2-27 Torque Lock
If you are parking on a hill and you don't shift your
transaxle into PARK (P) properly, the weight of the
vehicle may put too much force on the parking pawl in
the transaxle. You may find it difficult to pull the shift
lever out of PARK (P). This is called ªtorque lock.º To
prevent torque lock, set the parking brake and then shift
into PARK (P) properly before you leave the driver's
seat. To find out how, see ªShifting Into PARK (P)º in
the Index.
When you are ready to drive, move the shift lever out of
PARK (P) before you release the parking brake.
If torque lock does occur, you may need to have another
vehicle push yours a little uphill to take some of the
pressure from the parking pawl in the transaxle, so you
can pull the shift lever out of PARK (P).
Shifting Out of Park (P)
Your vehicle has a Brake-Transaxle Shift Interlock
(BTSI). You must fully apply your regular brakes before
you can shift from PARK (P) when the ignition is in
ON. See ªAutomatic Transaxle Operationº in the Index.
If you cannot shift out of PARK (P), ease pressure on
the shift lever by pushing it all the way into PARK (P)
while keeping the brake pedal pushed down. Release the
shift lever button as you maintain brake application.
Then move the shift lever out of PARK (P) into the gear
that you wish.
If you ever hold the brake pedal down, but still can't
shift out of PARK(P), try this:
1. Turn the key to ACC.
2. Apply and hold the brake.
3. Shift to NEUTRAL (N).
4. Start the engine, and then shift to the drive gear
you want.
5. Have the vehicle fixed as soon as you can.
ProCarManuals.com

yellowblue
5-34
CAUTION:
Incorrect wheel nuts or improperly tightened
wheel nuts can cause the wheel to become loose
and even come off. This could lead to an accident.
Be sure to use the correct wheel nuts. If you have
to replace them, be sure to get new GM original
equipment wheel nuts.
Stop somewhere as soon as you can and have
the nuts tightened with a torque wrench to
100 lb
-ft (140 N´m).
NOTICE:
Improperly tightened wheel nuts can lead to
brake pulsation and rotor damage. To avoid
expensive brake repairs, evenly tighten the wheel
nuts in the proper sequence and to the proper
torque specification.
10. Replace the plastic nut caps tightly by hand. Using
wheel wrench, tighten caps an additional 1/4 turn.
Storing the Flat Tire and Tools
CAUTION:
Storing a jack, a tire or other equipment in the
passenger compartment of the vehicle could
cause injury. In a sudden stop or collision, loose
equipment could strike someone. Store all these
in the proper place.
After you've put the compact spare tire on your vehicle,
you'll need to store the flat tire in your trunk. Use the
following procedure to secure the flat tire in the trunk.
ProCarManuals.com

yellowblue
6-36
NOTICE:

Using the wrong fluid can badly damage
brake system parts. For example, just a few
drops of mineral
-based oil, such as engine
oil, in your brake system can damage brake
system parts so badly that they'll have to be
replaced. Don't let someone put in the
wrong kind of fluid.

If you spill brake fluid on your vehicle's
painted surfaces, the paint finish can be
damaged. Be careful not to spill brake fluid
on your vehicle. If you do, wash it off
immediately. See ªAppearance Careº in
the Index.
Brake Wear
Your vehicle has four-wheel disc brakes.
Disc brake pads have built
-in wear indicators that make a
high
-pitched warning sound when the brake pads are worn
and new pads are needed. The sound may come and go or
be heard all the time your vehicle is moving (except when
you are pushing on the brake pedal firmly).
CAUTION:
The brake wear warning sound means that soon
your brakes won't work well. That could lead to
an accident. When you hear the brake wear
warning sound, have your vehicle serviced.
NOTICE:
Continuing to drive with worn-out brake pads
could result in costly brake repair.
Some driving conditions or climates may cause a brake
squeal when the brakes are first applied or lightly
applied. This does not mean something is wrong with
your brakes.
Properly torqued wheel nuts are necessary to help
prevent brake pulsation. When tires are rotated, inspect
brake pads for wear and evenly torque wheel nuts in the
proper sequence to GM specifications.
ProCarManuals.com

yellowblue
6-48
When rotating your tires, always use the correct rotation
pattern shown here.
Don't include the compact spare tire in your
tire rotation.
After the tires have been rotated, adjust the front and
rear inflation pressures as shown on the Tire
-Loading
Information label. Make certain that all wheel nuts are
properly tightened. See ªWheel Nut Torqueº in
the Index.
CAUTION:
Rust or dirt on a wheel, or on the parts to which
it is fastened, can make wheel nuts become loose
after a time. The wheel could come off and cause
an accident. When you change a wheel, remove
any rust or dirt from places where the wheel
attaches to the vehicle. In an emergency, you can
use a cloth or a paper towel to do this; but be
sure to use a scraper or wire brush later, if you
need to, to get all the rust or dirt off. (See
ªChanging a Flat Tireº in the Index.)
ProCarManuals.com

