3-30
DISP: Press this button to see how long the current track
has been playing. ET and the elapsed time will appear on
the display. To change what is normally shown on the
display (track or elapsed time), press the button until
you see the display you want, then hold the button for
two seconds. The radio will produce one beep.
AM FM: Press this button to play the radio when a
disc is in the player. The disc will stop but remain in
the player.
TAPE CD: With a CD in the player and the radio
playing, press this button to play a CD. Press AM FM
to return to the radio when a CD is playing. Press TAPE
CD to switch between the tape and compact disc if both
are loaded. The inactive tape or CD will remain safely
inside the radio for future listening.
EJT: Press this button located below the CD slot
to remove the disc. The radio will play. EJT may be
activated with either the ignition or radio off.
CDs may be loaded with the radio and ignition off
if this button is pressed first.
CAL ERR: This message is displayed when the
radio has not been calibrated properly for the vehicle.
You must return to the dealership for service.
LOCKED: This message is displayed when the
THEFTLOCK

system has locked up. You must
return to the dealership for service.
AM-FM Stereo with 6-Disc Compact Disc
Player with Programmable Equalization
and Radio Data System (RDS) (Option)
Playing the Radio
VOLUME PWR: Press this knob to turn the system
on and off. To increase volume, turn the knob clockwise.
Turn it counterclockwise to decrease volume.

3-31
AUTO VOL: Your system has a feature called
automatic volume. With this feature, your audio system
adjusts automatically to make up for road and wind
noise as you drive. Set the volume at the desired level.
Press this button to select MIN, MED or MAX. Each
choice allows for more volume compensation at faster
vehicle speeds. Then, as you drive, automatic volume
automatically increases the volume, as necessary, to
overcome noise at any particular speed. The volume
level should always sound the same to you as you drive.
If you don't want to use automatic volume, select OFF.
Finding a Station
AM FM: Press this button to switch between AM,
FM1 and FM2. The display shows your selection.
TUNE: Turn this knob to select radio stations.
SEEK: Press the right or left arrow to go to the next
higher or lower station and stay there. The sound will
mute while seeking.
SCAN: Press and hold either SEEK SCAN arrow for
two seconds until SC appears on the display and you
hear a beep. Use SCAN to listen to stations for a few
seconds. The radio will go to a station, stop for a few
seconds, then go on to the next station. Press either SEEK SCAN arrow again to stop scanning.
If you press SEEK SCAN for more than four seconds,
the radio will change to preset scan mode. The sound
will mute while scanning.
PUSHBUTTONS: The six numbered pushbuttons let
you return to your favorite stations. You can set up to
18 stations (six AM, six FM1 and six FM2) by
performing the following steps:
1. Turn the radio on.
2. Press AM FM to select the band.
3. Tune in the desired station.
4. Press AUTO EQ to select the equalization that best
suits the type of station selected.
5. Press and hold one of the six numbered buttons
until you hear a beep. Whenever you press that
numbered button, the station you set will return
and the equalization that you selected will also be
automatically selected for that button.
6. Repeat the steps for each pushbutton.

3-32
PRESET SCAN: Press and hold either SEEK SCAN
arrow for more than four seconds, PRESET SCAN will
appear on the display. You will hear a double beep and
the ªPº will blink with the preset number. Use PRESET
SCAN to listen to each of your preset stations for a few
seconds. The radio will go to a preset station stored on
your pushbuttons, stop for a few seconds, then go on to
the next preset station. Press either SEEK SCAN arrow
again to stop scanning presets.
Setting the Tone
BASS: Press the AUDIO knob until BASS appears on
the display. Turn the knob to increase or decrease bass.
When you use this control, the radio's tone setting will
switch to custom.
To set the bass to the middle position, select BASS and
press and hold the AUDIO knob. The radio will produce
one beep and set the display level to zero. To set all tone
and speaker controls to the middle position, press and
hold the AUDIO knob when no tone or speaker
control is active. The radio will produce one beep and
CENTERED will appear on the display.MID: Press the AUDIO knob until MID appears on
the display. Turn the knob to increase or decrease mid.
When you use this control, the radio's tone setting will
switch to custom.
To set the mid to the middle position, select MID and
press and hold the AUDIO knob. The radio will produce
one beep and set the display level to zero. To set all tone
and speaker controls to the middle position, press and
hold the AUDIO knob when no tone or speaker control
is active. The radio will produce one beep and
CENTERED will appear on the display.
TREB: Press the AUDIO knob until TREB appears on
the display. Turn the knob to increase or decrease treble.
When you use this control, the radio's tone setting will
switch to custom. If a station is weak or noisy, you may
want to decrease the treble.
To set treble to the middle position, select TREB and
press and hold the AUDIO knob. The radio will produce
one beep and set the display level to zero. To set all tone
and speaker controls to the middle position, press and
hold the AUDIO knob when no tone or speaker control
is active. The radio will produce one beep and
CENTERED will appear on the display.

