Part B: Owner Checks and Services
Listed in this part are owner checks and services which
should be performed at the intervals specified to help
ensure the safety, dependability and emission control
performance of your vehicle.
Be sure any necessary repairs are completed at once.
Whenever any fluids or lubricants are added to your
vehicle, make sure they are the proper ones, as shown
in Part D.
At Each Fuel Fill
It is important for you or a service station attendant to
perform these underhood checks at each fuel fill.
Engine Oil Level Check
Check the engine oil level and add the proper oil if
necessary. See ªEngine Oilº in the Index for
further details.
Engine Coolant Level Check
Check the engine coolant level and add DEX
-COOL

coolant mixture if necessary. See ªEngine Coolantº in
the Index for further details.Windshield Washer Fluid Level Check
Check the windshield washer fluid level in the
windshield washer tank and add the proper fluid if
necessary. See ªWindshield Washer Fluidº in the Index
for further details.
At Least Once a Month
Tire Inflation Check
Make sure tires are inflated to the correct pressures.
See ªTiresº in the Index for further details.
Cassette Deck Service
Clean cassette deck. Cleaning should be done every
50 hours of tape play. See ªAudio Systemsº in the
Index for further details.

yellowblue
7-32
Starter Switch Check
CAUTION:
When you are doing this check, the vehicle could
move suddenly. If it does, you or others could be
injured. Follow the steps below.
1. Before you start, be sure you have enough room
around the vehicle.
2. Firmly apply both the parking brake (see ªParking
Brakeº in the Index if necessary) and the
regular brake.
NOTE: Do not use the accelerator pedal, and be
ready to turn off the engine immediately if it starts.
3. Try to start the engine in each gear. The starter
should work only in PARK (P) or NEUTRAL (N).
If the starter works in any other position, your
vehicle needs service.Brake
-Transaxle Shift Interlock (BTSI) Check
CAUTION:
When you are doing this check, the vehicle could
move suddenly. If it does, you or others could be
injured. Follow the steps below.
1. Before you start, be sure you have enough room
around the vehicle. It should be parked on a
level surface.
2. Firmly apply the parking brake (see ªParking Brakeº
in the Index if necessary).
NOTE: Be ready to apply the regular brake
immediately if the vehicle begins to move.
3. With the engine off, turn the key to the RUN
position, but don't start the engine. Without applying
the regular brake, try to move the shift lever out of
PARK (P) with normal effort. If the shift lever
moves out of PARK (P), your vehicle's BTSI
needs service.

yellowblue
7-33
Ignition Transaxle Lock Check
While parked, and with the parking brake set, try to turn
the ignition key to LOCK in each shift lever position.

The key should turn to LOCK only when the shift
lever is in PARK (P).

The key should come out only in LOCK.
Parking Brake and Automatic Transaxle PARK (P)
Mechanism Check
CAUTION:
When you are doing this check, your vehicle
could begin to move. You or others could be
injured and property could be damaged. Make
sure there is room in front of your vehicle in case
it begins to roll. Be ready to apply the regular
brake at once should the vehicle begin to move.
Park on a fairly steep hill, with the vehicle facing
downhill. Keeping your foot on the regular brake, set the
parking brake.

To check the parking brake's holding ability: With
the engine running and transaxle in NEUTRAL (N),
slowly remove foot pressure from the regular brake
pedal. Do this until the vehicle is held by the parking
brake only.

To check the PARK (P) mechanism's holding ability:
With the engine running, shift to PARK (P). Then
release all brakes.
Underbody Flushing Service
At least every spring, use plain water to flush any
corrosive materials from the underbody. Take care to
clean thoroughly any areas where mud and other debris
can collect.

