Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Windows
2
-5 Keys
2
-7 Door Locks
2
-10 Remote Keyless Entry System (Option)
2
-16 Multifunction Alarm Locks and
Lighting Choices
2
-26 Dual Sliding Doors
2
-28 Power Sliding Door (Option)
2
-35 Liftgate
2
-36 Theft
2
-37 Content Theft-Deterrent (Option)
2
-40 PASS-Key
III
2
-42 New Vehicle ªBreak-Inº
2
-42 Ignition Positions
2
-44 Starting Your Engine
2
-45 Engine Coolant Heater (If Equipped)
2
-47 Automatic Transaxle Operation
2
-51 Parking Brake
2
-52 Shifting Into PARK (P)2
-55 Shifting Out of PARK (P)
2
-55 Parking Over Things That Burn
2
-56 Engine Exhaust
2
-56 Running Your Engine While You're Parked
2
-58 Turn Signal/Multifunction Lever
2
-65 Exterior Lamps
2
-67 Interior Lamps
2
-73 Storage Compartments
2
-84 Accessory Inflator System (Option)
2
-86 Accessory Power Outlets
2
-87 OnStar
System (If Equipped)
2
-91 HomeLink
Transmitter (Option)
2
-94 The Instrument Panel -- Your
Information System
2
-99 Warning Lights, Gages, Messages and
Indicators
2
-108 Message Center
2
-116 Driver Information Center (DIC) (Option)
2
-119 Rear Parking Assist (Option)

3-43
If the channel switch located on the right side is on A,
the headphones will play the DVD or auxiliary device.
See ªStereo RCA Jacksº later in this section for
more information. If the channel switch is on B, the
headphones will play the rear seat audio system. See
ªRear Seat Audio (Vehicles with the Entertainment
System)º in the Index for more information.
To adjust the volume on the headphones, use the volume
control located on the right side.
NOTICE:
Do not store the headphones in heat or direct
sunlight. This could damage the headphones and
would not be covered by your warranty. Keep the
headphones stored in a cool place.
Battery Replacement
To change the batteries, do the following:
1. Slide open the battery door located on the left side of
the headphones.2. Remove the batteries from the compartment.
3. Replace the two AAA batteries. Make sure that they
are installed correctly.
If the headphones are to be stored for a long period
of time, remove the batteries and keep them in a cool,
dry place.
Stereo RCA Jacks
The RCA jacks are located on the faceplate of the DVD
player. They allow you to hook up an auxiliary device
such as a camcorder or a video game unit. You may
require adapter connectors or cables to connect your
auxiliary device to the RCA jacks. Refer to the
manufacturer's instructions for proper usage.
The entertainment system will always start in the
auxiliary mode. To use the auxiliary function, connect a
camcorder or a video game unit to the RCA jacks and
turn on the auxiliary device. If you want to view a DVD,
insert the DVD into the DVD player. The system will
automatically switch to DVD and start to play. To return
to the auxiliary device, press the stop button to stop the
DVD or use the remote control. See ªRemote Controlº
later in this section for more information.

3-46
The entertainment system is only compatible with
DVDs authorized for use in the United States and
Canada. Regular audio CDs can also be played by
the DVD player. Home recorded CDs (CDRs) may not
play in this DVD player. Try the audio system CD
player instead.
DVD Player Buttons
PWR (Power): Press this button to turn the DVD
player on, to change to an auxiliary device or to turn the
system off.
(Play/Pause): Press this button to start play.
Press while playing to pause. Press it again to continue
playing.
(Stop/Eject): Press this button to stop playing.
Press the button a second time to eject the disc.
Playing a Disc
To play a disc, gently insert the disc (with the label side
up) into the loading slot until it stops. The DVD player
will continue loading the disc and the player will
automatically start.If a disc is already in the player, press the play/pause
button on the face of the player or on the remote control.
Some DVDs will not allow you to fast forward or skip
the copyright or previews. Some DVDs will begin
playing after the previews have finished. If the DVD
does not begin playing refer to the on
-screen
instructions.
Stopping and Resuming Playback
To stop a disc, press the stop/eject button on the DVD
player. To resume playback, press the play/pause button.
As long as you have not ejected the disc, it will resume
playback from the point where it was stopped. If the disc
has been ejected, the player will start playing at the
beginning of the disc.
Ejecting a Disc
Press the stop/eject button on the DVD player once to
stop and a second time to eject the disc.
If a disc is ejected from the player, but not removed,
the DVD player will reload the disc after a short period
of time.

5-4
1. Check the other vehicle. It must have a 12-volt
battery with a negative ground system.
NOTICE:
If the other system isn't a 12-volt system with a
negative ground, both vehicles can be damaged.
2. Get the vehicles close enough so the jumper cables
can reach, but be sure the vehicles aren't touching
each other. If they are, it could cause a ground
connection you don't want. You wouldn't be able
to start your vehicle, and the bad grounding could
damage the electrical systems.
To avoid the possibility of the vehicles rolling, set
the parking brake firmly on both vehicles involved in
the jump start procedure. Put an automatic transaxle
in PARK (P) or a manual transaxle in NEUTRAL
before setting the parking brake.
NOTICE:
If you leave your radio on, it could be badly
damaged. The repairs wouldn't be covered
by your warranty.
3. Turn off the ignition on both vehicles. Unplug
unnecessary accessories plugged into the cigarette
lighter or in the accessory power outlet. Turn off
the radio and all lamps that aren't needed. This will
avoid sparks and help save both batteries. And it
could save your radio!
4. Open the hoods and locate the batteries. Find the
positive (+) and negative (
-) terminal locations on
each vehicle.
You will not need to access your battery for jump
starting. Your vehicle has a remote positive (+)
jump starting terminal for that purpose.

5-5
The terminal is located
under a tethered cap
at the front of the
underhood fuse block.
See ªEngine
Compartment Overviewº
in the Index for more
information on location.
Squeeze the tabs and pull up on the cap to access the
remote positive (+) terminal. You should always use
the remote positive (+) terminal instead of the
positive (+) terminal on your battery.
CAUTION:
An electric fan can start up even when the engine
is not running and can injure you. Keep hands,
clothing and tools away from any underhood
electric fan.
CAUTION:
Using a match near a battery can cause battery
gas to explode. People have been hurt doing this,
and some have been blinded. Use a flashlight if
you need more light.
Be sure the battery has enough water. You don't
need to add water to the ACDelco
battery
installed in every new GM vehicle. But if a
battery has filler caps, be sure the right amount
of fluid is there. If it is low, add water to take
care of that first. If you don't, explosive gas
could be present.
Battery fluid contains acid that can burn you.
Don't get it on you. If you accidentally get it in
your eyes or on your skin, flush the place with
water and get medical help immediately.

5-7
8. Now connect the black
negative (
-) cable to the
negative (
-) terminal of
the good battery. Use a
remote negative (
-)
terminal if the
vehicle has one.
Don't let the other end touch anything until the
next step. The other end of the negative (
-) cable
doesn't go to the dead battery. It goes to a heavy,
unpainted metal part, or to a remote negative (
-)
terminal on the vehicle with the dead battery.
9. Connect the other end of
the negative (
-) cable at
least 18 inches (45 cm)
away from the dead
battery, but not near
engine parts that move.
The electrical connection is just as good there,
and the chance of sparks getting back to the battery
is much less.
10. Now start the vehicle with the good battery and run
the engine for a while.
11. Try to start the vehicle that had the dead battery.
If it won't start after a few tries, it probably
needs service.