3-33
AUTO EQ: This feature allows you to choose preset
bass, mid and treble equalization settings designed for
country, jazz, talk, pop, rock and classical stations.
The last setting will appear on the display when you
first press AUTO EQ. Each time you press AUTO EQ,
another setting will appear on the display. Press AUTO
EQ again after TALK appears and CUSTOM will
appear. Tone control will return to the BASS, MID and
TREB. Also, if you alter BASS, MID, or TREB while
in an auto EQ setting, the radio will return to CUSTOM.
CUSTOM will appear on the display.
Using RDS Mode
Your audio system is equipped with a Radio Data
System (RDS). RDS mode gives you many useful new
features. With RDS, the radio can do the following:

Seek only to stations with the types of programs
you want to listen to,

seek to stations with traffic announcements,

receive announcements concerning local and
national emergencies, and

receive and display messages from radio stations.RDS features are only available for use on FM stations
which broadcast RDS information. The RDS features of
your radio rely upon receiving specific RDS information
from these stations. These features will only work when
the RDS information is available. In rare cases, a radio
station may broadcast incorrect information that will
cause the radio features to work improperly. If this
happens, please contact the radio station.
When you are tuned to an RDS station, the station
name will appear on the display, instead of the
frequency. Most RDS stations provide their station
name, the time of day and a Program Type (PTY) for
their current programming.
TRAF: Press this button to receive traffic
announcements. The traffic announcement brackets will
appear on the display. TRAF will appear on the display
if the tuned station broadcasts traffic announcements.
If the current tuned station does not broadcast traffic
announcements, the radio will seek to a station that
does. When the radio finds a station that broadcasts
traffic announcements, it will stop. If no station is
found, NONE FOUND will appear on the display.

3-34
When a traffic announcement comes on the tuned
radio station or a related network station, you will
hear it, even if the volume is muted or a compact disc is
playing. If the compact disc player was being used, the
compact disc will stay in the player and resume play at
the point where it stopped.
INFO: If the current station has a message, INFO
will appear on the display. Press this button to see the
message. If the whole message does not appear on the
display, parts of the message will appear every three
seconds until the message is completed. To see the parts
of the message faster than every three seconds, press this
button again. A new group of words will appear on the
display. Once the complete message has been displayed,
INFO will disappear from the display until another new
message is received.
P
-TYPE: This button is used to turn on and off
Program Type (PTY) selections. PTY and the light next
to the button will turn on. The last selected PTY will
appear on the display for five seconds. Turn the P
-TYPE
knob to select the PTY you want to listen to. Press the
SEEK SCAN arrows to find radio stations of the PTY
you want to listen to. The last PTY selected will be used
for seek or scan modes. If a station with the selected PTY is not found, NONE
FOUND will appear on the display. If both P
-TYPE and
TRAF are on, the radio will search for stations with
traffic announcements and the selected PTY.
To use the P
-TYPE interrupt feature, press and hold
the P
-TYPE button until you hear a beep on the PTY
you want to interrupt on. When you are listening to a
compact disc, the last selected RDS FM station will
interrupt play if that selected PTY format is broadcast.
PUSHBUTTONS: The six numbered pushbuttons let
you return to your favorite Program Types (PTYs).
These buttons have factory PTY presets. You can set up
to 12 PTYs (six FM1 and six FM2) by performing the
following steps:
1. Press P
-TYPE, if it is not already on.
2. Press AM FM to select FM1 or FM2.
3. Turn the P
-TYPE knob to select a PTY.
4. Press and hold one of the six numbered buttons
until you hear a beep. Whenever you press that
numbered button, the PTY you set will return.
5. Repeat the steps for each pushbutton.

