OLDSMOBILE BRAVADA 2001 Owners Manual

2-46
Storage Compartments
Glove Box
To open your glove box, lift the lever on the front of the
glove box and lower the door. The glove box should not
be open while driving.
Overhead Console
The overhead console includes reading lamps, a driver
information system, a storage compartment for
sunglasses and a HomeLink

transmitter.Reading Lamps
Press the button located
near each lamp to turn a
reading lamp on or off.
The lamps can also be swiveled to point in the
desired direction.
ProCarManuals.com

2-47
Driver Information System
This system displays the outside air temperature, compass
direction and trip information in the overhead console.
US/MET: The US/MET (United States/metric) button
allows you to switch the display between the English
and metric system.
MODE: The MODE button can be used to toggle
between three modes of operation: OFF, COMP/TEMP
and TRIP.COMP/TEMP: This display provides the outside
temperature and one of eight compass readings to
indicate the direction the vehicle is facing.
Before you turn on the ignition and move the vehicle,
the temperature indicated will be the last outside
temperature recorded with the ignition on. If the outside
temperature is 37
F (3
C) or lower, the display
will toggle between the word ªICEº and the current
temperature every eight seconds. This is a warning to
the driver that road conditions may be icy, and that
appropriate precautions should be taken.
The compass is self
-calibrating, so it does not need
to be manually set. However, if ªCº (Calibration) is
displayed, the compass will need to be calibrated. You
may also place the compass in a non
-calibrated mode by
pressing and holding the MODE and US/MET buttons
simultaneously while in the COMP/TEMP mode. After
about 10 seconds, the compass will display ªCº and
you can release the buttons. Drive the vehicle in a
complete 360 degree circle three times at a speed of less
than 5 mph (8 km/h), and the compass will function
normally. Once the calibration is complete, the display
will return to a compass reading.
ProCarManuals.com

2-48
Variance is the difference between magnetic north and
geographic north. In some areas, the difference between
the two can be great enough to cause false compass
readings. If this happens, follow these instructions to
set the variance for your particular location:
1. Find your location on the zone map. Record your
zone number.
2. Press and hold both the MODE and the US/MET
buttons in the COMP/TEMP mode.3. After five seconds, the compass will acknowledge
the variation mode by displaying the current zone
number. When it does, release both buttons.
4. Press US/MET until your zone number appears on
the display.
5. Press MODE to enter your zone number. Your
variance is now set and the display will return to the
COMP/TEMP mode.
TRIP: Pressing the MODE button will step you through
the following TRIP functions:

AVG ECON: The average fuel economy since the
last reset is displayed.

INST ECON: Instantaneous fuel economy for the
last second of driving is displayed.

RANGE: The display indicates the estimated
distance that can be travelled with the remaining fuel
in the tank, based on the fuel economy for the last
few hours of driving.

FUEL USED: The fuel used since the last reset
is displayed.

AVG SPEED: The average speed since the last reset
is displayed.
ProCarManuals.com

2-49
To reset the trip computer, press the MODE and
US/MET buttons simultaneously for at least two seconds.
All functions will be displayed briefly once the system is
reset. Reset can only be performed in the AVG ECON,
FUEL USED and AVG SPEED modes. All three modes
are reset simultaneously.
Sunglasses Storage Compartment
To open the sunglasses storage compartment in the
overhead console, press the release button. Then pull the
compartment down.
Door Storage
You will find a storage compartment on each of the
doors. Cupholders are also located on the doors.
Front Storage Area
Lift the armrest cover of the console compartment to
reveal a coinholder and additional storage. Ribs have
been provided for convenient storage of cassette tapes
and compact discs.
ProCarManuals.com

2-50 Convenience Net
A convenience net in the rear of your vehicle helps
keep small items, like gloves and light clothing in place
during sharp turns or quick stops and starts.
The net is not designed to retain these items during
off
-road use. The net is not for larger, heavier items.
Attach the upper loops to the retainers on either side of
the liftgate opening (the label should be in the upper
passenger's side corner, visible from the rear of vehicle).
Attach the lower hooks to the rear cargo tie downs on
the floor.
Cargo Security Shade
You can use the cargo security shade to cover items in
the cargo area of your vehicle.
Grasp the handle and unroll the cover. Latch the posts
into the sockets on the inside of the vehicle to secure it.
CAUTION:
An improperly stored cargo cover could be
thrown about the vehicle during a collision or
sudden maneuver. You or others could be
injured. If you remove the cover, always store
it outside of the vehicle. When you put it back,
always be sure that it is securely reattached.
ProCarManuals.com

2-51
Cargo Tie Downs
There are five cargo tie
downs in the rear that allow
you to strap cargo in and
keep it from moving inside
the vehicle.
Rear Convenience System (If Equipped)
CAUTION:
If the convenience system isn't secured properly,
it can move around in a collision or sudden stop.
People in the vehicle could be injured. Be sure to
secure the convenience system properly.
The convenience system, located in the rear of your vehicle,
provides a place to store loose items in your vehicle.
A. Collapsible Dividers
B. Anchor Bracket/Cargo Tie
-Down Plugs
C. Partitions
D. Soda Pop/Gallon Jug Holder
E. Partition Storage
F. Cargo Tie
-Down Cutouts
ProCarManuals.com

