3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle. Be
sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-3 Air Conditioning
3
-4 Heating
3
-4 Defogging and Defrosting
3
-5 Rear Window Defogger
3
-5 Rear Climate Control (Option)
3
-8 Ventilation System
3
-9 Audio Systems
3
-9 Setting the Clock
3
-9AM-FM Stereo with Cassette Tape Player
and Automatic Tone Control
3
-14 AM-FM Stereo with Compact Disc Player
and Automatic Tone Control (If Equipped)3
-18 Rear Seat Audio (If Equipped)
3
-20 Remote Compact Disc Player (If Equipped)
3
-21 Theft-Deterrent Feature
3
-24 Audio Steering Wheel Controls (If Equipped)
3
-25 Understanding Radio Reception
3
-25 Tips About Your Audio System
3
-26 Care of Your Cassette Tape Player
3
-27 Care of Your Compact Discs
3
-27 Care of Your Compact Disc Player
3
-27 Integrated Windshield Antenna

yellowblue
3-2
Comfort Controls
This section tells you how to make your air system work
for you. Your comfort control system uses
ozone
-friendly R-134a refrigerant.
With this system, you can control the heating, cooling
and ventilation in your vehicle. Your vehicle also has a
flow
-through ventilation system described later in
this section.
Fan Knob
The left knob is the fan knob and selects the force of air
you want. Turn the knob clockwise to increase fan speed
and counterclockwise to decrease fan speed. The fan
must be turned on for the air conditioning compressor
to operate.Temperature Knob
The center knob controls the temperature of the air
coming through the system. Turn it counterclockwise
(toward the blue area) for cooler air. Turn it clockwise
(toward the red area) for warmer air.
Mode Knob
This knob selects the direction of where the air will
enter the vehicle.
UPPER: This setting directs outside air through
the instrument panel outlets.
BI-LEVEL: This setting directs outside air into
your vehicle in two ways. Cooler air is directed toward
your upper body through the front instrument panel
outlets, while warmed air is directed through the heater
ducts at your feet.
LOWER: This setting brings in most of the air
through the floor ducts. This setting is also used to send
air to the rear of the vehicle. Keep the area under the
front seats free of objects that could obstruct airflow to
the rear of the vehicle.

yellowblue
3-3
DEFOG: This setting directs air to the windshield
and through the floor ducts. This mode is particularly
useful during cold or inclement weather because of your
vehicle's larger windshield area.
DEFROST: This setting directs most of the air to
the windshield and side window vents.
Mode Buttons
RECIRCULATION: Press this button (the light
will glow) to limit the amount of fresh air entering your
vehicle by recirculating much of the air inside your
vehicle. You may use this setting to limit odors entering
your vehicle. Press the OUTSIDE AIR button (the light
on the RECIRCULATION button will go off) to let
outside air circulate into the vehicle.
OUTSIDE AIR: Press this button (the light will
glow) to send outside air into your vehicle. Using this
setting while trying to defrost or defog the windows will
help clear the vents of moisture. Press the
RECIRCULATION button (the light on the
OUTSIDE AIR button will go off) to limit outside air
entering the vehicle. When the DEFOG or DEFROST
setting is selected, the system will automatically go to
OUTSIDE AIR mode.
Air Conditioning
On very hot days, your vehicle will cool down more
quickly and economically if you open the windows long
enough to let hot, inside air escape. For all settings,
adjust the temperature control knob and fan speed
as desired.
To get maximum cooling or a quick cool
-down on very
hot days, press the A/C and RECIRCULATION buttons
(the lights will glow) and turn the temperature knob
counterclockwise (toward the blue area). Adjust the
mode knob to direct the air to the desired location. This
setting should not be used for long periods of time
because the air may become too cold and dry. Push the
A/C button again (the light will go off) to turn off the
air conditioning.
When the air conditioner compressor is on, you may
sometimes notice slight changes in your vehicle's engine
performance and power. This is normal. The system is
designed to help fuel economy while it maintains the
desired cooling level.
The air conditioner removes moisture from the air, so
you may sometimes notice water dripping from under
your vehicle's engine compartment when it is idling or
after it has been turned off. This is normal.

