NOTICE:
If you use an improper coolant mixture, your
engine could overheat and be badly damaged.
The repair cost wouldn't be covered by your
warranty. Too much water in the mixture can
freeze and crack the engine, radiator, heater core
and other parts.
If you have to add coolant more than four times a year,
have your dealer check your cooling system.
NOTICE:
If you use the proper coolant, you don't have to
add extra inhibitors or additives which claim to
improve the system. These can be harmful.
Checking Coolant (3800 V6 Engine)
The coolant recovery tank for the 3800 V6 engine is
located in the engine compartment, behind the headlamp
on the driver's side.
The vehicle must be on a level surface. When your
engine is cold, the coolant level should be at the COLD
mark or a little higher. When your engine is warm, the
level should be up to the HOT mark or a little higher.
ProCarManuals.com

yellowblue
6-38
CAUTION:
Batteries have acid that can burn you and gas
that can explode. You can be badly hurt if you
aren't careful. See ªJump Startingº in the Index
for tips on working around a battery without
getting hurt.
Contact your dealer to learn how to prepare your vehicle
for longer storage periods.
Also, for your audio system, see ªTheft
-Deterrent
Featureº in the Index.
Bulb Replacement
For the proper type of replacement bulb, see
ªReplacement Bulbsº in the Index.
Halogen Bulbs
CAUTION:
Halogen bulbs have pressurized gas inside and
can burst if you drop or scratch the bulb. You or
others could be injured. Be sure to read and
follow the instructions on the bulb package.
Headlamps
To replace your headlamps follow these steps:
1. Open the hood.
ProCarManuals.com

yellowblue
6-39
2. Pull straight up on the two headlamp retainers to
release the assembly locator tabs and take the
retainers off. At the same time, hold the headlamp
assembly in position by applying a little pressure
against the headlamp lens. This prevents the lamp
from falling out.3. Slide the lamp forward.
ProCarManuals.com

yellowblue
6-40
4. Remove the rubber access cover from behind the
bulb you are replacing.
5. Twist and turn the bulb socket counterclockwise and
remove it from the lamp.6. Replace the bulb.
7. Reverse all steps and reassemble the headlamp
assembly, then check the lamps.
ProCarManuals.com

yellowblue
6-41
Headlamp Aiming
Your vehicle has a headlamp system equipped with
horizontal and vertical aim indicators. The aim has been
pre
-set at the factory and should need no further
adjustment. This is true even though your vertical and
horizontal aim indicators may not fall exactly on the ª0º
(zero) marks on their scales.
If your vehicle is damaged in an accident, the headlamp
aim may be affected. Aim adjustment may be necessary
if it is difficult to see lane markers (for horizontal aim),
or if oncoming drivers flash their high beams at you (for
vertical aim). If you believe your headlamps need to be
re
-aimed, we recommend that you take it to your dealer
for service; however, it is possible for you to re
-aim
your headlamps as described in the following procedure.
NOTICE:
To make sure your headlamps are aimed
properly, read all the instructions before
beginning. Failure to follow these instructions
could cause damage to headlamp parts.
The vehicle should be properly prepared as follows:

The vehicle must have all four tires on a perfectly
level surface.

If necessary, pads may be used on an uneven surface.

The vehicle should not have any snow, ice or mud
attached to it.

The vehicle should be fully assembled and all other
work stopped while headlamp aiming is being done.

There should not be any cargo or loading of the
vehicle, except it should have a full tank of fuel and
one person or 160 lbs. (75 kg) on the driver's seat.

Close all doors.

Tires should be properly inflated.

