234Vehicle care9. Proceed to the right side frontwheel, and repeat the procedure
in Step 8.
10. Proceed to the right side rear wheel, and repeat the procedure
in Step 8.
11. Proceed to the left side rear wheel, and repeat the procedure
in Step 8. The horn sounds twice
to indicate the sensor
identification code has been
matched to the left side rear tyre,
and the tyre pressure sensor
matching process is no longer
active.
12. Turn off the ignition.
13. Set all four tyres to the recommended air pressure level
as indicated on the tyre pressure
label.
14. Ensure the tyre loading status is set according to the selected
pressure 3 93.
Tread depth Check tread depth at regular
intervals.Tyres should be replaced for safety
reasons at a tread depth of 2-3 mm
(4 mm for winter tyres).
For safety reasons it is recommended
that the tread depth of the tyres on
one axle should not vary by more than 2 mm.
The legally permissible minimum
tread depth (1.6 mm) has been
reached when the tread has worn
down as far as one of the tread wear
indicators (TWI). Their position is
indicated by markings on the
sidewall.
If there is more wear at the front than
the rear, swap round front wheels and rear wheels periodically. Ensure that
the direction of rotation of the wheels
is the same as before.
Tyres age, even if they are not used.
We recommend tyre replacement
every 6 years.
Changing tyre and wheel
size
If tyres of a different size than those
fitted at the factory are used, it may be necessary to reprogramme the
speedometer as well as the nominal
tyre pressure and make other vehicle modifications.
After converting to a different tyre
size, have the label with tyre
pressures replaced. 3 2319 Warning
The use of unsuitable tyres or
wheels may lead to accidents and will invalidate the vehicle
operating permit.

Vehicle care235Wheel covers
Wheel covers and tyres that are
factory approved for the respective
vehicle and comply with all of the
relevant wheel and tyre combination
requirements must be used.
If the wheel covers and tyres used are
not factory approved, the tyres must
not have a rim protection ridge.
Wheel covers must not impair brake
cooling.9 Warning
Use of unsuitable tyres or wheel
covers could lead to sudden
pressure loss and thereby
accidents.
Vehicles with steel wheels: When
using locking wheel nuts, do not
attach wheel covers.
Tyre chains
Use tyre chains only on front wheels.
9 Warning
Damage may lead to tyre blowout.
4-door notchback
Always use fine mesh chains that add no more than 10 mm to the tyre tread
and the inboard sides (including chain
lock).
Tyre chains are only permitted on
tyres of size 205/60 R16 and
215/50 R17.3-door hatchback
Tyre chains are permitted on tyres of
size 225/55 R17. Always use fine
mesh chains that add no more than
10 mm to the tyre tread and the
inboard sides (including chain lock).
Tyre chains are also permitted on
tyres of size 245/45 R18. Always use
fine mesh chains that add no more
than 7 mm to the tyre tread and the inboard sides (including chain lock).OPC Version
Tyre chains are permitted on tyres of
size 235/45 R18. Always use fine
mesh chains that add no more than
10 mm to the tyre tread and the
inboard sides (including chain lock).General
The use of tyre chains is not permitted on the temporary spare wheel.
Tyre repair kit
Minor damage to the tyre tread can be
repaired with the tyre repair kit.
Do not remove foreign bodies from
the tyres.

236Vehicle careTyre damage exceeding 4 mm or thatis at the tyre's sidewall cannot be
repaired with the tyre repair kit.9 Warning
Do not drive faster than 80 km/h.
Do not use for a lengthy period.
Steering and handling may be
affected.
If you have a flat tyre:
Apply the parking brake and engage
first gear, reverse gear or P.
The tyre repair kit is in a compartment under the floor cover in the load
compartment.
The illustrations show different
versions.1. Take the tyre repair kit from the compartment.
2. Remove the compressor.
3. Remove the electrical connection cable and air hose from the
stowage compartments on the
underside of the compressor.
4. Screw the compressor air hose to
the connection on the sealant
bottle.
5. Fit the sealant bottle into the retainer on the compressor.
Set the compressor near the tyre
in such a way that the sealant
bottle is upright.