yellowblue
7-34
Part C: Periodic
Maintenance Inspections
Listed in this part are inspections and services which
should be performed at least twice a year (for instance,
each spring and fall). You should let your dealer's service
department or other qualified service center do these jobs.
Make sure any necessary repairs are completed at once.
Proper procedures to perform these services may be
found in a service manual. See ªService and Owner
Publicationsº in the Index.
Steering, Suspension and Front Drive Axle
Boot and Seal Inspection
Inspect the front and rear suspension and steering system
for damaged, loose or missing parts, signs of wear or lack
of lubrication. Inspect the power steering lines and hoses
for proper hook
-up, binding, leaks, cracks, chafing, etc.
Clean and then inspect the drive axle boot seals for
damage, tears or leakage. Replace seals if necessary.
Exhaust System Inspection
Inspect the complete exhaust system. Inspect the body near
the exhaust system. Look for broken, damaged, missing or
out
-of-position parts as well as open seams, holes, loose
connections or other conditions which could cause a heat
build
-up in the floor pan or could let exhaust fumes into
the vehicle. See ªEngine Exhaustº in the Index.
Engine Cooling System Inspection
Inspect the hoses and have them replaced if they are
cracked, swollen or deteriorated. Inspect all pipes, fittings
and clamps; replace as needed. Clean the outside of the
radiator and air conditioning condenser. To help ensure
proper operation, a pressure test of the cooling system and
pressure cap is recommended at least once a year.
Throttle System Inspection
Inspect the throttle system for interference or binding,
and for damaged or missing parts. Replace parts as
needed. Replace any components that have high effort
or excessive wear. Do not lubricate accelerator and
cruise control cables.
Brake System Inspection
Inspect the complete system. Inspect brake lines and
hoses for proper hook
-up, binding, leaks, cracks,
chafing, etc. Inspect disc brake pads for wear and rotors
for surface condition. Also inspect drum brake linings
for wear and cracks. Inspect other brake parts, including
drums, wheel cylinders, calipers, parking brake, etc.
Check parking brake adjustment. You may need to have
your brakes inspected more often if your driving habits
or conditions result in frequent braking.

yellowblue
8-12
CURRENT PUBLICATIONS FOR 1999 OLDSMOBILE
SERVICE MANUALS
Service Manuals have the diagnosis and repair information
on engines, transmission, axle, suspension, brakes,
electrical, steering, body, etc.
RETAIL SELL PRICE: $90.00
TRANSMISSION, TRANSAXLE, TRANSFER CASE
UNIT REPAIR MANUAL
This manual provides information on unit repair service
procedures, adjustments and specifications for the
1999 GM transmissions, transaxles and transfer cases.
RETAIL SELL PRICE: $50.00
SERVICE BULLETINS
Service Bulletins give technical service information needed
to knowledgeably service General Motors cars and trucks.
Each bulletin contains instructions to assist in the
diagnosis and service of your vehicle.OWNER'S INFORMATION
Owner publications are written directly for Owners and
intended to provide basic operational information about the
vehicle. The owner's manual will include the Maintenance
Schedule for all models.
In-Portfolio: Includes a Portfolio, Owner's Manual and
Warranty Booklet.
RETAIL SELL PRICE: $15.00
Without Portfolio: Owner's Manual only.
RETAIL SELL PRICE: $10.00
CURRENT & PAST MODEL ORDER FORMS
Service Publications are available for current and past
model GM vehicles. To request an order form, please
specify year and model name of the vehicle.
PLEASE COMPLETE THE ORDER FORM SHOWN ON
THE FOLLOWING PAGE AND MAIL TO:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207OR ORDER TOLL FREE: 1-800-551-4123
Monday-Friday 8:00 AM ± 6:00 PM Eastern Time
For Credit Card Orders Only (VISA±MasterCard±Discover)
1999 OLDSMOBILE SERVICE PUBLICATIONS ORDERING INFORMATION
The following publications covering the operation and servicing of your vehicle can be purchased by filling out
the Service Publication Order Form in this book and mailing it in with your check, money order,
or credit card information to Helm, Incorporated (address below.)

