remote control OLDSMOBILE AURORA 1999 Owners Manual

2-
yellowblue
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Keys
2
-4 Door Locks
2
-9 Remote Lock Control
2
-14 Trunk
2
-15 Theft
2
-16 Universal Theft-Deterrent
2
-18 PASS-Key
II
2
-19 New Vehicle ªBreak-Inº
2
-20 Ignition Positions
2
-21 Starting Your Engine
2
-23 Engine Coolant Heater (Option)
2
-24 Automatic Transaxle Operation
2
-27 Parking Brake
2
-28 Shifting Into PARK (P)
2
-30 Shifting Out of PARK (P)
2
-31 Parking Over Things That Burn2
-31 Engine Exhaust
2
-33 Windows
2
-34 Tilt Wheel
2
-34 Turn Signal/Multifunction Lever
2
-42 Exterior Lamps
2
-44 Interior Lamps
2
-47 Mirrors
2
-51 Storage Compartments
2
-54 Accessory Power Outlet
2
-54 OnStar
System (Option)
2
-55 Sunroof (Option)
2
-56 Universal Transmitter
2
-60 The Instrument Panel - Your
Information System
2
-64 Warning Lights, Gages and Indicators
2
-75 Driver Information Center
ProCarManuals.com

yellowblue
2-4
Door Locks
CAUTION:
Unlocked doors can be dangerous.
Passengers -- especially children -- can easily
open the doors and fall out. When a door is
locked, the inside handle won't open it.
Outsiders can easily enter through an unlocked
door when you slow down or stop your vehicle.
This may not be so obvious: You increase the
chance of being thrown out of the vehicle in a
crash if the doors aren't locked. Wear safety belts
properly, lock your doors, and you will be far
better off whenever you drive your vehicle.
There are several ways to lock and unlock your vehicle.
From the outside, use your door key or remote lock
control transmitter.
From the inside, to lock the door, rotate the locking
lever forward.
To unlock the door, rotate the locking lever
rearward. There is a red mark on the switch when
the door is unlocked.
Central Door Unlocking System
If the driver's door key is held in the unlock position for
more than one second, all doors will unlock.
ProCarManuals.com

yellowblue
2-6
Mode 2: All doors automatically lock when shifted out
of PARK (P). Only the driver's door automatically
unlocks when shifted into PARK (P).
Mode 3: All doors automatically lock when shifted out
of PARK (P). All doors automatically unlock when
shifted into PARK (P).
Vehicles are delivered programmed in Mode 3.
To change the modes:
1. Close all doors and turn the ignition on. Keep all
doors closed throughout this procedure.
2. Press and hold the lock position on the driver's
power door lock switch through Step 4.
3. Press the LOCK button on the remote lock control
transmitter. The automatic door locks will remain in
the current mode.
4. Press the LOCK button on the transmitter again.
Each time the transmitter's LOCK button is pressed,
the mode will advance by one, going from Mode 3 to
Mode 0 to Mode 1, etc.
NOTE: The door locks will cycle according to the
mode entered while customizing memory door locks.
(Mode 0 has no feedback.)5. Release the power door lock switch. The
automatic door locks will remain in the most
recent mode selected.
6. Turn the ignition to OFF.
Delayed Locking
This personalization feature lets the driver delay the
actual locking of the vehicle. When the power door lock
switch is pressed with the key removed from the ignition
and the driver's door open, a chime will sound three
times to signal that the lock delay mode is active. When
all doors have been closed, the doors will lock
automatically after five seconds. If any door is opened
before this, the five
-second timer will reset itself once
all the doors have been closed again.
Pressing the door lock switch twice within two seconds
will override this feature.
ProCarManuals.com

