2-9
Last Door Closed Locking
The last door closed locking feature will delay the
power locking of the doors and liftgate for up to five
seconds after exiting the vehicle, when the power door
lock switch or the lock button on the remote keyless
entry transmitter is used to lock your vehicle.
To cancel this delay, press the power door lock switch or
the lock button on the remote keyless entry transmitter
a second time immediately.
If any door or the liftgate is open when locking the
vehicle, three chimes will be heard signaling that last
door closed locking is being used. Five seconds after the
last door is closed, all of the doors will lock.
If the ignition is in RUN or ACCESSORY, this feature
will not lock the doors.
To turn the last door closed locking feature off or on, see
ªMultifunction Alarm Locks and Lighting Choicesº in
the Index.
Automatic Door Locks
All of the doors will lock automatically when you move
your shift lever out of PARK (P). All doors will unlock
automatically when the ignition is turned off while the
shift lever is in PARK (P).If someone needs to get out while you are not in
PARK (P), have that person use the manual lever or
the power door lock switch. When the door is closed
again, it will not lock automatically. Use the manual
lever or the power door lock switch to lock the door.
To change the way the automatic door locks operate,
see ªMultifunction Alarm Locks and Lighting Choicesº
in the Index.
With the automatic door locks feature, you can lock or
unlock the doors at any time, either manually or by
using the power door lock switches.
Sliding Door Delayed Locking
If either sliding door is open when you use the power
door locks to lock the vehicle, the sliding door that is
open will not lock. Normally the last door closed
locking feature will be used to lock the sliding door after
it has been closed.
When the ignition is on or if the last door closed locking
feature has been overridden or programmed to be off,
the sliding door delayed locking feature will lock your
sliding door for you. Three seconds after either sliding
door is closed, all the doors will lock.

2-10 Lockout Deterrent
The lockout deterrent feature makes it difficult for you
to lock your keys in your vehicle. If the driver's door is
open while the keys are in the ignition, a chime will
sound and you will not be able to use your power door
lock switch to lock the vehicle.
If you don't leave the keys in the ignition or if you
use the manual door lock, you could still lock your keys
in your vehicle. Always remember to take your keys
with you.
To turn this feature off or on, see ªMultifunction Alarm
Locks and Lighting Choicesº in the Index.
Leaving Your Vehicle
If you are leaving the vehicle, take your keys, open your
door and set the locks from the inside. Then get out and
close the door.
Remote Keyless Entry
System (Option)
If your vehicle has this
feature, you can lock and
unlock your doors and the
liftgate from about 3 feet (1
m) up to 30 feet (9 m) away
using the remote keyless
entry transmitter supplied
with your vehicle.
Your remote keyless entry system operates on a radio
frequency subject to Federal Communications
Commission (FCC) Rules and with Industry Canada.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.

2-11
This device complies with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation of the device.
Changes or modifications to this system by other than an
authorized service facility could void authorization to
use this equipment.
At times you may notice a decrease in range. This is
normal for any remote keyless entry system. If the
transmitter does not work or if you have to stand closer
to your vehicle for the transmitter to work, try this:

Check the distance. You may be too far from your
vehicle. You may need to stand closer during rainy
or snowy weather.

Check the location. Other vehicles or objects may be
blocking the signal. Take a few steps to the left or
right, hold the transmitter higher, and try again.

Check to determine if battery replacement is
necessary. See the instructions that follow.

If you're still having trouble, see your dealer
or a qualified technician for service.Operation
Remote Driver's Door and All Door Unlock
When you press UNLOCK on the remote keyless entry
transmitter, only the driver's door will unlock. If you
press UNLOCK again within five seconds, all the doors
and the liftgate will unlock. If you would like all the
doors to unlock the first time you press UNLOCK, see
ªMultifunction Alarm Locks and Lighting Choicesº in
the Index.
If your vehicle has the content theft
-deterrent system,
the UNLOCK button on the remote keyless entry
transmitter will disarm the system. See ªContent
Theft
-Deterrentº in the Index for more details.
Remote All Door Lock
To lock all doors, press LOCK on the remote keyless
entry transmitter. See ªPower Door Locksº in the Index
for more details on the power door lock features. If your
vehicle has the content theft
-deterrent system, the
LOCK button may arm the system. See ªContent
Theft
-Deterrentº in the Index for more details.