yellowblue
9-3
Cleaning
Aluminum Wheels 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Built-in Child Restraint Pad 6-49 . . . . . . . . . . . . . . . . . . . .
Exterior Lamps/Lenses 6-51 . . . . . . . . . . . . . . . . . . . . . . . .
Fabric/Carpet 6-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glass 6-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside of Your Vehicle 6-47 . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument Panel 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior Plastic Components 6-49 . . . . . . . . . . . . . . . . . . . . .
Leather 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside of Your Vehicle 6-51 . . . . . . . . . . . . . . . . . . . . . . . .
Special Problems 6-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stains 6-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires 6-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vinyl 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheels 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield, Backglass and Wiper Blades 6-50 . . . . . . . . . .
Wiper Blades 6-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Climate Control System 3-2 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clock, Setting the 3-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compact Disc
Care 3
-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Player 3-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Player Care 3-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Player Errors 3-17, 3-20 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Player, Remote 3-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compact Overhead Console 2-69 . . . . . . . . . . . . . . . . . . . . . .
Compact Spare Tire 5-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Content Theft-Deterrent 2-33 . . . . . . . . . . . . . . . . . . . . . . . . .
Arming Confirmation 2-34 . . . . . . . . . . . . . . . . . . . . . . . . . .
Arming with the Power Lock Switch 2-34 . . . . . . . . . . . . . .
Arming with the Remote Lock Control Transmitter 2-34 . . . .
Arming with Your Key 2-34 . . . . . . . . . . . . . . . . . . . . . . . . . Disarming with the Remote Lock
Control Transmitter 2
-35 . . . . . . . . . . . . . . . . . . . . . . . . . .
Disarming with Your Key 2-35 . . . . . . . . . . . . . . . . . . . . . .
Nuisance Alarms 2-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Control of a Vehicle 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Convenience Net 2-74 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Convex Outside Mirror 2-68 . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant 6-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding 6-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking 6-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Heater, Engine 2-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recovery Tank 5-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
What to Use 6-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cooling System 5-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Courtesy Transportation 8-7 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cruise Control 2-58 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cupholders 2-73 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Customer Assistance
For Text Telephone Users 8
-4 . . . . . . . . . . . . . . . . . . . . . . .
Information 8-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Offices 8-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Customer Satisfaction Procedure 8-2 . . . . . . . . . . . . . . . . . . . .
Damage
Finish 6-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sheet Metal 6-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Daytime Running Lamps (DRL) 2-62 . . . . . . . . . . . . . . . . . . .
Dead Battery 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Defects, Reporting Safety 8-10 . . . . . . . . . . . . . . . . . . . . . . . .
Defensive Driving 4-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Defogger, Rear Window 3-5 . . . . . . . . . . . . . . . . . . . . . . . . . .
Defogging 3-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Defrosting 3-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
9-4
Delayed Illumination 2-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions, Vehicle 6-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dome Lamp 2-66 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door
Locks 2
-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Sliding 2-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sliding 2-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Ajar Light 2-99 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driver Information Center (DIC) 2-101 . . . . . . . . . . . . . . . . . .
Driver Position 1-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driver's Four-Way Manual Seat 1-2 . . . . . . . . . . . . . . . . . . . .
Driving
City 4
-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Defensive 4-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Drunken 4-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Freeway 4-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In a Blizzard 4-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In Foreign Countries 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
In the Rain 4-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Night 4-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
On Curves 4-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
On Grades While Towing a Trailer 4-38 . . . . . . . . . . . . . . .
On Hill and Mountain Roads 4-23 . . . . . . . . . . . . . . . . . . . .
On Snow and Ice 4-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Through Water 4-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wet Roads 4-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Winter 4-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
With a Trailer 4-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Drunken Driving 4-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical Equipment, Adding 2-41, 3-25 . . . . . . . . . . . . . . .
Electrical System 6-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electronic Level Control 4-31 . . . . . . . . . . . . . . . . . . . . . . . . . Engine 6
