OLDSMOBILE INTRIGUE 1999 Owners Manual

yellowblue
2-41 Exit Illumination
To see better when exiting your vehicle at night, your
vehicle is equipped with an Exit Illumination feature.
The interior lamps will illuminate for up to 25 seconds
when you remove your key from the ignition. After
25 seconds have elapsed, the interior lamps will slowly
fade out. The lamps will fade out before the 25 seconds
have elapsed if you:

turn the ignition to ON.

lock all doors using your remote keyless entry
transmitter (if equipped).

lock the doors using the power door lock switch.
When any door is opened, Exit Illumination is
cancelled. The interior lamps will stay on while any
door is opened. The interior lamps may stay on for up to
25 seconds after all the doors have been closed if they
have not been locked. See ªDelayed Illuminationº in
the Index.
Battery Saver
Your vehicle has a feature to help prevent you from
draining the battery in case you accidentally leave an
interior or trunk lamp on. If you leave any of these
lamps on while the ignition is in ACC or OFF, they will
automatically turn off after 20 minutes. The lamps won't
come back on until you do one of the following:

turn the ignition to ON,

turn the interior lamp dial all the way up or

open (or close and reopen) a door that is closed.
Note that if your vehicle has less than 15 miles (25 km)
on the odometer, the battery saver will turn off the lamps
after only three minutes.
Mirrors
Adjust all mirrors so you can see clearly when you are
sitting in a comfortable position.
Inside Day/Night Rearview Mirror
To reduce glare from lamps behind you, push the
lever away from you (to the night position). To return
the mirror back to the day position, pull the lever
toward you.
ProCarManuals.com

yellowblue
2-42 Electrochromic Day/Night Rearview Mirror
with Compass and Map Lamps
(If Equipped)
Your vehicle may have an automatic electrochromic
day/night rearview mirror with a compass and
map lamps.
This mirror automatically changes to reduce glare from
headlamps behind you. A time delay feature prevents
rapid changing from the day to night positions while
driving under lights and through traffic.
The mirror includes two map lamps, an automatic
dimming function and an eight
-point compass display in
the upper corner of the mirror face. When the compass
display is turned on, the compass automatically
calibrates as the vehicle is driven.
The automatic dimming feature is turned on or off by
pressing the IO button located on the lower part of the
mirror. Press and hold the IO button for up to three
seconds to turn this feature on or off.
The compass display feature is turned on or off by
pressing the IO button for three seconds or more.
When cleaning the mirror, use a paper towel or similar
material dampened with glass cleaner. Do not spray
glass cleaner directly on the mirror housing.
ProCarManuals.com

yellowblue
2-43
Compass Calibration
To place the compass into calibration mode, press both
map lamp buttons and hold for over eight seconds
until the letter ªCº is displayed in the mirror
compass window.
The mirror can be calibrated in one of two ways:

drive the vehicle in circles at 5 mph (8 km/h) or less
until the display indicates a direction, or

drive the vehicle on your everyday routine.
Compass Variance
The mirror is set in zone eight upon leaving the factory.
It will be necessary to adjust the compass to compensate
for compass variance if you live outside zone eight.
Under certain circumstances, as during a long distance
cross
-country trip, it will be necessary to adjust for
compass variance. Compass variance is the difference
between earth's magnetic north and true geographic
north. If not adjusted to account for compass variance,
your compass could give false readings.
To adjust for compass variance:
1. Find your current location and variance zone number
on the following zone map.2. Press and hold both map lamp buttons on the bottom
of the mirror, for five to eight seconds, until the zone
number appears in the display.
3. Press the right lamp button to increase the zone
numbers or press the left lamp button to decrease the
zone numbers. After you have selected your zone
number, the display will show a compass direction
after five seconds. (Compass calibration may be
necessary. See ªCompass Calibrationº in the Index.)
ProCarManuals.com

yellowblue
2-44 Power Outside Mirrors
The power mirror control is
near the driver's window,
on the armrest.
Switch the upper control to the left to adjust the left
mirror or to the right to adjust the right mirror. Then
press the lower control in the direction you want to
move the mirror.
Convex Outside Mirror
Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from the
driver's seat.
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder before
changing lanes.
Heated Outside Mirrors (If Equipped)
The left and right outside mirrors are heated when you
activate the rear window defogger. (See ªRear Window
Defoggerº in the Index.)
Storage Compartments
Glove Box
Use the key to lock and unlock the glove box.
ProCarManuals.com