2-12
Remote Lock Confirmation (Option)
If your vehicle has the content theft
-deterrent
system, your remote keyless entry transmitter will
have this feature.
When you use the remote keyless entry transmitter to
lock your vehicle, the parking lamps will flash to let you
know the command has been received. If you press the
LOCK button again, within five seconds, the horn will
sound and the parking lamps will flash to let you know
the vehicle is already locked.
If you would like to change the way the parking lamps
and horn operate with remote lock confirmation, see
ªMultifunction Alarm Locks and Lighting Choicesº in
the Index.
Remote Unlock Confirmation (Option)
If your vehicle has the content theft
-deterrent system,
your remote keyless entry transmitter will have this
feature.
When you use your remote keyless entry transmitter to
unlock your vehicle or to operate the optional power
sliding door(s), the parking lamps will flash to let you
know the command was received.If you would like to change the way the parking
lamps operate with remote unlock confirmation, see
ªMultifunction Alarm Locks and Lighting Choicesº
in the Index.
Panic Alarm (Option)
When you press the panic button with the horn symbol
on the remote keyless entry transmitter, the parking
lamps will flash and the horn will sound. This will allow
you to attract attention, if needed.
Press the panic button to stop the alarm from sounding.
Remote Power Sliding Door Operation (Option)
If your vehicle has the optional power sliding door,
your remote keyless entry transmitter will have a button
that has a van symbol on it. Press it to open or close
the sliding door. See ªPower Sliding Doorº later in
this section.
If your vehicle has the optional dual power sliding
doors, your remote keyless entry transmitter will
have two buttons that have a van symbol on it. The
van symbol on the left is for the driver's side sliding
door and the van symbol on the right is for the
passenger's side sliding door. See ªPower Sliding Doorº
later in this section.

2-13
If the power sliding door(s) is locked, first unlock all
doors, then press the van symbol to open the power
sliding door(s). The parking lamps will flash when the
right button with the van symbol is pressed and they
will not flash when the left button with the van symbol
is pressed. Press the van symbol again to close the
sliding door(s). See ªRemote Driver's Door and All
Door Unlockº earlier in this section and ªPower
Sliding Doorº later in this section.
You can operate the power sliding door(s) with
the remote keyless entry transmitter only when the
power sliding door override switch(es) on the overhead
console is turned off. See ªPower Sliding Doorº later
in this section.
If your vehicle's fuel filler door is opened, the driver's
side power sliding door will not open completely.
Do not try to force the door. Once the fuel filler
door is closed, the driver's side sliding door can be
opened normally.Matching Transmitter(s) to Your Vehicle
Each remote keyless entry transmitter is coded to
prevent another transmitter from unlocking your vehicle.
If a transmitter is lost or stolen, a replacement can be
purchased through your dealer. Remember to bring any
remaining transmitters with you when you go to your
dealer. When the dealer matches the replacement
transmitter to your vehicle, any remaining transmitters
must also be matched. Once your dealer has coded the
new transmitter, the lost transmitter will not unlock your
vehicle. Each vehicle can have a maximum of four
transmitters matched to it.
See your dealer to match transmitters to another vehicle.
Battery Replacement
Under normal use, the battery in your remote keyless
entry transmitter should last about three years.
You can tell the battery is weak if the transmitter won't
work at the normal range in any location. If you have to
get close to your vehicle before the transmitter works,
it's probably time to change the battery.

2-14
Replacing the Battery in the Remote Transmitter
NOTICE:
When replacing the battery, use care not to
touch any of the circuitry. Static from your
body transferred to these surfaces may damage
the transmitter.
1. Insert a flat object like a coin into the slot on the side
of the transmitter and twist it to separate the halves.
2. Gently pry the battery out of the transmitter. Do not
use the metal flanges to ªpop outº the battery.
3. Replace the battery.
4. Reassemble the transmitter. Make sure the halves are
snapped together tightly so water will not get in.
5. Check the transmitter operation.
Switchbanks
There are two sets of switchbanks located in the front
of the vehicle. The switches will vary with the options
that are on your vehicle. It is useful to become familiar
with them since they are used frequently while operating
the vehicle.