Vehicle care239Make the following preparations and
observe the following information:
● Park the vehicle on a level, firm and non-skid surface. The front
wheels must be in the straight- ahead position.
● Apply the parking brake and engage first gear, reverse gear or
P .
● Remove the spare wheel 3 242.
● Never change more than one wheel at once.
● Use the jack only to change wheels in case of puncture, not
for seasonal winter or summer
tyre change.
● The jack is maintenance-free. ● If the ground on which the vehicle
is standing is soft, a solid board
(max. 1 cm thick) should be
placed under the jack.
● Take heavy objects out of the vehicle before jacking up.
● No people or animals may be in the vehicle when it is jacked-up.
● Never crawl under a jacked-up vehicle.●Do not start the vehicle when it is
raised on the jack.
● Clean wheel nuts and thread with
a clean cloth before mounting the wheel.9 Warning
Do not grease wheel bolt, wheel
nut and wheel nut cone.
1. Disengage wheel nut caps with a
screwdriver and remove. Pull off
the wheel cover. Vehicle tools
3 227.
Alloy wheels: Disengage wheel
nut caps with a screwdriver and
remove. To protect the wheel,
place a soft cloth between the
screwdriver and the alloy wheel.Alloy wheels with centre wheel
bolt cap: Disengage centre cap by
inserting and pulling the extractor
in the recess of the brand
emblem. Vehicle tools 3 227.
2. Two types of jacks and wheel nut wrenches are possible dependingon the version. Vehicle tools
3 227.
Variant 1a with rigid wheel
wrench:

Vehicle care245
Only 3-door hatchback: position
the excentric conus in the recess
of the spare wheel before
tightening the wing nut.
5. Close floor cover and insert rear storage (only 3-door hatchback).
9 Warning
Storing a jack, a wheel or other
equipment in the load
compartment could cause injury if they are not secured properly.
During a sudden stop or a
collision, loose equipment could strike someone.
Always store jack and tools in the
respective storage compartments
and secure them by fixing.
Damaged wheel placed in the load compartment must always be
secured with the strap.
Temporary spare wheel
Caution
The use of a spare wheel that is smaller than the other wheels or in combination with winter tyres
could affect driveability. Have the defective tyre replaced as soon as
possible.
Only mount one temporary spare
wheel. Do not drive faster than
80 km/h. Take curves slowly. Do not use for a long period of time.
If your vehicle gets a flat tyre on the
rear while towing another vehicle,
mount the temporary spare wheel at
the front and the full tyre at the rear.
Tyre chains 3 235.
Spare wheel with directional tyre
Fit directional tyres such that they roll in the direction of travel. The rolling
direction is indicated by a symbol
(e.g. an arrow) on the sidewall.
The following applies to tyres fitted
opposing the rolling direction:
● Driveability may be affected. Have the defective tyre renewed
or repaired as soon as possible
and fit it instead of the spare
wheel.
● Drive particularly carefully on wet
and snow-covered road
surfaces.

246Vehicle careJump startingDo not start with quick charger.
A vehicle with a discharged vehicle
battery can be started using jump
leads and the vehicle battery of
another vehicle.9 Warning
Be extremely careful when starting
with jump leads. Any deviation
from the following instructions can
lead to injuries or damage caused
by battery explosion or damage to the electrical systems of both
vehicles.
9 Warning
Avoid contact of the battery with
eyes, skin, fabrics and painted
surfaces. The fluid contains
sulphuric acid which can cause
injuries and damage in the event
of direct contact.
● Never expose the vehicle battery
to naked flames or sparks.
● A discharged vehicle battery can already freeze at a temperature
of 0 °C. Defrost the frozen vehicle
battery before connecting jump leads.
● Wear eye protection and protective clothing when
handling a vehicle battery.
● Use a booster vehicle battery with the same voltage ( 12 Volts).
Its capacity (Ah) must not be
much less than that of the
discharged vehicle battery.
● Use jump leads with insulated terminals and a cross section of
at least 16 mm 2
(25 mm 2
for
diesel engines).
● Do not disconnect the discharged
vehicle battery from the vehicle.
● Switch off all unnecessary electrical consumers.
● Do not lean over the vehicle battery during jump starting.
● Do not allow the terminals of one
lead to touch those of the other
lead.● The vehicles must not come into contact with each other during
the jump starting process.
● Apply the parking brake, transmission in neutral,
automatic transmission in P.
● Open the positive terminal protection caps of both vehicle
batteries.
Lead connection order:
1. Connect the red lead to the positive terminal of the booster
vehicle battery.
2. Connect the other end of the red lead to the positive terminal of the
discharged vehicle battery.