yellowblue
9-11
Tire Loading 4-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire-Loading Information Label 4-32 . . . . . . . . . . . . . . . . . . .
Tires 6-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Alignment and Balance 6-52 . . . . . . . . . . . . . . . . . . . . . . . .
Buying New 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chains 6-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing a Flat 5-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning 6-59 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compact Spare 5-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inflation 6-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inflation Check 7-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inspection and Rotation 6-47 . . . . . . . . . . . . . . . . . . . . . . . .
Loading 4-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pressure 6-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temperature 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Traction 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Treadwear 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Uniform Quality Grading 6-50 . . . . . . . . . . . . . . . . . . . . . . .
Wear Indicators 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel Replacement 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . .
When It's Time for New 6-49 . . . . . . . . . . . . . . . . . . . . . . .
Top Strap 1-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Torque Lock 2-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Torque, Wheel Nut 5-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Towing a Trailer 4-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Towing Your Vehicle 5-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Traction
Control System 4
-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Control System Warning Light 2-56, 4-10 . . . . . . . . . . . . .
Enhanced System Warning Light 2-57, 4-10 . . . . . . . . . . . .
Low Light 2-58, 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Off Warning Light 2-56, 2-57, 4-10 . . . . . . . . . . . . . . . . . . Trailer
Brakes 4
-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving on Grades 4-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving with 4-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Cooling When Towing 4-41 . . . . . . . . . . . . . . . . . . .
Hitches 4-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance When Towing 4-41 . . . . . . . . . . . . . . . . . . . . .
Parking on Hills 4-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Chains 4-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tongue Weight 4-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Total Weight on Tires 4-37 . . . . . . . . . . . . . . . . . . . . . . . . . .
Towing 4-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn Signals 4-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Weight 4-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transaxle Fluid, Automatic 6-22 . . . . . . . . . . . . . . . . . . . . . . .
Transmitters, Matching to Your Vehicle 2-11 . . . . . . . . . . . . .
Transmitters, Remote Keyless Entry 2-9 . . . . . . . . . . . . . . . . .
Transportation, Courtesy 8-7 . . . . . . . . . . . . . . . . . . . . . . . . . .
Trip 2-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Before Leaving On A Long 4-23 . . . . . . . . . . . . . . . . . . . . .
Odometer 2-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trunk 2-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lock 2-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mounted CD Changer 3-20 . . . . . . . . . . . . . . . . . . . . . . . . .
Release, Remote 2-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TTY Users 8-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn Signal and Lane Change Signals 2-32 . . . . . . . . . . . . . . .
Turn Signal on Chime 2-32 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn Signal/Multifunction Lever 2-31 . . . . . . . . . . . . . . . . . . .
Turn Signals When Towing a Trailer 4-39 . . . . . . . . . . . . . . . .
ProCarManuals.com

yellowblue
9-12
Underbody Flushing Service 7-17 . . . . . . . . . . . . . . . . . . . . .
Underbody Maintenance 6-60 . . . . . . . . . . . . . . . . . . . . . . . . .
Underhood Electrical Center (Passenger's Side) 6-67 . . . . . . .
Vehicle
Control 4-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Damage Warnings iv. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions 6
-71 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Identification Number 6-62 . . . . . . . . . . . . . . . . . . . . . . . . .
Loading 4-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recreational Towing 4-31 . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage 6-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ventilation System 3-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Visor Vanity Mirrors 2-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Visors, Sun 2-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning Devices 5-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning Lights, Gages and Indicators 2-53 . . . . . . . . . . . . . . .
Warranty Information 8-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Washer Fluid, Windshield 6-33 . . . . . . . . . . . . . . . . . . . . . . . .
Washing Your Vehicle 6-57 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Weatherstrips 6-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Wheel
Alignment 6
-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Nut Torque 5-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wrench 5-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windows 2-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield Washer 2-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid 6-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid Level Check 7-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield Wipers 2-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Blade Cleaning 6-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Blade Replacement 6-45 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses 6-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Winter Driving 4-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiper Blade Check 7-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiper Blades, Cleaning 7-15 . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring, Headlamp 6-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wrench, Wheel 5-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ProCarManuals.com