yellowblue
2-45 Rear Console Cupholders
The cupholders are located in the rear of the front
console. Pull down to use the cupholders.
Center Console
To open the storage area located between the driver's
and passenger's seat, press back on the front edge and
lift the cover. The console has a cassette tape and
compact disc storage and a coinholder. The cupholder is
right below the center console. Push down on the door
and the cupholder will come out.
Convenience Net (If Equipped)
Your vehicle may have a convenience net. You'll see it
on the back wall of the trunk.
Put small loads, like grocery bags, behind the net. It can
help keep them from falling over during sharp turns or
quick starts and stops.
The net isn't for larger, heavier loads. Store them in the
trunk as far forward as you can.
You can unhook the net so that it will lie flat when
you're not using it. You can also push the net down and
hook it under the plastic hooks.
Ashtrays and Cigarette Lighter
When your vehicle is delivered, the ashtray and cigarette
lighter assembly will be in a plastic bag placed in the
center console storage area. If the ashtray and lighter are
needed, insert the ashtray and holder into the stationary,
open cupholder in front of the shift lever.
The lighter outlet is located behind a flip
-out door just
below the heating and air conditioning controls.
ProCarManuals.com

yellowblue
2-46
Sun Visors
To block out the glare, you can swing down the visors.
You can also swing them from front to side.
Visor Vanity Mirrors
Open the cover to expose the vanity mirror. If your
vehicle has the optional lighted vanity mirrors, the
lamps will come on when you open the cover.
Accessory Power Outlets
The power outlets are located on the lower left
passenger side and behind the flip
-out door of
the lighter.The power outlets can be used to plug electrical
equipment such as a cellular telephone, compact disc
radio, etc. Follow the proper installation instructions that
are included with any electrical equipment you install.
OnStar System (Option)
OnStar is a vehicle communications service which
may be ordered through your dealer. The following
OnStar services are available 24 hours a day:

Roadside Service with Location

Emergency Services Button

Remote Door Unlock

Vehicle Theft Tracking

Automatic Notification of Air Bag Deployment

Concierge/Customer Conveniences Services
For more information, contact your dealer.
Power Sunroof (If Equipped)
Your vehicle may be equipped with an express-open
sunroof. It includes a sliding and tilting glass panel and
a one
-piece sunshade. The control switch works only
when the ignition is in ACC or ON. The control switch
is located overhead on the headliner.
ProCarManuals.com

yellowblue
2-47
To open the power sunroof, press the rear of the switch
once and the power sunroof will fully open. This is the
express
-open feature. During operation, press the switch
again to stop the power sunroof at a desired position.Your sunroof also has a vent feature. It can be activated
from the closed sunroof position by pressing the front of
the switch. To close, press the rear of the sunroof switch.
When using this feature the sunshade should be fully
opened in the rearward position.
The sunshade can be opened manually by sliding it
rearward or automatically by opening the power
sunroof. You will need to close the sunshade manually
by sliding it forward.
To close the sunroof, press and hold the front of the
switch until the sunroof motor stops, or release the
switch when a desired position has been reached.
ProCarManuals.com

yellowblue
2-48
The Instrument Panel -- Your Information System
ProCarManuals.com

yellowblue
2-49
Your instrument panel is designed to let you know at a glance how your vehicle is running. You'll know how fast
you're going, about how much fuel is in your tank and many other things you need to drive safely and economically.
The main components of your instrument panel are:
A. Side Window Defogger Vent
B. Instrument Panel Outlets
C. Turn Signal/Multifunction Lever
D. Instrument Panel Cluster
E. Windshield Wipers/Washer Fluid Lever
F. Cruise Control (CRUISE) Button
G. Hazard Switch
H. Instrument Panel Fuse Block
I. Instrument Panel Dimmer
J. Fog Lamp Button
K. Fuel Door Release
L. Trunk Lid ReleaseM. Storage Bin
N. Trip Odometer
O. Tilt Wheel
P. Audio Steering Wheel Controls (If Equipped)
Q. Horn
R. Cruise Control Controls (RES ACCEL, CLEAR,
COAST SET)
S. Ignition Switch
T. Accessory Power Outlet
U. Comfort Controls
V. Audio System
W. Glove Box
ProCarManuals.com

yellowblue
2-50 Instrument Panel Cluster
3800 V6 Engine shown, 3.5L Similar
ProCarManuals.com
