrument panel makes the
DRL work,
so be sure it isn’t covered.
The DRL system will make your low-beam headlamps
come on at reduced brightness in daylight when:
The ignition is on,
The headlamp switch is off, and
0 The transaxle is not in PARK (P).
ProCarManuals.com

Cornering Lamps Twilight Sentinel
TWILIGHTSENTINEL
Twilight sentinel turns your
headlamps, taillamps and
parking lamps on and off by
sensing how dark it is
outside.
The cornering lamps are designed to
come on when you
signal a turn. This will provide more light for cornering
at night. To
operate it, leave the headlamp switch off and move
the twilight sentinel control toward MAX.
If you move the control all the way to MAX, your lamps
will remain on for three minutes after you turn off your
engine.
If you move the control toward MIN, the lamps
will
go off quickly when you turn off your engine. You
can set this delay time for only
a few seconds or up to
three minutes.
Light Sensor
Your twilight sentinel and daytime running lamps work
with the light sensor on top
of the instrument panel.
Don’t cover
it up. If you do it will read “dark” and the
headlamps will come on.
- ~~ ~~
~~
ProCarManuals.com

Interior Lamps
Instrument Panel Brightness
1
You can brighten or dim your instrument cluster,
radio and climate control displays and control lights
by rotating the INTERIOR LIGHTS control between
LO and HI when your lights are on. Rotate the control
all the way to HI and you,will turn on the interior
courtesy lamps.
Time Out Feature
The interior lamps will automatically shut off after
10 minutes if a door is left open. This feature is
designed to help eliminate battery wear down.
Courtesy Lamps
When any door is opened, several lamps go on. They
make it easy for you to enter and leave the car.
To turn
on these lamps, rotate the INTERIOR .LIGHTS knob all
the way to HI.
Delayed Illumination
When you open the door, the interior lamps will come
on. When you close the door with
the ignition off, the
interior lamps will stay
on for 25 seconds or until the
ignition is turned to the on position. Please note that
locking the doors will override the delayed illumination
feature and the lights will turn
off right away.
Theater Dimming
This feature allows for a three to five-second fade out of
the courtesy lamps instead of immediate
turn off.
Parade Dimming
This feature prohibits the dimming of your instrument
panel displays during daylight while your headlamps are
on. This feature operates with the light sensor for the
twilight sentinel and is
fully automatic. When the light
sensor reads darkness outside, you will be able to dim
your instrument panel displays once again.
t
ProCarManuals.com

Air Bag Readiness Light
There is an air bag readiness light on the instrument
panel, which shows AIR BAG. The system checks the
air bag’s electrical system for malfunctions. The light
tells you if there is an electrical problem. The system
check includes the air bag sensors, the air bag modules,
the wiring and the crash sensing and diagnostic module.
For more infoimation on the air bag system, see “Air
Bag” in the Index.
AIR BAG
You will see this light flash
for a few seconds when you
turn your ignition to RUN
or START. Then the light
should go out. This means
the system is ready.
If the air bag readiness light doesn’t come on when you
start your vehicle, or stays on, or comes
on when you
are driving, your air bag system may not work properly.
Have your vehicle serviced right away.
Battery Warnlng Light
VOLTS
This light will come on
briefly when you start the
vehicle, as a check to show
you it is working, then it
should
go out. If it stays on,
or comes on while
you are
driving, you may have a
problem with the electrical
charging system.
A warning chime and the message CHECK CHARGE
SYSTEM may also come on. Have it checked right
away. Driving while this light is on could drain your
battery.
If you must drive a short distance with the light on, be
certain to turn off all your accessories, such as the radio
and climate control.
ProCarManuals.com

Automatic Operation
Press the AUTO-PUSH knob when you want the system
to automatically adjust to changes in the temperature
inside the vehicle, the outside temperature and the sun
load on the vehicle. When the system
is set for 4%
automatic operation, air will come from the floor, upper
or the windshield outlets depending on the temperature
inside the vehicle, the outside temperature and the sun
load. Fan speed will vary as the system reaches and
.................
maintains the comfort setting you have selected.
. 7* -
....................................................................... \
To find your comfort setting, start with the system in
automatic mode by depressing the AUTO-PUSH knob.
Adjust
the comfort setting by using the red and blue
buttons located below the digital display until you reach a
value of
75 OF (24"C), on the display. Give the vehicle
about
20 minutes to stabilize and then adjust the comfort
setting
if necessary, through the use of the red and blue
buttons. The display will show
the comfort setting for five
seconds and then it will show the outside temperature.
In cold weather, the system will delay turning on the fan
to avoid blowing cold air. The length
of the delay
depends on the engine coolant temperature and the
outside temperature. Rotating the AUTO FAN knob will
override this delay by turning off the automatic fan
mode and changing the fan speed. Your
automatic electronic climate control system has
two sun sensors located on the top of the instrument
panel that detect direct sunlight. To keep you and your
passengers comfortable, the system may supply cooler
air to the
side towards the sun. Be careful not to put
anything over these sun sensors. The automatic
electronic climate control system may not operate
correctly if these sensors are covered.
To change the automatic electronic climate control
display from an English display to a Metric display, hold
down the OFF button located in the Driver Information
Center for five seconds. The display in the Driver
Information Center will also change from an English to
a Metric display.
To return to an English display, repeat
the above procedure.
3-3
ProCarManuals.com