2-15
Overhead Console Switchbank
This switchbank is located in the overhead console. The
switchbank may include the interior lamps override, the
power sliding door, the power sliding door override, the
power rear quarter windows and the rear parking aid
disable. If your vehicle has the optional dual power
sliding doors, the switchbank will have both power
sliding door switches. The power sliding door override
switches will be integrated on the power sliding door
switches. If your vehicle does not have some of the
options controlled by these switches, there will be a
blank switch in its place.
For more information, see each of these features in
the Index.
Instrument Panel Switchbank
This switchbank is located in the instrument panel below
the comfort controls. The switchbank may include the
rear fan knob, rear window wiper/washer, the fog lamps,
the traction control and the heated seats. If your vehicle
does not have some of the options controlled by these
switches, there will be a blank button in its place.
For more information, see each of these features in
the Index.
If your vehicle is not equipped with the optional rear
climate control system, there will be a storage space in
this switchbank. The rubber mat can be removed for
cleaning. Snap the mat into place after cleaning.

2-16
Multifunction Alarm Locks and Lighting Choices
Your vehicle's locks and lighting systems can be programmed with several different features. The features you can
program depend on the options that came with your vehicle. The following chart shows the features that can be
programmed. To determine which features your vehicle is equipped with, follow the steps listed for entering the
programming mode.

2-17
Entering Programming Mode
To program features, your vehicle must be in the
programming mode. Follow these steps:
1. The optional content theft
-deterrent system must
be disarmed. See ªContent Theft
-Deterrent Systemº
in this section.
2. Remove the BCM PRGRM fuse from the instrument
panel fuse block, located to the right of the glove
box. See ªFuses and Circuit Breakersº in the Index.
3. Close the driver's door.
4. Turn the ignition key to ACCESSORY.
5. Count the number of chimes you hear. You will
hear two to four chimes depending on the features
your vehicle is equipped with. Refer to the chart
shown previously.
You can now program your choices.
To exit the programming mode, follow the steps
listed under ªExiting Programming Modeº later in
this section.
Delayed Illumination and Exit Lighting
This feature allows you to customize the interior lamps
when entering and exiting the vehicle.
Programmable Modes
Mode 1: Both Features Off (The interior lamps will
turn on or off at the same instant that a door is opened
or closed.)
Mode 2: Delayed Illumination Only (The interior lamps
will stay on for about 25 seconds after all the doors and
liftgate are closed, or until you lock the doors.)
Mode 3: Exit Lighting Only (The interior lamps will
come on whenever you remove the key from the ignition
and stay on for about 25 seconds, or until you lock
the doors.)
Mode 4: Both Features On (This combines
Modes 2 and 3.)

2-18
Before your vehicle was shipped from the factory, it was
programmed in Mode 4. The mode to which the vehicle
was programmed may have been changed since it left
the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Follow the instructions for ªEntering Programming
Modeº listed previously.
2. Turn the interior lamps on by turning the instrument
panel brightness control all the way up.
3. Count the number of chimes you hear. The number
of chimes indicates the vehicle's current programmed
mode. (If you do not wish to change the current
mode, you can either exit the programming mode
by following the instructions later in this section or
program the next feature available on your vehicle.
4. Turn the interior lamps off to change the
current mode.
5. Turn the interior lamps from on to off until you hear
the number of chimes corresponding to the mode
selection you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.Automatic Door Locks
This feature allows you to customize the automatic
locking and unlocking of the doors when using
the gearshift.
Programmable Modes
Mode 1: Both Features Off (Automatic door locking
and unlocking is disabled. You will always need to
lock your doors manually before driving to increase
occupant safety.)
Mode 2: Automatic Door Locking Only

The automatic door unlock feature is turned off.

Shift out of PARK (P) with the ignition on and the
driver's door closed; all doors will lock automatically.
Mode 3: Automatic Unlocking with the Ignition Off

Turn off the ignition with the transaxle in PARK (P);
all doors will unlock automatically.

Shift out of PARK (P) with the ignition on and the
driver's door closed; all doors will lock automatically.