-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Cleaner/Filter 6-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant 6-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Heater 2-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Level Check 7-30 . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Temperature Gage 2-94 . . . . . . . . . . . . . . . . . . . . .
Coolant Temperature Warning Light 2-94 . . . . . . . . . . . . . .
Exhaust 2-52, 4-28, 4-36 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Identification 6-55 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil Level Check 7-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overheated Protection Operating Mode 5-10 . . . . . . . . . . .
Overheating 5-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Running While Parked 2-52 . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications 6-64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting Your 2-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Oil 2-98, 6-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Additives 6-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking 6-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Used 6-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
What Kind to Use 6-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
When to Add 6-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
When to Change 6-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Equipment, Adding to the Outside of Your Vehicle 6-3 . . . . . .
Exhaust, Engine 2-52, 4-28, 4-36 . . . . . . . . . . . . . . . . . . . . . .
Exit Lighting 2-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fabric Cleaning 6-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filling a Portable Fuel Container 6-7 . . . . . . . . . . . . . . . . . . . .
Filling Your Tank 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filter, Air 6-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filter, Passenger Compartment Replacement 6-16 . . . . . . . . .
Finish
Care 6
-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Damage 6-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
9-5
FIRST (1) Gear 2-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Flashers, Hazard Warning 5-2 . . . . . . . . . . . . . . . . . . . . . . . . .
Flat Tire, Changing 5-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Flip and Fold Feature 1-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid Capacities 6-64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluids and Lubricants 7-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog Lamps 2-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Folding Seatbacks 1-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Foreign Countries, Fuel 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
French Language Manual ii. . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Seat Storage
Bin 2
-73 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Net 2-75 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Sidemarker Lamp Bulb Replacement 6-35 . . . . . . . . . . .
Front Turn Signal/Parking Lamps Bulb Replacement 6-34 . . . . .
Fuel 6-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filling Your Tank 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gage 2-100 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In Foreign Countries 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses and Circuit Breakers 6-57 . . . . . . . . . . . . . . . . . . . . . . .
Gages
Engine Coolant Temperature 2-94 . . . . . . . . . . . . . . . . . . . .
Fuel 2-100 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speedometer 2-87 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Garage Door Opener Compartment 2-70 . . . . . . . . . . . . . . . . .
GAWR 4-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gear Positions, Automatic Transaxle 2-43 . . . . . . . . . . . . . . . .
Glove Box 2-68 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GM Mobility Program for Persons with Disabilities 8-5 . . . . .
GM Vehicle Care/Appearance Materials 6-54 . . . . . . . . . . . . .
Gross Axle Weight Rating (GAWR) 4-30 . . . . . . . . . . . . . . . .
Gross Vehicle Weight Rating (GVWR) 4-30 . . . . . . . . . . . . . . Guide en Fran†ais ii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GVWR 4
-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Halogen Bulbs 6-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hazard Warning Flashers 5-2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Head Restraints 1-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlamps 2-61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulb Replacement 6-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High/Low Beam Changer 2-56 . . . . . . . . . . . . . . . . . . . . . .
On Reminder 2-62 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring 6-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hearing Impaired, Customer Assistance 8-4 . . . . . . . . . . . . . .
Heated Outside Mirrors 2-68 . . . . . . . . . . . . . . . . . . . . . . . . . .
Heating 3-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High-Beam Headlamps 2-56 . . . . . . . . . . . . . . . . . . . . . . . . . .
Highway Hypnosis 4-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hill and Mountain Roads 4-23 . . . . . . . . . . . . . . . . . . . . . . . . .
Hitches, Trailer 4-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hood
Checking Things Under 6
-8 . . . . . . . . . . . . . . . . . . . . . . . . .
Prop 6-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Release 6-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horn 2-55 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hydroplaning 4-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Positions 2-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Transaxle Lock Check 7-33 . . . . . . . . . . . . . . . . . . . .
Illuminated Entry 2-64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inflation, Tire 6-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inflator, Air 2-81 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside Day/Night Rearview Mirror 2-67 . . . . . . . . . . . . . . . . .