Rock the vehicle to stabilize the suspension.
ProCarManuals.com

yellowblue
6-43 Front Parking, Sidemarker and Turn Signal
Cornering Lamp
1. Remove the headlamp assembly. Refer to the
removal procedure earlier in this section.
2. Remove the rubber bulb access cover.
3. Twist and pull each bulb socket from the
headlamp assembly.
4. Holding the base of the bulb, pull the bulb from
the socket.
5. Push the new bulb into the socket.
6. Put the bulb socket back into the headlamp assembly
and turn it clockwise until it is secure.
7. Replace the rubber access cover.
Center High-Mounted Stoplamp
1. Open the trunk.
2. Reach through the access opening in the trunk.
3. Remove the bulb by turning it one
-quarter of a
turn counterclockwise.
ProCarManuals.com

yellowblue
6-52 Wheel Alignment and Tire Balance
The wheels on your vehicle were aligned and balanced
carefully at the factory to give you the longest tire life
and best overall performance.
Scheduled wheel alignment and wheel balancing are not
needed. However, if you notice unusual tire wear or
your vehicle pulling one way or the other, the alignment
may need to be reset. If you notice your vehicle
vibrating when driving on a smooth road, your wheels
may need to be rebalanced.
Wheel Replacement
Replace any wheel that is bent, cracked, or badly rusted
or corroded. If wheel nuts keep coming loose, the wheel,
wheel bolts and wheel nuts should be replaced. If the
wheel leaks air, replace it (except some aluminum
wheels, which can sometimes be repaired). See your
dealer if any of these conditions exist.
Your dealer will know the kind of wheel you need.
Each new wheel should have the same load
-carrying
capacity, diameter, width, offset and be mounted the
same way as the one it replaces.
If you need to replace any of your wheels, wheel bolts
or wheel nuts, replace them only with new GM original
equipment parts. This way, you will be sure to have the
right wheel, wheel bolts and wheel nuts for your vehicle.
CAUTION:
Using the wrong replacement wheels, wheel bolts
or wheel nuts on your vehicle can be dangerous.
It could affect the braking and handling of your
vehicle, make your tires lose air and make you
lose control. You could have a collision in which
you or others could be injured. Always use the
correct wheel, wheel bolts and wheel nuts
for replacement.
NOTICE:
The wrong wheel can also cause problems with
bearing life, brake cooling, speedometer or
odometer calibration, headlamp aim, bumper
height, vehicle ground clearance and tire
clearance to the body and chassis.
See ªChanging a Flat Tireº in the Index for
more information.
ProCarManuals.com

yellowblue
6-63
Electrical System
Add-On Electrical Equipment
NOTICE:
Don't add anything electrical to your vehicle
unless you check with your dealer first. Some
electrical equipment can damage your vehicle
and the damage wouldn't be covered by your
warranty. Some add
-on electrical equipment can
keep other components from working as
they should.
Your vehicle has an air bag system. Before attempting to
add anything electrical to your vehicle, see ªServicing
Your Air Bag
-Equipped Vehicleº in the Index.
Headlamp Wiring
The headlamp wiring is protected by separate left and
right headlamp fuses in the underhood electrical center.
An electrical overload will cause a lamp to go off and
remain off. If this happens, have your headlamp system
checked right away.
Windshield Wipers
The windshield wiper motor is protected by a circuit
breaker and a fuse. If the motor overheats due to heavy
snow, etc., the wiper will stop until the motor cools. If
the overload is caused by some electrical problem, have
it fixed.
Power Windows and Other Power Options
Circuit breakers in the fuse panel protect the power
windows and other power accessories. When the current
load is too heavy, the circuit breaker opens and closes,
protecting the circuit until the problem is fixed.
Fuses and Circuit Breakers
The wiring circuits in your vehicle are protected from
short circuits by a combination of fuses, circuit breakers
and fusible thermal links in the wiring itself. This
greatly reduces the chance of fires caused by
electrical problems.
Look at the silver
-colored band inside the fuse. If the
band is broken or melted, replace the fuse. Be sure you
replace a bad fuse with a new one of the identical size
and rating.
ProCarManuals.com