2-52
To increase the space in the convenience system, do
the following:
1. Remove the individual partitions (C) by pulling
upward on the partitions. Storage for the partitions
is located in area (F).
2. Then fold the collapsible dividers (A) by pulling
upward and folding the dividers toward each other.
To reinstall or rearrange the partitions, push down gently
on the partitions making sure both sides fit into the
appropriate slots of the collapsible dividers (A).
Located on the top of each collapsible divider (A) are
T
-pins designed to hold grocery bags, etc., in an
upright position.
The anchor bracket/cargo tie down plugs (B), located in
the center and on each side of the convenience system
nearest the passenger compartment, are used to help seal
the convenience system. However, the plugs also cover
the anchor bracket /cargo tie
-downs. To remove the
plugs, grasp the edges of the plugs and pull straight out.
See ªChild Restraintsº and ªTop Strapº in the Index
for more information on using anchor brackets.There are two cutouts (E) for the rear cargo tie
-downs
located near the liftgate/endgate sill. In order to access
the rear cargo tie
-downs, the cutouts must be removed.
You will also find a soda pop/gallon jug holder (D) on
the passenger side of the convenience system. OnStar


equipped vehicles do not have this feature, but instead
include a smaller storage area.
To remove the entire convenience system, do
the following:
1. Remove the convenience net if it is in place.
See ªConvenience Netº in the Index for more
information. You may also want to remove the
partitions (C) and fold the collapsible dividers (A)
to make the convenience system easier to handle.
2. Grasp the sides of the convenience system and push
the sides together while sliding the unit out until it
clears the sides of the liftgate/endgate opening.
To reinstall the convenience system, reverse the
removal procedure.
ProCarManuals.com

2-53 Luggage Carrier
CAUTION:
If you try to carry something on top of your
vehicle that is longer or wider than the luggage
carrier
-- like paneling, plywood, a mattress, and
so forth
-- the wind can catch it as you drive
along. This can cause you to lose control. What
you are carrying could be violently torn off, and
this could cause you or other drivers to have a
collision, and of course damage your vehicle. You
may be able to carry something like this inside.
But, never carry something longer or wider than
the luggage carrier on top of your vehicle.
A luggage carrier allows you to load things on top of
your vehicle. The luggage carrier has slats and side rails
attached to the roof, sliding crossrails and places to use
for tying things down. These let you load some other
things on top of your vehicle, as long as they are not
wider or longer than the luggage carrier.To slide the crossrails to where you want them, push up
on the lever under each side of the crossrail. This will
release the crossrail and allow you to slide it. When the
crossrail is where you want it, push down on the lever to
lock it into place.
NOTICE:
Loading cargo that weighs more than 200 lbs.
(91 kg) on the luggage carrier may damage
your vehicle.
When you carry cargo on the luggage carrier of a
proper size and weight, put it on the slats, as far
forward as you can. Then slide the crossrail up
against the rear of the load, to help keep it from
moving. You can then tie it down.
Don't exceed the maximum vehicle capacity when
loading your vehicle. For more information on vehicle
capacity and loading, see ªLoading Your Vehicleº in
the Index.
To prevent damage or loss of cargo as you're driving,
check now and then to make sure the luggage carrier is
locked and cargo is still securely fastened.
ProCarManuals.com

2-54
Ashtrays and Cigarette Lighter
Pull the front ashtray door down to open it.
NOTICE:
Don't put papers and other things that burn
into your ashtray. If you do, cigarettes or
other smoking materials could set them on fire
causing damage.
To remove the front ashtray, pull the bin upward.
To use the lighter, press it in all the way, and let go.
When it's ready, it will pop back out by itself.
NOTICE:
Don't hold a cigarette lighter in with your hand
while it is heating. If you do, it won't be able to
back away from the heating element when it's
ready. That can make it overload, damaging the
lighter and the heating element.
Sun Visors
You can move down your visor to block out glare.
You can also move the visor from side
-to-side.
Visor Vanity Mirror
Pull the sun visor down and lift the cover to expose the
vanity mirror.
Illuminated Visor Vanity Mirror
Pull the sun visor down and lift the mirror cover to turn
on the lamps.
ProCarManuals.com

2-55
Accessory Power Outlets
With the accessory power outlets, you can plug in
auxiliary electrical equipment. The accessory power outlets
are located near the center of the vehicle on the lower part
of the instrument panel. Just remove the plug from the
outlet and follow the proper installation instructions that
are included with any electrical equipment you install.
Certain accessory power plugs may not be compatible
to the accessory power outlets and could result in blown
vehicle or adaptor fuses. If you experience a problem
see your dealer for additional information on the power
accessory plugs.
These circuits are protected by a fuse and have
maximum current levels.
NOTICE:
Adding some electrical equipment to your vehicle
can damage it or keep other things from working
as they should. This wouldn't be covered by your
warranty. Check with your dealer before adding
electrical equipment, and never use anything that
exceeds the fuse rating.
OnStar
System (If Equipped)
OnStar is a vehicle communications system that
offers a variety of services and provides a hands
-free
communication link between you and the OnStar Center.
A service subscription agreement and fee are required in
order to receive OnStar service. Services are available
24 hours a day, 7 days a week. For more information,
call 1
-888-ONSTAR-7 (1-888-667-8277).
OnStar Services Button: Press this button once
to contact an advisor who will be able to assist you with
these services. If you are not quickly connected, the
system will automatically reset and redial. This ensures
connection to the center; there is no additional action
required. Press the Call Answer/End button to cancel
the automatic redial.
ProCarManuals.com