yellowblue
2-7
Personalization Programming
The delayed locking feature can be turned on or off for
each driver's remote lock control transmitter.
To turn the feature on:
1. Press and hold the lock position on the driver's
power door lock switch throughout this procedure.
All of the doors will lock.
2. Press the UNLOCK button on the transmitter to
enter the programming mode. The lock delay is still
off and all doors will remain locked.
3. Press the UNLOCK button on the transmitter again.
Lock delay is now active and all doors will unlock.
4. Release the power door lock switch.
To turn the feature off, repeat this procedure.
This procedure changes the mode for only the
transmitter used to change this setting. The procedure
will need to be repeated for the second transmitter.Rear Door Security Locks
Your vehicle is equipped with rear door security locks
that help prevent passengers from opening the rear doors
of your vehicle from the inside.
To Use One of These Locks
1. Open one of the rear doors.
2. Move the lever on the
door all the way up to
the ENGAGED position.
3. Close the door.
4. Do the same thing to the other rear door lock.
The rear doors of your vehicle cannot be opened from
inside when this feature is in use.
ProCarManuals.com

yellowblue
2-8
To Open a Rear Door When the Security Lock is On
1. Unlock the door from
the inside, or from the
outside using the remote
lock control or central
door unlocking feature.
2. Then open the door from the outside using the
remote lock control transmitter or central door
unlocking feature.
If you don't cancel the security lock feature, adults or
older children who ride in the rear won't be able to open
the rear door from the inside. You should let adults and
older children know how these security locks work, and
how to cancel the locks.To Cancel the Rear Door Lock
1. Unlock the door from the inside or from the outside
using the remote lock control transmitter or central
door unlocking feature.
2. Open the door from the outside.
3. Move the lever all the
way down.
4. Do the same for the
other rear door.
The rear door locks will now work normally.
ProCarManuals.com

yellowblue
2-9 Anti-Lockout Feature
The power door locks will not work if the key is left
in the ignition with the driver's door open. You can
override this feature by holding the power door lock
switch for more than three seconds, unless the engine
is running.
Leaving Your Vehicle
If you are leaving the vehicle, open your door and
set the locks from the inside, then get out and close
the door.
Remote Lock Control
You can lock and unlock
your doors or unlock your
trunk from about 3 feet
(1 m) up to 30 feet (9 m)
away using the remote lock
control transmitter supplied
with your vehicle.Your remote lock control operates on a radio frequency
subject to Federal Communications Commission (FCC)
Rules and with Industry Canada.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
This device complies with RSS
-210 of Industry Canada.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation of
the device.
Changes or modifications to this system by other than an
authorized service facility could void authorization to
use this equipment.
ProCarManuals.com

yellowblue
2-10
This system has a range of about 3 feet (1 m) up to
30 feet (9 m). At times you may notice a decrease in
range. This is normal for any remote lock control
system. If the transmitter does not work or if you
have to stand closer to your vehicle for the transmitter
to work, try this:

Check to determine if battery replacement or
resynchronization is necessary. See the instructions
that follow.

Check the distance. You may be too far from your
vehicle. You may need to stand closer during rainy
or snowy weather.

Check the location. Other vehicles or objects may be
blocking the signal. Take a few steps to the left or
right, hold the transmitter higher, and try again.

If you're still having trouble, see your dealer or a
qualified technician for service.Operation
The driver's door will unlock when UNLOCK is
pressed. If UNLOCK is pressed again within five
seconds, all doors will unlock. Pressing the UNLOCK
button will also illuminate the interior lamps. See
ªIlluminated Entryº in the Index. All doors will lock
when LOCK is pressed.
The trunk will unlock when the trunk button is pressed
while the vehicle is in any gear.
Instant Alarm
When the button with the horn symbol on the remote
lock control transmitter is pressed, the horn will sound
and the headlamps and taillamps will flash for up to one
minute. This can be turned off by pressing the instant
alarm button again, unlocking the vehicle with a key or
by turning the ignition on.
ProCarManuals.com

yellowblue
2-11
Personalization Features
The following list of features that are available on your
vehicle can be programmed to the driver's preference
for each transmitter.

Memory Door Locks: This feature programs your
door locks to automatically lock or unlock when
shifting in and out of PARK (P).