yellowblue
6-69
Fuse Description
27 Horn
28 Fuel Injector (3800 V6 Engine Only)
Fuel Injector, Electronic Ignition
(3.5L V6 Engine Only)
29 Oxygen Sensor
30 Engine Emissions
31 Not Used
32 Headlamp (Right)
33 Rear Compartment Release/Fuel
Door Release
34 Parking Lamp
35 Fuel Pump
36 Headlamp (Left)
37 Spare
38 Spare
39 Spare
40 Spare
41 Spare
42 Spare Diode Description
A/C Clutch Diode
43 Fuse Puller
Replacement Bulbs
Center High-Mounted Stop
In Spoiler 891. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
On Shelf 1141. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Parking/Turn Signal 4157 NAK. . . . . . . . . . . . .
Headlamp
High Beam 9005. . . . . . . . . . . . . . . . . . . . . . . . . . .
Low Beam 9006. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sidemarker (Front/Rear) 194. . . . . . . . . . . . . . . . . . .
Stop/Tail/Turn Signal (Rear) 3057. . . . . . . . . . . . . . .
Cornering 3156. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ProCarManuals.com

yellowblue
9-2
Brake (Continued)
Parking 2-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pedal Travel 6-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing System Parts 6-37 . . . . . . . . . . . . . . . . . . . . . . . .
System Warning Light 2-54 . . . . . . . . . . . . . . . . . . . . . . . . .
Trailer 4-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transaxle Shift Interlock Check 2-22, 7-16 . . . . . . . . . . . . .
Wear 6-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brakes, Anti-Lock 4-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking in Emergencies 4-11 . . . . . . . . . . . . . . . . . . . . . . . . . .
Break-In, New Vehicle 2-15 . . . . . . . . . . . . . . . . . . . . . . . . . .
Brightness Control 2-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BTSI Check 2-22, 7-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulb Replacement 6-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center High-Mounted Stoplamp 6-43 . . . . . . . . . . . . . . . . .
Front Cornering 6-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Parking 6-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Sidemarker 6-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Turn Signal 6-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlamps 6-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Taillamp 6-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Canada, Ordering Service and Owner Publications 8-12 . . .
Canadian Roadside Assistance 8-7 . . . . . . . . . . . . . . . . . . . . . .
Capacities and Specifications 6-70 . . . . . . . . . . . . . . . . . . . . . .
Carbon Monoxide 2-13, 2-28, 4-31 . . . . . . . . . . . . . . . . . . . .
Cassette Deck Service 7-14 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cassette Tape Player 3-10, 3-14 . . . . . . . . . . . . . . . . . . . . . . .
Care 3-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Errors 3-12, 3-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center High-Mounted Stoplamp Bulb Replacement 6-43 . . . . Center Passenger Position 1
-32 . . . . . . . . . . . . . . . . . . . . . . . .
Certification/Tire Label 4-33 . . . . . . . . . . . . . . . . . . . . . . . . . .
Chains, Safety 4-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chains, Tire 6-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Change Oil Light 2-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing a Flat Tire 5-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Charging System 2-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking Your Restraint Systems 1-51 . . . . . . . . . . . . . . . . . .
Chemical Paint Spotting 6-60 . . . . . . . . . . . . . . . . . . . . . . . . . .
Child Restraints 1-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Add-On 1-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Securing in a Rear Outside Seat Position 1-42 . . . . . . . . . . .
Securing in the Center Rear Seat Position 1-44 . . . . . . . . . .
Securing in the Right Front Seat Position 1-46 . . . . . . . . . .
Top Strap 1-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Where to Put 1-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cigarette Lighter 2-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Circuit Breakers and Fuses 6-63 . . . . . . . . . . . . . . . . . . . . . . .
Cleaner, Air/Filter 6-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning
Aluminum Wheels 6
-59 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exterior Lamps/Lenses 6-58 . . . . . . . . . . . . . . . . . . . . . . . .
Fabric 6-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glass 6-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside of Your Vehicle 6-54 . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument Panel 6-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior Plastic Components 6-56 . . . . . . . . . . . . . . . . . . . . .
Leather 6-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside of Your Vehicle 6-57 . . . . . . . . . . . . . . . . . . . . . . . .
Special Problems 6-55 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stains 6-55 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ProCarManuals.com