3-35
ALERT!: This type of announcement warns of national
or local emergencies. You will not be able to turn off
alert announcements. ALERT! appears on the display
when an alert announcement plays. When an alert
announcement comes on the tuned radio station, you
will hear it, even if the volume is muted or a compact
disc is playing. If the compact disc player is playing,
play will stop for the announcement and resume when
the announcement is finished.
ALTERNATE FREQUENCY: This feature allows
the radio to switch to a stronger station with the same
program type. Press and hold AM FM for two seconds
to turn alternate frequency on. AF ON will appear on
the display. The radio may switch to stronger stations.
Press and hold AM FM again for two seconds to
turn alternate frequency off. AF OFF will appear on
the display. The radio will not switch to other stations.
When you turn the ignition off and then on again,
the alternate frequency feature will automatically be
turned on.Adjusting the Speakers
BAL
-FADE: The AUDIO knob adjusts balance and
fade. To adjust balance, press the AUDIO knob until
BAL appears on the display. Turn the knob to adjust the
sound to the left or right speakers. The middle position
balances the sound between the speakers. To adjust fade,
press and hold the AUDIO knob until FAD appears on
the display. Turn the knob to adjust the sound to the
front or rear speakers. The middle position balances the
sound between the speakers.
To set the balance and fade to the middle position,
select balance or fade and press and hold the AUDIO
knob. The radio will beep once and will set the display
level to the middle position. To set all tone and speaker
controls to the middle position, press and hold the
AUDIO knob when tone or speaker controls are not
active. The radio will produce one beep and
CENTERED will appear on the display.

3-36
Playing a Compact Disc
LOAD: This compact disc player will accommodate
up to six discs.
To insert one disc do the following:
1. Turn the ignition on.
2. Press and release the LOAD button.
3. Wait for the light, located to the right of the slot,
to turn green.
4. Load a disc. Insert a disc partway into the slot,
label side up. The player will pull the disc in.
When the disc is inserted, the CD symbol will be
displayed. If you select an EQ setting for your disc,
it will be activated each time you play a disc.
If the radio is on or off, the disc will begin to
play automatically.
To insert multiple discs do the following:
1. Turn the ignition on.
2. Press and hold the LOAD button for two seconds.
You will then hear a beep and the light, located to the
right of the slot, will begin to flash.3. Once the light stops flashing and turns green, load a
disc. Insert a disc partway into the slot, label side up.
The player will pull the disc in.
Once the disc is loaded, the light will begin flashing
again. Once the light stops flashing and turns green
you can then load another disc. The disc player takes
up to six discs. Do not try to load more than six.
When a disc is inserted, the CD symbol will be
displayed. If more than one disc has been loaded, a
number for each disc will be displayed. If you select
an EQ setting for your disc, it will be activated each
time you play a disc.
If the radio is on or off, the last disc loaded will
begin to play automatically.
4. To load more than one disc but less than six,
complete Steps 1, 2 and 3. When you have finished
loading discs, with the radio on or off, press LOAD
to cancel the loading function. The radio will begin
to play the last CD loaded.
As each new track starts to play, the track number will
appear on the display.

3-37
Playing a Specific Loaded CD: For every CD loaded,
a number will appear on the radio display. To play a
specific CD, first press the CD AUX button to start
playing a CD. Then press the numbered button that
corresponds to the CD you want to play. A small bar
will appear under the CD number that is playing,
and the track number will appear.
If CHECK CD appears on the radio display, it could be
due to one of the following conditions:

The road is too rough. The disc should play when
the road is smoother.

The disc is dirty, scratched, wet or upside down.