4. There’s a temperature sensor on the corner of the air
cleaner cover. Use a screwdriver to release the
sensor’s electrical connector retainer, and pull up.
A
5. Unsnap the two clamps by pushing down on the top
of the air cleaner cover and pushing in on the clamps
toward the center
of the cover. Then remove the cover.
ProCarManuals.com

Fuse
17
18
19
20
21
22
23
24
25
26
27
28 Usage
Driver Information
Center
Converter Oxygen Sensors
Radio
Open
Climate Control Relay
Open
Windshield Wipers Open
TMNSS
Cigarette Lighter
Crank,
Air Bag Module
Climate Control Blower
Removing the Rear Seat Cushion
To access the battery and rear compartment fuse panels,
the rear seat cushion must be removed.
This procedure is
somewhat difficult. You may wish to have your retailer
do this for you.
I NOTICE:
The battery and main fuse boxes are located under
the rear seat cushion. The battery’s ground
terminal and some relay wires are exposed. To help
avoid damage to the battery and wires, be careful
when removing
or reinstalling the seat cushion. Do
not remove covers from covered parts. Do not store
anything under the seat,
as objects could touch
exposed wires and cause a short.
To Remove the Rear Seat Cushion
1. Pull up on the front of the cushion to release the
front hooks.
2. Pull the cushion up and out toward the front of the
vehicle.
6-60
ProCarManuals.com

Lights Air Bag Readiness
....................... 1.19. 2.64
Anti-Lock Brake System Warning
............ 2.66. 4.6
Battery Warning
.............................. 2-64
Brake System Warning
......................... 2-65
Engine Oil Pressure Light
...................... 2-72
Interior
..................................... 2-45
Parking Brake Indicator
........................ 2-66
Safety Belt Reminder
...................... 1.6. 2.63
Service Engine Soon
.......................... 2-69
Traction Active
................................ 4-8
Traction Control System Active
.............. 2.68. 4.8
Traction Control System Warning
............ 2.67. 4.9
Traction
Off Warning ........................... 4-9
Light Sensor. Twilight Sentinel
.................... 2-44
Loading Your Vehicle
........................... 4-29
Locks
......................................... 2-3
Anti-Lockout Feature
.......................... 2-7
Automatic Door
............................... 2-4
Delayed Locking
............................. 2- 10
Door ........................................ 2-3
Key Lock Cylinder Service
..................... 7-39
PowerDoor
.................................. 2-4
Rear Door Security
............................. 2-6
Steering Column Lock Check
................... 7-41
Tr~nk
...................................... 2-13
Window
.................................... 2-32
Lubricants and Fluids
............................ 7-43
Lubrication Service. Body
........................ 7-39
Lumbar Controls
................................ 1-2 Magnasteer
............................ ; . GT 4-10
Maintenance
Normal Replacement Parts
...................... 6-69
Record
..................................... 7-45
Underbody
.................................. 6-54
When Trailer Towing
.......................... 4-38
Maintenance Schedule
............................ 7-1
Long Tripmighway Definition
................... 7-5
Long Tripwighway Intervals
..................... 7-5
Owner Checks and Services
..................... 7-38
Periodic Maintenance Inspections
................ 7-42
Recommended Fluids and Lubricants
............. 7-43
Scheduled Maintenance Services
.................. 7-2
Short Trip/City Definition
....................... 7-4
Short Trip/City Intervals
........................ 7-4
Malfunction Indicator Lamp
...................... 2-69
Maxifuse/Relay Center
.......................... 6-58
Methanol
...................................... 6-3
Mirrors
....................................... 2-48
Convex Outside
.............................. 2-49
Heated Outside
............................... 2-50
Power Remote Control
......................... 2-49
MMT
......................................... 6-3
MountainRoads
................................ 4-23
Multifunction Lever
............................. 2-33
Electrochromic
Daymight Rearview
.............. 2-48
Visor Vanity. Illuminated
....................... 2-53
Net. Convenience .............................. 2-51
Neutral. Automatic Transaxle
..................... 2-24
New Vehicle Break-In
........................... 2-18
Nightvision
................................... 4-16
ProCarManuals.com