yellowblue
9-6
Inspections
Brake System 7-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exhaust Systems 7-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Drive Axle Boot and Seal 7-34 . . . . . . . . . . . . . . . . . .
Radiator and Heater Hose 7-34 . . . . . . . . . . . . . . . . . . . . . .
Steering 7-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Suspension 7-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Throttle System 7-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument Panel 2-84 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cluster 2-86 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse Block 6-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Light Intensity Control 2-63 . . . . . . . . . . . . . . . . . . . . . . . . .
Switchbank 2-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior Lamps 2-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Control 2-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Override Switch 2-64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jack, Tire 5-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jump Starting 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key in the Ignition 2-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key Lock Cylinders Service 7-31 . . . . . . . . . . . . . . . . . . . . . .
Keys 2-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Labels
Certification/Tire 4-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Parts Identification 6-55 . . . . . . . . . . . . . . . . . . . . .
Tire-Loading Information 4-29 . . . . . . . . . . . . . . . . . . . . . .
Vehicle Identification Number 6-55 . . . . . . . . . . . . . . . . . . .
Lamps
Cargo 2
-66 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Delayed Illumination 2-65 . . . . . . . . . . . . . . . . . . . . . . . . . .
Dome 2-66 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Exit Lighting 2
-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exterior 2-61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog 2-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Illuminated Entry 2-64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior 2-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
On Reminder 2-62 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Last Door Closed Locking 2-6 . . . . . . . . . . . . . . . . . . . . . . . . .
Last Door Closed Locking and Lockout Prevention 2-16 . . . .
Leaving Your Vehicle 2-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leaving Your Vehicle with the Engine Running 2-49 . . . . . . .
Liftgate 2-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lighter 2-79 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lights
Air Bag Readiness 1
-40, 2-89 . . . . . . . . . . . . . . . . . . . . . . .
Anti-Lock Brake System Warning 2-91, 4-7 . . . . . . . . . . . .
Brake System Warning 2-90, 6-28 . . . . . . . . . . . . . . . . . . . .
Charging System Indicator 2-90 . . . . . . . . . . . . . . . . . . . . . .
Check Engine 2-95 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Ajar 2-99 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Coolant Temperature Warning 2-94 . . . . . . . . . . . . .
Low Coolant Warning 2-95, 6-24 . . . . . . . . . . . . . . . . . . . .
Low Fuel Warning 2-101 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Low Oil Level 2-100, 6-11 . . . . . . . . . . . . . . . . . . . . . . . . .
Low Traction 2-93, 4-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil Pressure 2-98 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PASS-Key
III Security 2-99 . . . . . . . . . . . . . . . . . . . . . . .
Power Sliding Door Warning Light 2-99 . . . . . . . . . . . . . . .
Safety Belt Reminder 1-24, 2-92 . . . . . . . . . . . . . . . . . . . . .
Service Engine Soon 2-95 . . . . . . . . . . . . . . . . . . . . . . . . . .
Traction Control System Warning 2-92, 4-10 . . . . . . . . . . .
Loading Your Vehicle 4-29 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lockout Deterrent 2-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
9-8
Odometer 2-87 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Odometer, Trip 2-87 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Off-Road Recovery 4-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil, Engine 2-98, 6-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil Pressure Light 2-98 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
OnStar System
2-80 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overhead Console 2-69 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overhead Console Switchbank 2-12 . . . . . . . . . . . . . . . . . . . .
Overheated Engine Protection 5-10 . . . . . . . . . . . . . . . . . . . . .
Overheating Engine 5-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Owner Checks and Services 7-30 . . . . . . . . . . . . . . . . . . . . . . .
Owner Publications, Ordering 8-12 . . . . . . . . . . . . . . . . . . . . .
Paint Spotting, Chemical 6-53 . . . . . . . . . . . . . . . . . . . . . . . .
PARK (P)
Shifting Into 2
-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shifting Out of 2-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic Transaxle 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking
At Night 2
-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake 2-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake Mechanism Check 7-33 . . . . . . . . . . . . . . . . . . . . . . .
Lots 2-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Over Things That Burn 2-51 . . . . . . . . . . . . . . . . . . . . . . . .
With a Trailer 4-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Passenger Compartment Air Filter Replacement 6-16 . . . . . . .
Passing 4-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PASS-Key
III 2-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PASS-Key
III Security Light 2-99 . . . . . . . . . . . . . . . . . . . .
Periodic Maintenance Inspections 7-34 . . . . . . . . . . . . . . . . . .
Portable Fuel Container, Filling a 6-7 . . . . . . . . . . . . . . . . . . .
Power
Accessory Outlets 2
-83 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Locks 2-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Option Fuses 6
-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Remote Control Mirrors 2-67 . . . . . . . . . . . . . . . . . . . . . . . .
Seat 1-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering 4-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windows 2-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Sliding Door Warning Light 2-99 . . . . . . . . . . . . . . . . .
Power Steering Fluid 6-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to Check 6-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
What to Use 6-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
When to Check 6-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pregnancy, Use of Safety Belts 1-37 . . . . . . . . . . . . . . . . . . . .
Pretensioners, Safety Belts 1-46 . . . . . . . . . . . . . . . . . . . . . . . .
Problems on the Road 5-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Publications, Service and Owner 8-12 . . . . . . . . . . . . . . . . . . .
Radiator 5-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radiator Pressure Cap 6-21 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radio Reception 3-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radios 3-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rain, Driving In 4-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reading Lamps 2-66 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear
Air Vents 3
-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cargo Lamp 2-66 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Climate Control 3-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Comfort Controls 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fan Control 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside Seat Position 1-47 . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Belt Comfort Guides 1-50 . . . . . . . . . . . . . . . . . . . . .
Seat Audio 3-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat Passengers 1-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seats 1-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage Compartments 2-73 . . . . . . . . . . . . . . . . . . . . . . . . .