yellowblue
3-4 Heating
Turn the temperature knob clockwise (toward the red
area) to warm the air.
In the LOWER mode, outside air will be brought in and
sent through the floor outlets. The heater works best if
you keep your windows closed while using it.
The BI
-LEVEL setting is designed for use on sunny
days when the air is only moderately warm or cool. On
days like these, the sun may adequately warm your
upper body, but your lower body may not be warm
enough. For the best results, turn the temperature control
knob to the middle position, and then adjust it
for comfort.
If you have the optional engine coolant heater and use it
during cold weather, 0
F (
-18
C) or lower, your heating
system will provide heat more quickly because the
engine coolant is already warmed. See ªEngine Coolant
Heaterº in the Index.
Defogging and Defrosting
To rapidly defrost the windshield, turn the temperature
control knob all the way clockwise (to the red area) and
turn the mode knob to DEFROST. Adjust the fan to the
highest speed.
To keep the windshield clear and bring in heated air
through the heater ducts, turn the mode knob
to DEFOG.
When the temperature outside is above freezing, the air
conditioner compressor will run in these settings to help
remove moisture from the air.
Your vehicle is equipped with side window defogger
vents located on the top of the instrument panel. For
additional side window defogging, turn the mode knob
to the BI
-LEVEL setting and adjust the fan to the
highest speed. Aim the side vents on the instrument
panel toward the side windows. For increased airflow to
the side vents, close the center vents.

yellowblue
3-6
Rear Fan Control
This option comes with the rear climate controls.
Keep the area around the base of the center instrument
panel console and the area between and under the front
seats free of objects that would obstruct airflow to the
rear of the vehicle.
The rear fan control is
located below the climate
control system, in
the switchbank.
Turn the fan to the desired setting for the amount of air
to be directed to the rear of the vehicle. The temperature
of the air will be the same as the air in the front of the
vehicle. The rear fan control in the instrument panel
switchbank has an R setting which allows the rear
passengers to use the rear climate control knobs to
adjust the air through the rear air outlets.Rear Comfort Controls
The rear climate control knobs are in the panel located
above the driver's seat.
Turn the temperature knob counterclockwise (to the blue
area) for cooler air, or clockwise (to the red area) for
warmer air.

yellowblue
3-9
Audio Systems
Your Delco Electronics audio system has been designed
to operate easily and give years of listening pleasure.
You will get the most enjoyment out of it if you acquaint
yourself with it first. Find out what your Delco
Electronics system can do and how to operate all its
controls, to be sure you're getting the most out of the
advanced engineering that went into it.
Setting the Clock
Press and hold HR until the correct hour appears. Press
and hold MN until the correct minute appears.
AM-FM Stereo with Cassette Tape Player
and Automatic Tone Control
Playing the Radio
PWR
-VOL: Press this knob to turn the system on and
off. To increase volume, turn the knob clockwise. Turn
it counterclockwise to decrease volume. The knob is
capable of rotating continuously.
RECALL: Press this button to recall the station being
played. If you press the button when the ignition is off,
the clock will show for a few seconds.

yellowblue
3-11
P.SCAN: Press this button to listen to each of your
favorite stations stored on your pushbuttons for a few
seconds. The radio will scan through each of the stations
stored on your pushbuttons, except those stations with
weak reception. The AUTO TONE setting stored for
that pushbutton will be automatically chosen. Press
P.SCAN or one of the pushbuttons again to stop
scanning. P.SCAN will be displayed whenever the tuner
is in the P.SCAN mode. The channel number (P1
-P6)
will appear momentarily just before the frequency is
displayed. In FM mode, this function will scan through
both FM1 and FM2 preset stations and FM1 or FM2 will
appear on the display.
Setting the Tone
BASS: Press this knob lightly so it extends. Turn the
knob clockwise to increase bass and counterclockwise to
decrease bass. When you use this control, the radio's
AUTO TONE setting will switch to manual and the
AUTO TONE display will go blank.
TREB: Press this knob lightly so it extends. Turn the
knob clockwise to increase treble and counterclockwise
to decrease treble. When you use this control, the radio's
AUTO TONE setting will switch to manual and the
AUTO TONE display will go blank. If a station is weak
or noisy, you may want to decrease the treble.Push these knobs back into their stored positions when
you're not using them.
AUTO TONE: This feature allows you to choose preset
bass and treble equalization settings designed for
country/western, classical, news, rock, pop and jazz
stations. C/W will appear on the display when you first
press AUTO TONE. Each time you press it, another
setting will appear on the display. Press it again after
JAZZ appears and the AUTO TONE display will go
blank. Tone control will return to the BASS and TREB
knobs. Also, if you use the BASS and TREB knobs,
control will return to them and the AUTO TONE display
will go blank. Use PUSHBUTTONS and AUTO TONE
button to program AUTO TONE for station presets.
Adjusting the Speakers
BAL: Press this knob lightly so it extends. Turn the
knob clockwise for the right speakers and
counterclockwise for the left speakers. The middle
position balances the sound between the speakers.
FADE: Press this knob lightly so it extends. Turn the
knob clockwise to adjust the sound to the front speakers
and counterclockwise for the rear speakers. The middle
position balances the sound between the speakers.
Push these knobs back into their stored positions when
you're not using them.

