2-23 Torque Lock
If you are parking on a hill and you don't shift your
transmission into PARK (P) properly, the weight of the
vehicle may put too much force on the parking pawl in
the transmission. You may find it difficult to pull the
shift lever out of PARK (P). This is called ªtorque lock.º
To prevent torque lock, set the parking brake and then
shift into PARK (P) properly before you leave the
driver's seat. To find out how, see ªShifting Into
PARK (P)º in the Index.
When you are ready to drive, move the shift lever out of
PARK (P) before you release the parking brake.
If torque lock does occur, you may need to have another
vehicle push yours a little uphill to take some of the
pressure from the parking pawl in the transmission, so
you can pull the shift lever out of PARK (P).
Shifting Out of PARK (P)
CAUTION:
Before shifting out of PARK (P) you must fully
apply your regular brakes. Your vehicle can roll.
If you have left the engine running, the vehicle
can move suddenly. You or others could be
injured. If you're pulling a trailer, see ªTowing a
Trailerº in the Index.
Your vehicle has a Brake-Transmission Shift Interlock
(BTSI). You have to fully apply your regular brake
before you can shift from PARK (P) when the ignition is
in RUN. See ªAutomatic Transmission Operationº in
the Index.

yellowblue
5-25
10. Use the wrench to
tighten the wheel nuts
firmly in a crisscross
sequence as shown.
CAUTION:
Incorrect wheel nuts or improperly tightened
wheel nuts can cause the wheel to become loose
and even come off. This could lead to an accident.
Be sure to use the correct wheel nuts. If you have
to replace them, be sure to get new GM original
equipment wheel nuts.
Stop somewhere as soon as you can and have
the nuts tightened with a torque wrench to
100 lb
-ft (140 N´m).
NOTICE:
Improperly tightened wheel nuts can lead to
brake pulsation and rotor damage. To avoid
expensive brake repairs, evenly tighten the wheel
nuts in the proper sequence and to the proper
torque specification.

yellowblue
6-30
CAUTION:
The brake wear warning sound means that soon
your brakes won't work well. That could lead to
an accident. When you hear the brake wear
warning sound, have your vehicle serviced.
NOTICE:
Continuing to drive with worn-out brake pads
could result in costly brake repair.
Some driving conditions or climates may cause a brake
squeal when the brakes are first applied or lightly
applied. This does not mean something is wrong with
your brakes.Properly torqued wheel nuts are necessary to help
prevent brake pulsation. When tires are rotated, inspect
brake pads for wear and evenly torque wheel nuts in the
proper sequence to GM specifications.
Brake linings should always be replaced as complete
axle sets.
See ªBrake System Inspectionº in Section 7
of this manual under Part C ªPeriodic
Maintenance Inspections.º
Brake Pedal Travel
See your dealer if the brake pedal does not return to
normal height, or if there is a rapid increase in pedal
travel. This could be a sign of brake trouble.
Brake Adjustment
Every time you make a brake stop, your disc brakes
adjust for wear.

yellowblue
6-39 Tire Inspection and Rotation
Tires should be rotated every 6,000 to 8,000 miles
(10 000 to 13 000 km). Any time you notice unusual wear,
rotate your tires as soon as possible and check wheel
alignment. Also check for damaged tires or wheels. See
ªWhen It's Time for New Tiresº and ªWheel
Replacementº later in this section for more information.
The purpose of regular rotation is to achieve more
uniform wear for all tires on the vehicle. The first
rotation is the most important. See ªScheduled
Maintenance Servicesº in the Index for scheduled
rotation intervals.
When rotating your tires, always use the correct rotation
pattern shown here.After the tires have been rotated, adjust the front and
rear inflation pressures as shown on the
Certification/Tire label. Make certain that all wheel nuts
are properly tightened. See ªWheel Nut Torqueº in
the Index.
CAUTION:
Rust or dirt on a wheel, or on the parts to which
it is fastened, can make wheel nuts become loose
after a time. The wheel could come off and cause
an accident. When you change a wheel, remove
any rust or dirt from places where the wheel
attaches to the vehicle. In an emergency, you can
use a cloth or a paper towel to do this; but be
sure to use a scraper or wire brush later, if you
need to, to get all the rust or dirt off. (See
ªChanging a Flat Tireº in the Index.)

yellowblue
6-60
Replacement Bulbs
Lamps Quantity Number
Halogen Headlamps, Composite Low Beam 2 9006 HB4
Halogen Headlamps, Composite High Beam 2 9005 HB3
Tail and Stoplamps 4 3057
Front Sidemarker Lamps 2 194
Front Turn Signal Lamps 2 3157NA
Turn Signal Lamps 2 3157 NA
Capacities and Specifications
Engine Description ªVORTECº 4300 V6. . . . . . . . .
Type V6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
VIN Code W. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Firing Order 1
-6-5-4-3-2 . . . . . . . . . . . . . . . . . . . . . .
Horsepower 190 at 4,400 rpm. . . . . . . . . . . . . . . . . . .
Thermostat Specification 195
F (91
C) . . . . . . . . . . .
Spark Plug Gap 0.060 inches (1.52 mm). . . . . . . . . .
Wheels and Tires
Wheel Nut Torque 100 lb-ft (140 N´m) . . . . . . . . . . .
Tire Pressure Look at the Certification/Tire label. . .
See ªLoading Your Vehicleº in the Index.
Capacities (Approximate)
Cooling System* 11.7 quarts (11.1 L). . . . . . . . . . . . .
Crankcase with Filter* 4.5 quarts (4.3 L). . . . . . . . . .
Automatic Transmission
(Drain and Refill)* 5.0 quarts (4.7 L). . . . . . . . . . .
Differential Fluid (Rear) 4.0 pints (1.9 L). . . . . . . . .
Differential Fluid (Front) 2.6 pints (1.2 L). . . . . . . . .
Fuel Tank 18.0 gallons (68.0 L). . . . . . . . . . . . . . . . . .
A/C Refrigerant 1.75 lbs (0.79 kg) of R
-134a . . . . . . .
*After refill, the level must be checked.