254Service and maintenancepollution, presence of airborne sand
and high dust content, driving at high
altitude and large variations of
temperature. Under these severe operating conditions, certain servicework may be required more frequently than the regular service interval.
The international service intervals are
valid for the countries which are not
listed in the European service
intervals.
Service display 3 83.
Confirmations
Confirmation of service is recorded in the Service and Warranty Booklet.
The date and mileage is completed
with the stamp and signature of the
servicing workshop.
Make sure that the Service and
Warranty Booklet is completed
correctly as continuous proof of
service is essential if any warranty or goodwill claims are to be met, and is
also a benefit when selling the
vehicle.Service interval with remaining
engine oil life duration
The service interval is based on
several parameters depending on
usage.
The service display lets you know
when to change the engine oil.
Service display 3 83.Recommended fluids,
lubricants and parts
Recommended fluids andlubricants
Only use products that meet the
recommended specifications.9 Warning
Operating materials are
hazardous and could be
poisonous. Handle with care. Pay
attention to information given on
the containers.
Engine oil
Engine oil is identified by its quality
and its viscosity. Quality is more
important than viscosity when
selecting which engine oil to use. The oil quality ensures e.g. engine
cleanliness, wear protection and oil
aging control, whereas viscosity
grade gives information on the oil's
thickness over a temperature range.

289Climate control ............................. 17
Climate control systems .............129
Clock............................................. 77
Code ............................................. 99
Collision damage repair ..............284
Control indicators.......................... 84
Control of the vehicle .................140
Controls ........................................ 73
Convex shape .............................. 31
Coolant and antifreeze ...............254
Cruise control ...................... 92, 159
Cupholders .................................. 60
Curtain airbag system .................. 53
Curve lighting.............................. 120
D Danger, Warnings and Cautions ...4
Daytime running lights ...............120
Declaration of conformity ............280
Diesel fuel system bleeding .......207
Diesel particle filter ...............90, 146
Door open .................................... 93
Doors ............................................ 27
Driver assistance systems ..........159
Driver Information Centre .............93
Driving characteristics and towing tips .............................. 194
Driving hints ................................ 140E
Electric adjustment ......................31
Electrical system......................... 222
Electric parking brake ...........88, 153
Electric parking brake fault ...........89
Electronic climate control system 132
Electronic driving programmes ..149
Electronic Stability Control.......... 155
Electronic Stability Control and Traction Control system ............90
Electronic Stability Control off....... 90
End-of-life vehicle recovery .......201
Engine compartment fuse box ...223
Engine coolant ........................... 203
Engine coolant temperature gauge ....................................... 83
Engine data ............................... 262
Engine exhaust .......................... 145
Engine identification ...................258
Engine oil ................... 202, 254, 259
Engine oil pressure ......................91
Entry lighting .............................. 127
ERA GLONASS .......................... 113
Event data recorders ..................287
Exit lighting ................................ 127
Exterior care .............................. 249
Exterior light ................................. 92
Exterior lighting ....................15, 116
Exterior mirrors ............................. 31F
Fault ........................................... 150
First aid ......................................... 69
First aid kit ................................... 69
Fixed air vents ........................... 137
Fog light ....................................... 92
Fog lights ................................... 212
Folding mirrors ............................. 32
Following distance indication ......172
Forward collision alert................. 169
Front airbag system .....................52
Front fog lights ........................... 124
Front seats.................................... 41
Front storage ................................ 61
Front turn signal lights ...............214
Fuel............................................. 188
Fuel consumption - CO 2-
Emissions ............................... 193
Fuel for diesel engines ..............189
Fuel for liquid gas operation .......190
Fuel for petrol engines ...............188
Fuel gauge ................................... 81
Fuel selector ................................ 81
Fuses ......................................... 222
G Gauges ......................................... 80
General information ...................194
Glass panel .................................. 38