yellowblue
3-16
P.SCAN: Press this button to listen to each of your
favorite stations stored on your pushbuttons for a few
seconds. The radio will scan through each of the stations
stored on your pushbuttons, except those stations with
weak reception. The AUTO TONE setting stored for
that pushbutton will be automatically chosen. Press
P.SCAN or one of the pushbuttons again to stop
scanning. P.SCAN will be displayed whenever the tuner
is in the P.SCAN mode. The channel number (P1
-P6)
will appear momentarily just before the frequency is
displayed. In FM mode, this function will scan through
both FM1 and FM2 preset stations and FM1 or FM2 will
appear on the display.
Setting the Tone
BASS: Press this knob lightly so it extends. Turn the
knob clockwise to increase bass and counterclockwise to
decrease bass. When you use this control, the radio's
AUTO TONE setting will switch to manual and the
AUTO TONE display will go blank.
TREB: Press this knob lightly so it extends. Turn the
knob clockwise to increase treble and counterclockwise
to decrease treble. When you use this control, the radio's
AUTO TONE setting will switch to manual and the
AUTO TONE display will go blank. If a station is weak
or noisy, you may want to decrease the treble.Push these knobs back into their stored positions when
you're not using them.
AUTO TONE: This feature allows you to choose preset
bass and treble equalization settings designed for
country/western, classical, news, rock, pop and jazz
stations. C/W will appear on the display when you first
press AUTO TONE. Each time you press it, another
setting will appear on the display. Press it again after
JAZZ appears and the AUTO TONE display will go
blank. Tone control will return to the BASS and TREB
knobs. Also, if you use the BASS and TREB knobs,
control will return to them and the AUTO TONE display
will go blank. Use PUSHBUTTONS and AUTO TONE
button to program AUTO TONE for station presets.
Adjusting the Speakers
BAL: Press this knob lightly so it extends. Turn the
knob clockwise for the right speakers and
counterclockwise for the left speakers. The middle
position balances the sound between the speakers.
FADE: Press this knob lightly so it extends. Turn the
knob clockwise to adjust the sound to the front speakers
and counterclockwise for the rear speakers. The middle
position balances the sound between the speakers.
Push these knobs back into their stored positions when
you're not using them.

yellowblue
9-3
Cleaning
Aluminum Wheels 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Built-in Child Restraint Pad 6-49 . . . . . . . . . . . . . . . . . . . .
Exterior Lamps/Lenses 6-51 . . . . . . . . . . . . . . . . . . . . . . . .
Fabric/Carpet 6-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glass 6-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside of Your Vehicle 6-47 . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument Panel 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior Plastic Components 6-49 . . . . . . . . . . . . . . . . . . . . .
Leather 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside of Your Vehicle 6-51 . . . . . . . . . . . . . . . . . . . . . . . .
Special Problems 6-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stains 6-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires 6-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vinyl 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheels 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield, Backglass and Wiper Blades 6-50 . . . . . . . . . .
Wiper Blades 6-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Climate Control System 3-2 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clock, Setting the 3-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compact Disc
Care 3
-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Player 3-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Player Care 3-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Player Errors 3-17, 3-20 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Player, Remote 3-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compact Overhead Console 2-69 . . . . . . . . . . . . . . . . . . . . . .
Compact Spare Tire 5-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Content Theft-Deterrent 2-33 . . . . . . . . . . . . . . . . . . . . . . . . .
Arming Confirmation 2-34 . . . . . . . . . . . . . . . . . . . . . . . . . .
Arming with the Power Lock Switch 2-34 . . . . . . . . . . . . . .
Arming with the Remote Lock Control Transmitter 2-34 . . . .
Arming with Your Key 2-34 . . . . . . . . . . . . . . . . . . . . . . . . . Disarming with the Remote Lock
Control Transmitter 2
-35 . . . . . . . . . . . . . . . . . . . . . . . . . .
Disarming with Your Key 2-35 . . . . . . . . . . . . . . . . . . . . . .
Nuisance Alarms 2-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Control of a Vehicle 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Convenience Net 2-74 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Convex Outside Mirror 2-68 . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant 6-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding 6-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking 6-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Heater, Engine 2-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recovery Tank 5-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
What to Use 6-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cooling System 5-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Courtesy Transportation 8-7 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cruise Control 2-58 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cupholders 2-73 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Customer Assistance
For Text Telephone Users 8
-4 . . . . . . . . . . . . . . . . . . . . . . .
Information 8-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Offices 8-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Customer Satisfaction Procedure 8-2 . . . . . . . . . . . . . . . . . . . .
Damage
Finish 6-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sheet Metal 6-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Daytime Running Lamps (DRL) 2-62 . . . . . . . . . . . . . . . . . . .
Dead Battery 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Defects, Reporting Safety 8-10 . . . . . . . . . . . . . . . . . . . . . . . .
Defensive Driving 4-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Defogger, Rear Window 3-5 . . . . . . . . . . . . . . . . . . . . . . . . . .
Defogging 3-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Defrosting 3-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
