wheel alignment OLDSMOBILE SILHOUETTE 2003 Owners Manual

Section 5 Service and Appearance Care
Service ............................................................ 5.3
Doing Your Own Service Work
......................... 5.3
Adding Equipment to the Outside
of
Your Vehicle .............................................. 5-4
Fuel
.............................................................. -5-5
Gasoline Octane
............................................ 5-5
Gasoline Specifications
................................... 5-5
California Fuel
............................................... 5-6
Additives
....................... .... ......... 5-6
Fuels in Foreign Countries
........... ..... 5-7
Filling Your Tank
............................ ..... 5-7
Filling a Portable Fuel Container
.................... 5-9
Checking Things Under the
Hood .................. -5-1 0
Hood Release .............................................. 5-10
Engine Compartment Overview ....................... 5-12
Engine Oil
................................................... 5-14
Engine Air CleanedFilter
................................ 5-19
Automatic Transaxle Fluid
.............................. 5-20
Radiator Pressure Cap
............................... 5-26
Engine Overheating
.................................... 5-26
Cooling System
............................. , ....... 5-29
Power Steering Fluid .................. , ....... 5-37
Windshield Washer Fluid
................. , ....... 5-38
Brakes
.......................... .... ........ 5-39
r.--.:.-- ---I-.- b CI lyll IC uuvlal I1 4-LU c r)r) .............................................
Battery ........................................................ 5.43
Jump Starting
............................................... 5-44
All-Wheel Drive
.............................................. 5-50
Bulb Replacement .......................................... 5-52
Halogen Bulbs
.............................. ......... 5-52
Front Turn Signal, Sidemarker and
Taillamps, Turn Signal, Stoplamps and
Headlamps
...................................... ..... 5-52
Parking Lamps
.............................. ..... 5-54
Replacement Bulbs
....................................... 5-57
Back-up Lamps
......................................... 5-56
Windshield Wiper Blade Replacement
.............. 5-58
Tires
.............................................................. 5-60
Inflation
- Tire Pressure ................................ 5-61
Tire Inspection and Rotation
........................... 5-62
When It
Is Time for New Tires ....................... 5-63
Buying New Tires
......................................... 5-64
Uniform Tire Quality Grading
.......................... 5-65
Wheel Alignment and Tire Balance
.................. 5-66
Wheel Replacement
...................................... 5-66
Tire Chains
.................................................. 5-67
Accessory Inflator
......................................... 5-68
If a Tire Goes Flat ........................................ 5-69
Changing a Flat Tire ..................................... 5-70
Compact Spare Tire ...................................... 5-86
5- 1

Tire Inspection and Rotation
Tires should be rotated every 7,500 miles (12 500 km).
Any time you notice unusual wear, rotate your tires
as soon as possible and check wheel alignment. Also
check for damaged tires or wheels. See
When It Is Time
for New Tires on page
5-63 and Wheel Replacement
on page
5-66 for more information.
Make sure the spare tire is stored securely. Push, pull,
and then try to rotate or turn the tire,
If it moves, use the
folding wrench to tighten the cable. See
Changing a Flat
Tire on page
5-70.
The purpose of regular rotation is to achieve more
uniform wear for all tires on the vehicle. The first rotation
is the most important. See “Part A: Scheduled
Maintenance Services,” in Section
6, for scheduled
rotation intervals.
I,‘
/I
When rotating your tires, always use the correct rotation
pattern shown here.
Don’t include the compact spare tire in your tire rotation.
5-62

Temperature - A, B, C
The temperature grades are A (the highest), B, and C,
representing the tire’s resistance to the generation
of heat and its ability
to dissipate heat when tested
under controlled conditions on a specified indoor
laboratory test wheel. Sustained high temperature
can cause the material of the tire to degenerate and
reduce tire life, and excessive temperature can lead
to
sudden tire failure. The grade C corresponds to a
level of performance which all passenger car tires must
meet under the Federal Motor Vehicle Safety Standard
No. 109. Grades B and A represent higher levels of
performance on the laboratory test wheel than the
minimum required by law.
Warning: The temperature grade for this tire is
established for a tire that is properly inflated and not
overloaded. Excessive speed, underinflation, or
excessive loading, either separately or in combination,
can cause heat buildup and possible tire failure.
Wheel Alignment and Tire Balance
The wheels on your vehicle were aligned and balanced
carefully at the factory to give you the longest tire life
and best overall performance.
Scheduled wheel alignment and wheel balancing are
not needed. However,
if you notice unusual tire wear or
your vehicle pulling one way or the other, the alignment
may need to be reset.
If you notice your vehicle
vibrating when driving
on a smooth road, your wheels
may need to be rebalanced.
Wheel Replacement
Replace any wheel that is bent, cracked or badly rusted
or corroded. If wheel nuts keep coming
loose, the
wheel, wheel bolts and wheel nuts should be replaced.
If the wheel leaks air, replace
it (except some
aluminum wheels, which can sometimes be repaired).
See your dealer
if any of these conditions exist.
Your dealer will know the kind of wheel you need.
Each new wheel should have the same load-carrying
capacity, diameter, width, offset and be mounted
the same way as the one it replaces.
5-66

Throttle System Inspection ..... ................ 6-15
Tilt Wheel
................................ ................. 3-7
Tire Inflation Check
...................................... 6-10
Tires
..................................................... 5-60, 5-92
Buying New Tires
........................................ 5-64
Chains
....................................................... 5-67
Changing a Flat Tire
.................................... 5-70
If a Tire Goes Flat ....................................... 5-69
Inflation
- Tire Pressure ............................... 5-61
Inspection and Rotation
................................ 5-62
Wheel Alignment and Tire Balance
................. 5-66
When It
Is Time for New Tires ...................... 5-63
To Use the Engine Coolant Heater
.................... 2-35
Top of the Instrument Panel
............................. 5-89
Top Strap Anchor Location
............................... 1-56
Total Weight on Your Vehicle’s Tires .................. 4-39
Towing
Recreational Vehicle
..................................... 4-32
Towing a Trailer
.......................................... 4-36
Your Vehicle
............................................... 4-32
Active Message
........................................... 3-53
Compact
Spare Tire
..................................... 5-86
Uniform Tire Quality Grading
......................... 5-65
Wheel Replacement
..................................... 5-66
Top Strap
...................................................... 1-55
Torque Lock
................................................... 2-42
Traction Control System (TCS)
.................................. 4-10 Traction
(cont.)
Control System Warning Light
....................... 3-46
Service Traction System Warning Message
..... 3-52
Trailer Brakes
................................................. 4-40
Trailer Wiring Harness
..................................... 4-43
Transaxle
Transaxle Operation, Automatic
......................... 2-36
Transfer Case (Power Transfer Unit)
.................. 5-50
Transmission, Transaxle, Transfer Case Unit Repair Manual
...................................... 7-10
Fluid, Automatic
........................................... 5-20
Transportation Options
...................................... 7-7
Trip Computer
................................................ 3-62
Turn and Lane-Change Signals
.......................... 3-8
Turn SignaVMultifunction Lever
........................... 3-7
Turn Signals When Towing a Trailer
.................. 4-42
Underbody Flushing Service
............................. 6-13
Underhood Fuse Block
................................... 5-100
Understanding Radio Reception
....................... 3-1 03
Uniform Tire Quality Grading ............................ 5-65
United States
................................................... 7-4
Used Replacement Wheels
.............................. 5-67
Using Cleaner on Fabric
.................................. 5-88
Using HomeLink@
........................................... 2-52
16