Security Feedback: This feature provides feedback
to the driver when the vehicle receives a command
from the remote lock control transmitter.

Delayed Locking: This feature lets the driver delay
the actual locking of the vehicle. When all doors
have been closed, the doors will lock automatically
after five seconds.

Perimeter Lighting: When the UNLOCK button on
the transmitter is pressed, the headlamps, parking
lamps, back
-up lamps and cornering lamps will turn
on in dark conditions.

Memory Seat and Mirrors: This feature programs
your driver's seat and outside mirrors to a set
memory position when the UNLOCK button on the
transmitter is pressed.
For more detailed information and programming
instructions, refer to the Index for each individual
feature listed above.Security Feedback
This personalization feature provides feedback to the
driver when the vehicle receives a command from the
remote lock control transmitter. The following modes
may be selected:
Mode 0: No transmitter response when locking or
unlocking the vehicle.
Mode 1: No transmitter response when locking;
headlamps, parking lamps, and cornering lamps flash
when unlocking the vehicle.
Mode 2: Headlamps, parking lamps, and cornering
lamps flash when locking; no response when unlocking
the vehicle.
Mode 3: Headlamps, parking lamps, and
cornering lamps flash when locking and when
unlocking the vehicle.
Mode 4: Headlamps, parking lamps, and cornering
lamps flash and horn chirps when locking; no response
when unlocking the vehicle.
Mode 5: Headlamps, parking lamps, and cornering
lamps flash and horn chirps when locking; exterior
lamps flash when unlocking the vehicle.
ProCarManuals.com

yellowblue
2-12
Vehicles are delivered programmed in Mode 5. To
change to another mode:
1. Turn the ignition key to OFF.
2. Press and hold the lock position on the driver's
power door lock switch throughout this procedure.
3. Press the trunk button on the transmitter to enter the
programming mode. The transmitter will remain in
its current mode.
4. Press the trunk button again. Each time the trunk
button is pressed, the horn will chirp and the
transmitter will advance to the next mode.
5. Release the power door lock switch.
This procedure changes the mode for only the
transmitter used to change this setting. The procedure
will need to be repeated for the second transmitter.Matching Transmitter(s) To Your Vehicle
Each remote lock control transmitter is coded to prevent
another transmitter from unlocking your vehicle. If a
transmitter is lost or stolen, a replacement can be
purchased through your dealer. Remember to bring any
remaining transmitters with you when you go to your
dealer. When the dealer matches the replacement
transmitter to your vehicle, any remaining transmitters
must also be matched. Once your dealer has coded the
new transmitter, the lost transmitter will not unlock your
vehicle. Each vehicle can have only four transmitters
matched to it.
See your dealer to match transmitters to another vehicle.
Battery Replacement
Under normal use, the battery in your remote lock
control transmitter should last about two years.
You can tell the battery is weak if the transmitter won't
work at the normal range in any location. If you have to
get close to your vehicle before the transmitter works,
it's probably time to change the battery.
ProCarManuals.com

yellowblue
2-14
Trunk
CAUTION:
It can be dangerous to drive with the trunk lid
open because carbon monoxide (CO) gas can
come into your vehicle. You can't see or smell
CO. It can cause unconsciousness and even death.
If you must drive with the trunk lid open or if
electrical wiring or other cable connections must
pass through the seal between the body and the
trunk lid:

Make sure all other windows are shut.

Turn the fan on your heating or cooling
system to its highest speed with the setting
on any airflow selection except RECIRC.
That will force outside air into your vehicle.
See ªComfort Controlsº in the Index.

If you have air outlets on or under the
instrument panel, open them all the way.
See ªEngine Exhaustº in the Index.
Trunk Lock Release
To unlock the trunk from the outside, insert the door key
and turn it.
Remote Trunk Release
Press the TRUNK release
button located to the right of
the steering column to
release the trunk lid. The
trunk release lockout switch
must be ON.
The system also works with the remote lock control.
The trunk will unlock when the trunk button is pressed
while the vehicle is in any gear.
ProCarManuals.com