yellowblue
9-9
Steering 4-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In Emergencies 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power 4-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel, Tilt 2-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering Wheel Controls 3-20 . . . . . . . . . . . . . . . . . . . . . . . . .
Storage Compartments 2-41 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage, Vehicle 6-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storing a Flat or Spare Tire and Tools 5-26 . . . . . . . . . . . . . . .
Stuck: In Sand, Mud, Ice or Snow 5-28 . . . . . . . . . . . . . . . . . .
Sun Visors 2-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sunglasses Storage 2-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sunroof 2-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Symbols, Vehicle vi. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tachometer 2-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Taillamp Bulb Replacement 6-34 . . . . . . . . . . . . . . . . . . . . . . .
Tape Player Care 3-22, 7-39 . . . . . . . . . . . . . . . . . . . . . . . . . .
Temperature Display 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Theft 2-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
THEFTLOCK
3-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermostat 6-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Third Gear 2-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tilt Steering Wheel 2-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Time, Setting 3-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire Chains 6-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire Inflation Check 7-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire Loading 4-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires 6-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires 6-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Alignment and Balance 6-43 . . . . . . . . . . . . . . . . . . . . . . . .
Buying New 6-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing a Flat 5-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Cleaning 6
-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inflation 6-38, 7-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inspection and Rotation 6-39 . . . . . . . . . . . . . . . . . . . . . . . .
Pressure 6-38, 7-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temperature 6-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Traction 6-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Treadwear 6-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Uniform Quality Grading 6-41 . . . . . . . . . . . . . . . . . . . . . . .
Wear Indicators 6-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Top Strap 1-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Torque Lock 2-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Torque, Wheel Nut 5-25, 6-60 . . . . . . . . . . . . . . . . . . . . . . . . .
Towing a Trailer 4-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Towing Your Vehicle 5-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trailer
Brakes 4
-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving on Grades 4-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving with a Trailer 4-48 . . . . . . . . . . . . . . . . . . . . . . . . . .
Hitches 4-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance When Towing 4-50 . . . . . . . . . . . . . . . . . . . . .
Parking on Hills 4-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Chains 4-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tongue Weight 4-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Total Weight on Tires 4-46 . . . . . . . . . . . . . . . . . . . . . . . . . .
Towing 4-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn Signals 4-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Weight 4-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring Harness 4-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transfer Case 6-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transmission Fluid 6-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transmission, Shifting 2-17 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transmitters, Keyless Entry 2-6 . . . . . . . . . . . . . . . . . . . . . . . .
Transportation, Courtesy 8-7 . . . . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
9-10
Trip
Computer 2-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Odometer 2-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trip, Before Leaving 4-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TTY Users 8-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn and Lane Change Signals 2-29 . . . . . . . . . . . . . . . . . . . .
Turn Signals When Towing a Trailer 4-49 . . . . . . . . . . . . . . . .
Underbody Flushing Service 7-42 . . . . . . . . . . . . . . . . . . . . .
Underbody Maintenance 6-51, 7-43 . . . . . . . . . . . . . . . . . . . .
Universal Transmitter 2-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessories 2-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Erasing Channels 2-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation 2-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Programming 2-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rolling Codes 2-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
US/MET Button 2-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle
Control 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Damage Warnings v. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions 6
-61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Identification Number 6-53 . . . . . . . . . . . . . . . . . . . . . . . . .
Loading 4-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage 6-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ventilation System 3-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Visors, Sun 2-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Voltmeter 2-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning Devices 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning Lights, Gages and Indicators 2-58 . . . . . . . . . . . . . . .
Washer Fluid, Windshield 6-26 . . . . . . . . . . . . . . . . . . . . . . . .
Washing Your Vehicle 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Weatherstrip Lubrication 7-40 . . . . . . . . . . . . . . . . . . . . . . . . .
Weatherstrips 6-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel
Alignment 6
-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Nut Torque 5-29, 6-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement 6-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windows 2-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield Washer 2-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid 6-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid Level Check 7-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield Wipers 2-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Blade Check 7-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Blade Replacement 6-35 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses 6-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear 2-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Blade Replacement 6-37 . . . . . . . . . . . . . . . . . . . . . . .
Winter Driving 4-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiper Blades, Cleaning 6-48 . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring, Headlamp 6-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wrecker Towing 5-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