290Glovebox ..................................... 60
Graphic-Info-Display, Colour- Info-Display .............................. 97
H Halogen headlights ....................208
Hand brake ......................... 152, 153
Hazard warning flashers ............123
Headlight flash ........................... 118
Headlight range adjustment ......119
Headlights................................... 116 Headlights when driving abroad 119
Head restraint adjustment .............8
Head restraints ............................ 39
Heated mirrors ............................. 32
Heated rear window ..................... 36
Heated steering wheel .................73
Heating ........................................ 47
Heating and ventilation system . 129
Height adjustable rear floor cover 67
High beam ........................... 92, 118
High beam assist ..................92, 118
Hill start assist ........................... 154
Horn ....................................... 16, 74
I
Identification plate .....................257
Ignition switch positions .............141
Immobiliser ............................ 31, 92
Indicators ...................................... 80
Information displays...................... 93Instrument cluster ........................80
Instrument panel fuse box .........225
Instrument panel illumination .....221
Instrument panel illumination control .................................... 125
Instrument panel overview ........... 11
Interactive driving system ...........157
Interior care ............................... 252
Interior lighting ............................ 125
Interior lights ...................... 125, 221
Interior mirrors .............................. 33
Interruption of power supply ......150
Introduction .................................... 3
J Jump starting ............................. 246
K Key, memorised settings ..............24
Keys ............................................. 22
Keys, locks ................................... 22
L Lane departure warning .......89, 187
Lashing eyes ............................... 68
Lighting features .........................127
Light switch ................................ 116
Load compartment ................27, 64
Load compartment cover .............66
Load compartment fuse box ......226
Loading information .....................70Low fuel ....................................... 91
Low washer fluid ..........................92
LPG .............................. 81, 190, 259
M
Malfunction indicator light ............88
Manual anti-dazzle ......................33
Manual mode ............................. 149
Manual seat adjustment ...............42
Manual transmission .................. 151
Manual windows ..........................34
Memorised settings ......................24
Midlevel-Display ........................... 93
Mirror adjustment ........................... 9
Misted light covers .....................125
N New vehicle running-in ..............140
Number plate light .....................221
O
Object detection systems ...........175
Odometer ..................................... 80
Oil, engine .......................... 254, 259
OnStar ........................................ 110
Operate pedal ............................... 88
Outside temperature ....................76
Overrun cut-off ........................... 142

292Traction Control system ............. 155
Traction Control system off........... 90
Traffic sign assistant ...................183
Trailer coupling ........................... 194
Trailer stability assist .................198
Trailer towing ............................. 195
Transmission ............................... 19
Transmission display .................147
Tread depth ............................... 234
Trip computer ............................ 103
Trip odometer .............................. 80
Turn and lane-change signals ...123
Turn signal ................................... 87
Tyre chains ................................ 235
Tyre designations ......................229
Tyre pressure ............................ 229
Tyre pressure monitoring system ............................... 91, 231
Tyre pressures ........................... 271
Tyre repair kit ............................. 235
U Ultrasonic parking assist ...... 90, 175
Underseat storage .......................62
Upholstery .................................. 252
Uplevel-Combi-Display .................93
Upshift .......................................... 89
Using this manual ..........................3V
Vehicle battery ........................... 205
Vehicle checks............................ 201
Vehicle data ................................ 259
Vehicle data recording and privacy ..................................... 287
Vehicle detected ahead ................93
Vehicle dimensions .................... 269 Vehicle Identification Number ....257
Vehicle jack ................................ 227
Vehicle messages .......................99
Vehicle personalisation .............105
Vehicle security ............................ 29
Vehicle specific data ......................3
Vehicle storage ........................... 200
Vehicle tools ............................... 227
Vehicle unlocking ........................... 6 Vehicle weight ........................... 267
Ventilation ................................... 129
W
Warning chimes .........................102
Warning lights ............................... 80
Warning triangle .......................... 69
Washer and wiper systems .........17
Washer fluid ............................... 204
Wheel changing .........................238
Wheel covers ............................. 235
Wheels and tyres .......................229
Windows ....................................... 33Windscreen................................... 33
Windscreen wiper/washer ...........74
Winter tyres ............................... 229
Wiper blade replacement ..........207