The air is very humid. If so, wait about an hour
and try again.
If any error occurs repeatedly or if an error can't be
corrected, please contact your dealer. If your radio
displays an error message, write it down and provide it
to your dealer when reporting the problem.CD: This button will eject a disc or discs, if you
have multiple discs loaded. To eject a disc or discs from
the disc player perform one of the following steps:

Press and release the eject button to eject the disc
that is currently playing, or

to eject all of the discs, press this button for two
seconds, you will hear a beep, and the light will flash
to let you know when a disc is being ejected.
When the eject button is pressed, the receiver will eject
the disc and REMOVE CD will be displayed. You can
now remove the disc. If the disc is not removed, after
25 seconds, the disc will be automatically pulled back
into the receiver. If you try to push the disc back
into the receiver, before the 25 second time period is
complete, the receiver will sense an error and will try to
eject the disc several times before stopping. You cannot
repeatedly press the eject button to eject the disc
after you have tried to push the CD in manually.
The receivers 25
-second eject timer will reset at each
press of eject, which will cause the receiver to not eject
the disc until the 25
-second time period has elapsed.

3-38
Once the player stops and the disc is ejected, remove
the disc. After removing the disc, press the VOLUME
PWR knob off and then on again. This will clear the
disc
-sensing feature and enable discs to be loaded into
the player again.
REV: Press and hold this button to reverse quickly
within a track. Release it to play the passage. You will
hear sound at a reduced volume. The display will show
elapsed time.
FWD: Press and hold this button to advance quickly
within a track. Release it to play the passage. You will
hear sound at a reduced volume. The display will show
elapsed time.
RPT: With repeat, you can repeat one track or an
entire disc. To use repeat, do the following:

To repeat the track you are listening to, press and
release the RPT button. RPT will appear on the
display. Press RPT again to turn it off.

To repeat the disc you are listening to, press and
hold the RPT button for two seconds. Press RPT
again to turn if off.RDM: With random, you can listen to the tracks in
random, rather than sequential order, on all of the discs
or on one disc. To use random, do the following:

Press and release the RDM button to play the
tracks on all of the discs that are loaded, in random
order. RDM will appear in the display. Press RDM to
turn it off.

To play the tracks on the disc you are listening to
in random order, press and hold RDM for more
than two seconds. You will hear a beep and RDM
will appear on the display. Press RDM again to
turn if off.
AUTO EQ: Press AUTO EQ to select the desired
preset equalization setting while playing a compact disc.
The equalization will be automatically set whenever you
play a compact disc.
SEEK: Press the left arrow while playing a CD to go to
the start of the current track, if more than ten seconds
have played. Press the right arrow to go to the next track.
If you press the button more than once, the player will
continue moving backward or forward through the disc.

3-39
SCAN: Press and hold either SEEK SCAN arrow for
more than two seconds until SCAN appears on the
display and you hear a beep. Use SEEK SCAN to
listen to each track for a few seconds. The sound will
mute while scanning. SCAN will appear on the display.
Press either SEEK SCAN arrow again, to stop scanning.
DISC SCAN: Press and hold either SEEK SCAN arrow
for more than four seconds until DISC SCAN appears
on the display and you hear a beep. Use DISC SCAN
to listen to the first track, for ten seconds of each disc
loaded. The sound will mute while scanning to the next
track. DISC SCAN will appear on the display. Press
either SEEK SCAN arrow again, to stop scanning.
RCL: Press this button to see how long the current track
has been playing. To change what is normally shown on
the display (track or elapsed time), press the button until
you see the display you want, then hold the button until
the display flashes.
AM FM: Press this button to play the radio when a disc
is in the player.Using Song List Mode
The integrated 6
-disc CD changer has a feature
called song list. This feature is capable of saving
20 track selections.
To save tracks into SONG LIST perform the
following steps:
1. The disc player must be on with at least one disc
loaded. See ªLOAD/EJECTº previously for
more information.
2. The disc changer must not be in song list mode.
S
-LIST should not appear in the display. If S-LIST
is present, press SONG LIST to turn it off.
3. Select the desired disc by pressing the numbered
pushbutton and then use the SEEK SCAN right
arrow button to locate the track that you want to
save. The track will begin to play.
4. Press and hold SONG LIST for two or more seconds
to save the track into memory. When SONG LIST
is pressed a beep will be heard immediately.
After two seconds of pressing SONG LIST
continuously, two beeps will sound, to confirm that
the track has been saved.
5. Repeat Steps 3 and 4 for saving other selections.
